Homeflow Smart Robot Vacuum Bedienungsanleitung
Robot vacuum cleaner
User manual
Smart Living
Smart Living
The Homeflow Smart Robot Vacuum should only be used for
domestic cleaning, as described in this User Manual. Please
ensure that this User Manual is fully understood before
operating the appliance. Please keep this User Manual for
reference. Use only consumables or spares recommended or
supplied by Homeflow.
Smart Living
Safety instructions
Product parts
Host
Charging dock
Remote control
Product specification
Accessories list
Product operation
Important matters
Charging mode
Installing the side brush
Remote control operation
Start cleaning
Downloading the Homeflow App
Water tank operation
Maintain
Dust box and HEPA filter cleaning
Water tank component cleaning
Other component cleaning
Troubleshooting
Contents Pages
1
3
3
5
5
6
7
21
19
20
21
8
9
10
11
12
13
18
Safety instructions
Important Safety Reminders Important Notes Before Use
WARNING:
Electricity can be extremely dangerous. This appliance is powered by
rechargeable Ni-MH batteries and is provided with a Charger Base Station.
Please ensure the voltage marked on the mains power adapter is suitable
for connection to standard mains power outlet voltage.
REMINDERS:
ŸAlways store the appliance indoors. Do not use outdoors or expose the
appliance to the elements, humidity or heating sources (oven, fireplace,
wet floor).
ŸDo not expose the vacuum or accessories to excessive heat / cold (keep
between 0 - 30°C).
ŸDo not drop the vacuum or use any accessory if it has been dropped,
damaged, left outdoors or dropped in water.
ŸNever unplug or pull the mains power adaptor by the power cord.
ŸNever pick up matches, hot ash, cigarette ends, or sharp objects.
ŸDo not spray with, or pick up flammable liquids, cleaning fluids, aerosols, or
their vapours, as this may cause risk of fire/explosion.
ŸDo not continue to use your vacuum if it appears to be faulty. If the mains
power adaptor power cord is damaged, stop using it IMMEDIATELY. Only
an authorised Homeflow Service engineer must replace the Power Cord.
ŸThe vacuum is for use on wooden flooring, rubber, ceramic tile, linoleum
and short pile carpet.
ŸDo not use to clean stairs.
After Use:
Return the Homeflow Robot Vacuum to the Charger Base Station. Always
switch off and disconnect the mains power adaptor before cleaning or
attempting any maintenance task. If the vacuum will not be used for a long
time (several weeks), unplug the Charger Base Station according to the
instructions in this User Manual.
Safety with children, the elderly or infirm:
This cleaner is not a toy.
Do not let children play with the appliance or its controls. Please supervise
the use of the appliance by older children, the elderly or the infirm.
Please read the following information carefully before using your Homeflow
Smart Robot Vacuum or its accessories.
Do not disassemble the vacuum and do not attempt to repair it yourself. If
a fault occurs, please contact the Homeflow Geek Group for professional
advice.
Battery Use: Your Homeflow Robot Vacuum is powered by rechargeable,
high capacity NiMh batteries. These rechargeable batteries are
guaranteed for a period of 6 months if they are maintained and operated
according to this User Manual.
In the event of a significant drop of the vacuum performance, replacement
batteries can be obtained from a retailer.
Only use Homeflow approved replacement parts for your vacuum cleaner.
Use of parts that are not approved by Homeflow are dangerous and will
invalidate your warranty.
Only use the supplied Charger Base Station and mains power adaptor to
recharge your vacuum.
Use of the incorrect Charger Base Station or mains power adaptor is
dangerous and will invalidate your warranty.
Smart LivingSmart Living
1 2
2.1 Host 2.2 Host
Water Tank
Universal Wheel
Right Brush
Battery Cover
Dust Sensor
Right Drive Wheel
Speaker
Electrode Plate
Left Brush
Downward Sensor
Left Drive Wheel
Water Outlet
Primary Filter
Dust Box
Filter Wool
(HEPA) Filter
High Efficiency Filter Sealing Ring
Middle cover
Dust box/ water tank
Spring contacts
DC port
Power on/off
ComponentComponent Product Information Product Information
Pull-tab
Rag Stent
Water Seepage Rag
Soft Rubber Cover
Electric Pump
Water In
Touch Point
Water Outlet
Infra-red Front Bumper
On/Off
Middle Cover
Wi-Fi Indicator
1. On/Off
2. Wi-Fi indicator light (connect with the Homeflow App)
Cover
1
2
Smart LivingSmart Living
3 4
2.3 Charging Dock
2.4 Remote Control
1
2
4
5
3
1. Power Indicator
2. Adapter
3. Power Socket
4. Electrode Patches
5. Adapter Port
Back to Charging Dock
Wi-Fi Connect
Fixed Point Mode
On/Off
Along the Wall Cleaning Mode
Stand by
Random Mode
Direction
Mop Mode
Sweeping Mode
Suction Control
Classify
Structure
Electrics
Sweeping Specs.
Item Specification
320mm
78mm
2.8 kgs
14.8V
Li-ion battery 2600mAh
28W
600ml
350ml
Auto/Hand
Planning, designated
along wall, booking mop floor
About 280mins
About 100-120mins
Physical buttons
Diameter
Height
Net weight
Voltage
Battery
Power
Dust box volume
Water tank volume
Charging mode
Sweeping mode
Charging/time
Sweeping/time
Host key type
Model No.
Work voltage (V) 14.8
19
KM-151
100-240V 0.6A MAX 50/60Hz
Input (V)
Remote control model
Battery and specs
Adapter model
Input
Charging dock
Main part model no. and specs.
Li-ion battery 2600mAh
NLB060190W1C4S35
Power (W)
Output current (A)
Input (V)
Output
28
0.6
3
19V 0.6A
SpecificationsComponent Product Information Product Information
Smart LivingSmart Living
5 6
Item Description
1
2
3
4
5
6
7
8
9
10
11
Host (including battery)
Charging Dock
Remote Control + 7AAA Battery
Adapter
Cleaning Brush
User Manual
Side Brush
HEPA Filter
Water Seepage
Water Tank
Rag Stent
1
1
1
1
1
1
Left 1pc & Right 1pc
1
1
1
1
Quantity
Before using it, please refer to the following instructions:
OperationAccessories
Sundries such as power cords scattered on
the ground can trip or entangle products,
please keep them aside.
Roll up the side of the carpet fringe or use
the vacuum on undercoat carpet
If the gap between the floor and sofa is less
than 8cm then cover the area to prevent the
vacuum from getting stuck.
Double layer edges should be protected.
1
5
9
2
6
10
3
7
11
4
8
List
Product Information Product Information
Smart LivingSmart Living
7 8
3.1 Charger Base Station Setup
OperationOperation
A. Turn on the power switch on the side of the vacuum. Directly connect the mains power adaptor to
the vacuum.
3Manual Charging
*Warm prompt
A. Before using it for the first time, please charge for 12 hours. The key with orange light means
product is charging. When finished charging, the green light will turn on.
B.During daily use, please put the machine on charging dockand make sure the charging dock
is plugged in.
4Install side bush
Please install the side brush according to the L-R letter which are labelled on the brush.
Please make sure to install the brush well.
1Charging dock placement
Place the Charging Dock, on a non-reflective level floor, preferably against the wall.
There should be no objects around the area for 3m in front and 0.5m each side.
After charging dock is connected to adapter, the light on the top of charging dock turns on.
*Warm prompt
2Automatic Charging
*Warm prompt
Please clean the electrode on charging dock every other day to avoid any impact on charging.
A. Under sweeping model, when power is at 15%, the vacuum will stop cleaning and search for the charging
dock.
B. Under other modes, press automatic charging key and the vacuum will search for the charging dock.
C. Press start/stop button for 3 seconds for the vacuum to enter the automatic recharge mode.
Product Information Product Information
Smart LivingSmart Living
9 10
Operation Operation
3.2 Remote Control
Press on/off button on the vacuum or the remote to stop the vacuum.
3.4 Stop Cleaning
3.3 Start Cleaning
Press on/off button on the vacuum or the remote to start the vacuum.
Sweeping Mode
2
Back to charge
3
Off
4
1
Stand by
Press the key for the machine to enter sleep mode and please press key if wakeup
is required..
The machine may automatically enter sleep mode if it is idle for two minutes.
Press the key of vacuum to enter the sweeping mode, please press this key to
paush.
Press the key for the machine to enter charging mode.
Press the key for the machine to pause and press the same key for the machine to exit
sleep mode.
A “ ” Forward Press the key to drive the machine forward in selection mode
B“ ” Backward Press the key to drive the machine forward in selection mode
C “ ” Left Press the key to drive the machine left in selection mode
D “ ” Right Press the key to drive the machine right in selection mode
Mop mode
6
Random Pattern
7
Along the wall cleaning
8
Fixed Point Pattern
9
WiFi Connect
10
Press the key to start the mopping mode after you have correctly inserted the water tank.
Press the key for the machine to enter random cleaning mode, please press this key if
the machine requires to be paused.
Direction
5
Press the key to start the machine cleaning along the wall corner.
Press the Wi-Fi button for 5 seconds while pointing at the device to reset it.
Press the key to start the machine's spiral point cleaning. *Please take off battery and keep it well if long time do not use the machine. If the battery leaks,
please take off the battery and clean the battery case.
*When battery is over-discharged or long time unused, the capacity will be lower suggest to active
the battery.
*The battery is with long life, no need to change frequently. If you need tochange, please contact
our after-sales center.
* Warm prompt
11 Suction control
Press the key in work mode to switch between "quiet / strong" suction.
Place the Charging Dock, on a non-reflective level floor, preferably against the wall.
There should be no objects around the area for 3m in front and 0.5m each side.
Product Information Product Information
Smart LivingSmart Living
11 12
OperationProduct Operation
3.5 Preset
For the convenience of cleaning, the product is equipped with the function of “scheduled cleaning”. You
should set the scheduled cleaning time through the Homeflow app connected to machine. After the preset is
complete, the machine shall perform cleaning at the set time every day. (Please refer to “APP Operation
Guide” for the specific method of connecting the machine to the mobile APP.)
Before setting the time, make sure the green light of the key on the machine
is always on and machine is in the startup state. If the machine is not started,
press the key on machine or the key on remote control to start it.
Select Preset Time Edit Scheduled
Cleaning Time
When to Cancel the scheduled
setting delete the preset
time in”scheduled” item.
1. Log in the Homeflow App.
2. In Operation interface of App, click “my” - “Family
Management” - “Family Name” - “Remove Family” - “Confirm
to Leave”.
3. After the device is disconnected, if you need to connect it
again, Please refer to “App Operation guide” for re-connct.
Disconnect with mobile phone
3.6 Disconnect the Machine
(Some products do not have this function)
3.6 App download and instructions
This product support remote control by mobile App.
Use your phone to download the Homeflow app on Apple App
Store or Google Play .
*Please refer to the APP operation guide for more function.
3.7 Choose model
The Product has serv modes of cleaning for different types of floor. you
can choose through the remote control or app.
¬Thought remote control or APP to switch between any model.
¬Make sure green light is on host is wake up. If host is not wake up, please
press or remote
1Sweeping mode
Please the key above for the vacuum to
enter the sweeping mode. If there is an
obstacle the vacuum will change direction.
(press or remote key, machine will
stop to work.)
Product Information Product Information
Smart LivingSmart Living
13 14
Operation Operation
*Please Key, Machine will sweep automatically.
*The host might stop for a while during cleaning to check for any missed areas or for path
planning. in this case, please wait with patience.
Mop the floor mode
2
Install the cloth at the bottom of the machine,
replace the dust box with water tank and enter
the mopping mode via app or remote control.
Press or key, host stops to work) suggest
first to clean dust then mop the floor.
*Please do not use this function on carpet.
3Fixed point sweep mode
Suitable for areas where dust has been
concentrated. Machine will clean in a spiral
mode and will proceed with normal cleaning
after the concentration cleaning has been
completed.
Sweep along the wall mode
4
This mode is for cleaning the interior corners.
Machine will sweep along object, (like wall). After
finishing sweep, host back to charge dock.
Recharging mode
5
Press on remote control or press key on
remote control for 3-5 mons for machine ti go back
to charging dock automatically. During sweeping,
machine will know when the power is low, and enter
‘recharge change’ mode aautomatically.
Suction control mode
6
This machine is with suction adjusting function.
During work, press switch to “quiet/strong”
mode.
Product Information Product Information
Smart LivingSmart Living
15 16
Inhaltsverzeichnis
Beliebte Staubsauger Handbücher anderer Marken
Bissell
Bissell LittleGreen Proheat 1425 Series Bedienungsanleitung
Panasonic
Panasonic MC-YL637S147-AE Bedienungsanleitung
NEFF
NEFF N17XH10 0 Series Bedienungsanleitung
LG
LG A9 Series Bedienungsanleitung
Oreck
Oreck Cordless Captura BK51700 Series Bedienungsanleitung
Kogan
Kogan KAVACROBVWA Bedienungsanleitung
