Intel® Server Chassis SR2400/SR2400DC

User Guide

Order Number: C51501-003

Disclaimer

Information in this document is provided in connection with Intel®products. No license, express or implied, by estoppel or

otherwise, to any intellectual property rights is granted by this document. Except as provided in Intel’s Terms and Conditions

of Sale for such products, Intel assumes no liability whatsoever, and Intel disclaims any express or implied warranty, relating

to sale and/or use of Intel products including liability or warranties relating to fitness for a particular purpose, merchantability,

or infringement of any patent, copyright or other intellectual property right. Intel products are not designed, intended or

authorized for use in any medical, life saving, or life sustaining applications or for any other application in which the failure of

the Intel product could create a situation where personal injury or death may occur. Intel may make changes to

specifications and product descriptions at any time, without notice.

Intel server boards contain a number of high-density VLSI and power delivery components that need adequate airflow for

cooling. Intel’s own chassis are designed and tested to meet the intended thermal requirements of these components when

the fully integrated system is used together. It is the responsibility of the system integrator that chooses not to use Intel

developed server building blocks to consult vendor datasheets and operating parameters to determine the amount of airflow

required for their specific application and environmental conditions. Intel Corporation can not be held responsible if

components fail or the server board does not operate correctly when used outside any of their published operating or non-

operating limits.

Intel, Intel Pentium, and Intel Xeon are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the

United States and other countries.

*Other names and brands may be claimed as the property of others.

Preface

Intel® Server Chassis SR2400/SR2400DC User Guide iii

Preface

About this Manual

Thank you for purchasing and using an Intel®Server Chassis SR2400/SR2400DC.

This manual is written for system technicians who are responsible for troubleshooting, upgrading,

and repairing this server chassis. This document provides a brief overview of the features of the

board/chassis, a list of accessories or other components you may need, troubleshooting information,

and instructions on how to add and replace components on the Intel Server Chassis

SR2400/SR2400DC. For the latest version of this manual, refer to

http://support.intel.com/support/motherboards/server/chassis/SR2400/manual.htm

✏NOTE

The Server Chassis SR2400/SR2400DC is used for multiple server boards.

Before purchasing or attempting to install any component discussed in this

manual, refer to the documentation provided with your server board to ensure

the component is compatible with your server board.

Manual Organization

Chapter 1 provides a brief overview of the Server Chassis SR2400/SR2400DC. In this chapter, you

will find a list of the server chassis features, pictures of the product, and product diagrams to help

you identify components and their locations.

Chapter 2 provides instructions on adding and replacing components. Use this chapter for step-by-

step instructions and diagrams for installing or replacing components such as the front panel board,

fans, power supply and other components.

At the back of this book, you will find some technical specifications1, regulatory information,

“getting help” information, and the warranty.

Product Accessories

The server chassis is compatible with the following Intel®Server Boards and Platforms:

 Intel®Server Board SE7520JR2

 Intel®Server Board SE7320VP2

 Intel®Server Platform SR2400SYS (integrated system)

 Intel®Server Platform SR2400SYSD2 (integrated system)

1For complete technical specifications and additional technical information, see the Intel® Server Chassis

SR2400/SR2400DC Technical Product Specification. See “Additional Information and Software” to find a

Web link to this document.

Your Server Chassis SR2400/SR2400DC shipped with the following items 2:

 A box of hardware components, referred to below as the “hardware box”

 One 700-W power supply (AC version) or one 600-W power supply (DC version), installed in

the chassis

 Low-profile PCI-X riser, installed in the chassis

 CD-ROM / DVD drive tray, installed in the chassis

 Four system fans, installed in the chassis

 Chassis intrusion switch, installed in the chassis

 Air baffle, installed in the chassis

 Processor air duct, installed in the chassis

 CD-ROM filler panel, in the hardware box

 Floppy carrier assembly, in the hardware box

 Six 32- 8mm screws, in the hardware box

 Cables, in the hardware kit box

 Rack handles, in the hardware box

 Quick Start User’s Guide, in the chassis box

 Attention document, in the chassis box

You must have one item from each of the following groups 3:

 Riser option, choose one:

⎯ Full-height PCI-X riser

⎯ Full-height performance PCI-X riser

⎯ Full-height PCI-Express* riser

 Hard drive installation option kit, choose one:

⎯ SCSI hot-swap backplane kit

⎯ SATA hot-swap backplane kit

⎯ Fixed SATA drive kit

 Control panel, choose one:

⎯ Standard control panel

⎯ Intel®Local Control Panel 4

2The contents list includes only items included with the Intel Server Chassis SR2400/SR2400DC. This list

does not include items that are shipped and pre-installed in the Intel Server Platform SR2400JR2.

3Before purchasing any required options, refer to your server board documentation to determine which

option(s) are supported on your server board.

4The Intel®Local Control Panel requires the installation of the optional Intel® Management Module –

Professional or Intel® Management Module – Advanced

Preface

Intel® Server Chassis SR2400/SR2400DC User Guide v

You may also need or want to purchase one or more of the following items for your server: 5

 Server rack cabinet and rails / brackets to mount the server into a rack

 Cable management arm

 Front bezel for the selected control panel option

 Processor(s) and heat sink(s)

 Memory DIMMs

 Intel®Management Module (Advanced or Professional)

 Tape drive kit

 Redundant fan kit (includes four fans)

 Redundant power supply

 Sixth drive SCSI or SATA kit

 Slimline CD-ROM drive or DVD-ROM drive

 Slimline floppy drive

 Kit to convert a hard drive bay to a floppy drive bay

For information about which of these items have been tested and can be used with your chassis, and

for ordering information for Intel products, see

http://www.support.intel.com/support/motherboards/server/chassis/SR2400/

5Before purchasing any optional items, refer to your server board documentation to determine which items

are supported on your server board.

Additional Information and Software

If you need more information about this product or information about the accessories that can be

used with this server board, use the following resources.

These sources are available at

http://support.intel.com/support/motherboards/server/chassis/SR2400/

Unless otherwise indicated in the table below, once on this Web page, type the document or

software name in the search field at the left side of the screen and select the option to search “This

Product.”

For this information or software Use this Document or Software

For in-depth technical information

about this product, including BIOS

settings and chipset information

Technical Product Specification

If you just received this product and

need to install it

Quick Start User’s Guide in the product box

For virtual system tours and

interactive repair information

A link to the SMaRT Tool is available under “Other Resources” at the right side

of the screen

Accessories or other Intel server

products

Search for “Spares and Configuration Guide”

Hardware (peripheral boards,

adapter cards) and operating

systems that have been tested with

this product

Search for “Tested Hardware and Operating System List”

Server boards that have been

tested with this product

Search for “Compatible Server Board”

Processors that have been tested

with this product

See your server board documentation

DIMMs that have been tested with

this product

See your server board documentation

To make sure your system falls

within the allowed power budget

See your server board documentation

For software to manage your Intel®

server

See your server board documentation

For drivers See your server board documentation

For firmware and BIOS updates See your server board documentation

For diagnostics test software See your server board documentation

Preface

Intel® Server Chassis SR2400/SR2400DC User Guide vii

Safety Information

WARNING

Before working with your server product, whether you are using this guide or any other

resource as a reference, pay close attention to the safety instructions. You must adhere to the

assembly instructions in this guide to ensure and maintain compliance with existing product

certifications and approvals. Use only the described, regulated components specified in this

guide. Use of other products / components will void the UL listing and other regulatory

approvals of the product and will most likely result in noncompliance with product

regulations in the region(s) in which the product is sold.

Emissions Disclaimer

To ensure EMC compliance with your local regional rules and regulations, the final configuration

of your end system product may require additional EMC compliance testing. For more information

please contact your local Intel Representative.

See “Regulatory and Integration Information” for product Safety and EMC regulatory compliance

information. This is an FCC Class A device. Integration of it into a Class B chassis does not result

in a Class B device.

Intended Uses

This product was evaluated as Information Technology Equipment (ITE), which may be installed in

offices, schools, computer rooms, and similar commercial type locations. The suitability of this

product for other product categories and environments (such as: medical, industrial,

telecommunications, NEBS, residential, alarm systems, test equipment, etc.), other than an ITE

application, may require further evaluation.

EMC Testing

Before computer integration, make sure that the chassis, power supply, and other modules have

passed EMC testing using a server board with a microprocessor from the same family (or higher)

and operating at the same (or higher) speed as the microprocessor used on this server board.

Main DC Power Disconnect (Intel® Server Chassis SR2400DC)

You are responsible for installing a properly rated DC power disconnect for the system. The main

disconnect must be readily accessible, and it must be labeled as controlling power to the system.

The circuit breaker of a centralized DC power system may be used as a disconnect device when

easily accessible and should be rated at no more than 10 amps.

Grounding the Server (Intel® Server Chassis SR2400DC only)

To avoid the potential for an electrical shock hazard, you must reliably connect an earth-grounding

conductor to the server. The earth- grounding conductor must be a minimum 18AWG connected to

the earth ground stud(s) on the rear of the chassis. The safety ground conductor should be

connected to the chassis stud with a Listed closed two-hole crimp terminal with a maximum width

of 0.25 inches. The nuts on the chassis earth-ground studs should be installed with a 10 in/lb torque.

The safety ground conductor provides proper grounding only for the system. You must provide

additional proper grounding for the rack and other devices installed in it.

viii

Warnings

System power on/off: The power button DOES NOT turn off the system

AC or DC power. To remove power from system, you must unplug the AC

power cord from the wall outlet or remove the DC external source. Make

sure the AC power cord is unplugged or DC external source removed before

you open the chassis, add, or remove any components.

Hazardous conditions, devices and cables:Hazardous electrical

conditions may be present on power, telephone, and communication cables.

Turn off the server and disconnect the power cord, telecommunications

systems, networks, and modems attached to the server before opening it.

Otherwise, personal injury or equipment damage can result.

Electrostatic discharge (ESD) and ESD protection: ESD can

damage disk drives, boards, and other parts. We recommend that you

perform all procedures in this chapter only at an ESD workstation. If one is

not available, provide some ESD protection by wearing an antistatic wrist

strap attached to chassis ground⎯any unpainted metal surface⎯on your

server when handling parts.

ESD and handling boards: Always handle boards carefully. They can be

extremely sensitive to ESD. Hold boards only by their edges. After removing

a board from its protective wrapper or from the server, place the board

component side up on a grounded, static free surface. Use a conductive foam

pad if available but not the board wrapper. Do not slide board over any

surface.

Installing or removing jumpers: A jumper is a small plastic encased

conductor that slips over two jumper pins. Some jumpers have a small tab on

top that you can grip with your fingertips or with a pair of fine needle nosed

pliers. If your jumpers do not have such a tab, take care when using needle

nosed pliers to remove or install a jumper; grip the narrow sides of the

jumper with the pliers, never the wide sides. Gripping the wide sides can

damage the contacts inside the jumper, causing intermittent problems with

the function controlled by that jumper. Take care to grip with, but not

squeeze, the pliers or other tool you use to remove a jumper, or you may

bend or break the stake pins on the board.

Preface

Intel® Server Chassis SR2400/SR2400DC User Guide ix

Safety Cautions

Read all caution and safety statements in this document before performing any of the instructions.

See also Intel Server Boards and Server Chassis Safety Information at

http://support.intel.com/support/motherboards/server/sb/CS-010770.htm.

The power supply in this product contains no user-serviceable parts. There may be

more than one supply in this product. Refer servicing only to qualified personnel.

Do not attempt to modify or use the supplied AC power cord if it is not the exact type

required. A product with more than one power supply will have a separate AC power

cord for each supply.

The power button on the system does not turn off system AC power. To remove AC

power from the system, you must unplug each AC power cord from the wall outlet or

power supply.

The power cord(s) is considered the disconnect device to the main (AC) power. The

socket outlet that the system plugs into shall be installed near the equipment and shall

be easily accessible.

SAFETY STEPS: Whenever you remove the chassis covers to access the inside of

the system, follow these steps:

1. Turn off all peripheral devices connected to the system.

2. Turn off the system by pressing the power button.

3. Unplug all AC power cords from the system or from wall outlets.

4. Label and disconnect all cables connected to I/O connectors or ports on the

back of the system.

5. Provide some electrostatic discharge (ESD) protection by wearing an

antistatic wrist strap attached to chassis ground of the system—any

unpainted metal surface—when handling components.

6. Do not operate the system with the chassis covers removed.

After you have completed the six SAFETY steps above, you can remove the system

covers. To do this:

1. Unlock and remove the padlock from the back of the system if a padlock has

been installed.

2. Remove and save all screws from the covers.

3. Remove the covers.

For proper cooling and airflow, always reinstall the chassis covers before turning on

the system. Operating the system without the covers in place can damage system

parts. To install the covers:

1. Check first to make sure you have not left loose tools or parts inside the

system.

2. Check that cables, add-in boards, and other components are properly

installed.

3. Attach the covers to the chassis with the screws removed earlier, and tighten

them firmly.

4. Insert and lock the padlock to the system to prevent unauthorized access

inside the system.

5. Connect all external cables and the AC power cord(s) to the system.

A microprocessor and heat sink may be hot if the system has been running. Also,

there may be sharp pins and edges on some board and chassis parts. Contact should

be made with care. Consider wearing protective gloves.

Danger of explosion if the battery is incorrectly replaced. Replace only with the same

or equivalent type recommended by the equipment manufacturer. Dispose of used

batteries according to manufacturer’s instructions.

The system is designed to operate in a typical office environment. Choose a site that

is:

 Clean and free of airborne particles (other than normal room dust).

 Well ventilated and away from sources of heat including direct sunlight.

 Away from sources of vibration or physical shock.

 Isolated from strong electromagnetic fields produced by electrical devices.

 In regions that are susceptible to electrical storms, we recommend you plug

your system into a surge suppresser and disconnect telecommunication lines

to your modem during an electrical storm.

 Provided with a properly grounded wall outlet.

 Provided with sufficient space to access the power supply cord(s), because

they serve as the product’s main power disconnect.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Intel Server Handbücher

Intel

Intel ISP1100 - Server Platform - 0 MB RAM Bedienungsanleitung

Intel

Intel SE7501BR2 - Server Board Motherboard Kurzanleitung zur Einrichtung

Intel

Intel OCPRF100 MP Bedienungsanleitung

Intel

Intel R1000WF Series Konfigurationshandbuch

Intel

Intel SC5650BCDP Sicherheitsleitfaden

Intel

Intel SR1550AL - Server System - 0 MB RAM Bedienungsanleitung

Intel

Intel SR2612UR - Server System - 0 MB RAM Betriebsanleitung

Intel

Intel M50FCP2UR Bedienungsanleitung

Intel

Intel NSC2U - IP Network Server Bedienungsanleitung

Intel

Intel R1304BTLSFAN Einrichtungshandbuch

Intel

Intel MB440LX Benutzerhandbuch

Intel

Intel R200LH2 Bedienungsanleitung

Intel

Intel TIGI2U - Carrier Grade Server Bedienungsanleitung

Intel

Intel P4304SC2SFEN Bedienungsanleitung

Intel

Intel MFSYS25 - AXXPSU 1000W Power Supply Module Bedienungsanleitung

Intel

Intel SR1560SF - Server System - 0 MB RAM Bedienungsanleitung

Intel

Intel R1000WF Series Bedienungsanleitung

Intel

Intel SPSH4 - Server Platform - 0 MB RAM Bedienungsanleitung

Intel

Intel SR2300 - FRONT BEZEL BLK Konfigurationshandbuch

Intel

Intel P4000RP Bedienungsanleitung

Intel

Intel MFSYS25V2 Bedienungsanleitung

Intel

Intel SR1630GP - Server System - 0 MB RAM Bedienungsanleitung

Intel

Intel R1000SPO series Konfigurationshandbuch

Intel

Intel SR1530CL - Server System - 0 MB RAM Bedienungsanleitung

Beliebte Server Handbücher anderer Marken

HP AlphaServer ES47 Bedienungsanleitung

Dell

Dell PowerEdge R410 Bedienungsanleitung

PowerNAS

PowerNAS CMA Bedienungsanleitung

Supero

Supero FatTwin F617R3-FT Bedienungsanleitung

MSI

MSI P1-109N-L70 Bedienungsanleitung

Dell

Dell PowerEdge XE9640 Handbuch

Dell

Dell PS4100 Montageanleitung

EtroVISION

EtroVISION EV3151 Bedienungsanleitung

NEC

NEC Express5800/T110j Bedienungsanleitung

HP ProLiant Gen9 Bedienungsanleitung

Compaq

Compaq ProLiant 3000 Handbuch

Dell

Dell PowerEdge 3YPMN Bedienungsanleitung

iRobo

iRobo IPC2U Bedienungsanleitung

Nortel

Nortel 1000 Con?guration guide Bedienungsanleitung

Asus

Asus AP7500 Bedienungs- und Wartungshandbuch

Avid Technology

Avid Technology AirSpeed 5000 Bedienungsanleitung

HP Integrity rx2600 Installationsanleitung

Milestone

Milestone Husky IVO 350T Bedienungsanleitung
