iMag, iMag Pro (II)

User Manual

80097503-001-Rev. F

26 September 2019

iMag, iMag Pro (II) User Manual

Page | 2

ID TECH

10721 Walker Street

Cypress, CA 90630

(714) 761-6368

www.idtechproducts.com

This document, as well as the hardware and software it describes, is furnished under license and may

only be used in accordance with the terms of such license. The content of this paper is furnished for

informational use, subject to change without notice, and not to be construed as a commitment by ID

TECH. ID TECH assumes no responsibility or liability for any errors or inaccuracies that may appear in

this document.

Except as permitted by such license, no part of this publication may be reproduced or transmitted by

electronic, mechanical, recorded, or any other method, or translated into another language or

language form without the express written consent of ID TECH. ID TECH is a registered trademark of

International Technologies and Systems Corporation. ViVOpay and Value through Innovation are

trademarks of International Technologies and Systems Corporation. Other trademarks are the

property of the respective owner.

Warranty Disclaimer

The services and hardware are provided "as is" and "as-available," and the use of these services and

hardware are at the user’s own risk. ID TECH does not make, and hereby disclaims, any and all other

express or implied warranties, including, but not limited to warranties of merchantability, title, fitness

for a particular purpose, and any warranties arising from any course of dealing, usage, or trade

practice. ID TECH does not warrant that the services or hardware will be uninterrupted, error-free, or

completely secure.

iMag, iMag Pro (II) User Manual

Page | 3

FCC Regulatory Compliance

Notices Class B Equipment

This equipment has been tested and found to comply with the limits for a Class B digital device

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. This device complies with part 15 of the FCC

rules. Operation is subject to two conditions: (1) This device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that may cause

undesired operation.

If this equipment does cause harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encouraged to try and correct the

interference by one or more of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and the receiver.

•Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

•Consult the dealer or an experienced radio/TV technician for help.

Changes or modifications to the ViVOpay Kiosk III not expressly approved by ID TECH could void the

user's authority to operate the ViVOpay Kiosk III.

IC Compliance Warning

Operation is subject to two conditions: (1) This device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that may cause

undesired operations.

Cautions and Warnings

Caution: The ViVOpay Kiosk III should be mounted 1-2 feet away from other

ViVOpay Kiosk IIIs. Can be adjusted based on lane setup.

Caution: Danger of Explosion if battery is incorrectly replaced. Replace only with

same or equivalent type recommended by the manufacturer. Discard used

batteries according to the manufacturer’s instructions.

Warning: Avoid close proximity to radio transmitters which may reduce the ability

of the reader.

iMag, iMag Pro (II) User Manual

Page | 4

Table of Contents

1. INTRODUCTION..................................................................................................................................................................................5

2. FEATURES............................................................................................................................................................................................5

3. SPECIFICATIONS................................................................................................................................................................................5

.............................................................................................................................6

4.1. Setting Command..................................................................................................................................................................6

4.2. Get Firmware Version ..........................................................................................................................................................6

4.3. Get Setting...............................................................................................................................................................................7

4.4. Function ID Table...................................................................................................................................................................7

4.4.1. EncryptionID................................................................................................................................................................................................................7

4.4.2. Read SecurityLevel ID ...........................................................................................................................................................................................8

4.4.3. Get Firmware Version...........................................................................................................................................................................................8

..................................................................................................................................................................9

5.1. iMag/ iMag Pro(II) Unencrypted Data Output Format................................................................................................9

.....................................................................................................9

6. DECRYPTION EXAMPLE ............................................................................................................................................................... 12

6.1. Decrypted Data ................................................................................................................................................................... 14

............................................................................................................................................. 15

iMag, iMag Pro (II) User Manual

Page | 5

1. Introduction

ID TECH iMag is a snap-on, magnetic stripe reader designed to work with iPhone and iPod Touch. The

iMag Pro works with all Apple mobile devices including the iPad. The reader delivers a superior

reading performance because of its ability to encrypt sensitive card data. The data encryption process

prevents card holder information from being accessed when the data is stored or in transit, so the

data remains secure from beginning until end.

The reader fully supports TDES and AES data encryption using DUKPT key management method.

2. Features

•Compact for comfort and mobility

•No external power supply required

•Mini USB port enables charging Apple devices with external cable

•Bi-directional card reading

•Reads encoded data that meets ANSI/ISO/AAMVA standards and some custom formats such

as ISO track 1 format on track 2 or 3

•Reads up to three tracks of card data

•Provides clear text confirmation data including card holder’s name and a portion of the PAN

as part of the Masked Track Data

3. Specifications

Communication Interface:

UART

Power Consumption:

5mA during card swipe, less than 1mA when idle

Magnetic Stripe Reader:

3 track bi-directional reading capabilities

Operating Life:

100,000 cycle minimum

Operating Environment:

0 °C to 55 °C (32 °F to 131 °F) non -condensing

Storage Environment:

-30 °C to 70 °C ( -22 °F to 158 °F) non -condensing

Dimensions:

iMag: 95 mm (L) x 30 mm (H) x 71 mm (W)

iMag Pro: 59mm (L) x 14 mm (H) x 32 mm (W)

iMag Pro II: 59.2mm(L) x 13.1mm(H) x 32.6mm(W)

iMag, iMag Pro (II) User Manual

Page | 6

4.1. Setting Command

The Setting command is a collection of many function-setting blocks in the following format:

Command:

Response:

<ACK> for successful settings or <NAK> for the wrong commands such as invalid funcID, length,

and value.

Each function-setting block <FuncSETBLOCK> has the following format:

Where:

•<FuncID> is a one-byte ID identifying the function being set.

•<Len> is a one-byte length count for the function-setting block <FuncData>.

•<FuncData> is the current setting for this function. It has the same format as in the

sending command for this function.

Example:

Set DUKPT Key management

CMD: \02\53\58\01\31\03\3A

OUT: 06

4.2. Get Firmware Version

The Get Firmware Version command returns the firmware version back to the application.

Command:

Response:

<Version String> is in the format of “ID TECH iMag Swipe Reader x.y.z” where x.y.z is the

major and minor version number.

iMag, iMag Pro (II) User Manual

Page | 7

4.3. Get Setting

The Get Setting command retrieves the reader’s current settings.

Command:

Response:

<FuncID>, <Len>, and <FuncData> retrieves the reader’s current settings.

Example:

Review all settings:

CMD: \02\52\1F\03\4C

OUT: \06\02\7E\01\31\4C\01\31\58\01\31\03\5B

4.4. Function ID Table

The available Function IDs with the default setting are shown in bold.

Function Name

Function ID

Description

EncryptionID

0x4C

Security Algorithm

‘0’ Clear Text

‘1’ Triple DES

‘2’ AES

SecurityLevelID

0x7E

Security Level (Read Only) ‘0’ ~ ‘3”

Default value ‘1’

GetFirmwareVersion

0x22

Returns current firmware version

4.4.1. EncryptionID

Set clear text:

CMD: 02 53 4C 01 30 03 2F

OUT: 06

Read EncryptionID:

CMD: 02 52 4C 03 1F

OUT: 06 02 4C 01 30 03 7C

Set Triple DES:

CMD: 02 53 4C 01 31 03 2E

OUT:06

Read EncryptionID:

CMD: 02 52 4C 03 1F

iMag, iMag Pro (II) User Manual

Page | 8

OUT: 06 02 4C 01 31 03 7D

Set AES:

CMD: 02 53 4C 01 32 03 2D

OUT: 06

Read EncryptionID:

CMD: 02 52 4C 03 1F

OUT: 06 02 4C 01 32 03 7E

4.4.2. Read SecurityLevel ID

CMD: 02 52 7E 03 2D

OUT: 06 02 7E 01 33 03 4D

4.4.3. Get Firmware Version

CMD: 02 52 22 03 71

OUT: 06 02 49 44 20 54 45 43 48 20 69 4D 61 67 00 31 31 30 03 04

Firmware Version: ID TECH iMag110

iMag, iMag Pro (II) User Manual

Page | 9

5.1. iMag/ iMag Pro(II) Unencrypted Data Output Format

Track 1:

<Start Sentinel 1><T

Data><End Sentinel><Track Separator>

Track 2:

Track 3:

Where:

Start Sentinel 1 = % Start

Sentinel 2=;

Start Sentinel 3 =; for ISO, % for AAMVA End Sentinel all tracks

= ?

Start or End

Sentinel:

Characters in the encoding format come before the first data character (start) and after the last

data character (end), indicating the beginning and end of data.

Track Separator:

A designated character that separates data tracks. The default character is NULL.

Terminator:

A designated character that comes at the end of the last track of data, to separate card reads. The

default character is CR (Carriage Return).

Example:

%B4352378366824999^TFSTEST

/THIRTYONE^05102011000088200882000000?;4352378366824999=05102011000088

iMag/ iMag Pro uses ID TECH’s enhanced data encryption format where all data tracks are encrypted.

Output Format:

STX

Data Length low byte

Data Length high byte

Card Encode Type 1

Track 1-3 Status 2

Track 1 data length

Track 2 data length

Track 3 data length

Clear/mask data sent status

Encrypted/Hash data sent

status

T1 clear/mask data

T2 clear/mask data

T3 clear/mask data

T1 encrypted data

T2 encrypted data

T3 encrypted data

Session ID (8 bytes) (Security

iMag, iMag Pro (II) User Manual

Page | 10

level 4 only, not used here)

T1 hashed (20 bytes each) (if

encrypted and hash tk1 allowed)

T2 hashed (20 bytes each) (if

encrypted and hash tk2 allowed)

T3 hashed (20 bytes each) (if

encrypted and hash tk3 allowed)

KSN (10 bytes)

CheckLRC

CheckSum

ETX

Where:

<STX> = 02h, <ETX> = 03h

Card Type is 8x for an enhanced encryption format and 0x for original encryption format.

Value Encode Type Description

00h / 80h ISO/ABA format

01h / 81h AAMVA format

03h / 83h Other

04h / 84h Raw; un-decoded format

For Type 04 or 84 Raw data format, all the tracks are encrypted and no mask data is sent. There

are no track indicators of ‘01’,‘02’,or ‘03’ in front of each track.

Track indicators ‘01’,’02’,and ‘03’ still exist for non-encrypted mode.

Note 2:Track 1 3 status byte.

Decoded bit: 1for decode success or no sampling data; 0for decode error (with sampled data but

failed to decode)

Sampling bit: 1for sample data exist; 0for sample data does not exist.

Note 3: Clear/mask data sent status

Field 4:

Bit 0:

1—track 1 decoded data present

Bit 1:

1—track 2 decoded data present

Bit 2:

1—track 3 decoded data present

Bit 3:

1—track 1 decoded data present

Bit 4:

1—track 2 decoded data present

Bit 5:

1—track 3 decoded data present

Bit 6,

7—Reserved for future use

Andere Handbücher für iMag

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere IDTECH Kartenleser Handbücher

IDTECH

IDTECH MINIMAG Gebrauchsanweisung

IDTECH

IDTECH MiniSmart II Installationshandbuch

IDTECH

IDTECH VP3300 OEM Bedienungsanleitung

IDTECH

IDTECH Spectrum Air Bedienungsanleitung

IDTECH

IDTECH MiniMag RS232 Bedienungsanleitung

IDTECH

IDTECH VP3300 OEM Bedienungsanleitung

IDTECH

IDTECH MINIMAG Bedienungsanleitung

IDTECH

IDTECH ViVOpay VP6300 Bedienungsanleitung

IDTECH

IDTECH ViVOpay VP5300 Bedienungsanleitung

IDTECH

IDTECH VP4880 Bedienungsanleitung

IDTECH

IDTECH ViVOpay VP6300 Bedienungsanleitung

IDTECH

IDTECH ViVOpay KioskII Bedienungsanleitung

IDTECH

IDTECH VP3300 Bedienungsanleitung

IDTECH

IDTECH BT Mag Bedienungsanleitung

IDTECH

IDTECH SREDKey Gebrauchsanweisung

IDTECH

IDTECH ViVOpay VP3300 Series Bedienungsanleitung

IDTECH

IDTECH minimag RS-232 Bedienungsanleitung

IDTECH

IDTECH MiniSmart II Bedienungsanleitung

IDTECH

IDTECH NEO 3 VP3350 Bedienungsanleitung

IDTECH

IDTECH MINIMAG Gebrauchsanweisung

IDTECH

IDTECH ViVOpay VP3350 Gebrauchs- und Pflegehandbuch

IDTECH

IDTECH UniPay Gebrauchsanweisung

IDTECH

IDTECH Spectrum IIa Bedienungsanleitung

IDTECH

IDTECH SREDKey Bedienungsanleitung

Beliebte Kartenleser Handbücher anderer Marken

Lindy

Lindy 43185 Bedienungsanleitung

Lindy

Lindy 43185 Bedienungsanleitung

ViziT

ViziT RD-4F Bedienungsanleitung

Jinmuyu Electronics

Jinmuyu Electronics MR811 Series Bedienungsanleitung

AVID ID

AVID ID AVID1043 Bedienungsanleitung

Conrad

Conrad PCMCIA Bedienungsanleitung

Rosslare

Rosslare DR-6255 Bedienungsanleitung

Lindy

Lindy 51541 Bedienungsanleitung

Diapro T?bbi Ürünler

Diapro T?bbi Ürünler Across System Bedienungsanleitung

Johnson Controls

Johnson Controls Kantech tyco ioSmart Bedienungsanleitung

ACS

ACS ACR122L Bedienungsanleitung

Secukey

Secukey S2-MF Bedienungsanleitung

Elecom

Elecom MR-SMC07 series Bedienungsanleitung

Alien

Alien ALR-9800 Bedienungsanleitung

ACS

ACS ACR310 Bedienungsanleitung

Datamars

Datamars R-IN1300 MID Bedienungsanleitung

Alarm Lock

Alarm Lock AL-PRE2 Bedienungsanleitung

xpr

xpr B100PROX-AH Benutzerhandbuch

IDTECH iMag Bedienungsanleitung

Beliebte Kartenleser Handbücher anderer Marken
