Intermec Sabre 1551E Bedienungsanleitung

1

Initial 1551E Set up for WinLEBCI and SIMM Users ONLY

Note: If you are NOT a WinLEBCI or SIMM user, please disregard this set-up sheet,

and please refer to the Getting Started Guide for installation instructions.

STEP 1: Remove 1551E from box, attach cable to scanner and plug scanner into terminal.

STEP 2: Power up the computer terminal.

STEP 3: Scan the TWO barcodes associated with the task you are to perform; WinLEBCI

requires first two barcodes, SIMM requires last two barcodes.

Reset factory defaults

Predefined terminal selections - RS-232 - standard RS-232 C (9600, 7, E, 2)

RS-232 - postamble - Carriage Return

\46\42\41\4A\01\24\45\54\3E\0D\60

Disable all symbologies

Code 11 - active

Code 11 - check digit – 1 digit (*)

Code 11 - check digit - checked and transmitted (*)

Code 39 - active (*)

Code 39 - format - full ASCII

Code 128 / EAN 128 - active

41\4B\42\44\45\43\45\45\41\4C\42\4B\41\5A\60

Reset factory defaults

Predefined terminal selections - Keyboard wedge - standard PC - QWERTY English

Keyboard wedge - postamble - Tab

46\42\41\4A\03\08\45\54\04\02\08\60

Disable all symbologies

Code 11 - active

Code 11 - check digit – 1 digit (*)

Code 11 - check digit - checked and transmitted (*)

Code 39 - active (*)

Code 39 - format - full ASCII

Code 128 / EAN 128 - active

41\4B\42\44\45\43\45\45\41\4C\42\4B\41\5A\60

Note: Scanner configuration needs only to be performed once prior to initial use. The

1551E scanner will retain configuration settings even if power is disconnected.

Technicians – please retain for your records.

WinLEBCI Users:

Both barcodes must

be scanned in the

order presented

before installing the

scanner for the first

time.

SIMM Users:

Both barcodes must

be scanned in the

order presented

before installing the

scanner for the first

time.

6001 36th Avenue West

P.O. Box 4280

Everett, WA 98203-9280

© 2001 Intermec

All Rights Reserved

Part No. 071632-001

*071632-001*

*071632-001*
