Hummer H3 Bedienungsanleitung
English
3 –11
Čeština
12 –19
Slovenčina
20 –28
Magyar
29 –37
Deutsch
38 –46
The product user guide contains product features, how to use, and the operating
procedure. Read the user manual carefully to get the best experience and avoid
unnecessary damage. Keep this manual for future reference. If you have any questions
or comments about the device, please contact the customer line.
✉www.alza.co.uk/kontakt
✆+44 (0)203 514 4411
Importer
Alza.cz a.s., Jankovcova 1522/53, Holešovice, 170 00 Praha 7, www.alza.cz
PRODUCT LAYOUT:
PARTS LIST:
#
Parts Name
Qty
#
Parts Name
Qty
1
Hummmer Multifunctional
Power Bank
1
5
User Guide
1
2
Micro USB cable
1
3
2A Car adapter
1
4
Sparkless Smart Cable
1
BATTERY CAPACITY INDICATOR LIGHTS:
Press the Power Button lightly to check the remaining battery level.
Indicator
lights
Unlit 1
1
Flashing
1 solid
2 solid
3 solid
4 solid
5 solid
Battery
level
0%
10%
20%
40%
60%
80%
100%
LED light
Power button
Battery Indicator light
Jump starter socket
USB5V/2A Output port
Micro USB 5V/2A Input port
Sparkless Smart Cable
Micro USB cable
2A Car Adapter
SPECIFICATIONS
For 12V Vehicles:
Recommended Vehicle Engine Displacements for Jump Starting:
For Engines Up to 3.5L Gasoline and 2.0L Diesel
CHARGING THE H3:
Connect the H3 using the included micro USB Cable to the USB input port and the 2A car
adapter. It can also be recharged from any USB powered port, like an AC adapter, car
charger and laptop etc. It is recommended to charge with the 2A USB adapter for
optimal charging speeds. The charging time of H3 will differ based on the discharge level
and the power source used. Actual results may vary due to battery
conditions.
JUMP STARTING A VEHICLE:
Before jump starting the vehicle, ensure that the battery level of the
H3 is sufficient for jump starting (i.e. over THREE lights).
Battery Capacity:
6000mAh (22.2Wh)
Jump Start Current:
12V/150A~300A
Output:
5V 2A; 12 V Jump start
Input:
5V 2A (Recommended to charge with 2A
USB adapter)
Operating Temperature:
-20°C to 60°C
Size:
5.3 x 3.1 x 0.6 inches
Weight:
0.5lbs
JUMP STARTING STEPS:
1. Ensure that the battery level of the jump starter is
sufficient for jump starting (i.e. over THREE lights).
2. Plug the Sparkless Smart Cable into the jump
starter.
JUMP STARTING STEPS:
1. Ensure that the battery level of the jump starter is sufficient for jump starting (i.e. over
TWO lights).
2. Plug the Sparkless Smart Cable into the jump
3. Connect Red clamp to the positive (+) battery terminal first, then connect Black
clamp to the negative (-) battery terminal.
4. Before jump starting, check the jump start indicator beside the BOOST button.
R: red clamp
B: black clamp
a. If the green indicator light is on, means ready to jump start.
b. If the red indicator light is on, means a misconnection between the clamp and battery
terminal.
c. If the red indicator light is blinking, means Reverse Charge protection is activated or
Low Battery.
d. If no light is on, press the BOOST button for 3 seconds until the green indicator light
turns on, by which time the jump starter is ready for use.
5. Once the vehicle has been successfully jump started, disconnect the jumper cable
clamps from the vehicle battery terminals.
Green
Red
R: red clamp
B: black clamp
JUMP STARTING WARNINGS!
•DON'T connect the RED and the BLACK clamps to each other or connect the two
clamps to any metal to prevent physical injury or damage to the vehicle.
•DON'T use the jumper cable for any purpose other than jump starting a vehicle.
•Always check to see if the jumper cable clamps are properly connected. DON'T
attempt to jump start after THREE attempts to prevent damage to the main unit.
Check your vehicle to see if it has any problems.
•DON’T crank the engine continuously for more than 5 seconds each time.
•Stay clear of the vehicle battery while jump starting.
•Use this product in a ventilated area. Wear safety glasses or goggles to protect
your eyes.
•Turn off the ignition before connecting the jumper cable clamps to the vehicle
battery.
•Never connect to the fuel line, fuel injector or carburetor as the engine ground.
•Keep away from children to prevent accident.
CHARGING USB DEVICES (e.g. SMARTPHONES):
1. Make sure the USB device is 5V powered.
2. Connect the included USB Charge Cable to the USB output port of the H3 and connect
to the USB device for charging. (If the included cable is not suitable for your device, you
can select your own appropriate USB Charge Cable).
3. The USB port will accept standard USB Charge Cable included with your USB device.
4. Press the Power button to start charging the USB device.
5. The number of times you can recharge a USB device will vary between devices.
TURNING ON/OFF THE LED LIGHT:
Press the LED ON/OFF Button and hold for 3 seconds to turn on the LED light. Press
again for Strobe, again for SOS light mode and again to turn the LED light off.
TURNING OFF THE H3:
The H3 has a built-in energy saving feature that will automatically turn the unit off after
the connected USB device has been fully charged or no load to the charger.
FAQ:
Q1: What are the features of the H3?
A1: Apart from jump starter function, the H3 can be used to recharge virtually any 5V
powered USB devices, such as mobile smartphones, tablets, portable gaming system,
digital cameras, camcorders, and portable GPS devices, etc. It can also jump start a
drained car battery with the included Sparkless Smart Cable. It is also equipped with a
built-in ultrabright LED flashlight.
Q2: How does the Sparkless Smart Cable work?
A2: If the green indicator light is on, means ready to jump start; If the red indicator light
is on, means a misconnection between the clamp and the battery terminal; If no light is
on, press the BOOST button for 3 seconds until the green indicator light turns on, by
which time the jump starter is ready for use. If the red indicator light is blinking, means
the Reverse Charge protection is activated or Low Battery.
Q3: Will reversing polarity connections of the jump start cable damage the vehicle?
A3: Not at all, the H3 is very safe with Sparkless Smart Cable. If you accidentally connect
the RED and BLACK cable clamps to the wrong polarity terminal and attempt to jump
start the vehicle, the Sparkless Smart Cable (the red indicator light is on) will cut the
power immediately to prevent injury and avoiddamaging the vehicle.
Q4: What if it doesn’t jump start the vehicle?
A4: If the H3 fails to jump start the engine, please wait at least 10 seconds before
attempting to try again and please do not crank the engine continuously for more than 5
seconds each time. If still not succeed after 3 attempts, it may be due to other
problems of the vehicle. Do not try to crank the engine continuously for more than 10
times in a row. It is also highly recommended to replace the vehicle battery once every
2-3 years.
Q5: How many times can the H3 jump start a vehicle?
A5: Approximately 10 times with a 100% fully charged battery. Actual results may vary
due to battery conditions.
Q6: How long is the H3 standby time?
A6: The standby time of H3 is up to 6 months if it is fully charged. It is recommended to
fully discharge the battery via USB output port and recharge to full every 3 months to
prolong its battery life. Result may vary depending on the owner usage and the
battery conditions.
Q7: How long will it take to fully recharge the H3 to the maximum
battery level?
A7: It takes about 3 to 4 hours through the 5V/2A input port. Actual results may vary due
to battery conditions. It is not recommended to use 1A adapter.
Q8: How long will it take to fully recharge a smartphone or USB
devices?
A8: The number of times you can recharge a smartphone will vary between different
smartphones and devices. For recharge times, contact your device manufacturer.
TROUBLE SHOOTING:
Finding
Cause
Remedies
The indicator light on
the Sparkless Smart
Cables controller is off
after connecting to the
vehicle battery.
The vehicle battery is
either at ZERO
voltage or is not
connected with a
battery.
Hold the BOOST button on
the controller for 3
seconds until the Green
light is on and it's ready to
jump start.
Takes over 10 hours to
recharge the H3
Incorrect AC adapter
being used to
recharge the H3.
Recommended to
recharge it by 2A output
USB charging adapter.
There is no response
when pressing the
Power button on the H3.
The low voltage
protection is
activated and the
electronic circuit has
been shut off.
Plug the charging adapter
into the charging port to
activate the electronic
circuit.
