H-KING J-20 Bedienungsanleitung

INSTRUCTION MANUAL

1

Packing list:

1: PP J20 fuselage *1

2: Carbon strip 1mm*3

3: Carbon strip 0.5mm * 2

4: Pull rod *2

5: Motor mount *1

6: Quick rod adjuster *2

7: Hinge*2

8: Hook and loop tape*1

Tools:

1: 1.5mm allen wrench

2: Phillips screwdriver

3: Modelling knife

4: Wire cutters

5: Hot melt glue gun and glue sticks

6: Foam Glue

7: No.502 glue

Electronic equipment:

Motor：2208-2212-2216

2000KV-2600KV*1

Prop：5-6 inch *1

ESC：20-40A*1

Servo：8/9g *2

Battery：1300-2200mah 3S *1

2

Glue the 2 pcs horizontal fuselages using hot glue

sticks.

Then put the 3 pcs carbon strips into horizontal

fuselage using No.502 glue.

Stick the 2 pcs carbon strips on vertical tail using foam

glue.

Press the 2 pcs vertical fuselages into horizontal

fuselage. Important: Don’t use glue!

3

Assemble bottom fuselage on vertical fuselage.

Reinforce bottom fuselage using hot glue sticks after

assembly. Then wait glue dried.

Applying glue on 2 pcs vertical fuselages using foam

glue sticks. Important: Just glue top side.

Reinforce bottom fuselage using hot glue sticks inside.Then take down bottom fuselage with 2 pcs vertical

fuselages.

Then assemble vertical fuselage and bottom fuselage

on horizontal fuselage using foam glue or hot glue

stick.

Also don’t forget to reinforce vertical fuselage using hot

glue sticks.

4

Applying foam glue on 2 pcs nose. Important: Wait 3 mins after applying foam glue,

then assemble the 2 pcs nose. Make sure 2 pcs

nose trim. Especially for step.

Assemble the nose on fuselage using hot glue sticks

or foam glue, make sure the motor mount location

must be flat!

Reinforce nose using hot glue sticks after assembly.

Install vertical tail on fuselage using hot glue sticks. Must use triangle foam board to make sure vertical

tail’s incline.

5

Assemble motor on motor mount using motor’s

screws. Then install prop on motor. Notice the prop’s

direction.

Assemble motor mount on fuselage, reinforce motor

mount using a little hot glue sticks.

Put hook and loop tape on fuselage using foam glue.

Then install ESC .

Install hinge into the hole on tail aileron using hot glue

stick.

Install arm on servo and electrify all servos to make

sure the arm perpendicular to servo. Then install arm

screws. Fix servo on fuselage using hot glue sticks.

6

Put hook and loop tape on fuselage using foam glue.

Then install battery. Let battery cable through the hole

to fix battery.

Then install the pull on the quick rod adjuster and

hinge. Adjust pull rod’s length and tighten the screw.

Put hook and loop tape near battery using foam glue.

Connect servo, ESC with receiver. Then put receiver

on tape.

C of G is on the front of the motor 8cm as shown in the

picture above.

Fix battery use battery cable and block the cover. IPP J20 need set delta wing mixed control on radio

(Elevator and aileron mixed control), it’s very stable

when flying. You can also add servo on canard wing

to make flying more agility.

7

Note

8

Note
