PRIMERGY RX200 S2 Onboard SCSI RAID User’s Guide

Areas Covered

Chapter 1 Features (Product Overview/Note)

This chapter explains the overview of the disk array and features of this product.

Chapter 2 Installation Flow and Note

This chapter explains how to install this product and points to note during installation.

Chapter 3 Installing Global Array Manager (GAM)

This chapter explains how to install Global Array Manager (GAM) to this product when

operating in the Windows Server 2003/Windows 2000/Linux environment.

Chapter 4 How to Use GAM

This chapter provides a description of Global Array Manager.

Chapter 5 Replacing a Hard Disk

This chapter explains maintenance related issues, such as hard disk replacement.

Appendix

This appendix explains supplemental items and error codes concerning this product.

Remarks

■Warning Descriptions

Various symbols are used throughout this manual. These are provided to emphasize important points

for your safety and that of others. The followings are the symbols and their meanings.

The following symbols are used to indicate the type of warning or caution being described.

■Key Descriptions / Operations

Keys are represented throughout this manual in the following manner.

E.g.: [Ctrl] key, [Enter] key, [→] key, etc.

The following indicate pressing several keys at once:

E.g.: [Ctrl] + [F3] key, [Shift] + [↑] key, etc.

■Expressions

Expressions used in this manual have the following meanings.

WARNING

Ignoring this symbol could be potentially lethal.

CAUTION

Ignoring this symbol may lead to physical injury and/or damage to the server or

hardware options.

The triangle mark emphasizes the urgency of the WARNING and CAUTION.

Details are detailed inside the triangle and above it.

A barred circle ( ) warns against certain actions (Do Not). These actions are

detailed inside the circle and above it.

A black circle indicates actions that must be taken. These actions are detailed

inside the black circle and above it.

Expression Meaning

These sections explain prohibited actions and points to note when using this

device. Make sure to read these sections.

These sections explain information needed to operate the hardware and

software properly. Make sure to read these sections.

→This mark indicates reference pages or manuals.

■Abbreviations

The following expressions and abbreviations are used throughout this manual.

■Screenshots

Screenshots provided in this manual show display examples. Display in each case may vary

depending on the type of the OS that is used.

Microsoft, Windows, and Windows Server are trademarks or registered trademarks of Microsoft

Corporation in the USA and other countries.

Global Array Manager is a trademark of LSI Logic Corporation in the USA.

Linux is a trademark or registered trademark of Linus Torvalds in the USA and other countries.

Red Hat and all Red Hat-related trademarks and logos are trademarks or registered trademarks of Red

Hat, Inc. in the USA and other countries.

Screen shot(s) reprinted with permission from Microsoft Corporation.

Product name Expressions and abbreviations

Global Array Manager™ GAM

Microsoft®Windows Server™ 2003, Standard Edition Windows Server 2003

Windows

Microsoft®Windows Server™ 2003, Enterprise Edition

Microsoft®Windows®2000 Server

Windows 2000 ServerMicrosoft®Windows®2000 Advanced Server

Microsoft®Small Business Server 2000

Red Hat®Enterprise Linux ES Linux

Contents

Chapter 1 Features (Product Overview/Note)

1.1 Disk Array . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

1.2 RAID Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

1.3 Logical Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

1.4 Rebuilding/Initializing a Logical Drive . . . . . . . . . . . . . . . . . 10

1.5 Media Verification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Chapter 2 Installation Flow and Note

2.1 Installation Flow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

2.2 Other Points to Note . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Chapter 3 Installing Global Array Manager (GAM)

3.1 Overview/ Product Requirements . . . . . . . . . . . . . . . . . . . . 18

3.1.1 Overview of Global Array Manager . . . . . . . . . . . . . . . . . . . . . . . . . . 18

3.1.2 Requirements for GAM software . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

3.2 Installing Global Array Manager (GAM) . . . . . . . . . . . . . . . . 19

3.2.1 How to Install GAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

3.2.2 Local Logon Setting on a Domain Controller . . . . . . . . . . . . . . . . . . 24

3.2.3 How to Uninstall GAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

3.3 Using GAM in a Linux Environment . . . . . . . . . . . . . . . . . . . 26

3.4 Using GAM in a Multiple Server Environment . . . . . . . . . . . 27

3.4.1 Interaction between ServerView and AlarmService . . . . . . . . . . . . . 27

Chapter 4 How to Use GAM

4.1 Overview of GAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

4.2 Starting and Exiting GAM . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

4.2.1 Starting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

4.2.2 Signing On (Logging On) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

4.2.3 Exiting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

4.3 Window Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

4.3.1 Startup Window Layout/Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

4.3.2 [Controller View] Window Layout/Functions . . . . . . . . . . . . . . . . . . . 35

4.3.3 Menu Layout/Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

4.3.4 Tool Bar Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

4.4 Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

4.4.1 Server Group and Server Settings . . . . . . . . . . . . . . . . . . . . . . . . . . 39

4.5 Viewing Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

4.5.1 Event . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

4.5.2 RAID Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

4.5.3 Viewing Hard Disk Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

4.5.4 Displaying Logical Drive Information . . . . . . . . . . . . . . . . . . . . . . . . . 45

4.5.5 Displaying Request Sense Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

4.5.6 Checking the Progress of a Rebuild . . . . . . . . . . . . . . . . . . . . . . . . . . 47

4.6 Maintenance Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

4.6.1 Rebuild . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Chapter 5 Replacing a Hard Disk

5.1 Replacing a Hard Disk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

5.2 Preventive Replacement Procedure of a Hard Disk . . . . . 51

Appendix

A RAID Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

A.1 RAID 0 (Striping) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

A.2 RAID 1 (Mirroring) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

A.3 RAID 5 (Striping + Parity) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

A.4 RAID 10 (Mirroring + Striping) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

B List of GAM Error Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Chapter 1

Features (Product Overview/

Note)

This chapter explains the overview and features of the disk

array.

1.1 Disk Array . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

1.2 RAID Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

1.3 Logical Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

1.4 Rebuilding/Initializing a Logical Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

1.5 Media Verification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

1.1 Disk Array

A disk array or Redundant Array of Independent Disks (RAID) is a system that can improve

reliability compared to a single hard disk, by using a disk controller and multiple hard disks. Access

to each hard disk is controlled by the disk controller, but different control methods are used

depending on the RAID level settings. It is also possible to give the disk redundancy so that the

system can be operated continuously without losing data even when one hard disk fails.

1.2 RAID Level

Although there are several types of RAID level, the onboard SCSI array controller for this server only

supports RAID1. The number of available hard disks, available capacity and applicability of

redundancy are shown in the table below.

Regardless of the applicability of redundancy, data backup should be performed as

frequently as possible just in case.

For more details of RAID levels, refer to "A RAID Level" (pg.54).

RAID level Number of hard disks Available capacity Redundancy

RAID1 2 Capacity of 1 hard disk Applied

Chapter 1 Features (Product Overview/Note) 9

1.3 Logical Drive

Logical Drive

A logical drive is a logical hard disk space consisting of multiple hard disk drives. It is recognized in

the same manner as a single hard disk by the OS.

In the following figure, a RAID1 disk array is created using 2 hard disks.

It is recognized by the OS as if a single hard disk is connected.

In case of RAID1, the same data is written redundantly to 2 hard disks.

Use hard disks of the same capacity and speed for Disks 1 and 2.

Logical drive has 3 types of status as follows:

• Online

Indicates that the logical drive is operating properly.

• Critical

Indicates that the logical drive is operating without redundancy due to a failure of 1 hard disk. In

this case, replace the failed hard disk as immediately as possible and perform the procedure to

recover the status to "Online" (rebuild). For more details, refer to "1.4 Rebuilding/Initializing a

Logical Drive" (pg.10).

• Offline

Indicates that the logical drive is not operating. This status occurs when 2 hard disks that compose

the logical drive fail. In this case, data in the logical drive will be lost.

In the case shown in the figure above, if Disk 1 fails for instance, the logical drive status becomes

"Critical".

For the onboard SCSI array controller for this server, only one logical drive is created.

Multiple logical drives cannot be created.

Logical drive 0

Disk 1 Disk 2

1.4 Rebuilding/Initializing a Logical Drive

In case of RAID1 logical drives, the same data is always written to 2 hard disks. When 1 hard disk

fails, the logical drive continues to operate in "Critical" status (status without redundancy) with the

other hard disk. Rebuild is the operation to recover data redundancy by copying data from a hard disk

that is running normally after replacing a failed hard disk with a new disk. The logical drive in

"Critical" status is recovered to "Online" status by performing the rebuild.

If the status of the logical drive becomes "Critical," perform a rebuild immediately to recover the

status to "Online." If the other hard disk also fails while the logical drive is in "Critical" status, it

becomes "Offline" and data in the drive will be lost.

For how to replace hard disks, refer to "5.1 Replacing a Hard Disk" (pg.50).

Initializing a Logical Drive

Immediately after creating a logical drive, data in 2 hard disks may not be the same. It is therefore

necessary to initialize the logical drive so that the data in 2 hard disks becomes identical.

The onboard SCSI array controller for this server performs a rebuild process automatically after

creating a logical drive to initialize it.

If the server is reset or turned off before completion of a rebuild process, the process is

stopped. At the next restart, the rebuild process resumes from the block where the process

stopped.

During rebuild operations, the access LED of the hard disks that compose the target logical

drive will light up. Also, the Fault LEDs of the hard disks will blink.

Time Required to Complete Rebuild

Without normal I/O access, the time required for initialization is about 6.5 hours for 73GB, about 13

hours for 147GB, and about 26 hours for 300GB, excluding power-off time.

It may take more time if initialization is executed simultaneously with normal I/O access. The time

required may differ depending on the configuration and hard disk type.

If the initialization is not completed within the specified time (about 13 hours for 73GB, about 26

hours for 147GB, about 52 hours for 300GB), please contact the maintenance person or system

administrator.

Rebuild is performed in parallel with normal I/O access operations as a background

task. Before completion of the rebuild process, I/O processing performance may be

less sufficient compared to the logical drives that have been rebuilt.

In normal operations, RAID1 logical drives maintain redundancy. Immediately after

creating the array or replacing a failed hard disk, however, they remain without

redundancy until the completion of the rebuild process.

Andere Handbücher für PRIMERGY RX200 S2

Inhaltsverzeichnis

Andere Fujitsu Server Handbücher

Fujitsu

Fujitsu SPARC ENTERPRISE T1000 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY RX2540 M6 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY MX130 S1 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY RX200 S5 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY BX900 Bedienungsanleitung

Fujitsu

Fujitsu SPARC Enterprise M3000 Bedienungsanleitung

Fujitsu

Fujitsu SPARC M12 Series Installations- und Betriebsanleitung

Fujitsu

Fujitsu PRIMERGY TX200 S6 Betriebsanleitung

Fujitsu

Fujitsu PRIMERGY TX1310 M1 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY ServerView Suite Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY BX924 S3 Bedienungsanleitung

Fujitsu

Fujitsu SPARC Enterprise M3000 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY RX2530 M4 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY RX2540 M4 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY SX940 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY RX2540 M2 Bedienungsanleitung

Fujitsu

Fujitsu Primergy RX300 S3 Bedienungsanleitung

Fujitsu

Fujitsu PRIMEQUEST 3800E2 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY TX2560 M1 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY CX2550 M1 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY ECONEL30 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY TX200 S6 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY S60 Bedienungsanleitung

Fujitsu

Fujitsu Primergy BX900 S2 Bedienungsanleitung

Beliebte Server Handbücher anderer Marken

HP AlphaServer ES47 Bedienungsanleitung

Dell

Dell PowerEdge R410 Bedienungsanleitung

PowerNAS

PowerNAS CMA Bedienungsanleitung

Supero

Supero FatTwin F617R3-FT Bedienungsanleitung

MSI

MSI P1-109N-L70 Bedienungsanleitung

Dell

Dell PowerEdge XE9640 Handbuch

Dell

Dell PS4100 Montageanleitung

EtroVISION

EtroVISION EV3151 Bedienungsanleitung

NEC

NEC Express5800/T110j Bedienungsanleitung

HP ProLiant Gen9 Bedienungsanleitung

Compaq

Compaq ProLiant 3000 Handbuch

Dell

Dell PowerEdge 3YPMN Bedienungsanleitung

iRobo

iRobo IPC2U Bedienungsanleitung

Nortel

Nortel 1000 Con?guration guide Bedienungsanleitung

Asus

Asus AP7500 Bedienungs- und Wartungshandbuch

Avid Technology

Avid Technology AirSpeed 5000 Bedienungsanleitung

HP Integrity rx2600 Installationsanleitung

Milestone

Milestone Husky IVO 350T Bedienungsanleitung
