HP Desktop Computer Bedienungsanleitung

Setup Utility

User Guide

Development Company, L.P.

Windows is a U.S. registered trademark of

Microsoft Corporation.

The information contained herein is subject

to change without notice. The only

warranties for HP products and services are

set forth in the express warranty statements

accompanying such products and services.

Nothing herein should be construed as

constituting an additional warranty. HP shall

not be liable for technical or editorial errors

or omissions contained herein.

First Edition: June 2008

Document Part Number: 483457-001

Table of contents

1 Starting the Setup Utility

2 Using the Setup Utility

Changing the language of the Setup Utility .......................................................................................... 2

Navigating and selecting in the Setup Utility ........................................................................................ 2

Displaying system information .............................................................................................................. 3

Restoring default settings in the Setup Utility ....................................................................................... 3

Exiting the Setup Utility ........................................................................................................................ 4

3 Setup Utility menus

Main menu ............................................................................................................................................ 5

Security menu ...................................................................................................................................... 5

System Configuration menu ................................................................................................................. 6

Diagnostics menu ................................................................................................................................. 6

Index ..................................................................................................................................................................... 7

iii

1 Starting the Setup Utility

The Setup Utility is a ROM-based information and customization utility that can be used even when your

Windows® operating system is not working.

NOTE: The fingerprint reader (select models only) cannot be used to access the Setup Utility.

The utility reports information about the computer and provides settings for startup, security, and other

preferences.

To start the Setup Utility:

▲Open the Setup Utility by turning on or restarting the computer. While the “Press the ESC key for

Startup Menu” message is displayed in the lower-left corner of the screen, press f10.

– or –

1. Open the Setup Utility by turning on or restarting the computer. While the “Press the ESC key for

Startup Menu” message is displayed in the lower-left corner of the screen, press esc.

2. When the Startup Menu is displayed, press f10.

2 Using the Setup Utility

Changing the language of the Setup Utility

The following procedure explains how to change the language of the Setup Utility. If the Setup Utility is

not already running, begin at step 1. If the Setup Utility is already running, begin at step 2.

1. Open the Setup Utility by turning on or restarting the computer. While the “Press the ESC key for

Startup Menu” message is displayed in the lower-left corner of the screen, press f10.

– or –

Open the Setup Utility by turning on or restarting the computer. While the “Press the ESC key for

Startup Menu” message is displayed in the lower-left corner of the screen, press esc. When the

Startup Menu is displayed, press f10.

2. Use the arrow keys to select System Configuration >Language, and then press enter.

3. Use the arrow keys to select a language, and then press enter.

4. When a confirmation prompt with your language selected is displayed, press enter.

5. To save your change and exit the Setup Utility, use the arrow keys to select Exit >Exit Saving

Changes, and then press enter.

Your change goes into effect immediately.

Navigating and selecting in the Setup Utility

Because the Setup Utility is not Windows based, it does not support the TouchPad. Navigation and

selection are by keystroke.

●To choose a menu or a menu item, use the arrow keys.

●To choose an item in a list or to toggle a field, for example an Enable/Disable field, use either the

arrow keys or f5 or f6.

●To select an item, press enter.

●To close a text box or return to the menu display, press esc.

●To display additional navigation and selection information while the Setup Utility is open, press

f1.

2 Chapter 2 Using the Setup Utility

Displaying system information

The following procedure explains how to display system information in the Setup Utility. If the Setup

Utility is not open, begin at step 1. If the Setup Utility is open, begin at step 2.

1. Open the Setup Utility by turning on or restarting the computer. While the “Press the ESC key for

Startup Menu” message is displayed in the lower-left corner of the screen, press f10.

– or –

Open the Setup Utility by turning on or restarting the computer. While the “Press the ESC key for

Startup Menu” message is displayed in the lower-left corner of the screen, press esc. When the

Startup Menu is displayed, press f10.

2. Select the Main menu. System information such as the system time and date, and identification

information about the computer is displayed.

3. To exit the Setup Utility without changing any settings, use the arrow keys to select Exit >Exit

Discarding Changes, and then press enter.

Restoring default settings in the Setup Utility

The following procedure explains how to restore the Setup Utility default settings. If the Setup Utility is

not already running, begin at step 1. If the Setup Utility is already running, begin at step 2.

1. Open the Setup Utility by turning on or restarting the computer. While the “Press the ESC key for

Startup Menu” message is displayed in the lower-left corner of the screen, press f10.

– or –

Open the Setup Utility by turning on or restarting the computer. While the “Press the ESC key for

Startup Menu” message is displayed in the lower-left corner of the screen, press esc. When the

Startup Menu is displayed, press f10.

2. Use the arrow keys to select Exit >Load Setup Defaults, and then press enter.

3. When the Setup Confirmation is displayed, press enter.

4. To save your change and exit the Setup Utility, use the arrow keys to select Exit >Exit Saving

Changes, and then press enter.

The Setup Utility default settings go into effect when the computer restarts.

NOTE: Your password, security, and language settings are not changed when you restore the factory

default settings.

Displaying system information 3

Exiting the Setup Utility

You can exit the Setup Utility with or without saving changes.

●To exit the Setup Utility and save your changes from the current session:

If the Setup Utility menus are not visible, press esc to return to the menu display. Then use the

arrow keys to select Exit >Exit Saving Changes, and then press enter.

●To exit the Setup Utility without saving your changes from the current session:

If the Setup Utility menus are not visible, press esc to return to the menu display. Then use the

arrow keys to select Exit >Exit Discarding Changes, and then press enter.

After either choice, the computer restarts in Windows.

4 Chapter 2 Using the Setup Utility

3 Setup Utility menus

The menu tables in this section provide an overview of Setup Utility options.

NOTE: Some of the Setup Utility menu items listed in this chapter may not be supported by your

computer.

Main menu

Select To do this

System information ●View and change the system time and date.

●View identification information about the computer.

●View specification information about the processor, memory size,

system BIOS, and keyboard controller version (select models only).

Security menu

Select To do this

Administrator password Enter, change, or delete an administrator password.

Power-On Password Enter, change, or delete a power-on password.

Main menu 5

System Configuration menu

Select To do this

Language Support Change the Setup Utility language.

Button Sound (select models only) Enable/disable the capacitive button tapping sound.

Virtualization Technology Enable/disable the processor Virtualization Technology.

Processor C4 State (select models only) Enable/disable the processor C4 sleep state.

LAN Power Saving (select models only) Enable/disable LAN Power Saving. When enabled, saves power when

the computer is in DC mode.

Card Reader/1394 Power Saving (select models

only)

Enable/disable Card Reader/1394 Power Saving. When enabled, saves

power when the computer is in DC mode.

Fan Always On Enabled/disable Fan Always On. When enabled, the computer fan will

always be on.

Boot Options Set the following boot options:

●f9 and f10 Delay (sec.)―Set the delay for the f9 and f10 functions

of the Setup Utility in intervals of 5 seconds each (0, 5, 10, 15, 20).

●CD-ROM boot―Enable/disable boot from CD-ROM.

●Floppy boot―Enable/disable boot from diskette.

●Internal Network Adapter boot―Enable/disable boot from Internal

Network Adapter.

●Boot Order―Set the boot order for:

◦USB Floppy

◦Internal CD/DVD ROM Drive

◦Hard drive

◦USB Diskette on Key

◦USB Hard drive

◦Network adapter

Diagnostics menu

Select To do this

Hard Disk Self Test Run a comprehensive self-test on the hard drive.

NOTE: On models with two hard drives, this menu option is called the

Primary Hard Disk Self Test.

Secondary Hard Disk Self Test (select models

only)

Run a comprehensive self-test on a secondary hard drive.

Memory Test Run a diagnostic test on the system memory.

6 Chapter 3 Setup Utility menus
