Fujitsu PRIMERGY TX200 S2 Bedienungsanleitung

PRIMERGY

PRIMERGY TX200 S2

Server System

Options Guide

Susanne Däschlein

Fujitsu Siemens Computers GmbH München

81730 München

e-mail: email: [email protected]

Tel.: (089) 61001155

Fax: (++49) 700 / 372 00000

U41593-J-Z156-2-76

Sprachen: En

Edition February 2006

Comments Suggestions Corrections

The User Documentation Department would like to

know your opinion of this manual. Your feedback helps

us optimize our documentation to suit your individual

needs.

Fax forms for sending us your comments are included in

the back of the manual.

There you will also find the addresses of the relevant

User Documentation Department.

Certified documentation

according to DIN EN ISO 9001:2000

To ensure a consistently high quality standard and

user-friendliness, this documentation was created to

meet the regulations of a quality management system

which complies with the requirements of the standard

DIN EN ISO 9001:2000.

cognitas. Gesellschaft für Technik-Dokumentation mbH

www.cognitas.de

Delivery subject to availability; right of technical modifications reserved.

All hardware and software names used are trademarks of their respective manufacturers.

U41593-J-Z156-2-76 Options Guide

Contents

1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

1.1 Overview of the documentation . . . . . . . . . . . . . . . . . . 5

1.2 Extensions and conversions . . . . . . . . . . . . . . . . . . . . 6

1.3 Notational conventions . . . . . . . . . . . . . . . . . . . . . . 9

2 Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

3 Safety notes . . . . . . . . . . . . . . . . . . . . . . . . . . 13

4 Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

4.1 Floorstand model . . . . . . . . . . . . . . . . . . . . . . . . 19

4.1.1 Opening the server . . . . . . . . . . . . . . . . . . . . . . . 19

4.1.2 Removing the front cover . . . . . . . . . . . . . . . . . . . . 20

4.2 Rack model . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

4.2.1 Opening the server . . . . . . . . . . . . . . . . . . . . . . . 23

4.2.2 Removing the rack front cover . . . . . . . . . . . . . . . . . . 26

5 Main memory . . . . . . . . . . . . . . . . . . . . . . . . . . 27

5.1 Equipping rules . . . . . . . . . . . . . . . . . . . . . . . . . 27

5.2 Extending/replacing the main memory . . . . . . . . . . . . . 28

6 Processors . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

6.1 Installing a second processor . . . . . . . . . . . . . . . . . . 31

6.2 Replacing the processor . . . . . . . . . . . . . . . . . . . . 40

6.3 Replacing the heat sink . . . . . . . . . . . . . . . . . . . . . 43

7 Accessible drives . . . . . . . . . . . . . . . . . . . . . . . 45

7.1 Installing a slim line CD/DVD-ROM drive . . . . . . . . . . . . 45

7.2 Installing an accessible 5.25-inch drive . . . . . . . . . . . . . 48

7.3 Installing the hard disks extension box . . . . . . . . . . . . . 53

8 Controller in the PCI slots . . . . . . . . . . . . . . . . . . . 57

8.1 Installing a controller (PCI slots 1-4) . . . . . . . . . . . . . . 58

8.2 Installing a controller (PCI slot 5) . . . . . . . . . . . . . . . . 60

8.3 PCI slot assembling . . . . . . . . . . . . . . . . . . . . . . . 64

9 RemoteView components . . . . . . . . . . . . . . . . . . . 67

9.1 Installing the chipDISK . . . . . . . . . . . . . . . . . . . . . 67

9.2 RemoteView Service Board S2 LP . . . . . . . . . . . . . . . 68

10 External SCSI interface . . . . . . . . . . . . . . . . . . . . 71

10.1 Installing the external SCSI interface . . . . . . . . . . . . . . 71

Options Guide U41593-J-Z156-2-76

Contents

11 Parallel interface for printers . . . . . . . . . . . . . . . . . 73

11.1 Installing a parallel interface . . . . . . . . . . . . . . . . . . . 73

12 Upgrading to redundant system fans . . . . . . . . . . . . 77

13 Conversion standard PS to hot-plug PS . . . . . . . . . . . 83

14 Converting from the floorstand model to the rack model . . 93

15 Completion . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

15.1 Floorstand model . . . . . . . . . . . . . . . . . . . . . . . . 97

15.1.1 Attaching the front cover . . . . . . . . . . . . . . . . . . . . 97

15.1.2 Closing the server . . . . . . . . . . . . . . . . . . . . . . . . 99

15.2 Rack model . . . . . . . . . . . . . . . . . . . . . . . . . . . 101

15.2.1 Attaching the rack front cover . . . . . . . . . . . . . . . . . . 101

15.2.2 Closing the server . . . . . . . . . . . . . . . . . . . . . . . . 102

16 Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105

16.1 Cabling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105

16.2 SCSI configurations . . . . . . . . . . . . . . . . . . . . . . . 111

Abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115

Related publications . . . . . . . . . . . . . . . . . . . . . . . . . . . 121

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123

U41593-J-Z156-2-76 Options Guide 5

1Introduction

The PRIMERGY TX200 S2 Server is an Intel-based server for medium-sized

networks and large companies. The server is suitable for use as a file server as

well as an application, information, or Internet server. It is available as a floor-

stand or rack model. The floorstand model can be converted to a rack model

using an optional conversion kit.

1.1 Overview of the documentation

IPRIMERGY manuals are available in PDF format on the ServerBooks CD

which is supplied in the ServerView Suite package for every server system.

These PDF files can also be downloaded free of charge from the

Internet: at http://manuals.fujitsu-siemens.com you will find an overview

page with the online documentation available on the Internet. You can go

to the PRIMERGY Server documentation by clicking on industry standard

servers.

Concept and target groups

This Options Guide shows you how you can expand and upgrade the server.

IThe Operating Manual for the server describes how you install/remove

the hot-plug components.

The activities described in this manual may only be performed by technical

specialists.

Additional documentation about the server

The PRIMERGY TX200 S2 documentation comprises the following additional

manuals:

– The “Safety” manual (printed copy always supplied with the server, and

available as a PDF file on the ServerBooks CD supplied)

– The “Guarantee” manual (printed copy always supplied with the server, and

available as a PDF file on the ServerBooks CD supplied)

– The “Returning used devices” manual (PDF file available on the ServerBooks

CD)

6 Options Guide U41593-J-Z156-2-76

Extensions and conversions Introduction

– The Operating Manual for PRIMERGY TX200 S2 (PDF available on the

ServerBooks CD supplied)

– The Technical Manual for the system board D1919 (PDF available on the

ServerBooks CD supplied)

– The “BIOS Setup” manual (PDF available on the ServerBooks CD supplied)

– The “PRIMERGY ServerView Suite - ServerStart” manual (printed copy

always supplied with the server, and available as PDF file on the ServerBooks

CD supplied)

– The “Global Array Manager Client Software User’s Guide” (PDF available on

the ServerBooks CD supplied)

– The “Integrated Mirroring User’s Guide” (PDF available on the ServerBooks

CD supplied)

IYou can order a supplementary ServerBooks CD by sending an e-mail to

the following address, quoting your server data:

Reklamat-PC-LO[email protected]

Further sources of information:

– Technical Manual on the relevant rack

– Manual on the monitor

– Manual on ServerView Server Management

– Manual on the RemoteView Remote Test and Diagnostics System

– Documentation on boards and drives

– Documentation on your operating system

– Information files on your operating system

(see also “Related publications” on page 121)

1.2 Extensions and conversions

Second processor

The system board can be upgraded with a second processor. Only processors

of the same type may be used on the system board. The second processor must

have at least the same clock frequency as the first processor.

U41593-J-Z156-2-76 Options Guide 7

Introduction Extensions and conversions

Extension of the main memory

The six slots for the main memory are suitable for PC2-3200 DDR DIMM

memory modules. The organization in three memory banks, 0 to 2, permits

rapid memory access with two-way interleaving.

Memory modules must always be incorporated in pairs. A memory bank must

always be equipped fully with the same type of memory modules.

Additional accessible drives

Two free 5.25-inch bays are available for accessible drives.

The third 5.25-inch bay offers a 5.25-inch slim line and a 5.25-inch bay. The

5.25-inch bay is occupied by a 3.5-inch x 1-inch floppy disk drive.

Hard disks extension box

The two free 5.25-inch bays for accessible drives can be used to integrate a

hard disks extension box.

The hard disks extension box enables up to three additional HDD modules to be

integrated. Each HDD module can accommodate a SCSI hard disk drive with

an SCA (Single Connector Attachment) interface and a height of at most 1 inch.

The connection to the SCSI backplane is made without cables via the SCA

interface. This makes it simple to plug in or pull out the HDD modules. If the

server has a RAID controller and the corresponding RAID configuration,

defective HDD modules can also be replaced while the system is operating.

Additional controllers in the PCI slots

The system board offers five PCI slots. The bus frequency of PCI slot 5 is

33 MHz, of the PCI slots 3 and 4 100 MHz/133 MHz and of the PCI slots 1

and 2 66 MHz.

The hardware of the system board optimizes the speed of the PCI bus (IOOP™)

for PCI slots 3 and 4, depending on how the slots are equipped. If only one of

this two slots is occupied, the PCI bus speed is 133 MHz. For all other

equipment variants the PCI bus speed is 100 MHz.

The PCI slot 1(blue socket) is prepared for Zero Channel RAID (ZCR).

8 Options Guide U41593-J-Z156-2-76

Extensions and conversions Introduction

RemoteView

RemoteView provides you with a comprehensive test and diagnostics package.

The test and diagnostics software is stored on a chipDISK. The chipDISK is a

memory component with an IDE interface. In the event of a fault the test and

diagnostics software is automatically loaded from the chipDISK and executed.

RemoteView Service Board S2 LP

The RemoteView Service Board S2 LP (RSB S2 LP) is a PCI board with a

completely independent system, i.e. it has its own operating system with Web

server and SNMP agents and can optionally be equipped with an external

power supply. The RSB S2 LP is inserted into PCI slot 5 and connected to the

system board via a power and a data cable. The RSB S2 LP permits remote

diagnosis for system analysis, remote system configuration and remote restart

even in the event of operating system failure or hardware faults. It has its own

LAN connection and its own COM port. All the functions of the RSB S2 LP are

thus available either via a LAN or modem.

External SCSI interface

If the internal hard disks are connected via a PCI RAID controller, one channel

of the on-board controller can also be made available for connecting peripheral

cabinets via an external SCSI interface.

Parallel interface for printers

As an option, a parallel interface can be provided for printers.

Upgrading to redundant system fans

The two system fans can be upgraded to four system fans. If four system fans

are installed, the fans are operating in a redundant configuration. A defective

system fan can be replaced during the next service.

Conversion standard power supply to hot-plug power supply

The standard power supply can be replaced by a hot-plug power supply. The

hot-plug power supply consists of two power supply modules.

If one power supply module fails, the other power supply module guarantees the

unrestricted operation and the defective power supply module can be replaced

be replaced while the system is operating (hot-plug).

U41593-J-Z156-2-76 Options Guide 9

Introduction Notational conventions

Conversion of the floorstand model to a rack model

The floorstand model can optionally be converted so that the server can be

integrated into the common rack systems.

1.3 Notational conventions

The following notational conventions are used in this manual:

Text in italics indicates commands, menu items or software programs.

„Quotation marks“ indicate names of chapters and terms that are being

emphasized.

Êdescribes activities that must be performed in the order

shown.

VCAUTION! pay particular attention to texts marked with this symbol.

Failure to observe this warning may endanger your life,

destroy the system or lead to the loss of data.

Iindicates additional information, notes and tips.

Table 1: Notational conventions

Andere Handbücher für PRIMERGY TX200 S2

Inhaltsverzeichnis

Andere Fujitsu Server Handbücher

Fujitsu

Fujitsu PRIMERGY TX300 S5 Betriebsanleitung

Fujitsu

Fujitsu SPARC Enterprise M5000 Installationsanleitung

Fujitsu

Fujitsu PRIMERGY BX400 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY TX2560 M1 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY RX2520 M5 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY RX2530 M4 Bedienungsanleitung

Fujitsu

Fujitsu Primergy BX2560 M1 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY BX600 Bedienungsanleitung

Fujitsu

Fujitsu SPARC Enterprise M4000 Handbuch

Fujitsu

Fujitsu SPARC Enterprise T5120 Bedienungsanleitung

Fujitsu

Fujitsu SPARC Enterprise T5120 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY RX220 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY RX200 S3 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY RX2540 M1 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY TX100 S3 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY RX600 S3 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY RX600 S5 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY TX2550 M5 Bedienungsanleitung

Fujitsu

Fujitsu Primergy RX4770 M1 Bedienungsanleitung

Fujitsu

Fujitsu Supercomputer PRIMEHPC FX700 Montageanleitung

Fujitsu

Fujitsu PRIMERGY RX100 S7 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY MX130 S2 Upgrade and maintenance... Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY SX940 Bedienungsanleitung

Fujitsu

Fujitsu PRIMERGY TX120 S2 Betriebsanleitung

Beliebte Server Handbücher anderer Marken

HP AlphaServer ES47 Bedienungsanleitung

Dell

Dell PowerEdge R410 Bedienungsanleitung

PowerNAS

PowerNAS CMA Bedienungsanleitung

Supero

Supero FatTwin F617R3-FT Bedienungsanleitung

MSI

MSI P1-109N-L70 Bedienungsanleitung

Dell

Dell PowerEdge XE9640 Handbuch

Dell

Dell PS4100 Montageanleitung

EtroVISION

EtroVISION EV3151 Bedienungsanleitung

NEC

NEC Express5800/T110j Bedienungsanleitung

HP ProLiant Gen9 Bedienungsanleitung

Compaq

Compaq ProLiant 3000 Handbuch

Dell

Dell PowerEdge 3YPMN Bedienungsanleitung

iRobo

iRobo IPC2U Bedienungsanleitung

Nortel

Nortel 1000 Con?guration guide Bedienungsanleitung

Asus

Asus AP7500 Bedienungs- und Wartungshandbuch

Avid Technology

Avid Technology AirSpeed 5000 Bedienungsanleitung

HP Integrity rx2600 Installationsanleitung

Milestone

Milestone Husky IVO 350T Bedienungsanleitung
