Grindmaster American Metal Ware LCD2-1 Bedienungsanleitung

Liquid Coffee Dispenser

Model LCD2-1-SS

MODEL LCD2-1-SS

Liquid Coffee Dispenser

Features:

•High ratio (50:1 - 110:1) and mid ratio (22:1 - 55:1)

dispensers available

•Accommodates most 1/2 gal. (1.9 L) and

1 gal. (3.8 L) bag-in-the-box (2 per machine)

•4.5 gal. (17 L) stainless steel hot water tank

•7" (17.8 cm) cup clearance accommodates most

20 oz. (592 ml) cups

•Large attractive backlit merchandiser

•3 dispense heads: Regular, Decaf, & Hot Water

•Digital controls for accurate mix ratios

•Product system shuts off dispense system when the

bag-in-the-box is empty

•15KW, 3ph for high volume applications

All specifications are subject to improvement or change without notice.

Ask about Grindmaster Corporation’s line of Coffee Grinders, Coffee Brewers, Coffee Urns, Coffee Shuttles, Coffee

Grinderbrewers, Espresso Grinders, Espresso Brewers, Beverage Dispensers, Granita Machines and Beverage Freezers.

Drink Output - # of 6 oz. (178 ml) cups per hour at:

Water Inlet Temperature 120V 208V

60°F 110 340

160°F 500 1500

Grindmaster® Coffee Grinders and Brewers • PrecisionBrew™ Brewing Systems • Espressimo® Espresso Machines

Crathco® Hot Beverage Dispensers • Crathco® Cold and Frozen Beverage Dispensers • AMW Coffee and Tea Systems

Tel (502) 425-4776 • Fax (502) 425-4664 • 1-800-695-4500 (USA & Canada only)

P.O. Box 35020 • Louisville, KY 40232 • USA

www.grindmaster.com • email: info@grindmaster.com 0108 Form# AM-279-04

© Grindmaster Corporation, 2000

PRINTED IN USA

Specifications Model LCD2-1-SS Model LCD2-3-SS

Volts/Watts/Amps (120/240V) / 6,600W / 28A

120V / 1,650W / 14A

(120/240V) / 15,000W / 36A / 3ph

(120/208V) / 11,300W / 32A / 3ph

# Dispensers 2 heads + hot water 2 heads + hot water

Dispense Rate 2 oz. (59 ml) per second 2 oz. (59 ml) per second

Portion Range 50:1 to 110:1/or 22:1 to 55:1 50:1 to 110:1/or 22:1 to 55:1

Water Line Connection 3/8” (9.5 mm) male flare 3/8” (9.5 mm) male flare

Tank Size 4.5 gal. (17 L) 4.5 gal. (17 L)

Cup Clearance 7” (17.8 cm) 7” (17.8 cm)

Dimensions (H x W x D) 31” x 12” x 23”

(79 cm x 31 cm x 59 cm)

31” x 12” x 23”

(79 cm x 31 cm x 59 cm)

Ship Dimensions (H x W x D) 32” x 16-1/4” x 26-1/2”

(81 cm x 41 cm x 67 cm)

32” x 16-1/4” x 26-1/2”

(81 cm x 41 cm x 67 cm)

Weight 85 lbs. (38.2 kg) 85 lbs. (38.2 kg)

Ship Weight 90 lbs. (40.5 kg) 90 lbs. (40.5 kg)

Listings UL, CUL & NSF UL, CUL & NSF
