HIMA HIMatrix F2 DO 16 01 Bedienungsanleitung

HIMatrix

Safety-Related Controller

F2 DO 16 01 Manual

HIMA Paul Hildebrandt GmbH + Co KG

Industrial Automation

Rev. 2.00 HI 800 159 E

HI 800 159 E Rev. 2.00 (1334)

All HIMA products mentioned in this manual are protected by the HIMA trade-mark. Unless noted otherwise,

this also applies to other manufacturers and their respective products referred to herein.

HIMax®, HIMatrix®, SILworX®, XMR®and FlexSILon®are registered trademarks of HIMA Paul Hildebrandt

GmbH + Co KG.

All of the instructions and technical specifications in this manual have been written with great care and

effective quality assurance measures have been implemented to ensure their validity. For questions, please

contact HIMA directly. HIMA appreciates any suggestion on which information should be included in the

manual.

Equipment subject to change without notice. HIMA also reserves the right to modify the written material

without prior notice.

For further information, refer to the HIMA DVD and our website at http://www.hima.de and

http://www.hima.com.

Contact

HIMA contact details:

HIMA Paul Hildebrandt GmbH + Co KG

P.O. Box 1261

68777 Brühl, Germany

Phone: +49 6202 709-0

Fax: +49 6202 709-107

E-mail: [email protected]

Type of change

Revision

index

Revisions

technical editorial

1.00 Added: Configuration with SILworX X X

1.01 Deleted: Chapter Monitoring the Temperature State integrated in

the system manual

2.00 Revised: Chapters 3.4.1 and 3.4.2.1

Added: F2 DO 16 024, SIL 4 certified according to EN 50126,

EN 50128 and EN 50129, Chapter 4.1.3

X X

F2 DO 16 01 Table of Contents

HI 800 159 E Rev. 2.00 Page 3 of 40

Table of Contents

1Introduction 5

1.1 Structure and Use of this Manual 5

1.2 Target Audience 6

1.3 Formatting Conventions 7

1.3.1 Safety Notes 7

1.3.2 Operating Tips 8

2Safety 9

2.1 Intended Use 9

2.1.1 Environmental Requirements 9

2.1.2 ESD Protective Measures 9

2.2 Residual Risk 10

2.3 Safety Precautions 10

2.4 Emergency Information 10

3Product Description 11

3.1 Safety Function 11

3.1.1 Safety-Related Digital Outputs 11

3.1.1.1 Reaction in the Event of a Fault 12

3.2 Equipment, Scope of Delivery 13

3.2.1 IP Address and System ID (SRS) 13

3.3 Type Label 14

3.4 Assembly 15

3.4.1 LED Indicators 16

3.4.1.1 Operating Voltage LED 16

3.4.1.2 System LEDs 16

3.4.1.3 Communication LEDs 17

3.4.1.4 I/O LEDs 17

3.4.2 Communication 18

3.4.2.1 Connections for Ethernet Communication 18

3.4.2.2 Network Ports Used for Ethernet Communication 18

3.4.3 Reset Key 19

3.5 Product Data 20

3.5.1 Product Data F2 DO 16 014 21

3.6 Certified HIMatrix F2 DO 16 01 21

4Start-up 22

4.1 Installation and Mounting 22

4.1.1 Connecting the Digital Outputs 22

4.1.2 Connecting the Operating Voltage 23

4.1.3 Cable plugs 23

4.1.4 Mounting the F2 DO 16 01 in Zone 2 24

4.2 Configuration 25

Table of Contents F2 DO 16 01

Page 4 of 40 HI 800 159 E Rev. 2.00

4.3 Configuration with SILworX 25

4.3.1 Parameters and Error Codes for the Output 25

4.3.2 Digital Outputs for F2 DO 16 01 25

4.3.2.1 Tab: Module 26

4.3.2.2 Tab: DO 16: Channels 27

4.4 Configuration with ELOP II Factory 27

4.4.1 Configuring the Outputs 27

4.4.2 Signals and Error Codes for the Output 27

4.4.3 Digital Outputs for F2 DO 16 01 28

5Operation 29

5.1 Handling 29

5.2 Diagnosis 29

6Maintenance 30

6.1 Faults 30

6.2 Maintenance Measures 30

6.2.1 Loading the Operating System 30

6.2.2 Proof Test 30

7Decommissioning 31

8Transport 32

9Disposal 33

Appendix 35

Glossary 35

Index of Figures 36

Index of Tables 37

Index 38

F2 DO 16 01 1 Introduction

HI 800 159 E Rev. 2.00 Page 5 of 40

1 Introduction

This manual describes the technical characteristics of the device and its use. It provides

information on how to install, start up and configure the module.

1.1 Structure and Use of this Manual

The content of this manual is part of the hardware description of the HIMatrix programmable

electronic system.

This manual is organized in the following main chapters:

Introduction

Safety

Product Description

Start-up

Operation

Maintenance

Decommissioning

Transport

Disposal

HIMatrix remote I/Os are available for the programming tools SILworX and ELOP II Factory.

Which programming tool can be used, depends on the processor operating system of the

HIMatrix remote I/O, refer to the following table:

Programming tool Processor operating system

SILworX CPU OS V7 and higher

ELOP II Factory CPU OS up to V6.x

Table 1: Programming Tools for HIMatrix Remote I/Os

In the manual, the differences are specified by using:

Separated chapters,

Tables differentiating among the versions

iProjects created with ELOP II Factory cannot be edited with SILworX, and vice versa!

iCompact controllers and remote I/Os are referred to as devices.

1 Introduction F2 DO 16 01

Page 6 of 40 HI 800 159 E Rev. 2.00

Additionally, the following documents must be taken into account:

Name Content Document number

HIMatrix System Manual

Compact Systems

Hardware description of the HIMatrix

compact systems

HI 800 141 E

HIMatrix System Manual

Modular System F60

Hardware description of the HIMatrix

modular system

HI 800 191 E

HIMatrix Safety Manual Safety functions of the HIMatrix system HI 800 023 E

HIMatrix Safety Manual for

Railway Applications

Safety functions of the HIMatrix system

using the HIMatrix in railway

applications

HI 800 437 E

SILworX Online Help Instructions on how to use SILworX -

ELOP II Factory

Online Help

Instructions on how to use ELOP II

Factory, Ethernet IP protocol

SILworX First Steps Introduction to SILworX using the

HIMax system as an example

HI 801 103 E

ELOP II Factory First Steps Introduction to ELOP II Factory HI 800 006 E

Table 2: Additional Relevant Documents

The latest manuals can be downloaded from the HIMA website at www.hima.com. The revision

index on the footer can be used to compare the current version of existing manuals with the

Internet edition.

1.2 Target Audience

This document addresses system planners, configuration engineers, programmers of

automation devices and personnel authorized to implement, operate and maintain the modules

and systems. Specialized knowledge of safety-related automation systems is required.

F2 DO 16 01 1 Introduction

HI 800 159 E Rev. 2.00 Page 7 of 40

1.3 Formatting Conventions

To ensure improved readability and comprehensibility, the following fonts are used in this

document:

Bold To highlight important parts.

Names of buttons, menu functions and tabs that can be clicked and used

in the programming tool.

Italics For parameters and system variables

Courier Literal user inputs

RUN Operating state are designated by capitals

Chapter 1.2.3 Cross references are hyperlinks even though they are not particularly

marked. When the cursor hovers over a hyperlink, it changes its shape.

Click the hyperlink to jump to the corresponding position.

Safety notes and operating tips are particularly marked.

1.3.1 Safety Notes

The safety notes are represented as described below.

These notes must absolutely be observed to reduce the risk to a minimum. The content is

structured as follows:

Signal word: warning, caution, notice

Type and source of risk

Consequences arising from non-observance

Risk prevention

The signal words have the following meanings:

Warning indicates hazardous situation which, if not avoided, could result in death or serious

injury.

Caution indicates hazardous situation which, if not avoided, could result in minor or modest

injury.

Notice indicates a hazardous situation which, if not avoided, could result in property damage.

NOTE

Type and source of damage!

Damage prevention

SIGNAL WORD

Type and source of risk!

Consequences arising from non-observance

Risk prevention

1 Introduction F2 DO 16 01

Page 8 of 40 HI 800 159 E Rev. 2.00

1.3.2 Operating Tips

Additional information is structured as presented in the following example:

iThe text corresponding to the additional information is located here.

Useful tips and tricks appear as follows:

TIP The tip text is located here.

F2 DO 16 01 2 Safety

HI 800 159 E Rev. 2.00 Page 9 of 40

2 Safety

All safety information, notes and instructions specified in this document must be strictly

observed. The product may only be used if all guidelines and safety instructions are adhered to.

This product is operated with SELV or PELV. No imminent risk results from the product itself.

The use in Ex-zone is permitted if additional measures are taken.

2.1 Intended Use

HIMatrix components are designed for assembling safety-related controller systems.

When using the components in the HIMatrix system, comply with the following general

requirements.

2.1.1 Environmental Requirements

Requirement type Range of values 1)

Protection class Protection class III in accordance with IEC/EN 61131-2

Ambient temperature 0...+60 °C

Storage temperature -40...+85 °C

Pollution Pollution degree II in accordance with IEC/EN 61131-2

Altitude < 2000 m

Housing Standard: IP20

Supply voltage 24 VDC

1) The values specified in the technical data apply and are decisive for devices with extended

environmental requirements.

Table 3: Environmental Requirements

Exposing the HIMatrix system to environmental conditions other than those specified in this

manual can cause the HIMatrix system to malfunction.

2.1.2 ESD Protective Measures

Only personnel with knowledge of ESD protective measures may modify or extend the system

or replace devices.

NOTE

Device damage due to electrostatic discharge!

When performing the work, make sure that the workspace is free of static, and wear

an ESD wrist strap.

If not used, ensure that the device is protected from electrostatic discharge, e.g., by

storing it in its packaging.

2 Safety F2 DO 16 01

Page 10 of 40 HI 800 159 E Rev. 2.00

2.2 Residual Risk

No imminent risk results from a HIMatrix system itself.

Residual risk may result from:

Faults related to engineering

Faults related to the user program

Faults related to the wiring

2.3 Safety Precautions

Observe all local safety requirements and use the protective equipment required on site.

2.4 Emergency Information

A HIMatrix system is a part of the safety equipment of a site. If a device or a module fails, the

system enters the safe state.

In case of emergency, no action that may prevent the HIMatrix systems from operating safely is

permitted.

Andere Handbücher für HIMatrix F2 DO 16 01

Inhaltsverzeichnis

Andere HIMA Controller Handbücher

HIMA

HIMA HIMatrix CIO 2/4 01 Bedienungsanleitung

HIMA

HIMA HIMatrix F30 03 Bedienungsanleitung

HIMA

HIMA HIMatrix F2 DO 8 01 Bedienungsanleitung

HIMA

HIMA HIMatrix F1 DI 16 01 Bedienungsanleitung

HIMA

HIMA HIMatrix MI 24 01 Bedienungsanleitung

HIMA

HIMA HIMatrix CIO 2/4 01 Bedienungsanleitung

HIMA

HIMA HIMatrix Bedienungsanleitung

HIMA

HIMA HIMatrix Series Benutzerhandbuch

HIMA

HIMA HIMatrix Bedienungsanleitung

HIMA

HIMA HIMatrix F2 DO 4 01 Bedienungsanleitung

HIMA

HIMA HIMatrix F35 Benutzerhandbuch

HIMA

HIMA HIMatrix Bedienungsanleitung

HIMA

HIMA HIMatrix F2 DO 16 01 Bedienungsanleitung

HIMA

HIMA HIMatrix DI 24 01 Bedienungsanleitung

HIMA

HIMA HIMatrix F2 DO 8 01 Bedienungsanleitung

HIMA

HIMA HIMatrix F10 PCI 03 Bedienungsanleitung

HIMA

HIMA HIMatrix DO 8 01 Bedienungsanleitung

HIMA

HIMA HIMatrix F30 011 Bedienungsanleitung

HIMA

HIMA HIMatrix F3 AIO 8/4 01 Bedienungsanleitung

HIMA

HIMA HIMatrix F20 Bedienungsanleitung

HIMA

HIMA HIMatrix F3 DIO 20/8 02 Bedienungsanleitung

HIMA

HIMA HIMatrix F3 DIO 8/8 01 Bedienungsanleitung

HIMA

HIMA HIMatrix F60 CPU 01 Bedienungsanleitung

HIMA

HIMA HIMatrix M45 Bedienungsanleitung

Beliebte Controller Handbücher anderer Marken

Digiplex

Digiplex DGP-848 Betriebsanleitung

YASKAWA

YASKAWA SGM series Bedienungsanleitung

Sinope

Sinope Calypso RM3500ZB Bedienungsanleitung

Isimet

Isimet DLA Series Style 2 Installationshandbuch

LSIS

LSIS sv-ip5a Bedienungsanleitung

Rockwell Automation

Rockwell Automation 1769-L31 Bedienungsanleitung

Airflow

Airflow Uno hab Bedienungsanleitung

ABB

ABB ACS580-01 drives Bedienungsanleitung

Panasonic

Panasonic GM1 Series Bedienungsanleitung

Emerson

Emerson SW93 Bedienungsanleitung

AutoAqua

AutoAqua Smart ATO micro SATO-120P Bedienungsanleitung

Panasonic

Panasonic FP? Positioning Unit RTEX Bedienungsanleitung

Samson

Samson Type 5824 Service-Handbuch

Alpha IP

Alpha IP MIOB 21001 Bedienungsanleitung

Siemens

Siemens OpenAir GMA 1 Series Bedienungsanleitung

Surecom

Surecom SR-629 Bedienungsanleitung

Fishman

Fishman TriplePlay Bedienungsanleitung

Regulus

Regulus SRS1 T Bedienungsanleitung
