Gefen DVI-1500HD Bedienungsanleitung

Audio

Embedder

3GSDI

Release A7

User Manual

EXT-DVI-1500HD

DVI 1500HD

Important Safety Instructions

GENERAL SAFETY INFORMATION

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this product near water.

6. Clean only with a dry cloth.

7. Do not block any ventilation openings. Install in accordance with the manufacturer’s

instructions.

8. Do not install or place this product near any heat sources such as radiators, heat

registers, stoves, or other apparatus (including ampliers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized

plug has two blades with one wider than the other. A grounding type plug has two

blades and a third grounding prong. The wide blade or the third prong are provided for

your safety. If the provided plug does not t into your outlet, consult an electrician for

replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs,

convenience receptacles, and the point where they exit from the apparatus.

11. Only use attachments/accessories specied by the manufacturer.

12. To reduce the risk of electric shock and/or damage to this product, never handle or

touch this unit or power cord if your hands are wet or damp. Do not expose this

product to rain or moisture.

13. Unplug this apparatus during lightning storms or when unused for long periods of time.

14. Refer all servicing to qualied service personnel. Servicing is required when the

apparatus has been damaged in any way, such as power-supply cord or plug is

damaged, liquid has been spilled or objects have fallen into the apparatus,

the apparatus has been exposed to rain or moisture, does not operate normally,

or has been dropped.

15. Batteries that may be included with this product and/or accessories should never be

exposed to open ame or excessive heat. Always dispose of used batteries

according to the instructions.

DVI 1500HD

Warranty Information

Gefen warrants the equipment it manufactures to be free from defects in material and

workmanship.

If equipment fails because of such defects and Gefen is notied within two (2) years from

the date of shipment, Gefen will, at its option, repair or replace the equipment, provided

that the equipment has not been subjected to mechanical, electrical, or other abuse or

modications. Equipment that fails under conditions other than those covered will be

repaired at the current price of parts and labor in effect at the time of repair. Such repairs

are warranted for ninety (90) days from the day of reshipment to the Buyer.

This warranty is in lieu of all other warranties expressed or implied, including without

limitation, any implied warranty or merchantability or tness for any particular purpose, all of

which are expressly disclaimed.

1. Proof of sale may be required in order to claim warranty.

2. Customers outside the US are responsible for shipping charges to and from Gefen.

3. Copper cables are limited to a 30 day warranty and cables must be in their original

condition.

The information in this manual has been carefully checked and is believed to be accurate.

However, Gefen assumes no responsibility for any inaccuracies that may be contained

in this manual. In no event will Gefen be liable for direct, indirect, special, incidental, or

consequential damages resulting from any defect or omission in this manual, even if

advised of the possibility of such damages. The technical information contained herein

regarding the features and specications is subject to change without notice.

For the latest warranty coverage information, refer to the Warranty and Return Policy under

the Support section of the Gefen Web site at www.gefen.com.

PRODUCT REGISTRATION

Please register your product online by visiting the Register Product page under the

Support section of the Gefen Web site.

iii

DVI 1500HD

Gefen, LLC

c/o Customer Service

20600 Nordhoff St.

Chatsworth, CA 91311

Telephone: (818) 772-9100

(800) 545-6900

Fax: (818) 772-9120

Email: [email protected]

Visit us on the Web: www.gefen.com

Technical Support Hours: 8:00 AM to 5:00 PM Monday - Friday, Pacic Time

DVI 1500HD is a trademark of Gefen, LLC.

Important Notice

Gefen, LLC reserves the right to make changes in the hardware, packaging, and any

accompanying documentation without prior written notice.

All trademarks are the property of their respective owners.

Contacting Gefen Technical Support

3GSDI Audio Embedder

• 50 or 62.5 micron multimode ber optic cable is required for operation of the

DVI 1500HD.

• Maximum extension range of 330 feet (100 meters) when the source requires HDCP.

One CAT-5, CAT-5e or CAT6 cable is used to transmit DDC and HDCP data back to

the source.

• Maximum range of 1650 feet (500 meters) when the source does not require HDCP.

This scenario does not require the CAT-5, CAT5e or CAT-6 cable if the source does

not require DDC information. If DDC is required, the use of an EDID storage device

(Gefen part no. EXT-DVI-EDIDN or EXT-DVI-EDIDP) can be used to transmit DDC

information back to the source.

• Compatible with all DVI and HDMI (when used with a HDMI-to-DVI adapter) displays.

Operating Notes

DVI 1500HD

Features

• Extends any DVI device without HDCP up to 1650 feet (500 meters)

• Extends any DVI device with HDCP up to 330 feet (100 meters) (requires additional

CAT-5e cable)

• Supports resolutions up to 1920 x 1200

• Uses a four-strand multimode LC-LC ber optic cable

• Uses one CAT-5e cable for DDC and control signals

• Eliminates computer noise at your workstation

• Supports DDWG standard for DVI-compliant monitors

• HDCP compliant (maximum distance is 330 feet with HDCP)

• Rack-mountable

Packing List

The DVI 1500HD ships with the items listed below. If any of these items are not present in

your box when you rst open it, immediately contact your dealer or Gefen.

• 1 x DVI 1500S Sender Unit

• 1 x DVI 1500R Receiver Unit

• 2 x 5V DC Power Supply with locking connector

• 1 x 6 ft. DVI cable (M-M)

• 2 x Sets of Rack Ears

• 1 x Quick-Start Guide

DVI 1500HD

Features and Packing List

1080P

3GSDI Audio EmbedderDVI 1500HD

Table of Contents

viii

01 Getting Started

Sender Unit ........................................................................................................... 2

Sender - Front Panel..................................................................................... 2

Sender - Back Panel ..................................................................................... 3

Receiver Unit......................................................................................................... 4

Receiver - Front Panel .................................................................................. 4

Receiver - Back Panel................................................................................... 5

Installation ............................................................................................................. 6

Connecting the DVI 1500HD......................................................................... 6

Sample Wiring Diagram ................................................................................ 6

02 Appendix

Network Cable Diagram ...................................................................................... 10

Rack Tray Installation ...........................................................................................11

Specications ...................................................................................................... 12
