AP Series Indoor Wireless LAN Access Points

Quick Start Guide

No part of this document may be reproduced or transmitted in any form or by any means without prior written

consent of Huawei Technologies Co., Ltd.

Trademarks and Permissions

and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.

All other trademarks and trade names mentioned in this document are the property of their respective holders.

Notice

The purchased products, services and features are stipulated by the contract made between Huawei and the

customer. All or part of the products, services and features described in this document may not be within the

purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information,

and recommendations in this document are provided "AS IS" without warranties, guarantees or

representations of any kind, either express or implied.

The information in this document is subject to change without notice. Every effort has been made in the

preparation of this document to ensure accuracy of the contents, but all statements, information, and

recommendations in this document do not constitute the warranty of any kind, express or implied.

Huawei Technologies Co., Ltd.

Address: Huawei Industrial Base

Bantian, Longgang

Shenzhen 518129

People’s Republic of China

Website: http://enterprise.huawei.com

Symbol

Description

Alerts you to a potentially hazardous situation that could, if not avoided, result

in equipment damage, data loss, performance deterioration, or unanticipated

results.

Provides additional information to emphasize or supplement important points

of the main text.

Alerts you to a medium or low risk hazard that could, if not avoided, result in

moderate or minor injury.

Alerts you to a high risk hazard that could, if not avoided, result in serious

injury or death.

Preface

This document describes the hardware configuration, installation preparation, installation method, installation

procedure, cable connection, and procedure for logging in to the indoor APs.

The preface is organized as follows:

•Intended Audience

•Symbol Conventions

•Documentation Obtaining

•Technical Support

Symbol Conventions

The symbols that may be found in this document are defined as follows:

WARNING

DANGER

NOTE

CAUTION

Intended Audience

This document is intended for:

•Hardware installation engineers

•Onsite maintenance engineers

•Network administrators configuring and maintaining the network

Documentation Obtaining

You can visit http://enterprise.huawei.com to obtain the latest product documentations. Choose Product

Support > Enterprise Networking > Datacom Network > WLAN > Product Documentation, and then select

the document of a specified version.

You can select the document as required. For example, if you want to obtain AP7110DN-AGN documents,

select AP7110DN-AGN.

NOTE

Technical Support

If you have trouble in locating or rectifying faults during maintenance or troubleshooting by following

instructions in this document, contact the Huawei customer service center (CSC) for help.

•Tel: 4008229999

You can also visit http://enterprise.huawei.com, click Contact Us in the lower area of the page, and select the

country to obtain contact information about Huawei local office.

Change History

Changes between document issues are cumulative. Therefore, the latest document issue contains all the

changes in previous issues.

Change in Issue 01 (2012-10-31)

Initial commercial release.

Device Introduction

The Huawei AP series indoor wireless LAN access point provides eight models: AP3010DN-AGN,

AP5010DN-AGN, AP5010SN-GN, AP6010DN-AGN, AP6010SN-GN, AP6310SN-GN, AP7110DN-AGN,

and AP7110SN-GN. The indoor AP features high reliability, high security, simple network deployment,

automatic AC discovery and configuration, and real-time management and maintenance.

The APs are recommended in scenarios where the building structure is simple and the building area is

small, have a high density of users, and have high capacity demands, for example, small-scale meeting

rooms, bars, and entertainment places. The APs can be flexibly deployed.

Table 1 lists the dimensions and weights of indoor APs.

Table 1 Dimensions and weight

Model

Dimensions

Weight

AP3010DN-AGN

AP5010DN-AGN

AP5010SN-GN

AP6010DN-AGN

AP6010SN-GN

180mm×180mm×50mm（W×D×H）

0.4kg

AP6310SN-GN

130mm×150mm×35mm（W×D×H）

0.6kg

AP7110DN-AGN

200mm×200mm×45mm（W×D×H）

0.95kg

AP7110SN-GN

200mm×200mm×45mm（W×D×H）

0.92kg

Table 2 Interfaces on indoor APs

AP3010DN-AGN

AP5010DN-AGN

AP5010SN-GN

AP6010DN-AGN

AP6010SN-GN

AP6310SN-GN

1 2 3 4 5

DC 12V

Default

ETH/PoE Console

12346 8

Device Introduction

No.

Name

Description

DC 12V

Connected to the power adapter.

Default

Press and hold down the Reset button for 3 seconds to restore the

factory settings and restart the AP.

ETH/PoE

10/100/1000M port, which connects to the wired Ethernet. The port

can connect to a PoE switch or a PoE power supply to provide

power for APs.

Console

Connected to the maintenance terminal for device configuration and

management.

Security slot

Connected to the security lock.

2.4 GHz

antenna port

A port connected to the 2.4 GHz antenna.

5 GHz antenna

port

A port connected to the 5 GHz antenna.

Ground screw

Connect the ground cable to the AP with a ground screw.

Table 2 Interfaces on indoor APs

Table 3 Interfaces on indoor APs

AP7110DN-AGN

AP7110SN-GN

1234 5 6

Console ETH/PoE Default

DC 12V

Console ETH/PoE Default

DC 12V

Installation Preparations

1. Safety Precautions

2. Installation Environment Check

Before installation, verify that the device runs in a favorable environment.

The table lists requirements on the environment that a device works in, including the temperature,

humidity, altitude, and pressure.

Table 4 Requirements on the environment

Only the qualified personnel are permitted to install and remove the device and its accessories.

Before installation and operation, read the safety precautions carefully.

Take proper measures to prevent injuries and device damage.

Place the device in a dry and flat position away from any liquid and prevent the device from

slipping.

Keep the device clean.

Do not put the device and tools in the aisles.

Item

Range

Temperature

AP3010DN: -5℃～+45℃

AP5010DN&SN: -5℃～+45℃

AP6010DN&SN: -5℃～+45℃

AP6310SN: -5℃～+45℃

AP7110DN&SN: -5℃～+55℃

Relative humidity

5% to 95%

Altitude

-60 m to +4000 m

Pressure

70 kPa to 106 kPa

WARNING

Installation Preparations

3. Device Accessories

The following accessories are delivered together with indoor APs:

4. Installation Tools

To install indoor APs, prepare the following tools:

AP6010DN&SN, AP6310SN,

AP7110DN&SN: sheet metal wall-

mounting bracket Expansion screws

Measuring tape

Phillips screwdriver Flat-head screwdriver

Utility knife

Wire stripper

Network cable tester Multimeter

Adjustable wrench

Maker

RJ45 crimping toolDiagonal pliers

Ladder

COAX crimping tool

Hammer drill

Hammer

ESD gloves Level 6mm drill bit

AP3010DN, AP5010DN&SN:

plastic wall-mounting bracket

Installing the AP

1. Installation Flowchart

Figure 1 Flowchart for installing an AP

2. Checking Before Installation

Unpack the package. Ensure that all the items listed in the packing list are included in the carton. If

any item is missing, contact the supplier.

Table 5 Packing list

No.

Item

Quantity

Unit

AP device

PCS

Power adapter (optional)

PCS

Sheet metal wall-mounting bracket

PCS

Plastic wall-mounting bracket

PCS

2.4 GHz antenna

PCS

5 GHz antenna

PCS

Expansion screws

PCS

Quick Start

PCS

The AP6010, AP6310, and AP7110 series have sheet metal wall-mounting bracket delivered

with them, while the AP3010 and AP5010 series have plastic wall-mounting bracket delivered

with them.

Three 2.4 GHz antennas and three 5 GHz antennas are contained in the AP7110DN-AGN carton,

and three 2.4 GHz antennas are contained in the AP7110SN-GN carton. Cartons of other models

do not contain antennas.

Start

Determine the

installation location

To a T-rail Against the ceiling

End

Check before

installation

Fix the wall-mounting

bracket against the ceiling

Fix the wall-mounting

bracket to a T-rail

Install the AP

Connect the

cable

Connect the

security lock to

the lock hole

Against the wall

Fix the wall-mounting

bracket against the wall

NOTE
