IBM Systems and Technology

Data Sheet

BladeCenter

IBM BladeCenter HX5

Unprecedented ﬂexibility, processing power, memory

and I/O capacity in a blade server

Highlights

●Provide optimal performance for your

demanding virtualization and database

applications

●Reduce qualiﬁcation time by standard-

izing on same system for two- and

four-socket server needs

●Scale memory without adding CPUs or

software licenses

●Get faster time to value by deploying

workload-optimized systems

Maximize memory

Going beyond the industry standards with unique innovations from

ﬁfth-generation IBM®X-Architecture®technology (eX5), the new

IBM BladeCenter®HX5 enables unprecedented performance and uti-

lization in a blade form factor for database and virtualization. With

MAX5 scalability, the HX5 blade offers memory capacity of up to

320 GB—in double-wide blade. The result is optimal server utilization

with more virtual machines per system and larger and faster databases.

Minimize cost

With MAX5, HX5 offers the most memory of any server in its class.

Reduce software license costs by expanding memory capacity with

MAX5 without purchasing additional processors.

Easy to own, manage and upgrade with pay-as-you-grow expansion,

the HX5 blade server helps protect your investments over the long

term. Capabilities such as advanced light path diagnostics, error han-

dling and around-the-clock remote access management help simplify

systems management and minimize downtime. Automatic node failover

and QPI faildown help promote greater system uptime. In addition, an

energy-smart design and IBM Systems Director Active Energy

Manager™ help lower power consumption and costs.

Simplify deployment

Flexible conﬁgurations make it easy to implement the right system.

Get up and running up to four times faster by standardizing on a single

platform for two- and four-socket server needs. Harness the MAX5

module to boost memory without adding processors or software license

costs. And ﬂexible, no-touch node partitioning from four processors to

two lets you optimize licensing and other operational costs.

Select conﬁgurations of the HX5 blade are part of the IBM Express

Advantage®Portfolio designed to meet the needs of midsized

businesses. Easy to manage, Express®models and conﬁgurations

vary by country.

Please Recycle

IBM BladeCenter HX5 at a glance

Form factor/height

Processor (max)

Number of processors (std/max)

Cache (max)

Memory (max)

Expansion slots

Disk bays (total/hot swap)

Maximum internal storage

Network interface

RAID support

Systems management

Operating systems

supported

Singlewide (30 mm) – double-wide

(60 mm)

Intel® Xeon® 7500 and 6500 proces-

sors; 4/6/8 cores, up to 2.66 GHz

Up to 2 processors per single-wide HX5;

scalable to 4 processors

1/2 (scalable to 4)

Up to 24 MB per processor (8 core)

16 DDR-3 VLP DIMM slots, capacity

up to 128 GB, per single-wide HX5

(scalable up to 320 GB max, at speeds

up to 1067 MHz, via 40 DIMM slots,

using a MAX5 expansion blade)

1 CIOv slot (standard PCIe daughter

card) and 1 CFFh slot (high-speed PCIe

daughter card) for total of 8 ports of I/O

to each blade, including 4 ports of

high-speed I/O

Scalable up to 16 ports of I/O in

4-socket, double-wide form factor

2 non-hot-swap bays supporting solid-

state drives per single-wide HX5

Up to 100 GB of solid-state storage per

single-wide HX5 (with 50 GB SSDs)

Broadcom 5709S onboard NIC with dual

Gigabit Ethernet ports with TOE

Optional RAID-0, -1, -1E

Integrated systems management

processor

Microsoft® Windows®, Red Hat Linux®,

SUSE Linux, VMware

Limited warranty 3-year customer replaceable unit and

on-site limited warranty

For more information

World Wide Web

U.S. ibm.com/bladecenter/

Canada ibm.com/systems/ca/en/servers/bladecenter

©Copyright IBM Corporation 2010

IBM Systems and Technology Group

Route 100

Somers, New York 10589

Produced in the United States of America

August 2010

IBM, the IBM logo, ibm.com, BladeCenter and

X-Architecture are trademarks or registered trademarks of

International Business Machines Corporation in the

United States, other countries, or both. If these and other

IBM trademarked terms are marked on their ﬁrst occurrence

in this information with a trademark symbol (®or ™), these

symbols indicate U.S. registered or common law trademarks

owned by IBM at the time this information was published.

Such trademarks may also be registered or common

law trademarks in other countries. A current list of

IBM trademarks is available on the web at “Copyright and

trademark information” at ibm.com/legal/copytrade.shtml

Intel and Intel Xeon are trademarks or registered trademarks

of Intel Corporation or its subsidiaries in the United States

and other countries.

Linux is a registered trademark of Linus Torvalds in the

United States, other countries, or both.

Microsoft and Windows are registered trademarks of

Microsoft Corporation in the United States, other countries,

or both.

Other product, company or service names may be

trademarks or service marks of others.

BLD03032-USEN-04
