VP4880, VP4880C,

VP4880E, VP4880 OEM

User Manual

80149509-001-A

ID TECH

10721 Walker Street

Cypress, CA 90630

(714) 761-6368

www.idtechproducts.com

support@idtechproducts.com

This document, as well as the software and hardware described in it, is furnished

under license and may be used or copied online in accordance with the terms of

such license. The content of this document is furnished for information use only, is

subject to change without notice, and should not be construed as a commitment by

ID TECH. While every effort has been made to ensure the accuracy of the

information provided, ID TECH assumes no responsibility or liability for any

unintentional errors or inaccuracies that may appear in this document. Except as

permitted by such license, no part of this publication may be reproduced or

transmitted by electronic, mechanical, recording, or otherwise, or translated into

any language form without the express written consent of ID TECH.

ID TECH and ViVOpay are trademarks or registered trademarks of ID TECH.

Warranty Disclaimer

The services and hardware are provided "as is" and "as-available" and the use of

the services and hardware are at its own risk. ID TECH does not make, and hereby

disclaims, any and all other express or implied warranties, including, but not limited

to, warranties of merchantability, fitness for a particular purpose, title, and any

warranties arising from a course of dealing, usage, or trade practice. ID TECH does

not warrant that the services or hardware will be uninterrupted, error-free, or

completely secure.

This device complies with Part 15 of the FCC Rules:

1. This device may not cause harmful interference, and

2. This device must accept any interference received, including

interference that may cause undesired operation of the device.

Cautions and Warnings

Caution: Danger of Explosion if battery is

incorrectly charged. Use only standard USB 5V

power source. Device contains a lithium battery.

Approved temperature range for storage: -20℃to

+60℃. Disposal: Contact your local recycling

center.

Warning: Avoid close proximity to radio

transmitters, which may reduce the capabilities of

the reader.

Introduction

VP4880 is ID TECH's family of ultra-compact, EMV L1/L2-certified contactless

card readers, designed for low cost, high reliability, and maximum compatibility

with existing contactless payment technologies (including Apple Pay, Android Pay,

and Samsung Pay).

The VP4880 family includes models with and without contact-EMV capability, as

well as with and without magnetic swipe reader (MSR) functionality. (See the chart

shown further below.) The economical VP4880C, which offers

contactless-transaction capability without contact-EMV or MSR, provides an

extremely cost-effective way for merchants to add tap-and-go capability to existing

payment options, without the need to replace other hardware. Likewise, for

merchants who already have MSR capability but need to add contact-EMV and

NFC, the VP4880E offers an economical way to do so.

The VP4880 series incorporates the proven EMV L2 kernel of ID TECH's popular

UniPay III card reader. Developers can integrate VP4880-series products into

EMV-ready terminal systems with minimal effort using ID TECH's Universal SDK,

available for Windows, Android, or iOS.

Major Features of VP4880 Family

Micro-USB port for communications and power.

Magnetic stripe support (VP4880 only): ISO 7810/ISO 7811, Hi-Co+Lo-Co

Magnetic, JIS1/JIS2.

MSR (VP4880 only) is bidirectional, reading up to 3 tracks of data at once.

ICC support (VP4880 and VP4880E): EMV Level 1 and EMV L2 approvals. All

L1 & L2 on the device.

Contactless transaction support via Near Field Communication (NFC): all

models.

LED status indicator.

Audio feedback.

Field upgradable firmware.

Standby mode for low power consumption.

Compact and ergonomic design to integrate with a variety of devices.

Available with a sturdy stand, for tabletop use.

TDES and AES 128 encryption support.

DUKPT key management.

Software Development Kits for Windows, Android, iOS.

One-year manufacturer's warranty.

Feature

VP4880

VP4880C

VP4880E

Contactless reader (NFC capability)



ICC reader with landing contacts and

EMV L1 and L2 certification



3-track MSR (magstripe reading)



EMVCo Contactless L1 and major

card brand contactless certifications

(L2’s)



Compact Size



4 green LEDs for the contactless

indication



Audio feedback to signal good/bad

card reads, etc.



TDES and AES encryption algorithms



Supports ID TECH standard TR31

(and optional TR34) Remote Key

Injection



Supports multiple key slots



RoHS and REACH compliant



1 year manufacturer warranty



Magnetic Stripe Features (VP4880 only)

ISO 7810 / ISO 7811

AAMVA format

JIS I / II

Single / Dual / Triple Track Support

Bi-directional reading

Samsung Pay MST

ICC Contact Card Features (VP4880, VP4880E)

EMVCo Contact Level 1 & 2 compliant.

Contactless (NFC) Features:

ISO 14443 Type A&B

ISO 18092 (P2P)

MasterCard® MCL (Formerly PayPass)

Visa payWave/VCPS

Visa IRWIN

Discover® DPAS

American Express® ExpressPay

MIFARE

Apple Pay

Samsung Pay NFC

Android Pay

Google Wallet / Softcard SmartTap

Before You Start Using VP4880

Devices in the VP4880 family are compact micro-USB devices for handling

contactless transactions. (See chart above for differences between models.) Your

VP4880-series device is designed to operate in conjunction with certified third party

payment software and compatible hosts, such as USB-equipped tablets, PCs, and

smartphones. Before you connect VP4880 to the host, install and activate the

software application service according to the instructions provided by your payment

application service or software provider, then connect the VP4880 to the host

through a micro-USB cable (not included).

Battery Charging Instructions

All VP4880-series devices incorporate a Lithium Ion Polymer Battery for backup of

cryptographic keys and continuous operation of the onboard realtime clock. The

battery is delivered in a partially charged state. You should fully charge it before

using it for the first time. Allow 2.5 hours for the initial charge. Battery shelf life is 5

years.

To charge the unit: Use a USB to micro-USB cable (not included) to charge the unit.

LED Status During Unit Charging

Rear LED Indicators: Two LEDs on the back of the device communicate the state of

the device (powered, charging, fully charged, etc.) depending on whether the

VP4880 is connected to a host via USB-to-micro-USB cable, or not. Connecting

with such a cable allows the VP4880 to charge its internal battery.

LED Status for Power Management

Top LED Flashes Amber & Green: Battery is low, please charge the battery.

Bottom LED Solid Red: Battery is charging.

Both LCD off: Battery is full, please stop charging the device.

LED Status During Transactions and Operation

ICC processing: Top LED flashes amber during transaction, do not remove card.

ICC process successful: Top LED displays solid green (2 seconds), please

remove card.

Magnetic stripe read successful: Top LED displays solid green (2 seconds.

Magnetic stripe read failed: Top LED displays solid red (2 seconds).

Contactless read successful: All 4 LEDs on the unit's face (contactless antenna

side) flash green simultaneously

Physical Specifications (VP4880, VP4880C, VP4880E)

Operation and Storage Environment

No.

Item

Specification

Physical

Dimensions

64mm x 49mm x 14.5mm(LxWxH)

Structure Material

Plastic, PC UL 94V-0

Housing Color

Black /White

Texture

MT11010

Weight

50g

Item

Specification

Note

Operating

Temperature

0 °C to 55 °C

1. Non-condensing.

2. Product operation temperature is

limited to the range for the reason

FCC Regulatory Compliance: Notices: Class B Equipment

This equipment has been tested and found to comply with the limits for a Class B

digital device pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses, and can radiate radio frequency energy

and, if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. This device complies with part

15 of the FCC rules. Operation is subject to two conditions: (1) This device may not

cause harmful interference, and (2) this device must accept any interference

received, including interference that may cause undesired operation.

If this equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following

measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and the receiver.

Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

Changes or modifications to the VP4880, VP4880C, or VP4880E not

expressly approved by ID TECH could void the user's authority to operate

the device.

Other Agency Approvals and Compliances

CE (EN55022/EN55024, Class- B)

FCC (Part 15, Class-B)

RoHS (DIRECTIVE 2011/65/EU)

of the constraint of Li-Battery

specification.

Storage Temperature

-20 °C to 60

°C

1. Non-condensing.

2. Product storage temperature is

limited to the range for the reason

of the constraint of Li-Battery

specification.

Operating Humidity

5% to 95%

Non-condensing

Storage Humidity

5% to 95%

Non-condensing

UL

REACH

EMV Contact L1&L2

EMV Contactless L1

TQM

For Software Developers: Software Development Support

VP4880 devices are designed to be compatible with a wide range of third party

payment applications. ID TECH offers a Universal SDK (available for iOS,

Android, or Windows) to enable rapid application development with any model of

VP4880 as the target device. The languages supported include Objective C (on iOS),

Java (on Android), and C# (on Windows). The Universal SDK includes rich,

powerful libraries that make communication with VP4880 comparatively easy while

greatly facilitating debugging.

Normally, development of applications that take advantage of VP4880 capabilities

can be done in a high-level language like Java or C# (using convenience objects and

data structures), obviating the need to send hex-code commands directly via

USB-HID. Nevertheless, if you need to communicate with the device via audio jack

or via USB-HID, it is possible to do so. For a command reference for VP4880-series

products, consult the NEO Interface Developers Guide (IDG), P/N 80139403-001.

Demo App

The Universal SDK comes with a rich, fully featured demo app. Complete source

code for the demo app is included with the SDK.

To use the demo app: On Windows, plug your VP4880-series device into the host

using a USB-to-micro-USB cable (not included), then double-click the

UniversalSDKDemo.exe file and allow a few seconds for the main window to appear

(see illustration below).

The Demo App displays available commands in a command tree, as shown above.

Single-click on a command to populate the center panel of the window with optional

settings relevant to the command (e.g., "Amount" and "Start EMV Additional Tags"

above). In some cases, text fields will appear, allowing you to enter custom values.

When you are ready to execute the command in question, double-click it in the

command tree. The command executes in real time and a data trace appears

automatically in the center and/or right-hand panels. (Use the Clear Logs button to

clear both panels.)

Revision History

Revision

Date

Description of Changes

9/15/2016

Initial release

10/26/2016

Add VP4880 OEM to cover. No content

change.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere IDTECH Kartenleser Handbücher

IDTECH

IDTECH VP3300 Bedienungsanleitung

IDTECH

IDTECH SecureMag Bedienungsanleitung

IDTECH

IDTECH 80140502-001 Bedienungsanleitung

IDTECH

IDTECH Kiosk V Bedienungsanleitung

IDTECH

IDTECH MiniSmart II Bedienungsanleitung

IDTECH

IDTECH ViVOpay VP3300 Series Bedienungsanleitung

IDTECH

IDTECH Spectrum IIa Bedienungsanleitung

IDTECH

IDTECH OMNI Bedienungsanleitung

IDTECH

IDTECH SmartPIN L80 Bedienungsanleitung

IDTECH

IDTECH minimag RS-232 Bedienungsanleitung

IDTECH

IDTECH PiP Bedienungsanleitung

IDTECH

IDTECH MINIMAG Bedienungsanleitung

IDTECH

IDTECH MINIMAG Bedienungsanleitung

IDTECH

IDTECH ViVOpay VP3320 Bedienungsanleitung

IDTECH

IDTECH iMag Bedienungsanleitung

IDTECH

IDTECH ViVOpay KioskII Bedienungsanleitung

IDTECH

IDTECH Augusta Bedienungsanleitung

IDTECH

IDTECH ViVOpay VP6300 Bedienungsanleitung

IDTECH

IDTECH ViVOpay VP5200 Bedienungsanleitung

IDTECH

IDTECH Kiosk III Bedienungsanleitung

IDTECH

IDTECH MiniSmart II Installationshandbuch

IDTECH

IDTECH VP3300 OEM Bedienungsanleitung

IDTECH

IDTECH OMNI Bedienungsanleitung

IDTECH

IDTECH NEO 3 VP3350 Bedienungsanleitung

Beliebte Kartenleser Handbücher anderer Marken

Lindy

Lindy 43185 Bedienungsanleitung

Lindy

Lindy 43185 Bedienungsanleitung

ViziT

ViziT RD-4F Bedienungsanleitung

Jinmuyu Electronics

Jinmuyu Electronics MR811 Series Bedienungsanleitung

AVID ID

AVID ID AVID1043 Bedienungsanleitung

Conrad

Conrad PCMCIA Bedienungsanleitung

Rosslare

Rosslare DR-6255 Bedienungsanleitung

Lindy

Lindy 51541 Bedienungsanleitung

Diapro T?bbi Ürünler

Diapro T?bbi Ürünler Across System Bedienungsanleitung

Johnson Controls

Johnson Controls Kantech tyco ioSmart Bedienungsanleitung

ACS

ACS ACR122L Bedienungsanleitung

Secukey

Secukey S2-MF Bedienungsanleitung

Elecom

Elecom MR-SMC07 series Bedienungsanleitung

Alien

Alien ALR-9800 Bedienungsanleitung

ACS

ACS ACR310 Bedienungsanleitung

Datamars

Datamars R-IN1300 MID Bedienungsanleitung

Alarm Lock

Alarm Lock AL-PRE2 Bedienungsanleitung

xpr

xpr B100PROX-AH Benutzerhandbuch
