HUSKY LINERS 3231 Handbuch

3231 Front_Rear.doc

09/18/03

THANK YOU FOR SELECTING A HUSKY FLOOR LINER

FROM WINFIELD CONSUMER PRODUCTS

CARE AND USE INSTRUCTIONS

Your new floor liners are custom molded to fit your particular vehicle. The liners are made to take the place

of your factory floor mats. For correct fit, it is necessary to remove the factory floor mat before installing your

new floor liners. However, do not remove the factory-installed carpeting.

Your liners are made from an engineering resin that is lightweight and extremely tough and durable. The

easiest way to clean your liners is with a damp cloth or sponge. If using a cleaner, 409®or Glass Plus®work

well. Use of Armor All®, Son-of-a-Gun®or similar items is discouraged as these products make the liners slick.

INSTALLATION INSTRUCTIONS FOR YOUR S-10/BLAZER/

BRAVADA/ENVOY/HOMBRE/JIMMY/SONOMA FLOOR LINERS

LEFT OR

DRIVER’S

SIDE

RIGHT OR

PASSENGER’S

SIDE

SEE BACK OF THIS SHEET FOR ADDITIONAL INSTRUCTIONS.

3231 Front_Rear.doc

09/18/03

Your Husky Floor Liners come molded with Sta-Put Nibs® on the back surface of the liners to help hold them

in place. Additionally, we have included an optional Velcro® anchoring system to further secure your driver’s

side liner. To install the optional Velcro® anchoring system, just follow the easy steps listed below.

First, Locate the hardware bag included in the shipping container. Inside it you will find 2 anchor screws with

the “loop” pad portion of the Velcro® fasteners already applied. Also included are two Velcro® hook pads that

will need to be applied to your liner.

Before positioning the Velcro® hook pads on your liner, it will be necessary to remove any nibs that would

keep the pads from laying flat. A pair of clippers work well for removing nibs. Photos 1 and 2 below show

where a nib has been removed and Velcro® hook pad has been installed. Install the hook pads towards the back

edge of the liner (nearest the seat) opposite of each other. Choose a flat area underneath which the carpet screw

can be installed (make sure the anchor screw will actually screw into the area chosen). Pre-fitting the liner may

help determine “good” locations.

Finally, install the liner in your vehicle making sure it is properly aligned. The anchor screws will need to be

installed in your factory carpet directly beneath the Velcro® hook patches you applied. To do this, pull up a

corner of your liner as shown in photo 3 below. Attach the anchor screw (the Velcro will hold the screw to the

liner) to the pad then lower the raised edge and note the position where the anchor screw touches the vehicle

carpet. Insert the anchor screw and repeat procedure for the other pad location.

PHOTO 1. ARROW POINTING TO

NIB THAT HAS BEEN REMOVED

TO ALLOW HOOK PAD TO LAY

FLAY.

PHOTO 3. ANCHOR SCREW SHOWN INSTALLED

IN CARPET ALIGNED BELOW HOOK PAD.

PHOTO 2. VELCRO® HOOK PAD

SHOWN ATTACHED TO LINER.
