USER MANUAL

4K60 Wall Plate Extender with HDMI/Type-C Inputs

JTD-2987 I JTECH-EXW30

Table of Contents

1. Introduction.....................................................................................................................

2. Features...........................................................................................................................

3. Package Contents.........................................................................................................

4. Specifications.................................................................................................................

5. Product Dimensions.....................................................................................................

6. Operation Controls and Functions..........................................................................

6.1 Transmitter Panel....................................................................................................

6.2 Receiver Panel.........................................................................................................

7. Application Example.....................................................................................................

8. Maintenance...................................................................................................................

9. Warranty...........................................................................................................................

10. Mail-In Service..............................................................................................................

11. Limited Warranty Limits and Exclusions................................................................

1. Introduction

2. Features

3. Package Contents

1× 18Gbps CAT 50M with USB-C/HDMI Wall Plate Transmitter

1× User Manual

The wall plate is a 2x1 switcher and CAT transmitter with HDMI and USB-C

inputs. It features a US one-gang enclosure for Decora-style wall plate

openings with interchangeable black and white wall plates and faceplates.

Support video resolution up to 4K2K@50/60Hz 4:4:4. CAT6 output can

extend video transmission distance up to 164ft / 50m.

The product is remotely powered by the receiver or other CAT-equipped

devices via POC.

Compliant with HDMI 2.0b, HDCP 2.2 and Display Port 1.2a

HDMI input supports 18Gbps video bandwidth;

USB-C input supports 5.4Gbps video bandwidth

Video resolution up to 4K2K@50/60Hz 4:4:4

CAT6 output can extend video transmission distance up to 164ft / 50m

for 4K@24 or 115ft / 35m for 4K@60 444 via a single CAT5e/6 cable

Support 3D, HDR10 and Dolby Vision

HDMI audio formats support LPCM, Dolby Digital/Plus/EX, Dolby True

HD, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio, DSD

Support HDMI and USB-C input

With USB-C charging port

US one-gang enclosure for Decora-style wall plate openings

Input signal selection supports automatic mode and manual mode

Support POC function (only from Receiver to Transmitter)

Available in white or black coating

4. Specifications

Human body model — ±8kV (Air-gap discharge) &

±4kV (Contact discharge)

ESD Protection

Technical

HDMI Compliance HDMI 2.0b

HDCP Compliance HDCP 2.2

HDMI: 18 Gbps

Video Resolution 480i~1080p50/60Hz, 4Kx2K@24/30Hz, 4k2k@60Hz

Color Space RGB, YCbCr 4:4:4 / 4:2:2, YUV 4:2:0

Color Depth

LPCM, Dolby Digital/Plus/EX, Dolby True HD, DTS,

DTS-EX, DTS-96/24, DTS High Res, DTS-HD

Master Audio, DSD

8/10/12-bit (1080P@60Hz)

8-bit (4K@60Hz)

HDMI Audio Formats

Connection

Transmitter

Receiver

Inputs: 1 x HDMI Type A [19-pin female]

1 x USB-C

Outputs: 1 x CAT6 OUT [RJ45, 8-pin female]

1x USB-C (only for charging)

Control: 1x FW [Micro USB, Update port]

Input:1x CAT IN [RJ45, 8-pin female]

Output: 1x HDMI OUT [Type A, 19-pin female]

Controls: 1x IR IN [3.5mm Stereo Mini-jack]

1x SERVICE [Micro USB, Update port]

Support

Transmission

Distance

Max distance (4K@24) : 164ft / 50m over CAT5e/6

Max distance (4K@60) : 115ft / 35m over CAT5e/6

HDR

DP Compliance

Video Bandwidth USB-C: 5.4 Gbps

Display Port 1.2a

5. Product Dimensions

Front Back

Side

Unit: mm

Power Supply

Dimensions

White / Black

Color

POC (only from Receiver to Transmitter)

Operating

Temperature

Storage Temperature

32 - 104°F / 0 - 40°C

Relative Humidity

-4 - 140°F / -20 - 60°C

20 - 90% RH (no condensation)

Mechanical

Metal EnclosureHousing

Weight Wall plate: 195g, Receiver: 155g

Wall plate:

33.3mm [W] x 65.7mm [D] x 68.7mm [H]

Faceplate:

69.9mm [W] x 3mm [D] x 114.3mm [H]

Receiver:

88mm (W) × 61mm (D) × 18mm (H)

Power Consumption Wall plate: 3W (Max), Receiver: 3.72W (Max)

69.9

114.3

60.9

68.7

33.3

6. Operation Controls and Functions

6.1 Transmitter Panel

No. Name Function Description

1 Power LED

The power LED indicator will illuminate in green

when the product is powered on, and red when

the product is on standby.

2 HDMI LED When the HDMI input port is active and the HDMI

signal is detected, the green LED will be on.

3 USB-C LED When the USB-C input port is active and USB-C

signal is detected, the green LED will be on.

4 HDMI port HDMI input port, connect to HDMI source device.

5 USB-C port (1) USB-C signal input port.

(2) Charging port for devices with USB-C port.

CHARGE port Connect this port to power supply, then the

USB-C port will power the connected device.

SOURCE button Used to switch HDMI / USB-C input signal.

CAT6 OUT Connect to the CAT IN port of Receiver with a

CAT5e/6 cable.

FW port Firmware update port.

HDMI

USB-CSOURCE

HDMI

USB-CCHARGE

CAT6 OUT

6.2 Receiver Panel

Note:

This transmitter supports automatic/manual mode for source signal input.

In manual switching mode, press the SOURCE button to select HDMI/

USB-C input source.

In automatic switching mode, the last connected or the currentlly connected

source signal will be selected automatically; When both HDMI and USB-C

ports are connected to active signal, HDMI signal input is preferred.

HDMI OUT DC 12VIR INSERVICECAT IN

345 6 7

No. Name Function Description

CAT IN Connect to the CAT6 OUT port on the transmitter

with a CAT cable.

HDMI OUT HDMI output port, connect to HDMI display device

such as TV or Projector with an HDMI cable.

Data signal

Indicator Lamp

(Orange)

When there is signal transmission between the

transmitter and the receiver, the lamp will be on.

Power Indicator

Lamp (Green)

When the receiver is powered on, the power

indicator lamp will be on.

SERVICE port Used for firmware update.

IR IN IR signal input port. Connect to the IR Receiver

cable.

7 DC 12V

Plug DC 12V/1A power supply into the unit and

connect the adapter to an AC outlet.

(Note: The CAT receiver provides power for the

transmitter via a CAT cable. )

7. Application Example

CAT5e/6 Cable

Notebook TV or Monitor

Power Adapter

Mac

Apple

Transmitter

Receiver

The terms HDMI and HDMI High-Definition Multimedia interface, and the

HDMI Logo are trademarks or registered trademarks of HDMI Licensing

LLC in the United States and other countries.

HDMI

USB-CSOURCE

HDMI

USB-CCHARGE

CAT6 OUT HDMI OUT DC 12VIR INSERVICECAT IN

Apple Power

Adapter

8. Maintenance

Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner, or

benzine to clean.

9. Warranty

If your product does not work properly because of a defect in materials of

workmanship, our company (referred to as “the warrantor”) will, for the

length of the period indicated as below, “Parts and Labor (18) Months”, which

starts with the date of original purchase (“Limited Warranty period”), at its

option either (a) repair your product with new or refurbished parts, or (b)

replace it with a new or a refurbished product. The decision to repair or

replace will be made by the warrantor.

During the “Labor” limited warranty period, there will be no charge for labor.

During the “Parts” warranty period, there will be no charge for parts. You

must mail-in your product during the warranty period. This Limited Warranty

is extended only to the original purchaser and only covers products

purchased as new. A purchase receipt or other proof of original purchase

date is required for Limited Warranty service.

10. Mail-In Service

When shipping the unit, carefully pack and send it prepaid, adequately

insured, and preferably in the original carton. Include a letter detailing the

complaint and provide a day time phone and/or email address where you

can be reached.

11. Limited Warranty Limits and Exclusions

This Limited Warranty ONLY COVERS failures due to defects in material or

workmanship, and DOES NOT COVER normal wear and tear or cosmetic

damage. The Limited Warranty ALSO DOES NOT COVER damages which

occurred in shipment, or failures which are caused by products not supplied

by warrantor, or failures which result from accidents, misuse, abuse, neglect,

mishandling, misapplication, alteration, faulty installation, set-up adjustments,

mis-adjustment of consumer controls, improper maintenance, power line

surge, lightning damage, modification, or service by anyone other than a

Factory Service center or other Authorized Servicer, or damage that is

attributed to acts of God.

THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED UNDER “LIMITED

WARRANTY COVERAGE”. THE WARRANTOR IS NOT LIABLE FOR INCIDENTAL

OR CONSEQUENTAIL DAMAGES RESULTING FROM THE USE OF THIS

PRODUCT, OR ARISING OUT OF ANY BREACH OF THIS WARRANTY. (As

examples, this excludes damages for lost time, cost of having someone

remove or re-install an installed unit if applicable, travel to and from the

service, loss of or damage to media or images, data or other recorded

content. The items listed are not exclusive, but are for illustration only.) PARTS

AND SERVICE, WHICH ARE NOT COVERED BY THIS LIMITED WARRANTY, ARE

YOUR RESPONSIBILITY.
