Fujitsu PRIMERGY ServerView Suite Bedienungsanleitung

PRIMERGY ServerView Suite

ServerView Remote Management Frontend

ServerView Operations Manager V4.90

Redakteur

cognitas3

81730 München

Tel.: (089) 61001-123

Fax: 0 700 / 372 00000

ServerView Remote Management Frontend

Sprachen: En

Edition June 2009

Comments…Suggestions…Corrections…

The User Documentation Department would like to

know your opinion of this manual. Your feedback helps

us optimize our documentation to suit your individual

needs.

Feel free to send us your comments by e-mail to

[email protected]ujitsu.com.

Certified documentation

according to DIN EN ISO 9001:2000

To ensure a consistently high quality standard and

user-friendliness, this documentation was created to

meet the regulations of a quality management system

which complies with the requirements of the standard

DIN EN ISO 9001:2000.

cognitas. Gesellschaft für Technik-Dokumentation mbH

www.cognitas.de

Delivery subject to availability; right of technical modifications reserved.

All hardware and software names used are trademarks of their respective manufacturers.

ServerView Remote Management Frontend

Contents

1 Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

1.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

1.2 Structure of the manual . . . . . . . . . . . . . . . . . . . . . 8

1.3 Changes since the last edition . . . . . . . . . . . . . . . . . 9

1.4 Notational conventions . . . . . . . . . . . . . . . . . . . . 10

2 Configuring the Remote Management Frontend . . . . . . . 11

2.1 Configuring multisession support, SSH access and

console redirection . . . . . . . . . . . . . . . . . . . . . . . 11

2.2 Deleting/not deleting the console area on text console

redirection after the end of a session . . . . . . . . . . . . . 13

3 Starting the Remote Management Frontend . . . . . . . . . 15

3.1 Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . 16

3.1.1 Requirements at the managed server . . . . . . . . . . . . . . 16

3.1.2 Requirements at the remote workstation . . . . . . . . . . . . 17

3.2 Starting the Remote Management Frontend via the

Operations Manager . . . . . . . . . . . . . . . . . . . . . . 18

3.2.1 Starting the Remote Management Frontend via an

iRMC/ iRMC S2 . . . . . . . . . . . . . . . . . . . . . . . . . 20

3.2.2 Starting Remote Management Frontend via an

RSB/ RSB S2/ RSB S2 LP(3HU) or a BMC . . . . . . . . . . . 25

3.2.3 Starting Remote Management Frontend via a

RemoteView Management Blade . . . . . . . . . . . . . . . . 30

ServerView Remote Management Frontend

Contents

4 Working with the ServerView Remote Management

Frontend . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

4.1 The Remote Management Frontend user interface . . . . . . 33

4.1.1 Remote Management window for Remote Manager and

Console Menu . . . . . . . . . . . . . . . . . . . . . . . . . . 34

4.1.2 Remote Management window for text console redirection

and power management . . . . . . . . . . . . . . . . . . . . . 38

4.2 Establishing a connection to the managed server . . . . . . 42

4.2.1 Establishing a connection to the iRMC/ iRMC S2,

RSB S2/ RSB S2 LP (3 HU) via Telnet/SSH (Remote Manager) . 42

4.2.2 Establishing a connection to the iRMC/ iRMC S2/BMC for

power management and console redirection . . . . . . . . . . . 49

5 Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

5.1 Password protection . . . . . . . . . . . . . . . . . . . . . . 53

5.2 Console redirection . . . . . . . . . . . . . . . . . . . . . . . 54

Related Publications . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

ServerView Remote Management Frontend 5

1 Preface

The ServerView Remote Management Frontend provides you with a web-based

working environment for the remote management of PRIMERGY servers which

is integrated in the ServerView Operations Manager. The ServerView Remote

Management Frontend is started from the ServerView Operations Manager and

the installation of this application is therefore a necessary precondition.

The ServerView Remote Management Frontend and the ServerView Opera-

tions Manager are referred to below as the Remote Management Frontend and

the Operations Manager respectively.

You simply need a standard web browser for the display at the remote

workstation. You can open a separate browser window for each PRIMERGY

server displayed in the Operations Manager ServerList window. From here, you

can then open various windows for the remote management of the corre-

sponding PRIMERGY server.

As a web-based solution, the Remote Management Frontend can be installed

on a remote workstation set up under a Windows or Linux system.

IIn the case of an individual PRIMERGY server with installed

iRMC/ iRMC S2, you can also use the Remote Management Frontend

functionality via this iRMC/ iRMC S2's web interface (See the manuals

“iRMC - integrated Remote Management Controller” and “iRMC S2 -

integrated Remote Management Controller”).

6 ServerView Remote Management Frontend

Overview Preface

1.1 Overview

The type of window displayed in the Remote Management Frontend depends,

on the one hand, on the hardware (iRMC, RSB etc.) which you use to establish

the connection to the managed server and, on the other, on the interface which

is provided in each case.

Hardware-specific displays in the Remote Management Frontend

The Remote Management Frontend's displays and controls are adapted to the

remote hardware via which you establish the connection to a managed

PRIMERGY server:

– In the case of a PRIMERGY server with an installed iRMC or iRMC S2, you

can use either the Telnet/SSH “Remote Manager” application or the

managed server's power management and console redirection window in

the Remote Management Frontend's console area.

– In the case of a PRIMERGY server with an installed RSB or RSB S2/

RSB S2 LP (as of firmware version 6.4.57.29), the Telnet “Remote

Manager” application is available to you in the Remote Management

Frontend's console area once a connection has been established.

Only in the case of RSB:

You can use the Remote Manager to redirect the display at the console of

the managed server. In this way, you can access the BIOS setup and the

RemoteView/Diagnose system tools on the managed server.

– In the case of a PRIMERGY server with an installed BMC with firmware

version 2.x or higher, the managed server's power management and

console redirection window is available in the Remote Management

Frontend's console area after the establishment of a connection.

– In the case of a blade server with a RemoteView Management Blade, the

RemoteView Management Blade Telnet “Console Menu” application is

available to you in the Remote Management Frontend's console area after

the establishment of a connection. You can use the Console Menu to redirect

the display at the consoles of the managed server blades. In this way, you

can access the BIOS setup at the managed server blade.

ServerView Remote Management Frontend 7

Preface Overview

The interface provided by the Remote Management Frontend for the

remote management of PRIMERGY servers:

Depending on the hardware available for remote management on the individual

managed servers, the Remote Management Frontend provides the following

interfaces for web-based access to the managed servers.

●Telnet-based interface (Remote Manager)

Depending on the managed PRIMERGY server, the connection may be

established via

– an iRMC/ iRMC S2 or

– an RSB/ RSB S2/ RSB S2 LP (3HU) with firmware version 6.4.57.29 or

higher.

●Telnet-based interface (Console Menu) via a RemoteView Management

Blade

●SSH-based interface (Remote Manager) via an iRMC/ iRMC S2.

●Interface for power management and console redirection (IPMI (1.5)-over-

LAN-based) via a Kalypso BMC (BMC - firmware version 2.x or higher)

●Interface for power management (IPMI (2.0)-over-LAN-based) and console

redirection (via SOL) via

– an iRMC/ iRMC S2 or

– a BMC of the RX/TX 600 S2/S3

8 ServerView Remote Management Frontend

Structure of the manual Preface

1.2 Structure of the manual

This manual provides you with information about the following topics:

–Chapter 1: Preface

This chapter provides you with a brief overview of the Remote Management

Frontend.

–Chapter 2: Configuration

This chapter describes how you can configure the basic settings of the

Remote Management Frontend depending on your requirements.

–Chapter 3: Starting the Remote Management Frontend

This chapter describes how you start the Remote Management Frontend via

the graphical user interface of the Operations Manager, the prerequisites

that must be fulfilled and the special requirements that exist depending on

the remote management hardware used in the managed server.

–Chapter 4: Working with the Remote Management Frontend

This chapter starts by explaining the structure and components of the

Remote Management Frontend user interface. It then describes how you

establish a connection to a managed server via the Remote Management

Frontend's user interface.

–Chapter 5: Security

This chapter provides a brief overview of password protection in the

Operations Manager and in the remote management hardware.

ServerView Remote Management Frontend 9

Preface Changes since the last edition

1.3 Changes since the last edition

This edition is valid for the Remote Management Frontend V4.90 and replaces

the following online manual: “Remote Management Frontend V4.80“, edition

April 2009.

10 ServerView Remote Management Frontend

Notational conventions Preface

1.4 Notational conventions

The meanings of the symbols used in this manual are as follows:

If reference is made to passages elsewhere in this manual, the title of the

chapter or section is named and the page number given refers to the start of the

section.

VWarning This symbol is used to draw attention to risks which

may represent a health hazard or which may lead

to data loss or damage to the hardware.

IThis symbol is used to highlight important infor-

mation and tips.

ÊThis symbol indicates an action which you must

carry out.

Text in italics In running text, commands, menu items, and the

names of buttons, options, files and paths are

shown in italics.

<text> Indicates variables which must be replaced by

current values.

Monospaced font Output from the system is shown in monospaced

font.

Monospaced font

Bold monospaced font

Commands to be entered at the keyboard are

shown in bold, monospaced font.

[square brackets] Indicate optional entries.

{braces} Indicate a list of alternatives separated by “|”.

[Keyboard] [symbols] Keys are shown as they appear on the keyboard. If

uppercase characters are to be entered explicitly,

this is indicated for instance by [SHIFT] - [A] for A.

If two keys are to be pressed simultaneously, this

is indicated by a hyphen between the two keyboard

symbols.

Table 1: Notational conventions

Inhaltsverzeichnis

Andere Fujitsu Server Handbücher

Fujitsu

Fujitsu PRIMERGY TX100 S2 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY TX2560 M1 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY TX100 S3 Bedienungsanleitung

Fujitsu

Fujitsu BX630 - PRIMERGY - S2 Dual Bedienungsanleitung

Fujitsu

Fujitsu PRIMEQUEST 2000 Series Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY TX1330 M3 Bedienungsanleitung

Fujitsu

Fujitsu BS2000 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY TX150 S5 Betriebsanleitung

Fujitsu

Fujitsu PRIMERGY RX900 S1 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY BX400 S1 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY TX140 S1 Bedienungsanleitung

Fujitsu

Fujitsu Primergy CX270 S2 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY RX500 S7 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY RX600 S4 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY TX200 S5 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY CX2550 M2 Bedienungsanleitung

Fujitsu

Fujitsu Primergy TX300 S4 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY CX420 S1 Benutzerhandbuch

Fujitsu

Fujitsu PRIMERGY RX2540 M4 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY TX150 S4 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY BX920 S2 Bedienungsanleitung

Fujitsu

Fujitsu BS2000 SE320 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY BX900 S1 Bedienungsanleitung

Fujitsu

Fujitsu Primergy BX920 S3 Bedienungsanleitung

Beliebte Server Handbücher anderer Marken

HP AlphaServer ES47 Bedienungsanleitung

Dell

Dell PowerEdge R410 Bedienungsanleitung

PowerNAS

PowerNAS CMA Bedienungsanleitung

Supero

Supero FatTwin F617R3-FT Bedienungsanleitung

MSI

MSI P1-109N-L70 Bedienungsanleitung

Dell

Dell PowerEdge XE9640 Handbuch

Dell

Dell PS4100 Montageanleitung

EtroVISION

EtroVISION EV3151 Bedienungsanleitung

NEC

NEC Express5800/T110j Bedienungsanleitung

HP ProLiant Gen9 Bedienungsanleitung

Compaq

Compaq ProLiant 3000 Handbuch

Dell

Dell PowerEdge 3YPMN Bedienungsanleitung

iRobo

iRobo IPC2U Bedienungsanleitung

Nortel

Nortel 1000 Con?guration guide Bedienungsanleitung

Asus

Asus AP7500 Bedienungs- und Wartungshandbuch

Avid Technology

Avid Technology AirSpeed 5000 Bedienungsanleitung

HP Integrity rx2600 Installationsanleitung

Milestone

Milestone Husky IVO 350T Bedienungsanleitung
