OWNER'S

MANUAL

How to operate your new Programmable Thermostat

Congratulations! You made a smart choice when you purchased your new programmable thermostat.

It’s the smart thermostat that:

■

Keeps you comfortable

by automatically calculating exactly when the furnace or air conditioning

should go on to have the house at the desired comfort temperature at the time you want.

■

Saves the maximum amount of energy and money

by remembering to automatically set back the

heat or air conditioning when you leave home or sleep.

■

Provides the ultimate in comfort and convenience

. It comes already programmed, so it’s your

choice—use the pre-programmed schedule or set your own.

TABLE OF CONTENTS

Programmed Recovery......................................... 1-4

Recovery Setting................................................... 5-6

Programming Your Thermostat ......................... 7-22

Set the current day and time ..................................7

Set the program schedule and

heating temperatures........................................8

Set the cooling temperatures,

if you have air conditioning ..............................15

Set the system and fan switches,

if your thermostat has them .............................21

Operating Your Thermostat ............................. 23-29

Temporarily changing the program ......................23

Permanently changing the program .....................25

Operating the thermostat manually ......................26

Canceling program settings..................................27

Checking the program times

and temperatures ............................................28

Checking the current

temperature setting..........................................29

Maintaining Your Thermostat .......................... 31-34

Removing the thermostat .....................................31

Replacing the thermostat .....................................32

Replacing the batteries.........................................33

Power outages .....................................................34

Glossary............................................................. 35-37

Your Personal Program .................................... 39-40

Troubleshooting Guide..................................... 41-42

Typical Questions ............................................. 43-46

Typical Energy Savings..........................................47

Quick Reference to the Keys ........................... 49-50

Index................................................................... 51-52

PROGRAMMED RECOVERY

M168

PROGRAMMED RECOVERY—

BREAKTHROUGH TECHNOLOGY

SENSES TEMPERATURE

MORE LIKE YOU DO

Your new thermostat is so smart,

it’s almost human. ■

Your body perceives temperature

from a variety of sources, not only

from the air in the room, but also from your surroundings—walls,

windows and furnishings.

■

Human beings feel differences

in temperature as slight as one

degree Celsius.

■

Common household thermometers and standard thermostats

sense

only air temperature, which may or may not reflect how hot or cold

the room actually

feels

to a human being.

■

Your new thermostat

reads the temperature of the wall as well as the

air—and responds to temperature changes as little as one-half

degree Celsius—so room temperature is more likely to “feel right”to

you and your family.

PROGRAMMED RECOVERY

■

This thermostat is actually a small but powerful computer

. When

calculating the exact time to turn on your furnace or air conditioner,

it considers (1) air temperature, (2) the temperature of the wall and

(3) when you want the comfort temperature established.

SUN MON TUE WED THU FRI SAT COOL ON HEAT ON

WAKE LEAVE RETURN SLEEP TEMPORARY UNOCCUIPIED

REPL

BAT

SET

System Operating

in Energy Saving Mode

Recovery Begins Recovery Continues

System Operating

in Comfort Mode

ENERGY

SAVINGS

PERIOD RECOVERY FROM ENERGY SAVINGS COMFORT

PERIOD

TIME

TEMPERATURE

THE THERMOSTAT USES THE SAME SCHEME TO RETURN GRADUALLY

TO LOWER COMFORT TEMPERATURE DURING THE COOLING SEASON.

M467A

SUN MON TUE WED THU FRI SAT COOL ON HEAT ON

WAKE LEAVE RETURN SLEEP TEMPORARY UNOCCUIPIED

REPL

BAT

SET

SUN MON TUE WED THU FRI SAT COOL ON HEAT ON

WAKE LEAVE RETURN SLEEP TEMPORARY UNOCCUIPIED

REPL

BAT

SET

SUN MON TUE WED THU FRI SAT COOL ON HEAT ON

WAKE LEAVE RETURN SLEEP TEMPORARY UNOCCUIPIED

REPL

BAT

SET

THE OPTIMUM COMFORT AND

ENERGY SAVINGS SOLUTION

■

During Programmed Recovery the thermostat increases the control

temperature gradually and turns the equipment on and off

several

times to save energy by avoiding “overshooting”the comfort

temperature. You can see the current control temperature anytime

during recovery by pressing the PRESENT SETTING key. On some

models, both the SYSTEM and ENRG SAV lights may be lit at the

same time during recovery.

■

This “smart”control learns from experience

. Each day it checks how

closely it “hit the target”and adjusts the recovery start time accord-

ingly.

It typically takes four to eight days after installation for this

thermostat to adjust to the weather, your life style, home

construction and heating/cooling system. The thermostat calculates

the LEAVE/RETURN recovery separately from the SLEEP/WAKE

recovery.

■

With this thermostat you can choose

whether you want to use

Programmed Recovery or conventional recovery. Use Programmed

Recovery if you want to choose the exact time that the room

reaches your

comfort

temperature. Use conventional recovery if you

prefer to choose the exact time your furnace or air conditioner

comes on

to start recovery.

RECOVERY SETTING

Your thermostat includes a screw on the back marked “3A”, allowing

for the Programmed Recovery/conventional recovery choice.

Your thermostat was shipped from the factory with the screw posi-

tioned for Programmed Recovery. Your installer may have left the

screw in this position, or may have changed it to conventional

recovery. Before programming, you must know for which recovery

method your thermostat has been set.

•With Programmed Recovery, the dwelling will reach the comfort

temperature at the exact time you have programmed into the

thermostat. See pages 1-4 for detailed explanation of Programmed

Recovery.

•With conventional recovery, the programmed time will mark the start

of recovery; therefore, you should program the start time to be

earlier than the desired comfort time. It may require some trial and

error to arrive at the best starting time, and the best starting time will

vary as the seasons change.

RECOVERY

SELECTION

ADAPTIVE

INTELLIGENT

CONVENTIONAL

(FACTORY SETTING)

OUT 1/2 TO 1 TURN

M2120C

To determine which type of recovery is set into your thermostat, make

sure thermostat is powered with fresh batteries, or is mounted and

powered on the wall (see page 32).

Press key. Check thermostat display.

•If the ■shows in the lower right-hand corner (see illustration), the

thermostat is set for conventional recovery. If you would rather have

Programmed Recovery, remove thermostat from wallplate, turn

screw 3A (on back of thermostat) clockwise until it bottoms. DO

NOT OVERTIGHTEN.

•If the ■does not show, the thermostat is set for Programmed

Recovery. If you would rather have conventional recovery, remove

thermostat from wallplate, turn screw 3A (on back of thermostat)

out 1/2 to 1 turn.

RUN

PROGRAM

RECOVERY SETTING

MON

WAKE

INDICATES

THERMOSTAT IS SET

FOR CONVENTIONAL

RECOVERY
