Intel IB840 Bedienungsanleitung

IB840

Socket 478 Pentium 4

Intel 865G Chipset

Full Size CPU Card

USER’S MANUAL

Version 1.0

ii IB840 User’s Manual

Acknowledgments

Award is a registered trademark of Award Software International,

Inc.

PS/2 is a trademark of International Business Machines

Corporation.

IntelandPentium 4areregisteredtrademarks ofIntelCorporation.

Microsoft Windows is a registered trademark of Microsoft

Corporation.

Winbond is a registered trademark of Winbond Electronics

Corporation.

All other product names or trademarks are properties of their

respective owners.

IB840 User’s Manual iii

Table of Contents

Introduction........................................................1

Checklist...........................................................................1

Product Description..........................................................2

Specifications....................................................................3

Product Name........................................................................3

Board Dimensions.............................................................4

Installations........................................................6

Installing the CPU.............................................................7

ATX Power Installation....................................................8

Installing the Memory.......................................................8

Setting the Jumpers...........................................................9

Connectors on IB840 ......................................................18

BIOS Setup........................................................29

Drivers Installation.......................................53

iv IB840 User’s Manual

This page is intentionally left blank.

INTRODUCTION

IB840 User’s Manual 1

Introduction

Checklist

Your IB840 Pentium 4CPU card package should include the items listed

below:

-The IB840 CPU Card

•This User’s Manual

•1 IDE Ribbon Cable

•1 Floppy Ribbon Connector

•SATA Power Cord

•SATA Cable

•2 Serial Port Ribbon Cable and 1 Parallel Port Attached to a

Mounting Bracket

•1 Y-Cable supporting a PS/2 Keyboard and a PS/2 Mouse

•1 CD containing the following:

•Chipset Drivers

•Flash Memory Utility

•Optional audio cable with bracket (Audio8K)

•Optional USB cable with bracket (USB2K-4)

•Optional Secondary CRT VGA cable with bracket (VGA4K, for

use with IBA110)

•Optional TMDS cable with bracket (ID120P, for use with

IBA110)

•Optional TV-out cable (TVOUT-6, for use with IBA120)

•Optional MicroAGP cards (IBA120, IBA110)

INSTALLATIONS

2IB840 User’s Manual

Product Description

The IB840 Pentium 4 CPU card incorporates the Intel 865G chipset that

can utilize a single PGA478 processor of up to 3.2GHz or higher and

supports FSB frequency of 400/533/800Mhz (100Mhz, 133Mhz, and

200Mhz HCLK respectively).

The 865G chipset comes with a Graphics Memory Controller Hub

(GMCH) designed for use with the Pentium 4 processor with 512-KB L2

cache on 0.13 micron process. The GMCH component provides the CPU

interface, DDR interface, AGP interface, Hub Interface, and integrated

graphics with display interfaces.

Aside from CRT support, the VGA function feature a Micro AGP slot for

optional daughter cards:

IBA120: with Chrontel CH7017 chipset that supports dual channel

LVDS, TV-out interface

IBA110: with ATI M7CSP32, M9CSP64 / M10CSP64 chipset,

64MB/32MB frame buffer and supports dual channel LVDS

interface, TMDS and CRT2 display function.

The board also has one Intel 82547EI Gigabit LAN and an Intel 82551

10/100MB fast Ethernet LAN.

Other advanced features include two Serial ATA ports, four USB 2.0

ports, IrDA interface and audio function.

INTRODUCTION

IB840 User’s Manual 3

Specifications

Product Name IB840

Form Factor PICMG (full size CPU card)

CPU Type Socket 478 (Intel Pentium 4 )

CPU Voltage 0.8375V~1.6V (VRD10)

System Speed 1.30G~3.2GHz

CPU Frequency 400 MHz /533MHz/800MHz

Green /APM APM1.2

CPU Socket Socket 478

Chipset

Intel 865G Chipset

GMCH: 82865G 932 pin FC-BGA

ICH5: 82801EB 460 pin MBGA

BIOS Award BIOS, support ACPI Function

Cache 128K/256K/512K Level 2 (CPU integrated)

VGA Two selections:

1. Embedded 82865G, AGP 4X,support CRT interface only.

2. On board ATI Mobility M7/ M9 / M10 graphics

controller, embedded 32/64MB Frame buffer (DDR),

AGP 4X, support CRT, LVDS, TV-out /2nd CRT.

Primary LAN Intel 82551QM LAN controller (10/100Mb)

Secondary LAN Intel 82547EI (10/100/1000Mb) Gigabit LAN

Audio ICH5 Built-in Sound controller + AC97 Codec ALC650, 2x6

12 pin header (Line-out, Line-in, MIC.). Supports 5.1

channels.

Memory type

2 x DDR 2.5V PC266/333/400 DDR SDRAM (without ECC

Function) DIMM Module, Max. capacity -2GB

LPC I/O Winbond 83627HF: IrDAx1 Parallel x1,

COM1(RS-232),COM2(RS-232/RS422/RS485), FDC

2.88MB (3 Mode Support), Hardware monitoring

RTC/CMOS ICH5 Built-in

Battery Lithium Battery

PS2 KB/Mouse Controller built in Winbond 83627HF

Local bus IDE ICH5 built in, IDE1, IDE2 (Ultra DMA 33/66/100)

Serial ATA 2 ports

PCI to ISA Bridge ITE 8888

ISA High drive Supported by SN74ABT16245

USB 4 ports, USB 2.0

IrDA Pin header

Disk On Chip Supports up to 288MB capacity

Watchdog Timer Yes ( 256 segments : 0,1,2,...255 sec/min)

Expansion slots MicroAGP VGA socket for IBA120 and IBA110

D-type

connector PS/2 keyboard/mouse, VGA (CRT), RJ-45 x 2

Power

Connector ATX 12V

System Voltages +5V, +12V, -12V, 5VSB

Board Size 122 x 338 mm

Other Features Modem Wakeup, LAN Wakeup ,

INSTALLATIONS

4IB840 User’s Manual

Board Dimensions

12.917" [328.09mm]

13.317" [338.25mm]

IDE2

0.2" [5.08mm]

4.4" [111.76mm]

4.8" [121.92mm]

0.2" [5.08mm]

JP15

RT3

DIMM1 DIMM2

0.2" [5.08mm]

BZ1

CN1

3.95" [100.33mm]

1.1" [27.94mm]

J16

JP14

BAT1

AGP1

J18

J17

JP13

JP12

J21

J20

J19

J12

CN3

CN2

JP1

J10

IDE1

J14

J13

J11

FDD1

JP2~JP4 J15

JP5~JP11

INTRODUCTION

IB840 User’s Manual 5

INSTALLATIONS

6IB840 User’s Manual

Installations

This section provides information on how to use the jumpers and

connectors on the IB840 in order to set up a workable system. The topics

covered are:

Installing the CPU.............................................................7

ATX Power Installation....................................................8

Installing the Memory.......................................................8

Setting the Jumpers ..........................................................9

Connectors on IB840...................................................... 18
