Gefen EXT-COMPAUD-141 Bedienungsanleitung
www.gefen.com
®
Component
w/Audio Extender
EXT-COMPAUD-141
USER MANUAL
Technical Support:
Telephone (818) 772-9100
(800) 545-6900
Fax (818) 772-9120
Technical Support Hours:
8:00 AM to 5:00 PM Monday thru Friday PST
Write To:
Gefen Inc.
C/O Customer Service
20600 Nordhoff St
Chatsworth, CA 91311
www.gefen.com
Notice
Gefen Inc. reserves the right to make changes in the hardware, packaging and any
accompanying documentation without prior written notice.
Component w/ Audio Extender is a trademark of Gefen Inc.
© 2009 Gefen Inc., All Rights Reserved
ASKING FOR ASSISTANCE
All trademarks are the property of their respective companies.
Rev X2
TABLE OF CONTENTS
INTRODUCTION / HOW IT WORKS / OPERATION NOTES
FEATURES
PANEL DESCRIPTION
PANEL DESCRIPTION
INSTALLATION INSTRUCTIONS / BRIGHTNESS AND FOCUS TRIM POTS
CAT5 WIRING DIAGRAM
CONNECTIONS DIAGRAM
SPECIFICATIONS
WARRANTY
1
2
3
4
5
6
7
8
9
Thank you for purchasing the Component with Audio Extender by Gefen, Inc.
Extendyouraudioand videosignal usingthe GefenComponentAudioExtender. Place
your source anywhere and extend the signal up to 1000 feet (300 meters) away. The
Component Audio Extender will extend Analog Component as well as Analog Audio
and Digital Audio via SPDIF or TOSlink.
INTRODUCTION
1
READ THESE NOTES BEFORE INSTALLING
OR OPERATING THE COMPONENT EXTENDER SYSTEM
• Use industry standard Category-5e (CAT-5e) cable to operate the Component with
Audio Extender system. CAT-5e cable is preferred.
• Please connect all the cables between the source and the Component with Audio
Extender before powering up the Component with Audio Extender unit.
• The Component with Audio Extender units are housed in a metal box for better RF
shielding.
OPERATION NOTES
HOW IT WORKS
The Component Audio Extender sender unit connects to any component video and
audio source using the supplied Component and RCA cables. The receiver unit con-
nects to your HDTV component video display and audio input up to 1000 feet (300
meters) away. One CAT-5e cable is used to connect the sender to receiver for perfect
video extension up to 1080p. The sender and receiver will be powered individually by
5V power supplies.
Features
• Supports up to 1080p component video
• Supports analog L+R audio
• Plug and play installation
• Equalizations for different CAT-5 skews
• One CAT-5 cable for extension
Includes:
(1) Component Audio Extender Sender
(1) Component Audio Extender Receiver
(1) 6ft. 5 RCA Component w/Audio Cable
(2) 5V Power Supply
FEATURES
2
PANEL DESCRIPTIONS
3
Sender
5V Power
Supply Input Component
Input Analog Audio
Input
SPDIF Input
Optical /
Toslink Input
Power Light
Indicator
5V Power
Supply Input Component
Output Analog Audio
Output
SPDIF Output
Optical /
Toslink Output
Power Light
Indicator
Receiver
PANEL DESCRIPTIONS
4
CAT-5e
Cable Input Brightness
Trim Pot
Focus
Trim Pot
Sender
Receiver
CAT-5e
Cable Input
Connect the Component output of your source / receiver to the input on the
Component Extender Sender Unit.
Connect the audio output of your source / receiver to the input on the
Component Extender Sender Unit.
Connect the Component input of your display to the Component output on the
Component Extender Receiver Unit.
Connect the audio input of your display to the Component output on the
Component Extender Receiver Unit.
Connect a CAT-5 cable between the Component Extender sender and
receiver’s CAT-5 input.
Power on the display first and then the source.
INSTALLATION INSTRUCTIONS
1.
2.
3.
4.
5.
6.
5
Note: Any of the 3 RCA lines can be used for any color. Both ends will need to be
matched for the signal to be passed through correctly.
BRIGHTNESS AND FOCUS TRIM POTS
The brightness and focus adjustments are found on the receiver unit and will help
compensate for issues that can be introduced by outside interference and cable
variances. If the outgoing image is too dark or too bright, the brightness trim pot can
be tuned to help brighten the image. If there is a ghosting or blurring effect on the
image, the focus trim pot can be used to eliminate these artifacts. Insert a small flat
head device, such as a screw driver into either the brightness or focus trim pot hole.
Turn the trim pot in millimeter increments in either a clockwise or counterclockwise
direction. Once the desired brightness and focus are reached, simply remove the
adjustment device from the trim pot hole.
White/Orange
Orange
White/Green
Blue
White/Blue
Green
White/Brown
Brown
RJ-45 Jack RJ-45 Jack
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
1818
CAT5 WIRING DIAGRAM
6
7
CONNECTIONS DIAGRAM
