HIK VISION DS-2CD7133-E Bedienungsanleitung

Network Mini Dome Camera

Installation Manual

V3.0.0

Hangzhou Hikvision Digital Technology Co., Ltd.

http://www.hikvision.com

2010-04

Thank you for purchasing our product. If there are any questions, or requests,

please do not hesitate to contact the dealer.

This manual applies to DS-2CD7133-E and DS-2CD7153-E Network Camera.

This manual may contain several technical incorrect places or printing errors,

and the content is subject to change without notice. The updates will be added

to the new version of this manual. We will readily improve or update the

products or procedures described in the manual.

DISCLAIMER STATEMENT

“Underwriters Laboratories Inc. (“UL”) has not tested the performance or

reliability of the security or signaling aspects of this product. UL has only

tested for fire, shock or casualty hazards as outlined in UL’s Standard(s) for

Safety, UL60950-1. UL Certification does not cover the performance or

reliability of the security or signaling aspects of this product. UL MAKES NO

REPRESENTATIONS, WARRANTIES OR CERTIFICATIONS WHATSOEVER

REGARDING THE PERFORMANCE OR RELIABILITY OF ANY SECURITY OR

SIGNALING RELATED FUNCTIONS OF THIS PRODUCT.”

Installation Manual of Network Mini Dome Camera

Safety Instruction

These instructions are intended to ensure that the user can use the product correctly to avoid

danger or property loss.

The precaution measure is divided into ‘Warnings’ and ‘Cautions’:

Warnings: Serious injury or death may be caused if any of these warnings are neglected.

Cautions: Injury or equipment damage may be caused if any of these cautions are neglected.

Warnings Follow these safeguards to

prevent serious injury or death.

Cautions Follow these precautions to

prevent potential injury or material

damage.

Warnings:

1. In the use of the product, you must strictly comply with the electrical safety regulations

of the nation and region.

2. Source with DC 12V according to the IEC60950-1 standard. Please refer to technical

specifications for more details.

3. Do not connect several devices to one power adapter as an adapter overload may cause

over-heating and can be a fire hazard.If use the POE as the power supply, please make

sure that the POE Switch have the sufficient power.

4. Please make sure that the plug is firmly inserted into the power socket.

5. When the product is installed on a wall or ceiling, the device should be firmly fixed.

Installation Manual of Network Mini Dome Camera

6. If smoke, odor, or noise rise from the device, turn off the power at once and unplug the

power cable, then contact the service center.

7. If the product does not work properly, please contact your dealer or the nearest service

center. Never attempt to disassemble the camera yourself. (We shall not assume any

responsibility for problems caused by unauthorized repair or maintenance.)

Installation Manual of Network Mini Dome Camera

Notice:

1. Make sure the power supply voltage is correct before using the camera.

2. Do not drop the camera or subject it to physical shock.

3. Do not touch sensor modules with fingers. If cleaning is necessary, use a clean cloth with

a bit of ethanol and wipe it gently. If the camera will not be used for an extended period

of time, put on the lens cap to protect the sensor from dirt.

4. Do not aim the camera at the sun or extra bright places. A blooming or smear may occur

otherwise (which is not a malfunction however), and affecting the endurance of sensor at

the same time.

5. The sensor may be burned out by a laser beam, so when any laser equipment is being

used, make sure that the surface of the sensor will not be exposed to the laser beam.

6. Do not place the camera in extremely hot or cold temperatures (the operating

temperature should be between -10°C ~ 60°C, dusty or damp locations, and do not

expose it to high electromagnetic radiation.

7. To avoid heat accumulation, good ventilation is required for a proper operating

environment.

8. While shipping, the camera should be packed in its original packing, or packing of the

same texture.

9. Regular part replacement: a few parts (e.g. electrolytic capacitor) of the equipment

should be replaced regularly according to their average life time. The average time varies

because of differences between operating environment and usage history, so regular

Installation Manual of Network Mini Dome Camera

checking is recommended for all users. Please contact with your dealer for more details.

Installation Manual of Network Mini Dome Camera

Table of Contents

Chapter 1 Introduction..............................................................................................................1

1.1 Network camera Functions and Features .............................................................1

1.2 Applications .....................................................................................................................2

Chapter 2 Installation.................................................................................................................3

2.1 Camera Description ......................................................................................................3

2.1.1 Camera Physical Description...........................................................................4

2.1.2 Camera Connection............................................................................................5

2.2 Hardware Installation ...................................................................................................6

Appendix Product Specification.......................................................................................... 10

DS-2CD7133-E .................................................................................................................... 10

Specification ................................................................................................................. 10

Dimensions.................................................................................................................... 11

DS-2CD7153-E .................................................................................................................... 12

Specification ................................................................................................................. 12

Dimensions.................................................................................................................... 13

Installation Manual of Network Mini Dome Camera

Chapter 1 Introduction

Network camera is a kind of embedded digital surveillance product that combines the

features of both traditional analog camera and network DVS (Digital Video Server). Due to

the embedded Linux operation system and the latest Davinci hardware platform of TI, the

system operates with high scheduling efficiency. Furthermore, the firmware is burned in the

flash, which makes the product small, reliable and highly stable.

1.1 Network camera Functions and Features

Functions:

Network Function: Support the TCP/IP protocols and IE browsing.

Heartbeat Function: The server can acquire real time operating performance of the

network camera through the heartbeat function.

Alarm Function: Supports Motion Detection.

User Management: Support multilevel right management. The administrator can create

up to 15 separate users with different right levels, which highly improves the system

security.

Compression Functions:

Support 1 channel video signal and standard H.264 video encoding compression, which

supports both variable bit rate and variable frame rate; besides, you can self-define both

the video quality and its compressed bit rate.

Remote Control:

Installation Manual of Network Mini Dome Camera

The product offers a 10M/100M self-adaptive Ethernet interface.

Support TCP/IP, HTTP, DHCP, DNS, DDNS, RTP/RTSP, PPPoE, SMTP, NTP protocols.

Set the parameters, browse real time videos or check the camera performance through

software or IE, and store the compressed bit rate through network.

Support remote upgrades and maintenance.

1.2 Applications

This camera is ideal for remote control network applications. E.g.:

1. Network surveillance for supermarkets and factories.

2. Remote surveillance for homes and offices.

3. Indoor monitoring scenes, such as hotel, corridor, stairway.

Installation Manual of Network Mini Dome Camera

Chapter 2 Installation

NOTE:

1. Please check if all the items on the package list have been included with your

camera.

2. Read the following contents carefully before the installation.

3. Make sure that all the related equipment is power-off during the installation.

4. Check the power supply to prevent any damage caused by mismatching problems.

5. If the product does not operate properly, please contact your dealer or the nearest

service center. Never attempt to disassemble the camera yourself. Users are

responsible for any problem caused by modification or repairing without

authorization.

2.1 Camera Description

NOTE: The camera supports PoE power supply.
