GOLDENSEA UV UVS4 Bedienungsanleitung
1
USER GUIDE
USER GUIDE-WARNINGS
2
Improper use of this product may cause damage to skin and eyes
This device may only be used by trained personnel
Before operating this product the operator must read the user guide
and be aware of all the risks associated with this product and best
practices for using it
Never enter the disinfection area when the product is in operation
and the red LED is illuminated
!
!
!
!
!
3
SAFETY BY DESIGN
Motion Detection Audible/ Visual Alarms Delayed Start Time Fall Auto Protect*
*UVS4, UVP36, UVM216, UVM432, UVAIR216 are
fitted with this sensor
4
SAFETY BY DESIGN
Included Warning Sign Included UV Safety Glasses
5
SAFETY BY DESIGN
!
EVEN THOUGH ALL GOLDENSEA UV PRODUCT HAVE BUILT IN
SAFETY FEATURES IT IS ESSENTIAL THAT ALL OPERATORS AND
COMMERCIAL REPRESENTATIVES UNDERSTAND THE BEST
PRACTICES AROUND USING THESE PRODUCTS!
USER GUIDE-PREPARE
6
!
•Ensure unit is on a stable surface or properly wall mounted
•Confirm disinfection area is clear of LIVING BEINGS PRIOR TO PROCEEDING
•Wear the supplied UV glasses
•Place supplied warning sign on outside of door and use use additional signs if required
•Confirm there is a clear path to the exit
•Know how long you have to exit the area after starting the cycle (page 15)
•Identify and plan to cover significant gaps at doors to disinfection area
•Locate the remote control and keep it on your person
•It is best practice to wear tightly woven clothing covering all exposed skin and nitrile gloves
USER GUIDE-SETUP
7
!
1. Plug the unit into an electrical outlet, do not modify/ alter the electrical
connection of the product in anyway
2. Turn on the product by setting the I/0rocker switch to I. The green LED will
illuminate.The UVC tubes are NOT illuminated at this time
3. Where possible use the included remote control and move to the door in
preparation for activation
4. Select the appropriate disinfection time by pressing the relevant button
5. Before pressing start reassess the area, make sure there are no living
beings in the area and that your path to exit is clear
USER GUIDE-ACTIVATE
8
!
1. Press the start button
2. Once the start button is pressed an audible alarm will sound and ared LED light
will flash for the duration of the delayed start time
3. YOU MUST EXIT THE DISINFECTION AREA IMMEDIATELY
4. Once the delayed start time has ended, the tubes will activate and the red LED light
will illuminate for the duration of the disinfection process
5. During emission there will be an audible ping every 10 seconds until the emission
time is over
USER GUIDE-END OF CYCLE
9
!
1. Once the disinfection process has ended, the red LED light will turn off and be
replaced by the green LED light.This will indicate that it is now safe to enter the
room
2. Upon entering the room, open windows to ventilate area
1. You may encounter an unusual smell which is anormal result of the
disinfection process and is not harmful
3. If using amobile product return the unit to its safe storage location
4. Remember to return the UV Warning Sign, Remote control and UV Glasses to their
storage location
USER GUIDE-INTERRUPTION OF
CYCLE
10
!
1. If the disinfection cycle is interrupted due to the motion sensor being activated,
the unit will sound an alarm tone until an operator resets the unit
1. The unit may be reset by selecting the relevant timing cycle followed by the
start button
2. The unit will now go through the delay start process and then begin the cycle
3. You may also restart the unit using the remote control
2. If the disinfection cycle is interrupted due to apower outage, no alarm tone will
sound.Once power returns the disinfection cycle will need to be restarted as per
previous instructions
