IHome IBT76 Bedienungsanleitung

Color Changing Rechargeable

Bluetooth Speaker

with Speakerphone

instruction manual

Model: iBT76

CHARGE

BEFORE

USE

Introduction

Thank you for purchasing the iHome iBT76. This product is designed to

provide high quality wireless sound for your iPad, iPhone, iPod, computer,

PDA or other Bluetooth audio device.

This instruction booklet explains the basic operation and care of the unit.

Please read it carefully and keep for future reference.

Maintenance

• Place the unit on a level surface away from sources of direct sunlight or

excessive heat.

• Protect your furniture when placing your unit on a natural wood and

lacquered ﬁnish. A cloth or other protective material should be placed

between it and the furniture.

• Clean your unit with a soft cloth moistened only with mild soap and water.

Stronger cleaning agents, such as thinner or similar materials can damage

the surface of the unit.

iBT76

What’s Included

• iBT76 speaker

• Combination micro USB to USB charging cable/audio in cable

• Carry strap

iBT76

Carry strap

Combination

micro USB to USB cable/audio cable

iBT76

Front

Microphone

Back

Bluetooth/

Speakerphone

Button

Color Mode Button

(press and hold for

Battery Review)

Lower/Raise Volume

Buttons

Charging/

Aux-in

USB port

Carry Strap

Channel

Meet Your iBT76

Bottom

Top

Power On/O

Switch

Charging/Bluetooth

Status Indicator

Light

Carry Strap

Channel

(lantern mode)

Getting Started: Carry Strap

The iBT76 has two channels to attach the

included carry strap, one on the bottom to hang

the unit like a lantern, and one on the lower back

of the unit. To attach the carry strap, form a small

loop in one end of the carry strap. Insert this loop

through the desired channel, then pull the

loop back through the larger loop formed in the

carry strap to tighten.

Charging the Unit

CHARGE UNIT BEFORE USE/KEEP UNIT OFF FOR FASTER CHARGING

1. Connect the micro USB plug on the included combination cable to the

micro USB Charging/Aux-in USB Port on the side of the unit.

2. Connect the standard USB plug end of the cable to a power USB port

on a computer, a USB AC adaptor or other USB charging device. For

ﬁrst time use, charge unit for about 4 hours. The status indicator LED

on top of the unit turns solid red while charging and turns o once unit

is fully charged.

iBT76

Charge via computer USB port, USB AC adaptor or other powered USB port

iHome iBT76 USB port

Computer USB port

Computer

connected to

working outlet

iHome iBT76 USB port

USB AC adaptor

(not included)

USB AC adaptor

connected to working outlet

3.To review the charging status of the unit while it is charging, press and

hold the Color Mode Button. The cabinet lights will ﬂash green from

bottom to top for 12 seconds to show unit is charging.

Reviewing Battery Charge Level

(Charger is Disconnected and unit is ON)

1. Press and hold the Color Mode Button when unit is ON but not

charging (micro USB cable not connected) to enter Battery Review

Mode. The cabinet lights will blink and built-in voice will announce the

current battery level.

TIP: On some iOS (Apple)

devices, you can view the iBT76

battery status on your device’s

screen. When device is paired

and connected, look for a

vertical battery icon next to the

Bluetooth icon on the upper

right corner of the

device’s screen.

LowVery Low

RED GREEN

Good High

iBT76

Pairing Your Device

Pairing is the set-up process to introduce your Bluetooth-capable device to

the iBT76. Once your device is paired, the iBT76 can recognize it and you can

play your audio through it.

1. Turn on your Bluetooth device and make it “discoverable”

by turning on Bluetooth mode (check in Options or

Settings).

2. Slide the Power On/O Switch to ON to turn on the

iBT76. The ﬁrst time the unit is powered on, it will enter

auto-pairing mode: the unit will beep and the Bluetooth

status indicator light on top of the unit will ﬂash quickly

while the unit attempts to pair. (If Color Mode is on, the

cabinet lights will ﬂash blue and red.) “iHome iBT76”

should appear in your device’s Bluetooth menu. Select

“iHome iBT76” on device to begin/complete pairing. If

prompted for a passcode, enter “1234” on your device’s

keypad. 1 beep will sound and the Bluetooth status

indicator light will appear solid blue (in Color Mode,

cabinet will ﬂash blue twice), indicating the iBT76 is

paired and ready to play music. There should also be an

indication on your device. If no device is successfully

paired within 3 minutes the iBT76 will default to previous

mode.

3. To pair with a dierent device or at a dierent time, make

sure unit is powered on, then press and hold the

Bluetooth/Speakerphone Button for 2 seconds. Select

“iHome iBT76” on device to pair.

Once the iBT76 is paired to a device, it will attempt to

autolink when the device is within range (about 33 feet).

Using the iBT76

o on

iHome iBT76

Playing Audio Via Bluetooth

1. Slide the Power On/O Switch to ON to turn on the unit. The Bluetooth status

indicator will glow solid blue when a linked device is in range and detected. You

can then listen to audio streamed wirelessly from your paired Bluetooth device.

2. Use controls on your Bluetooth device to play, pause and navigate tracks.

3. Press the –or +Button to adjust the iBT76 volume. You can also adjust volume

on your device.

4. When done listening, slide the Power On/O Switch to OFF to turn the unit OFF.

Remember to turn o your device, too.

Speakerphone Operation

NOTE: The unit must be powered on and linked to a Bluetooth phone to receive a

call.

1. When a call is received, playing music is muted to hear the ring tone and the

cabinet lights ﬂash green. Press the Bluetooth/Speakerphone Button to

answer the call, or press and hold to reject the call. For call waiting function,

press the button again to answer a second call, and once more to return to the

original call. Press and hold to end the current call and return to a remaining

call.

2. When a call is completed, press the Bluetooth/Speakerphone Button to end

the call and resume previous function.

Using the iBT76

Playing Audio via Aux In

1. Connect micro USB charging/audio cable to the Charging/Aux-in USB Port on

the side of the unit and connect the 3.5mm audio plug end to the headphone or

line-out jack on your audio device.

2. Slide the Power On/O Switch to ON to turn the unit ON.

3. Power on the audio device and use the controls on the device to play or pause

audio and to navigate tracks.

4. Press the –or +Button to adjust the system volume. You can also adjust

volume on your device.

5. When done listening, slide the Power On/O Switch to OFF to turn the unit OFF.

Remember to turn o your device, too.

Using Color Modes

There are six color modes, which you cycle through in this order:

a. Slow Fade (colors slowly fade from one into the next

b. Fast Change (colors change rapidly)

c. One Color (select a favorite color)

d. Pulse to Music (lights ﬂash to the beat of the music)

e. Preset Pulsing (each light array pulses through its own preset pattern of colors)

f. O (no display)

1. Slide the Power On/O Switch to ON to turn the unit ON.

2. Press the Color Mode Button repeatedly to cycle to the desired color mode.

For One Color mode, ﬁrst cycle to Fast Change mode and press the Color Mode

Button when the desired color appears. For Pulse to Music, make sure the

volume on your connected Bluetooth device is above 30%.

3. When done, slide the Power On/O Switch to OFF to turn the unit OFF.

Using the iBT76

Unit doesn’t respond (no power)

• Make sure unit is completely charged.

• Check that all connections are correct and properly plugged in.

• Make sure your device is properly paired with the iBT76.

• Make sure the unit is on

Unit doesn’t respond (locked up/ “frozen”)

If the unit does not respond, try resetting the unit. Press and hold both the

+and –Buttons at the same time for about 10 seconds. Note that doing so

will clear settings, and any Bluetooth devices will need to be re-paired.

Trouble pairing device with iBT76

Bluetooth implementation varies depending on your device’s hardware and

operating system. Please see our website for updates on pairing.

• When you power ON the speaker, it will automatically link with the last

previously paired Bluetooth device if the device is still within range

(about 33 feet). To pair with a dierent device you must turn o

Bluetooth capability on the already paired device, or take it out of range.

• If your device does not auto-link when within range, re-pair the device. To

do so, ﬁrst delete the iBT76 from your Bluetooth device’s menu.

• Make sure your device is working properly. Check your device’s manual

for details on Bluetooth pairing and linking.

For further information and to see the latest instructions, visit

www.ihome.com/support

Troubleshooting
