EtherExpress™PRO/100 Mobile

Adapter 16-bit PC Card

With Integrated 100 Mbps Transceiver

User’s Guide

How to Use This Manual

This User’s Guide contains the latest and most complete information

available at press time on the installation and operation of the

PRO/100 PC Card. It is designed to help both new and experienced

network users install and configure the Intel product in the shortest

time possible.

Overview of the Installation Process

For an overview of the installation process, see the Quick Start Card

and Chapters 1 and 2 in this User’s Guide. For technical details on

configuration issues see Chapter 3, Configuration Reference.

How to Find More Information

Use the Table of Contents, Index, and page and text headings in this

User’s Guide to find what you need. Check the README file on the

Intel Network Driver diskette. For updated drivers, access the Intel

support website at:

http://support.intel.com

See Appendix A for additional support information.

Intel Corporation

5200 N.E. Elam Young Parkway

Hillsboro, OR 97124-6497

Intel Corporation assumes no responsibility for errors or omissions in this

guide. Nor does Intel make any commitment to update the information

contained herein.

*Other product and corporate names may be trademarks of other companies

and are used only for explanation and to the owners’ benefit, without intent to

infringe.

Second edition May 1997 668562-002

iii

Contents

Hardware Installation .............................................. 7

Before Installing Hardware .................................................................. 7

What to Do Next ................................................................................. 11

Software Installation ............................................. 13

Microsoft Windows 95........................................................................ 14

Microsoft Windows NT 4.0 ................................................................ 16

Microsoft Windows NT 3.51 .............................................................. 16

Microsoft MS-DOS............................................................................. 17

IBM OS/2 and OS/2 Warp .................................................................. 17

Microsoft Windows 3.x (including Windows for Workgroups) ........ 17

Running the Intel Installation Program (Windows 3.x including

Windows for Workgroups) ............................................................. 17

Completing the Installation ................................................................ 19

Alphabetical Reference ...................................................................... 20

Artisoft LANtastic version 6.0 ........................................................... 21

AT&T StarGROUP LAN Manager version 2.1a ............................... 21

Banyan VINES version 6.0................................................................. 22

DEC PATHWORKS versions 5.x or 6.x ............................................ 23

FTP Software LANWatch................................................................... 26

FTP Software PC/TCP........................................................................ 28

Generic Installation ............................................................................ 33

HP LAN Manager ............................................................................... 33

IBM Local Area Network Support Program...................................... 33

IBM OS/2 and OS/2 Warp .................................................................. 36

IBM PC LAN and IBM DOS LAN Requester .................................. 36

Manual Installation ............................................................................. 37

Microsoft LAN Manager .................................................................... 37

Microsoft Windows for Workgroups .................................................. 40

CONTENTS

Novell NetWare................................................................................... 46

NetWare Requester for OS/2 .............................................................. 47

SunSoft PC-NFS (version 3.5) ........................................................... 50

Ungermann-Bass Net/One for DOS and OS/2 .................................. 52

Wollongong PathWay Access for DOS .............................................. 54

Configuration Reference ...................................... 57

Who Should Consult This Chapter .................................................... 57

PRO/100 PC Card Features ................................................................ 58

Windows for Workgroups Using the ODI Driver with NetWare

as Secondary Network.................................................................... 66

Windows 95 and Windows NT Driver Parameters Reference .......... 68

Windows 3.x Driver Parameters......................................................... 72

ODI Settings (for drivers M16AODI.COM and M16AODI.OS2) .... 73

NDIS 2.0.1 Settings (for drivers M16ANDIS.EXE and

M16ANDIS.OS2) ........................................................................... 75

Novell Server Driver Settings (for driver M16AODI.LAN) ............. 78

Packet Driver Settings (for driver M16APD.COM) .......................... 78

Diagnostic Test Utility Settings (M16ATEST.EXE) ......................... 79

Keyword Alphabetical Reference....................................................... 80

Troubleshooting .................................................... 85

LED Indicators.................................................................................... 86

Diagnostic Self Test ............................................................................ 87

Error Messages.................................................................................... 89

Windows 95 Troubleshooting............................................................. 92

Microsoft Windows 3.x Troubleshooting .......................................... 96

Network Operating System Troubleshooting under Windows 3.x . 105

Artisoft LANtastic ............................................................................ 105

DEC Pathworks ................................................................................. 106

Windows for Workgroups ................................................................. 107

Novell NetWare................................................................................. 111

Computer-Specific Troubleshooting ................................................ 112

General Troubleshooting Checklist ................................................. 119

Intel Automated Customer Support .................. 121

CONTENTS

Specifications...................................................... 123

Media Interface Specifications......................................................... 123

General Specifications...................................................................... 124

Compatibility .................................................................................... 125

Technical Specifications................................................................... 125

Limited Lifetime Warranty................................. 127

Network Software License Agreement.............. 131

Regulatory Agency Notices ............................... 135

Index..................................................................... 137

CONTENTS

Follow the instructions in this chapter to install PRO/100 PC Card

hardware and network cabling.

See Chapter 2, Software Installation for instructions on how to

install network software using the Intel Installation Program.

Model Number

MBLA1600

This model provides access to both 10Base-T and 100Base-TX

networks with a single adapter cable, and detects 10 Mbps or 100 Mbps

network speed. Note that 100 Mbps operation requires Category 5

(data grade) unshielded twisted pair (UTP) cabling.

Before Installing Hardware

Check Package Contents

Use the following list to check the package contents:

• PRO/100 PC Card

• A network adapter cable with a 15-pin PC Card connector at one

end and a RJ-45 connector at the other (for 100Base-TX or

10Base-T Ethernet connectivity)

• Software on two 3.5-inch diskettes

•Quick Install Card

•User’s Guide

• Product registration card (in this guide)

• Protective adapter case

Chapter 1

Hardware Installation

CHAPTER 1

Note

Please fill out the Product Registration Card and mail it

immediately to the Intel office indicated on the card.

Verify Other Required Equipment

To install the PRO/100 PC Card, you need the following:

1An Ethernet local area network running at 10 or 100 Mbps and a

network operating system supported by the PRO/100 PC Card.

See Chapter 2, Software Installation for a list of the network

operating systems supported.

Note

Since the PRO/100 PC Card, automatically detects the

speed of the network to which it is connected, it may be

safely connected to either a 100Base-TX or 10Base-T

network, as specified in items 2 and 3 below.

2For connection to a 100Base-TX Ethernet network, a Category 5

(data grade) unshielded twisted pair (UTP) network cable

terminating in a male RJ-45 connector.

Note

For 100 Mbps connectivity, network cable must be

Category 5 (data grade) unshielded twisted pair (UTP).

Category 3 (voice grade) wiring is reliable for 10 Mbps,

however Intel recommends using Category 5 wiring

whenever possible.

3For connection to a 10Base-T twisted pair Ethernet network, a

network cable terminating in a male RJ-45 connector and

connected to a 10 Mbps hub or switch.

Determine System Requirements

During installation of the PRO/100 PC Card hardware, power to the

computer may be ON or OFF. For best results, the computer should be

ON and your standard operating software should be loaded. If

configured to do so, your system will detect the PRO/100 PC Card. For

details on how to install driver software for your particular

environment, see Chapter 2, Software Installation.

Hardware Installation

Installing the Hardware

Insert the PRO/100 PC Card

1Grasp the PRO/100 PC Card by the edges with the Intel label

facing upward and the wide PC Card connector next to the insert

slot.

2Insert the PRO/100 PC Card into a PC Card slot and push it in until

it is firmly seated (the Intel Installation Program will determine

what slot the PRO/100 PC Card is in and configure accordingly).

Inserting the PRO/100 PC Card into the Computer

Removing the PRO/100 PC Card

Follow the PC card removal instructions specified in the documentation

for your computer.

The PRO/100 PC Card hardware is compatible with all type II and III

PC Card slots (16-bit or 32-bit). Installation and removal procedures

may vary on different computers. It can safely install in a CardBus, 32-

bit slot.

16 bit

PC Card

Intel EtherExpress

™

PRO/100 Mobile Adapter

CHAPTER 1

Connecting the 10Base-T/100Base-TX Adapter

Cable to the PRO/100 PC Card

• With the Intel logo facing up, attach the 15-pin connector at the

end of the adapter cable to the mating connector on the end of the

PRO/100 PC Card. Press the cable connector gently into the

connector on the PRO/100 PC Card until it clicks into place. Do

not force the connection.

Connecting the 10Base-T/100Base-TX Adapter Cable to the PRO/100

PC Card

16 bit

PC Card

Intel EtherExpress

™

PRO/100 Mobile Adapter

Andere Handbücher für ETHEREXPRESS PRO/100

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Intel Computerhardware Handbücher

Intel

Intel LGA1155 SOCKET - THERMAL MECHANICAL S AND DESIGN GUIDELINES... Bedienungsanleitung

Intel

Intel Xeon 5600 Series Technisches Handbuch

Intel

Intel LGA1155 SOCKET - THERMAL MECHANICAL S AND DESIGN GUIDELINES... Bedienungsanleitung

Intel

Intel Compute Module MFS2600KI Bedienungsanleitung

Intel

Intel Core i7-3960X Bedienungs- und Sicherheitshinweise

Intel

Intel ETHEREXPRESS PRO/100 Bedienungsanleitung

Intel

Intel Pentium III Processor 512K Leitfaden

Intel

Intel iAPX 86 Bedienungsanleitung

Intel

Intel RS25DB080 Installationshandbuch

Intel

Intel Xeon Processor E5-2600 Montageanleitung

Intel

Intel ATOM PROCESSOR N 500 - UPDATE REVISION 001 Bedienungsanleitung

Intel

Intel RS2BL040 - Raid Controller Installationshandbuch

Intel

Intel RS25AB080 Bedienungsanleitung

Intel

Intel NUC Kit NUC11PAHi7 Bedienungsanleitung

Intel

Intel ETHEREXPRESS PRO/100 Bedienungsanleitung

Intel

Intel Xeon Processor E5-2600 Bedienungsanleitung

Intel

Intel P9500 - Core 2 Duo 2.53 GHz 6M L2 Cache 1066MHz FSB Socket P Mobile... Bedienungsanleitung

Intel

Intel 45NM - Phenom II X4 925 AM3 2.8GHZ 8MB 95W 4000MHZ... Bedienungsanleitung

Intel

Intel Dialogic D/240SC-T1 Bedienungsanleitung

Intel

Intel Quark SoC X1000 Bedienungsanleitung

Intel

Intel 925 - Pentium D 925 3.0GHz 800MHz 4MB-Cache Socket 775... Bedienungsanleitung

Intel

Intel 852GME Leitfaden

Intel

Intel BX80623G530 Bedienungsanleitung

Intel

Intel G22856-001 Installationshandbuch

Beliebte Computerhardware Handbücher anderer Marken

EMC2

EMC2 VNX Series Betriebsanleitung

Panasonic

Panasonic DV0PM20105 Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Bedienungsanleitung

Gigabyte

Gigabyte B660M DS3H AX DDR4 Bedienungsanleitung

Raidon

Raidon iT2300 Bedienungsanleitung

National Instruments

National Instruments PXI-8186 Bedienungsanleitung

Hauppauge

Hauppauge WinTV-HVR-2250 Bedienungsanleitung

Kontron

Kontron CP6002 Bedienungsanleitung

Manhattan

Manhattan 702843 Bedienungsanleitung

Aphex

Aphex 230 Bedienungsanleitung

AMD

AMD Phenom II Betriebshandbuch

dbx

dbx Zone Pro 1260 Bedienungsanleitung

Galaxy

Galaxy GHDX2-2430S-24F4D Bedienungsanleitung

Kontron

Kontron DIMM-PC/MD Bedienungsanleitung

ST X-NUCLEO-SAFEA1B Betriebsanleitung

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Bedienungsanleitung

Advantech

Advantech ASMB-935 Series Bedienungsanleitung

Jupiter

Jupiter RAM PACK Bedienungsanleitung
