Harbor Freight Tools 94840 Kurzanleitung

ASSEMBLY & OPERATING INSTRUCTIONS

3491 Mission Oaks Blvd., Camarillo, CA 93011

Visit our Web Site at www.harborfreight.com

any artwork contained herein may be reproduced in any shape or form without the

express written consent of Harbor Freight Tools.

For technical questions and replacement parts please call 1-800-444-3353.

94840

RADIO CONTROLLED

Due to continuing improvement, actual product may differ slightly from product described herein.

BIPLANE

Important: If damage is caused due to a crash; your warranty is void.

SKU 98480 For technical questions please call 1-800-444-3353. Page 2

THANK YOU for choosing a HARBOR FREIGHT TOOLS product. For future reference, please

complete the owner’s record below:

Model______________ SerialNo._____________ PurchaseDate_______________

SAVE THE RECEIPT, WARRANTY AND THESE INSTRUCTIONS. It is important that you read the

entire manual to become familiar with the unit BEFORE you begin assembly.

Specifications

Material: Styrofoam wings, plastic frame,

propellors and stand

Motors included: Dual, rear mounted DC

Propellors: 2 rear facing; 2-1/2” Long

Wing Span: Central:15-3/8”W;Front:6-1/2”W

WingWidth: Central:2-3/4”;Front:1-5/8”

Power: 4 wrapped cells, 2 Ni-Mh battery packs

ChargeTime: 3-5 minutes

FlyTime: 2-4 minutes

Overall Dimensions: 12-1/2” L X 15-1/2”W X 6-1/2” H

Frequency: 27 MHZ

Transmitter/Charger: 2-Channel PCM

Batteries Required: (8) “AA” (not included)

Overall Length: 12-1/2”

Weight: 2.9 Ounces

Safety Warnings and Precautions

WARNING:When using product, basic safety precautions should always be followed to

reduce the risk of personal injury and damage to equipment.

Read all instructions before using this product!

1. Keep work area clean. Cluttered areas invite injuries.

2. Observe work area conditions. Keep work area well lit. Keep work area uncluttered and free

of debris. Cluttered areas invite injury.

3. Check for damaged parts. Before using any product, any part that appears damaged should

be carefully checked to determine that it will operate properly and perform its intended function.

Check for any broken or damaged parts and any other conditions that may affect its operation.

Replace or repair damaged or worn parts immediately.

4. Replacement parts and accessories. When servicing, use only identical replacement parts.

Use of any other parts will void the warranty.

5. Always check hardware and assembled parts after assembling. All connections should be

tight and hardware tightened.

6. Do not let children use the Biplane without adult supervision. Failure to do so could result

in personal injury and/or property damage.

SKU 98480 For technical questions please call 1-800-444-3353. Page 3

7. Store idle equipment. When not in use always lock up the Biplane and keep it out of the

reach of children.

8. Dress properly. Wear restrictive hair covering to contain long hair.

9. Use eye protection. Always wear ANSI-approved impact safety goggles when using and

assembling this product.

10. Maintain products with care. Keep the Biplane in a dry location. Do not expose it to

prolonged moisture.

11. Use the right Biplane for the job. Do not attempt to force a small Biplane to do the work of a

larger Biplane. There are certain applications for which this Biplane was designed. Do not

modify this Biplane and do not use this Biplane for a purpose for which it was not intended.

12. Do not use or assemble the Biplane if under the influence of alcohol or drugs. Read

warning labels on prescriptions to determine if your judgement or reflexes are impaired while

taking drugs. If there is any doubt, do not assemble or use the Biplane.

13. Do not pick up the Biplane while it is in motion.

14. Use only batteries of the type recommended.

15. Do not mix old and new batteries and remove batteries if the Biplane is not used for a

long period of time.

16. NiCad batteries must be disposed of properly. Do not incinerate. Batteries may burst,

causing personal injury and/or property damage. Contact your local hazardous waste disposal

authority for proper disposal.

17. Do not recharge non-rechargeable batteries.

18. Make certain to use the Biplane in a large area free from interference from trees,

electrical power lines and other obstacles.

19. Never fly near buildings, cars, busy streets or at other people or animals.

20. Do not fly the Biplane if wind speeds are above 10 MPH.

21. Do not allow children to use glue without adult supervision. Make certain that all glue

is stored out of reach of children and animals.

22. If two airplanes with the same frequency are used (both with the same numbers on the

transmitter and/or receiver) they must be at least 1,640 feet away from one another.

23. Before flying, perform a distance check to be certain that you can maintain radio control

at least 25 feet from the transmitter to the Biplane with the antenna collapsed.

24. Do not trim the Biplane’s antenna. Trimming the antenna will affect radio range.

Warning: People with pacemakers should consult their physician(s) before using this

product. Electromagnetic fields in close proximity to a heart pacemaker could cause

interference to/or failure of the pacemaker.

SKU 98480 For technical questions please call 1-800-444-3353. Page 4

WARNING: The warnings, cautions, and instructions discussed in this instruction manual cannot

cover all possible conditions and situations that may occur. It must be understood by

the operator that common sense and caution are factors which cannot be built into

this product, but must be supplied by the operator.

Assembly

Your Biplane will require some assembly. It is important that you read the entire manual to become

familiar with the product BEFORE you assemble and use the Biplane. Be sure that you have all

parts described in the Parts List located on page 7 of this manual.

Attaching the Battery Pack

1. Turn off the power before connecting the Battery Pack to the Biplane.

2. Plug the Battery Pack (4) into the outlet located on the Biplane as seen in Figure 1.

3. Please note:The Battery Pack is installed from the rear by sliding it forward until it rests

against the lip/stop on the airframe, as seen in Figure 2.Once installed, the Battery Pack

should be locked into place by inserting the the rubber pin through the holes in the battery

tray and airframe.

Plug in

Battery Pack

here

Figure 1

Charging the Battery Pack

1. The Battery Pack (4) is charged from the Transmitter/Charger Unit (2). Plug the Battery

Pack (4) into the Charging jack, located at the side of the Transmitter/Charger Unit (2)-see

Figure 3.

2. Hold down the red button until the battery indicator turns orange.

3. A charge time of three to five minutes is usually sufficient.

4. During charging the Battery Pack will get warm. Make certain it does not get overly hot.

5. The Battery Pack must have three to four initial charges of a longer duration before they

obtain a full run time of 4 to 6 minutes.

Brackets for

Battery Pack (4)

Figure 2

SKU 98480 For technical questions please call 1-800-444-3353. Page 5

Operating the Radio Transmitter

1. The Transmitter uses 8 “AA” batteries (not included). Remove the Battery Compartment

Cover (12)-see Figure 4. Insert the batteries into the Battery Compartment making certain to

line up the batteries with the polarity indicated in the Battery Compartment. Press the

Battery Compartment Cover (12) back into place.

2. The Radio Transmitter (2) transmits a signal to the airplane’s receiver.

3. The Radio Transmitter (2) has a LED display that will light up when the Transmitter is on.

The LED readout will indicate the strength of the battery charge:

Green indicates the batteries are at full capacity

Yellow indicates the batteries are at half capacity

Red indicates the batteries need replacing.

4. The Radio Transmitter/Charger is turned ON and OFF with the On/Off Switch located

midway between the Control Sticks-see Figure 4.

5. The Radio Transmitter/Charger has two Control Sticks.

The Control Stick located on the left moves vertically and controls the Climb. Push

the Climb Control Stick forward to turn on the twin motors and cause the Biplane to climb.

Pull back on the Climb Control Stick to slow down the twin motors and cause the Biplane to

lower altitude-see Figure 4.

The Control Stick located on the right moves horizontally and controls the direction of the

Biplane.Pushing the Turn Control Stick right or left causes the Biplane to turn right or left.

6. Attach the Wind Ribbon to the Radio Transmitter Antenna.

InstallingPropellers

1. Make certain Radio Transmitter is OFF and that the Battery Pack is unplugged.

2. The Biplane comes with spare Propellers. If necessary, remove the Nut holding each

Propeller in place. Remove the Propeller. Install new Propeller.

Transmitter/Charger Unit (2)

Battery Pack (4)

Figure 3

Charging

Jack

LED readout

On/Off

Switch

Climb

Control

Stick

Turn Control

Stick

Figure 4

SKU 98480 For technical questions please call 1-800-444-3353. Page 6

Operating and Flying the Biplane

Preparing for Take-Off

1. Choose a day when the wind is light. The ribbon attached to the Radio Transmitter

antenna should be blowing slightly (not greater than 30 degrees) and not be

blowing straight out. Find a wide-open field.

2. Turn ON the Radio Transmitter.

3. Face the Biplane into the wind. Move the left hand control stick all the way forward so

both motors are running at full power.

Note: It is recommended that two people work together to hand launch the Biplane. One

should control the Remote Control and one will launch the Biplane.

4. With the Biplane tilted at about 10 degrees, propel and release it into the wind.

5. Let the Biplane climb to and fly at about 50 to 300 feet high. By moving the Climb andTurn

control sticks you can change speed and direction.

6. To steer the Biplane, move the right Turn control stick to the left to steer to the left, and

right to steer it right. Move the Turn Control Stick slightly to adjust for minor changes in

direction and tilt of the Biplane.

7. Note that letting go of the control sticks will automatically bring them to a center position.

This will cause the Biplane to resume normal flight.

8. Normal flight time for one full charge is about four to six minutes. When the battery begins

to reach the end of its power, the red LED light on the Radio Transmitter will light up,

indicating low transmitter power. When this occurs, IMMEDIATELY LAND THE BIPLANE.

9. To bring in the Biplane for landing, glide the Biplane down against the wind. Move the

left Climb control stick toward the center to slow the Propellers. Move the right Turn control

stick to adust for direction. Continue to decrease the Propeller speed and direction until you

bring them to a stop and land the Biplane.

10. Turn OFF the Radio Transmitter.

Inspection, Maintenance and Cleaning

1. All inspections, maintenance, and cleaning should be performed only by an adult.

2. Always make certain the Biplane is unplugged and that the Transmitter is OFF before

performing any inspection, adjustments, maintenance or cleaning.

Important: If damage is caused due to a crash; your warranty is void.

3. Never use solvents or liquid cleaners to clean the Biplane. Use of solvents or liquid cleaners

will damage the styrofoam. Use only a dry, soft cloth for cleaning.

SKU 98480 For technical questions please call 1-800-444-3353. Page 7

4. Before each use check for loose screws, misalignment or binding of moving parts, cracked

or broken parts, damaged housing, damaged wiring, loose wheels and any other condition

that may affect its safe operation. If abnormal noise or vibration occurs, have the problem

corrected before further use. Do not use the Biplane if it is damaged.

5. Do not leave the Biplane outside as prolonged exposure to the elements will damage the

exterior of the Biplane.

Parts List

Part # Description Quantity Part # Description Quantity

1 BiplaneBody 1 6 SparePropeller 2

2 Radio Transmitter/ 7 VerticalStabilizer 3

ChargerUnit 1 8 Display Stand 1

3 Antenna 1 9 HorizontalStabilizer 1

4 Battery Pack 2 10 Battery Cover 1

5 Wind Gauge Flag 1

PLEASE READ THE FOLLOWING CAREFULLY

THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS DIAGRAM IN THIS MANUAL AS A REFERENCE

TOOL ONLY. NEITHER THE MANUFACTURER NOR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY

KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT OR THAT HE OR SHE IS

QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT,THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY

STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND LICENSED

TECHNICIANS AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER

REPAIRSTOTHE ORIGINAL PRODUCT OR REPLACEMENT PARTSTHERETO, OR ARISING OUT OF HIS OR HER INSTALLATION

OF REPLACEMENT PARTS THERETO.

Note: Some parts are listed and shown for illustration purposes only and are not available

individually as replacement parts.

Inhaltsverzeichnis

Andere Harbor Freight Tools Spielzeug Handbücher

Harbor Freight Tools

Harbor Freight Tools 94737 Bedienungsanleitung

Harbor Freight Tools

Harbor Freight Tools U.S. GENERAL Junior 56515 Montageanleitung

Harbor Freight Tools

Harbor Freight Tools 95125 Stücklistenhandbuch

Harbor Freight Tools

Harbor Freight Tools 95641 Stücklistenhandbuch

Harbor Freight Tools

Harbor Freight Tools 91311 Kurzanleitung

Harbor Freight Tools

Harbor Freight Tools 3514 Bedienungsanleitung

Harbor Freight Tools

Harbor Freight Tools 91131 Bedienungsanleitung

Harbor Freight Tools

Harbor Freight Tools 94840 Installationshandbuch

Harbor Freight Tools

Harbor Freight Tools 68752 Bedienungsanleitung

Harbor Freight Tools

Harbor Freight Tools 91192 Bedienungsanleitung

Harbor Freight Tools

Harbor Freight Tools 95641 Stücklistenhandbuch

Harbor Freight Tools

Harbor Freight Tools BUCK HORN WAGON WOODEN MODEL 9141 Bedienungsanleitung

Harbor Freight Tools

Harbor Freight Tools 57990 Montageanleitung

Harbor Freight Tools

Harbor Freight Tools 62578 Montageanleitung

Harbor Freight Tools

Harbor Freight Tools River Boat Bedienungsanleitung

Harbor Freight Tools

Harbor Freight Tools 94774 Installationshandbuch

Harbor Freight Tools

Harbor Freight Tools 90034 Kurzanleitung

Harbor Freight Tools

Harbor Freight Tools Lightning Airplane with Charger 42619 Installationshandbuch

Harbor Freight Tools

Harbor Freight Tools 56513 Montageanleitung

Harbor Freight Tools

Harbor Freight Tools 95149 Bedienungsanleitung

Harbor Freight Tools

Harbor Freight Tools 92304 Kurzanleitung

Harbor Freight Tools

Harbor Freight Tools 90033 Kurzanleitung

Harbor Freight Tools

Harbor Freight Tools 57293 Montageanleitung

Harbor Freight Tools

Harbor Freight Tools AIR PIXIE HELICOPTER Installationshandbuch

Beliebte Spielzeug Handbücher anderer Marken

marklin

marklin 37321 Bedienungsanleitung

Canon

Canon PAPER CRAFT Bedienungsanleitung

GREAT PLANES

GREAT PLANES Pitts M-12S Bedienungsanleitung

NOCH

NOCH 14261 Bedienungsanleitung

Hausler

Hausler 450 SE V2 Bedienungsanleitung

Dynaflite

Dynaflite Daydream Bedienungsanleitung

MiniacRC

MiniacRC MIGHTY MINI P40 WARHAWK Handbuch

Kenner

Kenner Batman 63651 Bedienungsanleitung

LEGO

LEGO 8527 Bedienungsanleitung

iKarus

iKarus ECO 8 Bedienungsanleitung

Multiplex

Multiplex EasyStar II Bedienungsanleitung

Walkera

Walkera 38 Bedienungsanleitung

Hasbro

Hasbro TRANSFORMERS BUMBLEBEE Bedienungsanleitung

MD MXION SWD Bedienungsanleitung

Mattel

Mattel Disney Pixar Cars Cozy Cone Spiral Rampway Bedienungsanleitung

marklin

marklin 39671 Bedienungsanleitung

Meccano

Meccano 15103 Bedienungsanleitung

LEGO

LEGO TECHNIC 8735 Bedienungsanleitung
