Universal Remote

Instruction Manual

24912

Congratulations on your purchase of the 24912

Universal Remote Control. The 24912 is one of the

most easy to use remote controls available today.

With the 24912, juggling multiple remote controls

is a thing of the past! Your 24912 controls up to

three devices, including the most popular brands

of TV, DVD, DVR, CBL, and SAT. The 24912 is

easy to use, easy to program, and it gives you total

control—at the touch of your ngertips!

Note: Some functions from your original remote

may not be controlled by this remote. Use the

original remote, if available, to control such

functions. Sometimes buttons other than described

in these instructions may actually perform the

function. For example, the CHAN and VOL

buttons might be used to navigate through menu

choices. We recommend you experiment with the

remote to identify if such situations pertain to your

equipment.

Introduction............................................................ 3

Setup ..................................................................... 3

Battery Installation............................................ 3

Battery Saver.................................................... 3

Code Saver ...................................................... 3

Code Setup ...................................................... 3

Button Functions.................................................... 4

Direct Code Entry .................................................. 6

Code Search.......................................................... 7

Using Your Remote................................................ 8

Code Identication............................................ 8

Using SHIFT for Menu and Navigation............. 9

Controlling Devices with Separate

Power On and Off........................................... 10

Controlling Combo Devices............................ 10

DVD/DVR Punch-Through ............................. 10

Volume/Mute Control and Punch-Through ..... 11

Setting All Volume/Mute Control

to any one Mode............................................. 11

Setting any Mode for its own

Volume/Mute Control...................................... 12

Troubleshooting................................................... 13

Table of Contents

Battery Installation

1. On the back of the remote, push down on the

tab and lift the cover off.

2. Match the batteries to the + and - marks inside

the battery case, then insert 2 AAA Alkaline

batteries.

3. Press the battery cover back into place.

Battery Saver

Your remote automatically turns off if the buttons

are depressed more than 30 seconds. This will

save your batteries should your remote get stuck in

a place where the buttons remain depressed (e.g.,

between the sofa cushions).

Code Saver

You will have up to 10 minutes to change the

batteries in your remote without losing codes you

have programmed. However, do not press any

buttons until batteries are installed in the remote.

If buttons are pressed without batteries in the

remote, all codes will be lost.

Code Setup

The SETUP button is used to setup the remote.

You can either setup the remote using the code

tables (on separate sheet), or you can search

through the library of codes until you nd a code

that works for your product. Please refer to “ Code

Search” on page 7 for more information on using

the code search feature to learn how to search

through the library of codes for your products.

NOTE: You can store any kind of code under any

mode (except TV). I.e., you can store a DVR code

under the CBL/SAT button, or a Cable code under

the DVD/DVR button, etc. However, you can only

store TV codes under the TV button.

Setup

INPUT

For some TVs, press repeatedly

to select from available viewing

sources (antenna, cable box,

DVR, etc.).

RECORD, PLAY, STOP,

REW, FF, PAUSE DVR

control buttons operate

your DVR even when the

remote is set to operate

the TV. Also operates DVD

Scan -/+. Note the DVR

buttons also control DVD

when in DVD Mode.

Some buttons on the remote might have functions that

are referred to by different names on the device you

are controlling. E.g., PREV.CH may be called RECALL,

or ENTER may be called DISPLAY. These differences

depend on the brand and model of your product. Also,

this remote can only operate features that exist on your

product. E.g., your product must have PREV.CH ability

for the PREV.CH button to operate this feature.

TV, CBL/SAT, DVD/DVR

Selects product to be

operated.

Red Indicator

Lights when any

button is pressed.

Button Functions

INFO button brings up DVD

Display or Control Menu for

Chapter/Track/Title number,

Time remaining/elapsed,

system information, etc. Also

displays on-screen channel

information.

MENU Press and release

SHIFT/SETUP then MENU/

INFO to display the Menu on

the TV. See “Using SHIFT

for Menu and Navigation”

description on Page 9 for

more information.

DOT: Used to select digital

channels, e.g., 2.3.

VOLUME UP/DOWN

Changes the volume

level of the product,

normally the TV.

NUMBERS

Enter numbers for direct

channel selection. Some

products require ENTER to

be pressed after channel

selection.

ON-OFF Turns

product On or Off.

CHANNEL Up/Down

Changes the channels.

Button Functions, cont.

SETUP Used to setup the remote,

and for code search function.

SHIFT Press and release to access buttons

labeled in reverse print (OK, MENU, EXIT).

See “Using SHIFT for Menu and Navigation”

description on Page 9

for more information.

Note: The REC button must be pressed TWICE to record

from your DVR. For some brands of DVRs, you might

need to press the REC button once, then press it again

for three seconds.

ENTER

For some TV models,

used after direct

channel number

entry to immediately

change to the selected

channel.

MUTE Turns off the

TV sound while the

picture remains.

OK Selects menu

items for the device

you are controlling.

PREV.CH Returns to

the previously selected

channel.

EXIT Exits On-Screen Menus

and/or Returns to previous On-

Screen selection.

Write your codes down here for easy reference

later.

Direct Code Entry

1. Press and hold the SETUP button until

the red indicator stays on, then release

the SETUP button.

2. Press and release the desired device

button (TV,DVR, etc.). The red indicator

blinks, then stays lit.

3. Enter the 4-digit code

from the code tables

(on separate sheet).

Note: after a valid

code entry, the red

indicator turns off. For

an invalid code, the

red indicator ashes.

4. With your device on, press ON/OFF.

If the device turns off, no further

programming is required. Note: If

some buttons do not operate your

equipment, try one of the other

codes for your brand.

Device Device stored Code

TV TV

CBL/SAT

DVD/DVR

Code Search

If your device does not respond after you have

tried all the codes for your brand, or if your brand is

not listed, try searching for your code by following

these steps.

1. Manually turn on the device (TV, DVR, etc.) to

be controlled.

2. Press and hold the SETUP button

until the red indicator stays on, then

release the SETUP button.

3. Press and quickly release the desired

device button (TV, DVR, etc.). The red

indicator blinks off once.

4. Press the ON-OFF button repeatedly

(up to 300 times) until the device

to be controlled turns off. The red

indicator blinks off with each button

press.

Most users will store DVR codes under the DVR

button, Cable codes under CABLE, etc. If (for

example) you want to store a DVR code under

CABLE, rst follow the procedure for Direct Code

Entry (previous page) and press CABLE in step 2

of Direct Code Entry, then enter ANY DVR code in

step 3 of Direct Code Entry. Then follow the steps

above for Code Search.

Note: Code Search starts from the currently

stored 4-digit number under that mode. Sometimes

the rst code that “works” with your device may

only allow limited functionality (e.g., the MENU

button might not work). There may be a code

that performs more functions. Continue the code

search process until the best code is found.

5. Press and release ENTER to install the

code.

Using Your Remote

Code Identication

The Code Identication Feature allows you to

identify the 4-digit library code stored under your

device button. For example, if you want to nd out

what 4-digit code is stored under your TV device

button, follow the six steps below:

1. Press and hold the SETUP button until

the red indicator stays on. Release the

SETUP button.

2. Press and release the desired

device button (TV, DVR, etc.). The

red indicator blinks, then stays lit.

3. Press and release the SETUP button.

The red indicator blinks once and

remains lit.

4. To nd the rst digit

for the code stored

under the device

button pressed in step

2, press each numeric

button from 0-9 in

turn. The number that

causes the indicator

light to blink is the rst

digit in your code.

5. To nd the second digit, repeat step 4, this

time when the red indicator blinks off this is the

second digit.

6. Repeat step 4 to nd the third and fourth digits.

Using Your Remote, cont.

MENU/INFO.

For OK, press and release SHIFT/

SETUP then OK/MUTE.

For EXIT, press and release

SHIFT/SETUP then PREV.CH/

EXIT.

For Up, Down, Left or Right

Navigation, press and release SHIFT/

SETUP followed by the respective

Channel or Volume button.

Using SHIFT for Menu and Navigation

The SHIFT button allows access to more than one

function for certain buttons.

Use the SHIFT/SETUP button prior to accessing

the MENU, OK, EXIT and Navigation functions, for

example:

For MENU, press and release SHIFT/SETUP then

Using Your Remote, cont.

Controlling Devices with Separate

Power On and Off Buttons

Some GE, RCA and ProScan models require

you to press the device button for more than one

second to turn the device on and the ON•OFF

button to turn the device off.

Controlling Combo Devices

Some Combo devices (e.g., TV/DVR, TV/DVD,

DVR/DVD, etc.) will require you to set up two

different Mode buttons to control both parts of the

Combo device. For example, if you have a TV/

DVD Combo, you might need to set up one code

under the TV button to control the TV part AND a

separate code (under any other Mode button) to

control the DVD part.

DVR/DVD Punch-Through

This remote allows the 6 DVR transport buttons

(i.e., PLAY, PAUSE, STOP, FF, REWIND, and

REC) to Punch-Through control from any Mode

programmed with TV, SAT or Cable codes to the

last DVR, or DVD programmed Mode you used.

This feature will not operate if the programmed

TV, SAT or Cable code has its own DVR transport

button control, e.g., a TV Combo, DVR/SAT, etc.

Inhaltsverzeichnis

Andere GE Universalfernbedienung Handbücher

Beliebte Universalfernbedienung Handbücher anderer Marken

Pronto

Pronto Peel Bedienungsanleitung

Radio Shack

Radio Shack Wireless Remote Control System Bedienungsanleitung

AUVIO

AUVIO Universal Home Theater Remote Bedienungsanleitung

Philips

Philips Icon SRU4106 Bedienungsanleitung

THOMSON

THOMSON ROC4309 Bedienungsanleitung

Philips

Philips pm625S Bedienungsanleitung

RCA

RCA RCU600WMS - Universal Remote Control Bedienungsanleitung

Blackweb

Blackweb BWB17AV002 Bedienungsanleitung

Marmitek

Marmitek DoorGuard 300 Bedienungsanleitung

Chunghop

Chunghop RM-L618 Bedienungsanleitung

Anderic

Anderic KTN828 Bedienungsanleitung

Sunwave Tech.

Sunwave Tech. Touch Screen Remote Control Bedienungsanleitung

Medion

Medion E74023 Bedienungsanleitung

intensity

intensity RM02A Bedienungsanleitung

Sky

Sky MY Bedienungsanleitung

RCA

RCA RCU600M - Universal Remote Control Bedienungsanleitung

Savant

Savant SUR-0500 Kurzanleitung

GDI

GDI GDI-WT2K Bedienungsanleitung
