Hama 176932 Bedienungsanleitung
RUS
E
D
GB
I
PL
CZ
SK
RO
Operating Instructions
Bedienungsanleitung
Mode d‘emploi
Instrucciones de uso
Руководство по эксплуатации
Istruzioni per l‘uso
Instrukcja obsługi
Návod k použití
Návod na použitie
Manual de utilizare
F
00
176932
TS35C
Outdoor Sensor
Außensensor
433MHz
HYGRO-THERMO
CH
22.7C
1
1
6
34
5
2
2
GOperating instruction
Controls and Displays
A Measuring station
1. LED indicator
2. Battery compartment
3. RESET button = restores factory settings
4. CHANNEL slide switch = selects channel
5. Recess for wall mounting
6. LCD display
Thank you for choosing a Hama product.
Take your time and read the following instructions and information
completely. Please keep these instructions in a safe place for future
reference. If you sell the device, please pass these operating instructions
on to the new owner.
1. Explanation of Warning Symbols and Notes
Warning
This symbol is used to indicate safety instructions or to draw your
attention to specic hazards and risks.
Note
This symbol is used to indicate additional information or important
notes.
3
2. Package Contents
•TS35C Outdoor Sensor
•These operating instructions
3. Safety Notes
•The product is intended for private, non-commercial use only.
•Do not operate the product outside the power limits given in the
specications.
•Do not use the product in moist environments and avoid splashes.
•Do not use the product in the immediate vicinity of heaters or other
heat sources or in direct sunlight.
•Do not use the product in areas where the use of electronic devices
is not permitted.
•Do not put the product near interference elds, metal frames,
computers, TVs, etc. Electronic devices and window frames can
negatively affect the product’s functionality.
•Do not drop the product and do not expose it to any major shocks.
•Do not open the device or continue to operate it if it becomes
damaged.
•Do not attempt to service or repair the product yourself. Leave any and
all service work to qualied experts.
•Keep the packaging material out of the reach of children due to the
risk of suffocation.
•Dispose of packaging material immediately according to locally
applicable regulations.
•Do not modify the product in any way. Doing so voids the warranty.
4
Warning – Batteries
•Immediately remove and dispose of dead batteries from the
product.
•Only use batteries (or rechargeable batteries) that match the
specied type.
•Do not mix old and new batteries or batteries of a different type
or make.
•When inserting batteries, note the correct polarity (+ and -
markings) and insert the batteries accordingly. Failure to do so
could result in the batteries leaking or exploding.
•Do not overcharge batteries.
•Keep batteries out of the reach of children.
•Do not short circuit the batteries/rechargeable batteries and keep
them away from uncoated metal objects.
4. Getting started
•Open the battery compartment (2).
•Move the CH slide switch (4) to the left or right to select the channel
on which the measuring station transmits.
•Insert two AA batteries with the correct polarity.
•Once the channel has been assigned to a transmitter, it can only be
changed by removing the batteries or by resetting the measuring
station (see section 6.5 Reset).
•Then close the battery compartment cover.
5
Replacing the batteries
•Open the battery compartment (2), remove and properly dispose of
the dead batteries and insert two new AAA batteries with the correct
polarity. Then close the battery compartment cover.
Note
Before use, make sure that you insert the batteries in the measuring
station rst and then in the base station.
5. Installation
Note – Installation
•We recommend initially placing the base and measuring stations
in the intended locations without installing them and making all
the settings described in 6. Operation.
•Only install the stations once the appropriate settings have been
made and a stable wireless connection is established.
6
Note
•The wireless transmission range between the measuring and base
stations is up to 30 metres in open spaces.
Before installation, ensure that wireless transmission will not
be disrupted by interference or obstacles like buildings, trees,
vehicles, high-voltage lines, etc.
•Before the nal installation, ensure that there is sucient
reception between the intended installation locations.
•When installing the measuring station, ensure that it is protected
from direct sunlight and rain.
•The international standard height for measuring air temperature is
1.25 m (4 ft) above ground.
Warning
•Buy special or suitable installation material from a specialised
dealer for wall-mounting.
•Ensure that no faulty or damaged parts are installed.
•Never apply force during installation. This could damage the
product.
•Before installation, ensure that the chosen wall is suitable for
the weight to be installation, and make sure that there are
no electrical wires, water, gas or other lines in the wall at the
installation site.
7
•You can position the measuring station on a level outdoor surface
using the base.
•We recommend installing the measuring station securely on an
outdoor wall.
•Install an anchor, screw, nail, etc. in the wall of your choice.
•Hang the measuring station using the opening intended for this
purpose (4).
6. Operation
6.1. Connection to the measuring station
•To connect the base station and the measuring station, place the two
devices as close together as possible.
•After you insert the batteries, the base station automatically searches
for a connection to the measuring station and performs initial setup.
•If the device does not connect automatically, the manual search
program on the base station must be started.
Note
•Initial setup takes approximately 5 minutes.
•During the connection attempt, the radio symbol and the LED
indicator (1) on the measuring station will ash.
•Do not press any buttons during setup. Otherwise, values may
not be transmitted correctly and there is a risk of value errors and
inaccuracies.
•The setup process is completed when the indoor and outdoor
measurement data is displayed on the base station.
•The measured value is automatically updated by the base device
about every 60–64 seconds.
8
6.2. Selecting the channel/Other measuring stations
Note
•You can connect up to three different base stations to the
measuring station. Ensure that the base station and measuring
station are set to the same channel. Suitable base stations can be
found at www.hama.com
•The transmission channel on the supplied measuring station can
be changed/set (CH1, CH2, CH3).
•The measuring station is suitable for the following base stations:
113984, 113985, 113986
6.3. Low battery charge
Once the battery symbol appears on the display of the base station,
the capacity of the batteries in the measuring station is very low. Replace
the batteries immediately.
Note – Replacing the batteries
•Note that the stations have to be resynchronised each time after
you change the batteries in the measuring or base station.
•To do this, remove the batteries from the other station and then
reinsert them, or change them as required.
9
6.4 Reset
Press the RESET button (3) to restart the station. The measuring station
returns to the factory settings.
7. Care and Maintenance
•Only clean this product with a slightly damp, lint-free cloth and do not
use aggressive cleaning agents.
•Make sure that water does not get into the product.
8. Warranty Disclaimer
Hama GmbH & Co KG assumes no liability and provides no warranty for
damage resulting from improper installation/mounting, improper use of
the product or from failure to observe the operating instructions and/
or safety notes.
9. Service and Support
Please contact Hama Product Consulting if you have any questions about
this product.
Hotline: +49 9091 502-115 (German/English)
Further support information can be found here:
www.hama.com
