Interlogix TVB-1101 Bedienungsanleitung

TruVision IP Camera

Installation Guide

P/N 1072668A-EN • REV 1.0 • ISS 24SEP13

Inc.

Interlogix is part of UTC Climate Controls & Security, a

unit of United Technologies Corporation. All rights

reserved.

Trademarks and

patents

The TruVision name and logo are trademarks of United

Technologies.

Other trade names used in this document may be

trademarks or registered trademarks of the

manufacturers or vendors of the respective products.

Manufacturer UTC Fire & Security Americas Corporation, Inc.

2955 Red Hill Avenue, Costa Mesa, CA 92626-5923,

USA

Authorized EU manufacturing representative:

UTC Fire & Security B.V.

Kelvinstraat 7, 6003 DH Weert, The Netherlands

Certification

N4131

FCC compliance Class A: This equipment has been tested and found to

comply with the limits for a Class A digital device,

pursuant to part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against

harmful interference when the equipment is operated in

a commercial environment. This equipment generates,

uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the instruction

manual, may cause harmful interference to radio

communications. Operation of this equipment in a

residential area is likely to cause harmful interference in

which case the user will be required to correct the

interference at his own expense.

ACMA compliance Notice! This is a Class A product. In a domestic

environment this product may cause radio interference

in which case the user may be required to take

adequate measures.

Canada This Class A digital apparatus complies with Canadian

ICES-003.

Cet appareil numérique de la classe A est conforme à

la norme NMB-0330 du Canada.

European Union

directives

12004/108/EC (EMC directive): Hereby, UTC Fire &

Security declares that this device is in compliance with

the essential requirements and other relevant

provisions of Directive 2004/108/EC.

2002/96/EC (WEEE directive): Products marked with

this symbol cannot be disposed of as unsorted

municipal waste in the European Union. For proper

recycling, return this product to your local supplier upon

the purchase of equivalent new equipment, or dispose

of it at designated collection points. For more

information see: www.recyclethis.info.

Contact information For contact information, see www.interlogix.com or

www.utcfssecurityproducts.eu.

Installation Guide 5

Content

Introduction 6

Product overview 6

Installation 7

Installation environment 7

Package contents 8

Cable requirements 8

Camera description 9

Setting up the camera 12

Accessing the SD card 13

Mounting the bullet camera 13

Mounting the VF dome camera 15

Mounting the indoor mini dome camera 19

Mounting the wedge dome camera 21

Using the camera with an Interlogix NVR or Hybrid DVR or

another system 22

Using the camera with TruVision Navigator 22

Specifications 23

TruVision IP bullet cameras 23

TruVision IP indoor mini dome 23

TruVision IP wedge cameras 24

TruVision IP VF mini dome cameras 24

Pin definitions 25

6 Installation Guide

Introduction

Product overview

This is the installation guide for TruVision IP camera models:

TVB-1101 (1.3MPX IP bullet camera, PAL)

TVB-3101 (1.3MPX IP bullet camera, NTSC)

TVB-1102 (3MPX IP bullet camera, PAL)

TVB-3102 (3MPX IP bullet camera, NTSC)

TVD-1103 (1.3MPX IP VF mini dome, PAL)

TVD-3103 (1.3MPX IP VF mini dome, NTSC)

TVD-1104 (3MPX IP VF mini dome, PAL)

TVD-3104 (3MPX IP VF mini dome, NTSC)

TVD-1101 (1.3MPX IP indoor mini dome, PAL)

TVD-3101 (1.3MPX IP indoor mini dome, NTSC)

TVD-1102 (3MPX IP indoor mini dome, PAL)

TVD-3102 (3MPX IP indoor mini dome, NTSC)

TVW-1101 (1.3MPX IP wedge dome, PAL)

TVW-3101 (1.3MPX IP wedge dome, NTSC)

TVW-1102 (3MPX IP wedge dome, PAL)

TVW-3102 (3MPX IP wedge dome, NTSC)

Installation Guide 7

Installation

This section provides information on how to install the

cameras.

Installation environment

When installing your product, consider these factors:

• Electrical: Install electrical wiring carefully. It should be

done by qualified service personnel. Always use a proper

PoE switch or a 12 VDC UL listed Class 2 or CE certified

power supply to power the camera. Do not overload the

power cord or adapter.

• Ventilation: Ensure that the location planned for the

installation of the camera is well ventilated.

• Temperature: Do not operate the camera beyond the

specified temperature, humidity or power source ratings.

The operating temperature of the camera is between -30

to +60°C (-22 to 140°F). Humidity is below 90%.

• Moisture: Do not expose the camera to rain or moisture,

or try to operate it in wet areas. Turn the power off

immediately if the camera is wet and ask a qualified

service person for servicing. Moisture can damage the

camera and also create the danger of electric shock.

• Servicing: Do not attempt to service this camera

yourself. Any attempt to dismantle or remove the covers

from this product will invalidate the warranty and may

also result in serious injury. Refer all servicing to qualified

service personnel.

• Cleaning: Do not touch the sensor modules with fingers.

If cleaning is necessary, use a clean cloth with some

ethanol and wipe the camera gently. If the camera will not

8 Installation Guide

be used for an extended period of time, put on the lens

cap to protect the sensors from dirt.

Package contents

Check the package and contents for visible damage. If any

components are damaged or missing, do not attempt to use

the unit; contact the supplier immediately. If the unit is

returned, it must be shipped back in its original packaging.

Package contents:

Camera

Hex wrench (for dome and mini dome cameras only)

Installation manual

CD with Configuration manual and TruVision Device

Finder

CAUTION: Use direct plug-in UL listed power supplies

marked Class 2/CE certified or LPS (limited power source) of

the required output rating as listed on the unit.

Cable requirements

For proper operation, adhere to the following cable and power

requirements for the cameras. Category 5 cabling or better is

recommended. All network cabling must be installed according

to applicable codes and regulations.

Table 1 on page 9 lists the requirements for the cables that

connect to the camera.

Installation Guide 9

Table 1: Recommended power cable requirements

Bullet camera:

Mini dome:

Wedge camera:

12 VDC power jack or PoE (802.3af)

PoE (802.3af)

12 VDC power jack or PoE (802.3af)

VF dome camera: 12 VDC power jack or PoE (802.3af)

Camera description

Figure 1: IP bullet camera

Adjustable

bracket

Housing

Sun

shield

Grounding

screws

Reset button

10 Installation Guide

Figure 2: IP indoor mini dome camera

1. Base

2. Lens

3. Dome liner

4. Housing

5. Ethernet RJ45 and BNC

cable

6. Safety cable
