ITSU IS0148 Bedienungsanleitung
AROMA DIFFUSER
IS0148 user manual
This appliance can be used by
children aged from 8 years and
above and persons with reduced
physical,sensory or mental capa-
bilities or lack of experience and
knowledge if they have been giv-
en supervision or instruction con-
cerning use of the appliance in a
safe way and understand the haz-
WARNING
AROMA DIFFUSER
ards involved. Children shall not
play with the appliance. Cleaning
and user maintenance shall not
be made by children without sup-
ervision.
It must only be supplied at safety
extra low voltage corresponding to
the marking on the appliance.
Unplug the appliance during fill-
ing and cleaning.
AROMA DIFFUSER
Do not empty water from the
side which air-vent located.
Do not lean the aroma diffuser
during operation.
A .FUNCTION
B .SPECIFICATION
C .INSTALLATION
D .MAINTENANCE
E .TROUBLESHOOTING
AROMA DIFFUSER
With innovative and unique design, this Aroma
Diffuser combines the soul of both orient and western
cultures with new fashion and modern science.
By breaking up the mixture of water and essential oil into
millions of micro-particles, a stream of air entirely diffuses
activated ingredients of blended essential oil, which could
be easily absorbed by body and stay long in the room.
Under the richly enhanced effect as aromatherapy, your nerve
would be eased gradually and your skin would be moisturized
at the same time.
Product name: Aroma Diffuser
Product Size: ø147mmXH131mm
Input Voltage: 5.0V 5.0W
Water Load: 150mL
A.Top Cover
B.Base
C. USB Line
(Water Tank)
1. Air-Vent
2. Max water level line
3. Ceramic disc
4. Untime LED1
5. 2 Hour LED2
Once
Twice
Mist ON
LED1 ON
POWER OFF
Changing
Times Of Key
Pressed Light
Mist
Color choose
Left Button Right Button
Long press
( 2 second)
6. 4 Hour LED3
(untime)
POWER OFF
Short Press
Light Mode
Light OFF
Timer Mode
2 hour(LED2 ON)
4 hour(LED3 ON)
Three times Changing
untime(LED1 ON)
1
23
4 5 6
AROMA DIFFUSER
Max Water level
line 150ml
Left Button Right Button
,
,
Important Notes Before Use:
tap water,pure water or mineral water in normal temperature(no
demineralized water).Corrosive liquid is not suitable to this unit.
B.Fill water (150ml) into the water tank.
C.Water-soluble essential oil is recommended. Be careful, some
essential oils are corrosive so they can affect your item.Please
contact your local dealer for further information.
D.When the product is tripped during opeartion,liquid may then
flow into the internal space of the unit. Unplug the power
and empty all water,keep the unit standing still in a ventilated
place for 3 days.If there s anything wrong when you reuse,
contact your local dealer for help.
A.Place the unit on an even surface,It s suggested to put on
2.Fill water(Max.150mL)
Into the water tank.
3.Add 2~3 drops of
essential oil into
the water
1.Take out all the cover.
DO NOT EXCEED
THE MAX WATER
LEVEL LINE
1
2
3
AROMA DIFFUSER
4.Put back the cover
4
7.Press the power button and enjoy.
5-6.Plug the adapter and press
the power button
5
6
MAINTENANCE
3.Twist the cover
and take it out.
1-2.Power off the unit and
then pull out the plug
1
2
3
AROMA DIFFUSER
4.Empty water from the back side and
avoid water flowing into the air-vent.
5.Use a clean swab or cloth to
clean the unit(At least once
per 3 days is suggested).
6.Keep it clean and dry if you don’t use it
for long time.
AROMA DIFFUSER
There is too much water
(more than 150 ml).
The power lead is not connected.
Plug the adapter into an
electric socket and turn
the power switch on.
There is not enough water. Pour a sufficient quantity
of water in.
Take out excess water.
The lid is obstructed by water
droplets or other particles.
Clean the obstruction with
a cotton bud and leave the
area ventilated.
POSSIBLE CAUSE SOLUTION
+603 67323722
AROMA DIFFUSER
警告
本产品可用于8岁以上的儿童以及受过安
全使用方面的监督或指导，并了解所涉及的危
险的那些感官或精神能力较弱或缺乏经验和知
识的人员。 儿童不得玩耍本产品。
儿童不得在没有监督的情况下进行清洁和
用户维护。
只能以与设备标记相对应的安全超低电压
供电。
在填充和清洁过程中，请拔下设备电源。
请勿从出风口所在的一侧倒水。
在操作过程中，请勿倾斜香气扩散器。
AROMA DIFFUSER
产品目录
A .产品功能
B .产品规格
C .操作方式
D .维护保养
E .疑难排解
产品功能
这款香薰机采用创新和独特的设计，将东方和西方文化
的灵魂与新时尚和现代科学融为一体。
通过将水和香精油的混合物分解成数百万个微粒，空气
流会完全扩散混合香精油的活性成分，这些成分很容易被人
体吸收并在室内停留很长时间。
在如芳香疗法这样的丰富增强效果下，您的神经将逐渐
被舒缓，同时皮肤将被保湿。
