PRIMERGY TX150 S5 Server

Operating Manual

Edition august 2006

Comments…Suggestions…Corrections…

The User Documentation Department would like to

know your opinion of this manual. Your feedback helps

us optimize our documentation to suit your individual

needs.

Fax forms for sending us your comments are included in

the back of the manual.

There you will also find the addresses of the relevant

User Documentation Department.

Certified documentation

according to DIN EN ISO 9001:2000

To ensure a consistently high quality standard and

user-friendliness, this documentation was created to

meet the regulations of a quality management system

which complies with the requirements of the standard

DIN EN ISO 9001:2000.

cognitas. Gesellschaft für Technik-Dokumentation mbH

www.cognitas.de

Delivery subject to availability; right of technical modifications reserved.

All hardware and software names used are trademarks of their respective manufacturers.

TX150 S5 Operating Manual

Contents

1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

1.1 Documentation Overview . . . . . . . . . . . . . . . . . . . . . 5

1.2 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

1.3 Notational Conventions . . . . . . . . . . . . . . . . . . . . . 13

1.4 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . 14

2 Installation Steps: Overview . . . . . . . . . . . . . . . . . 17

3 Important Information . . . . . . . . . . . . . . . . . . . . . 19

3.1 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

3.2 CE Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . 26

3.3 FCC Class A Compliance Statement . . . . . . . . . . . . . . 27

3.4 Transporting the Server . . . . . . . . . . . . . . . . . . . . . 28

3.5 Rack Installation Instructions . . . . . . . . . . . . . . . . . . 28

3.6 Environmental protection . . . . . . . . . . . . . . . . . . . . 29

4 Hardware Installation . . . . . . . . . . . . . . . . . . . . . 31

4.1 Installation Steps . . . . . . . . . . . . . . . . . . . . . . . . 32

4.2 Unpacking the Server . . . . . . . . . . . . . . . . . . . . . . 33

4.3 Setting up the floorstand model . . . . . . . . . . . . . . . . . 34

4.3.1 Fitting the Anti-Tilt Bracket . . . . . . . . . . . . . . . . . . . 35

4.4 Installing/Removing the Rack Model . . . . . . . . . . . . . . 37

4.4.1 Installation in PRIMECENTER/DataCenter Rack . . . . . . . . 42

4.4.2 Installation in Classic Rack . . . . . . . . . . . . . . . . . . . 45

4.4.3 Installation in 3rd Party Racks . . . . . . . . . . . . . . . . . . 53

4.4.4 Inserting the server . . . . . . . . . . . . . . . . . . . . . . . 54

4.5 Connecting Devices to the Server . . . . . . . . . . . . . . . . 57

4.6 Connecting the Server to the Mains . . . . . . . . . . . . . . . 58

4.7 Instructions: Connecting / Disconnecting Cables . . . . . . . . 60

5 Starting Up and Operation . . . . . . . . . . . . . . . . . . 61

5.1 Access to Drives (Floorstand Model) . . . . . . . . . . . . . . 61

5.2 Controls and Displays . . . . . . . . . . . . . . . . . . . . . . 63

5.2.1 Front of server . . . . . . . . . . . . . . . . . . . . . . . . . . 63

5.2.2 Rear of Server . . . . . . . . . . . . . . . . . . . . . . . . . . 68

5.3 Switching the Server On and Off . . . . . . . . . . . . . . . . 71

5.4 Configuring the Server . . . . . . . . . . . . . . . . . . . . . 73

5.4.1 Configuration with ServerStart . . . . . . . . . . . . . . . . . 73

5.4.2 Configuration without ServerStart . . . . . . . . . . . . . . . . 74

5.5 Cleaning the Server . . . . . . . . . . . . . . . . . . . . . . . 75

Operating Manual TX150 S5

Contents

6 Property and Data Protection . . . . . . . . . . . . . . . . . 77

6.1 Mechanical Access Protection . . . . . . . . . . . . . . . . . 77

6.2 BIOS Setup Security Functions . . . . . . . . . . . . . . . . . 77

7 Troubleshooting and Tips . . . . . . . . . . . . . . . . . . . 79

7.1 Power On Indicator Remains Unlit . . . . . . . . . . . . . . . 79

7.2 Server Switches Itself Off . . . . . . . . . . . . . . . . . . . . 80

7.3 Screen Remains Blank . . . . . . . . . . . . . . . . . . . . . 80

7.4 Flickering Stripes on Monitor Screen . . . . . . . . . . . . . . 81

7.5 No Screen Display or Display Drifts . . . . . . . . . . . . . . . 81

7.6 No Mouse Pointer Displayed on Screen . . . . . . . . . . . . . 82

7.7 Unable to Read From / Write To Floppy Disk . . . . . . . . . . 82

7.8 Incorrect Date and Time . . . . . . . . . . . . . . . . . . . . . 83

7.9 Drives Reported as “Dead” When Starting System . . . . . . . 83

7.10 Added Drive Reported as Defective . . . . . . . . . . . . . . . 84

7.11 Error Message on Screen . . . . . . . . . . . . . . . . . . . . 84

8 Hot plug components . . . . . . . . . . . . . . . . . . . . . 85

8.1 Hot-plug power supply units . . . . . . . . . . . . . . . . . . . 85

8.1.1 Replacing Hot Pluggable Power Supply Units . . . . . . . . . . 86

8.1.2 Adding a Hot Pluggable Power Supply Unit . . . . . . . . . . . 87

8.2 Hot-pluggable hard disk drives . . . . . . . . . . . . . . . . . 88

8.2.1 Handling HDD Modules . . . . . . . . . . . . . . . . . . . . . 89

8.2.2 Installing/Removing HDD/Dummy Unit . . . . . . . . . . . . . 90

Abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

Literature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107

TX150 S5 Operating Manual 5

1Introduction

The PRIMERGY TX150 S5 server is an Intel-based server for small and

medium-sized networks and can be used as a floorstand or rack model. The

floorstand model can be converted to a rack model using an optional conversion

kit.

Thanks to its highly developed hardware and software components, the

PRIMERGY TX150 S5 server offers a high level of data security and availability.

These includes hot pluggable hard disk drive modules, optional hot pluggable

power supply units, the ServerView server management software, Prefailure

Detection and Analyzing (PDA) and Automatic Server Reconfiguration and

Restart (ASR&R).

Security functions in the BIOS Setup and on the system board protect the data

on the server against manipulation. Additional security is provided by the

lockable drive cover on the floorstand model and the lockable rack door on the

rack model.

The rack model occupies 5 height units in the rack.

1.1 Documentation Overview

IPRIMERGY manuals are available in PDF format on the ServerBooks CD,

which is part of the ServerView Suite provided with each server system.

These PDF files can also be downloaded from the Internet free of

charge: At http://manuals.fujitsu-siemens.com you will find an overview

page showing the online documentation available on the Internet. You

can go to the PRIMERGY Server documentation by clicking on industry

standard servers.

6 Operating Manual TX150 S5

Documentation Overview Introduction

Concept and target group of this manual

This operating manual describes how to install, set up and operate your server.

This manual is intended for those responsible for installing the hardware and

ensuring that the system runs smoothly. The manual contains all the information

required to install and operate your PRIMERGY TX150 S5.

A knowledge of hardware and data transmission, as well as basic knowledge of

the operating system used, is necessary to fully understand the various

expansion options. You should also have a good working knowledge of the

English language.

Additional server documentation

The PRIMERGY TX150 S5 documentation also includes:

– “Quick Start Hardware - PRIMERGY TX150 S5” (leaflet)

– “Quick Start Software - PRIMERGY ServerView Suite” (leaflet)

– “Warranty” manual (print version delivered together with the system, PDF file

available on the ServerBooks CD)

– “Safety notes and other important information” manual (print version

delivered together with the system, PDF file available on the ServerBooks CD)

– “Ergonomics” manual (PDF file available on the ServerBooks CD)

– “Returning used devices” manual (PDF file available on the ServerBooks CD)

– “Helpdesk” (leaflet with worldwide helpdesk telephone numbers)

– Technical Manual for the D2399 system board (PDF file available on the

ServerBooks CD)

– “BIOS Setup” (PDF file available on the ServerBooks CD)

– “PRIMERGY TX150 S5 Options Guide” (PDF file available on the

ServerBooks CD)

IThe “Options Guide” describes the server expansion and modifi-

cation options.

– The “ServerView Suite” contains the ServerStartCD and the ServerBooksCD.

The PDF version of the “PRIMERGY ServerView Suite - ServerStart” user

manual is also available on the ServerBooks CD.

IIf you need a replacement copy of the ServerBooks CD send the

details of your server to the following e-mail address:

[email protected]

– “LSI SATA Software RAID User’s Guide” (PDF file available on

theServerBooks CD supplied)

TX150 S5 Operating Manual 7

Introduction Documentation Overview

– “LSI Logic MegaRAID SAS Software User’s Guide” (PDF file available on

theServerBooks CD supplied)

– “LSI Logic MegaRAID SAS Device Driver Installation” (PDF file available on

theServerBooks CD supplied)

– “Integrated RAID for SAS User’s Guide” (PDF file available on the

ServerBooks CD supplied)

– “Embedded SATA Software RAID for ICH7R User’s Guide” (PDF file

available on theServerBooks CD supplied)

– “ServerView RAID User Manual” (PDF file available on the ServerBooks CD)

– “Global Array Manager Client Software User’s Guide” (PDF file available on

the ServerBooks CD)

– “Global Array Manager Server Software User’s Guide” (PDF file available on

the ServerBooks CD)

– “Integrated Mirroring User’s Guide” (PDF file available on the ServerBooks

CD)

Further sources of information:

– Technical Manual for the relevant rack

– Manual for the monitor

– Manual on ServerView Server Management

– Manual for the remote testing and diagnostic system RemoteView

– Documentation for boards and drives

– Documentation for your operating system

– Information files on your operating system

(See also “Literature” on page 103.)

8 Operating Manual TX150 S5

Features Introduction

1.2 Features

System board

The features of the system board are described in the technical manual for the

system board D2399 for the hardware and in the “BIOS Setup” for the firmware

(see “Literature” on page 103).

Hard disk drives

Two versions of the server are available:

SAS server variant:

The server has a drive bay in which up to four SAS disk drive modules can be

installed. Each hard disk drive module (HDD module) can accommodate a SAS

hard disk drive with a maximum height of 1 inch. The module is connected to

the SAS backplane without cables via the SAS interface. This allows hard disk

drive modules to be easily plugged in or pulled out.

SATA server variant:

The server has a drive bay in which up to four SATA disk drive modules can be

installed. Each hard disk drive module (HDD module) can accommodate a

SATA hard disk drive with a maximum height of 1 inch. The module is connected

to the SATA backplane without cables via the SATA interface. This allows hard

disk drive modules to be easily plugged in or pulled out.

The SAS hard disk drives are either controlled by the onboard SAS controller or

by an optional PCI zero channel RAID controller. The SATA hard disk drives are

either controlled by the onboard SATA controller or by an optional PCI SATA

RAID controller. If the server has a RAID configuration, the HDD modules can

be exchanged during operation (hot plugging).

TX150 S5 Operating Manual 9

Introduction Features

Onboard SAS controller with Integrated Mirroring Enhanced functionality

An eight-channel SAS controller with “Integrated Mirroring Enhanced” (IME)

functionality is provided to operate the four hard drives. IME also provides RAID

functionality for configuration of the internal hard drives (RAID level 1, 1E).

IA separate utility is available to the controller for IME configuration. For

further information, refer to the “Integrated RAID for SAS User’s Guide”

on the ServerBooks CD (select “Controllers” from the menu).

The RAID functionality can optionally be expanded with a corresponding PCI

expansion module (zero-channel RAID controller). In addition to RAID levels 0,

1 and 10, this controller also offers the option of configuring RAID-5 or RAID-50.

The ZCR controller uses the Onboard SAS controller using logic that is specially

integrated on the system board.

Onboard SATA controller

A four-channel SATA controller is integrated on the system board; up to four

SATA hard disk drives can be connected to the controller. The LSI SATA RAID

software supports RAID levels 0, 1 and 10.

IThe controller has its own configuration utility. More detailed information

may be found in the “LSI SATA Software RAID User’s Guide” manual (on

the ServerBooks CD under “Controller”).

An eight-channel PCI SATA RAID controller can optionally be used for

increased data security and availability of the SATA server variant. The PCI

SATA RAID controller supports RAID Level 5.

IThe controller has its own configuration utility. More detailed information

may be found in the “LSI Logic MegaRAID SAS Software User’s Guide”

manual (on the ServerBooks CD under “Controller”).

10 Operating Manual TX150 S5

Features Introduction

Accessible drives

The first (top) bay contains the server's DVD drive. The fourth (bottom) bay can

be used for a 3.5” disk drive (1.44 Mbyte).

The two middle 5.25” bays are available for additional usable drives (CD/DVD

drives or a magnetic tape drive). Alternatively, these two bays can be used to

install the HDD extension box (this is only possible for the SAS server variant).

The accessible drives cannot be replaced during operation.

Power supply

With the basic configuration, the server has a fixed power supply unit. One or

two redundant hot pluggable power supply units are available as an option. If a

power supply unit is defective, in a redundant configuration the other unit

ensures that the operation can continue with no interruptions. The defective

power supply unit can be replaced during operation (hot plugging). Both power

supply unit versions automatically adjust to a mains voltage in the range

100 V - 240 V.

High level of availability and data security

When memory data is accessed, 1-bit errors in the main memory are identified

and automatically corrected with the ECC (Error Correcting Code) method.

ASR&R (Automatic Server Reconfiguration and Restart) restarts the system in

case of an error and automatically “hides” the defective system components.

The PDA (Prefailure Detection and Analyzing) technology from Fujitsu Siemens

Computers analyzes and monitors all components that are critical for system

reliability.

Optional pluggable RAID controllers support different server RAID levels and

increase the availability and data security of the system.

The hot plug compatible HDD modules provide additional protection.

Andere Handbücher für PRIMERGY TX150 S5

Inhaltsverzeichnis

Andere Fujitsu Server Handbücher

Fujitsu

Fujitsu SPARC Enterprise M9000 Bedienungsanleitung

Fujitsu

Fujitsu SPARC Enterprise M4000 Service-Handbuch

Fujitsu

Fujitsu PRIMERGY BX920 S1 Bedienungsanleitung

Fujitsu

Fujitsu SPARC M12 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY RX2530 M4 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY TX300 Bedienungsanleitung

Fujitsu

Fujitsu Primergy RX100 S4 Betriebsanleitung

Fujitsu

Fujitsu Primergy RX600 S2 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY RX1330 M3 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY CX120 S1 Betriebsanleitung

Fujitsu

Fujitsu Primergy RX100 S3 Leitfaden

Fujitsu

Fujitsu PRIMERGY TX100 S1 Bedienungsanleitung

Fujitsu

Fujitsu Primergy TX120 Bedienungsanleitung

Fujitsu

Fujitsu Primergy TX300 S4 Bedienungsanleitung

Fujitsu

Fujitsu Supercomputer PRIMEHPC FX700 Montageanleitung

Fujitsu

Fujitsu Primergy RX300 S3 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY TX140 S2 Bedienungsanleitung

Fujitsu

Fujitsu SPARC Enterprise M3000 Service-Handbuch

Fujitsu

Fujitsu PRIMERGY TX300 S7 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY BX620 S6 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY RX2540 M1 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY TX150 S8 Bedienungsanleitung

Fujitsu

Fujitsu PRIMEQUEST 2000 Series Bedienungsanleitung

Fujitsu

Fujitsu Primergy BX900 S2 Bedienungsanleitung

Beliebte Server Handbücher anderer Marken

HP AlphaServer ES47 Bedienungsanleitung

Dell

Dell PowerEdge R410 Bedienungsanleitung

PowerNAS

PowerNAS CMA Bedienungsanleitung

Supero

Supero FatTwin F617R3-FT Bedienungsanleitung

MSI

MSI P1-109N-L70 Bedienungsanleitung

Dell

Dell PowerEdge XE9640 Handbuch

Dell

Dell PS4100 Montageanleitung

EtroVISION

EtroVISION EV3151 Bedienungsanleitung

NEC

NEC Express5800/T110j Bedienungsanleitung

HP ProLiant Gen9 Bedienungsanleitung

Compaq

Compaq ProLiant 3000 Handbuch

Dell

Dell PowerEdge 3YPMN Bedienungsanleitung

iRobo

iRobo IPC2U Bedienungsanleitung

Nortel

Nortel 1000 Con?guration guide Bedienungsanleitung

Asus

Asus AP7500 Bedienungs- und Wartungshandbuch

Avid Technology

Avid Technology AirSpeed 5000 Bedienungsanleitung

HP Integrity rx2600 Installationsanleitung

Milestone

Milestone Husky IVO 350T Bedienungsanleitung
