4/6/2010 RS2MB044 Configuration Guide Page 1 of 5

Intel®RAID Controller RS2MB044

Configuration Guide

All Items Subject to Change

A reference guide to assist customers in ordering components to install a storage solution based on

Intel® RAID Controller RS2MB044

Revision 1.0

January 2010

Enterprise Platforms and Services Marketing

4/6/2010 RS2MB044 Configuration Guide Page 2 of 5

1. Table of Contents

1.Table of Contents................................................................................................................. 2

2.Revision History................................................................................................................... 3

3.Legal Disclaimer...................................................................................................................3

4.RAID Controller and Accessory Ordering Information....................................................4

4.1Table 1: RAID Controllers........................................................................................4

4.2Table 2: Accessories...............................................................................................4

5.Naming Convention.............................................................................................................5

6.JBOD/Solution Guidance .................................................................................................... 5

4/6/2010 RS2MB044 Configuration Guide Page 3 of 5

2. Revision History

Date Rev Modification

Jan 6, 2010 1 First Published Document

3. Legal Disclaimer

INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL® PRODUCTS. NO LICENSE, EXPRESS OR

IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS GRANTED BY THIS DOCUMENT.

EXCEPT AS PROVIDED IN INTEL'S TERMS AND CONDITIONS OF SALE FOR SUCH PRODUCTS, INTEL ASSUMES NO LIABILITY

WHATSOEVER, AND INTEL DISCLAIMS ANY EXPRESS OR IMPLIED WARRANTY, RELATING TO SALE AND/OR USE OF INTEL

PRODUCTS INCLUDING LIABILITY OR WARRANTIES RELATING TO FITNESS FOR A PARTICULAR PURPOSE,

MERCHANTABILITY, OR INFRINGEMENT OF ANY PATENT, COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT.

Intel products are not intended for use in medical, life saving, life sustaining applications. Intel may make changes to specifications and product

descriptions at any time, without notice.

Intel server boards, server chassis, and processors may contain design defects or errors known as errata, which may cause the product to deviate from

published specifications. Current characterized errata are available on request.

Intel, Intel Xeon, Pentium, and the Intel logo are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and

other countries.

*Other names and brands may be claimed as the property of others.

4/6/2010 RS2MB044 Configuration Guide Page 4 of 5

4. RAID Controller and Accessory Ordering Information

4.1 Table 1: RAID Controllers

Image MM /

UPC Product Code Description of Product Qty

Per Min

Order

904993

00735858

213028 RS2MB044

Intel® RAID Controller RS2MB044 - 6Gb/s

SAS, 3Gb/S SAS/SATA, x8 PCIe 2.0, 4

internal and 4 external ports, 512MB

embedded memory, MD2 Low Profile, half

length form factor. Includes Quick Start

Users Guide, and CD ROM with technical

documentation and software.

5 5

4.2 Table 2: Accessories

Image MM /

UPC Product Code Description of Product Qty

Per Min

Order

Same as below with

cable and remote

mounting kit (image not

available)

903148

00735858

210676

AXXRSBBU7

Intel® RAID Smart Battery AXXRSBBU7,

optional battery back up for use with Intel’s

6G SAS RAID add-in cards. Provides 72

hours of cache data retention. Includes

remote mounting kit.

5 5

903767 AXXRSBBU7D10

Intel® RAID Smart Battery AXXRSBBU7

direct attach 10 pack includes 10 BBU and

hardware for direct mounting 10 units.

Provides optional battery backup for up to

72 hours of cache data retention.

10 10

4/6/2010 RS2MB044 Configuration Guide Page 5 of 5

5. Naming Convention

Intel’s 6Gb/s SAS RAID cards have product names per the convention RS2XX##^ where:

R = RAID

S = SAS (“T” would be used for SATA)

2 = specification generation

XX = two letters representing the Intel code name (For example, MB = Mobile Bay)

## = internal port count

^ = external port count

6. JBOD/Solution Guidance

Intel is continually testing JBOD to ensure compatibility with Intel® RAID Controller RS2MB044. For

the latest list, please visit the RSMB044 section of http://support.intel.com.

For information on performance, integration and deployment of Intel RAID, see

http://www.intel.com/go/RAID.
