Hisense HRBM417S Montageanleitung

HRBM417S

HRBM417C

Contents

Safety and warning information……....2

Installing your new appliance…………7

Description of the appliance……………12

Display controls…………………………13

Using your appliance…………………… 16

leaning and care………………………17

Helpful hints and tips……………………19

Troubleshooting………………………….21

Disposal of the appliance………………22

Safety and warning information

For your safety and correct usage, before installing and first using the

appliance, read this user manual carefully, including its hints and warnings. To

avoid unnecessary mistakes and accidents, it is important to make sure that all

people using the appliance are thoroughly familiar with its operation and safety

features. Save these instructions and be sure that they remain with the

appliance if it is moved or sold, so that anyone using it throughout its life, will

●

be properly informed on its usage and safety notices.

For the safety of life and property, keep the precautions of these user's

instructions as the manufacturer is not responsible for damages caused by

omission.

Safety for children and others who are vulnerable people

●

According to EN standard

This appliance can be used by children aged from 8 years and above and

persons with reduced physical, sensory or mental capabilities or lack of

experience and knowledge if they have been given supervision or instruction

concerning use of the appliance in a safe way and understand the hazards

involved. hildren shall not play with the appliance. leaning and user

maintenance shall not be made by children without supervision.

●

According to IE standard

This appliance is not intended for use by persons (including children) with

reduced physical, sensory or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision or instruction concerning

use of the appliance by a person being responsible for their safety.

 Keep all packaging away from children as there is risk of suffocation.

 If you are discarding the appliance, pull the plug out of the socket, cut the

connection cable (as close to the appliance as you can) and remove the

door to prevent children playing from suffering an electric shock or from

closing themselves inside it.

 If this appliance, featuring a magnetic door seals, is to replace an older

appliance having a spring lock (latch) on the door or lid, be sure to make

the spring lock unusable before you discard the old appliance. This will

prevent it from becoming a death trap for a child.

General safety

 WARNING —This appliance is intended to be used in household

and similar applications such as

-staff kitchen areas in shops, offices and other working environments;

-farm houses and hotels, motels and other residential type environments;

-bed and breakfast type environments;

-catering and similar non-retail applications.

 WARNING — Do not store explosive substances such as aerosol cans

with a flammable propellant in this appliance.

 WARNING — If the supply cord is damaged, it must be replaced by the

manufacturer, its service agent or similarly qualified persons in order to

avoid a hazard.

●

 WARNING — Keep ventilation openings, in the appliance enclosure or in

the built-in structure, clear of obstruction.

 WARNING — Do not use mechanical devices or other means to

accelerate the defrosting process, other than those recommended by the

manufacturer.

 WARNING — Do not damage the refrigerant circuit.

 WARNING — Do not use electrical appliances inside the food storage

compartments of the appliance, unless they are of the type recommended

by the manufacturer.

 WARNING — The refrigerant and insulation blowing gas are flammable.

When disposing of the appliance, do so only at an authorized waste

disposal centre. Do not expose to flame.

 WARNING — When positioning the appliance, ensure the supply cord is

not trapped or damaged.

 WARNING — Do not locate multiple portable socket-outlets or portable

power supplies at the rear of the appliance.

●

Replacing the illuminating lamps

 WARNING— The illuminating lamps must not be replaced by the user! If

the illuminating lamps is damaged, contact the customer helpline for

assistance. This warning is only for refrigerators that contain illuminating

lamps.

Refrigerant

The refrigerant isobutene (R600a) is contained within the refrigerant circuit of

the appliance, a natural gas with a high level of environmental compatibility,

which is nevertheless flammable. During transportation and installation of the

appliance, ensure that none of the components of the refrigerant circuit

becomes damaged.

The refrigerant (R600a) is flammable.

WARNING — Refrigerators contain refrigerant and gases in the insulation.

Refrigerant and gases must be disposed of professionally as they may cause

eye injuries or ignition. Ensure that tubing of the refrigerant circuit is not

damage prior to proper disposal.

It is hazardous for anyone other than an Authorized Service Person to service

this appliance. In Queensland the Authorized Service Person Must hold a Gas

Work Authorized for hydrocarbon refrigerants to carry out servicing or repairs

which involve removal of covers.

WARNING: Ris of fire / flammable materials

The symbol is a warning and indicates the refrigerant and insulation blowing

gas are flammable.

If the refrigerant circuit should be damaged:

●

Avoid opening flames and sources of ignition.

-Thoroughly ventilate the room in which the appliance is situated.

It is dangerous to alter the specifications or modify this product in any way.

Any damage to the cord may cause a short circuit, fire, and/or electric shock.

Electrical safety

1.The power cord must not be lengthened.

2. Make sure that the power plug is not crushed or damaged. A crushed or

damaged power plug may overheat and cause a fire.

3. Make sure that you can access the main plug of the appliance.

4. Do not pull the main cable.

5. If the power plug socket is loose, do not insert the power plug. There is a risk

of electric shock or fire.

6.You must not operate the appliance without the interior lighting lamp cover.

7.The fridge is only applied with power supply of single phase alternating

current of 220~240V/50Hz. If fluctuation of voltage in the district of user is so

large that the voltage exceeds the above scope, for safety sake, be sure to

apply A. . automatic voltage regulator of more than 350W to the fridge. The

fridge must employ a special power socket instead of common one with other

electric appliances. Its plug must match the socket with ground wire.

Daily use

 Do not store flammable gases or liquids in the appliance, There is a risk of

an explosion.

●

 Do not operate any electrical appliances in the appliance (e.g. electric ice

cream makers, mixers etc.).

 When unplugging always pull the plug from the mains socket, do not pull

on the cable.

 Do not place hot items near the plastic components of this appliance.

 Do not place food products directly against the air outlet on the rear wall.

 Store pre-packed frozen food in accordance with the frozen food

manufacture’s instructions.

 The appliances manufactures storage recommendations should be strictly

adhered to relevant instructions for storage.

 Do not place carbonated or fizzy drinks in the freezer compartment as it

creates pressure on the container, which may cause it to explode, resulting

in damage to the appliance.

 Frozen food can cause frost burns if consumed straight from the freezer

compartment.

 Do not place the appliance in direct sunlight.

 Keep burning candles, lamps and other items with naked flames away

from the appliance so that do not set the appliance on fire.

 The appliance is intended for keeping food stuff and/or beverages in

normal household as explained in this

●

instruction booklet . You should take

care when move it as the appliance is heavy.

 Do not remove nor touch items from the freezer compartment if your hands

are damp/wet, as this could cause skin abrasions or frost/freezer burns.

 Never use the base, drawers, doors etc. to stand on or as supports.

 Frozen food must not be refrozen once it has been thawed out.

 Do not consume ice popsicles or ice cubes straight from the freezer as this

can cause freezer burn to the mouth and lips.

 To avoid items falling and causing injury or damage to the appliance, do

not overload the door racks or put too much food in the crisper drawers.

Caution!

Care and cleaning

 Before maintenance, switch off the appliance and disconnect the mains

plug from the mains socket.

 Do not clean the appliance with metal objects, steam cleaner, ethereal oils,

organic solvents or abrasive cleansers.

 Do use a plastic scraper instead of a sharp objects to remove frost from

the appliance.

Installation Important!

 For electrical connection carefully, follow the instructions given in this

manual. Unpack the appliance and check if there are damages on it.

 Do not connect the appliance if it is damaged. Report possible damages

immediately to the place you bought it. In

●

this case retain packing.

 It is advisable to wait at least four hours before connecting the appliance to

allow the oil to flow back in the compressor.

 Adequate air circulation should be around the appliance, lacking this leads

to overheating. To achieve sufficient ventilation, follow the instructions

relevant to installation.

 Wherever possible, the back of the product should not be too close to a

wall to avoid touching or catching warm parts (compressor, condenser) to

prevent the risk of a fire, follow the instructions relevant to installation.

 The appliance must not be located close to radiators or cookers.

 Make sure that the mains plug is accessible after the installation of the

appliance.

Service

 Any electrical work required to do the servicing of the appliance should be

carried out by qualified electrician or competent person.

 This product must be serviced by an authorized Service

enter, and

●

only genuine spare parts must be used.

1) If the appliance is Frost Free.

●

2) If the appliance contains freezer compartment.

Note:

hildren aged from 3 to 8 years are allowed to load and unload

refrigerating appliances. (This clause applies only to the EU region.)

Installing your new appliance

Before using the appliance for the first

time, you should be informed of the

following tips.

Warning!

For proper installation, this refrigerator

must be placed on a level surface of hard

material that is the same height as the rest

of the flooring. This surface should be

strong enough to support a fully loaded

refrigerator.

●

The rollers, which

●

are not castors, should

be only used for forward or backward

movement. Moving the refrigerator

sideways may damage your floor and the

rollers.

Ventilation of appliance

In order to improve efficiency of

the cooling system and save

energy, it is necessary to maintain good

ventilation around the appliance for the

dissipation of heat. For this reason,

sufficient clear space should be available

around the refrigerator.

Suggest: It is advisable for there to be at

least 50mm of space from the back of

appliance to the wall, at least 100mm from

its top, at least 50mm from its side to the

wall and a clear space in front to allow the

doors to open 130°. As shown in follow

diagrams.

Note:

This appliance performs well within the

climate class from SN to T showed in the

table below. It may not work properly if being

left at a temperature above or below the

indicated range for a long period.

Climate class

Ambient temperature

SN +10°C to +32°C

N +16°C to +32°C

ST +16°C to +38°C

T +16°C to +43°C

Stand your appliance in a dry place to

avoid high moisture.

Keep the appliance out of direct sunlight,

rain or frost. Stand the appliance away from

heat sources such as stoves, fires or

heaters.

Leveling of appliance

For sufficient leveling and air circulating in

the lower rear section of the appliance, the

bottom feet may need to be adjusted. You

can adjust them manually by hand or by

using a suitable spanner.

To allow the doors to self-close, tilt the top

backwards by 10-15mm.

Reversing the door

●

The side at which the door opens can be

changed, from the right side (as supplied) to

the left side if required.

Warning! When reversing the door, the

appliance must not be connected to the

Power, Ensure that the plug is removed from

the power socket.

Not provided

Wrench(8mm) Philips Screwdriver

Thin-blade

screwdriver Monkey wrench

Additional parts (in the plastic bag)

Allen Wrench(4mm)

Upper Hinge-Left Upper Hinge

over-left

●

crew Hole

over-right Middle Hinge-left

Stop Block-left *2 Door Stopper-left *2

Note: If required, you may lay the

refrigerator on its back in order to gain

access to the base, you should rest it on soft

foam packaging or similar material to avoid

damaging the backboard of the refrigerator.

To reverse the door, the following steps

generally recommended.

1. Stand the refrigerator upright. Open the

door to take out all door racks (to avoid

damage) and then close the door.

●

Caution!

Please slightly squeeze the door rack from

two sides toward center and inside of door

rack, and then move it upward when taking

out the upper rack and lower rack.

2. Remove upper hinge cover-right ①from

the right-top corner of cabinet. Remove the

temperature sensor from the cabinet and

right upper hinge cover, Install it on the

upper hinge cover-left (provided in the

plastic accessory bag). Unscrew the 3

screws ② which are used for fixing the

upper hinge-right (see the picture below)

and take down the upper hinge-right ③.

3. Remove the upper door from the middle

hinge by carefully lifting the door straight

up. Then place the upper door on a

smooth surface with its panel upwards.

4. Unscrew screw ③ and take down part

② and part ①, Install replacement door

stopper-left ④ and stop block-left ⑤

(provided in the plastic accessory bag) to

the left side with screw ③. Keep part ①

and part ② with the appliance for future

reference.

5. Use the Allen wrench (provided in the

plastic accessory bag) to unscrew the

screws used to fix the middle hinge-right

and remove middle hinge

●

-right. Then

remove the lower door.

●

. Place the lower door on a smooth

surface with its panel upwards. Unscrew

screw ③ and take down part ② and part

① , Install replacement door stopper-left

④ and stop block-left ⑤ (provided in the

plastic accessory bag) to the left side with

screw ③. Keep part ① and part ② with

the appliance for future reference.

7. Install screw hole cover-right ①

(provided in the plastic accessory bag) to

the right-top corner of cabinet. Remove

screw hole cover-left ② from the left-top

corner of cabinet with thin-blade

screwdriver and Put the screw hole

cover-left and upper hinge -right into the

plastic accessory bag for future reference.

8. hange screw hole covers and screw

on middle cover plate from left to right (as

shown in figure below).

9.Lie the refrigerator backwards, Remove

part ④ (right), Remove 3 self-tapping

screws from the lower hinge -right.

Unscrew the lower hinge-right axis then

Andere Handbücher für HRBM417S

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Hisense Kühlschrank Handbücher

Hisense

Hisense RL423N4CW2 Montageanleitung

Hisense

Hisense RS694N4BCE Montageanleitung

Hisense

Hisense HRCD610TS Montageanleitung

Hisense

Hisense PureFlat RF22B3FSE Bedienungsanleitung

Hisense

Hisense RD-39DR4SAA/CPA1 Bedienungsanleitung

Hisense

Hisense HR6TFF222 Bedienungsanleitung

Hisense

Hisense RS694N4TF2 Bedienungsanleitung

Hisense

Hisense RF540N4WFE Montageanleitung

Hisense

Hisense RB645N4BFE Montageanleitung

Hisense

Hisense RD-43WC4SBA/CSA2 Montageanleitung

Hisense

Hisense RB338N4EW1 Montageanleitung

Hisense

Hisense FV 191 N4AW2 Montageanleitung

Hisense

Hisense RL481N4BIE Montageanleitung

Hisense

Hisense RS-22DC4SJB/CPA2 Montageanleitung

Hisense

Hisense H780SB-IDL Montageanleitung

Hisense

Hisense LCT33D6ABE Bedienungsanleitung

Hisense

Hisense RB418D4AD2 Technisches Handbuch

Hisense

Hisense HRF266N6CSE Bedienungsanleitung

Hisense

Hisense RS-17DR1SS Montageanleitung

Hisense

Hisense BCD-543WPAZR/HC1(E) Bedienungsanleitung

Hisense

Hisense FSN535A20D Montageanleitung

Hisense

Hisense FV341N4EC1 Montageanleitung

Hisense

Hisense RF27A3FSE Montageanleitung

Hisense

Hisense RR154D4AW2 Montageanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
