FC-2000 Technical Manual 406
Installation Section
Technical Bulletin
Issue Date 0794
© 1994 Johnson Controls, Inc. 1
Order No. 406-020
Introduction Page 3
●
Description 3
●
Key Features 4
●
Minimum System Configurations 4
●
NFPA Standards 5
●
UL Documents 6
●
Other Standards and Documents 6
Installation 9
●
Installation Outline 10
●
Cabinet Installation 12
●
Trim Ring for CAB-x3 Enclosures 15
●
CAB-x3 Door Assembly 16
●
Installing the CHS-4 Chassis 19
●
Installing the AVPS-24 21
●
Mounting the Main Power Supply in the Cabinet 22
●
Mounting the ARM-4 Auxiliary Relay Module 23
●
Mounting Optional Module Expanders 26
●
Mounting Modules in the Chassis 27
●
Mounting the CPU-2000 28
●
Connecting Row Ribbon Cables to Modules 29
Field Wiring the Modules 31
●
Field Wiring the CPU-2000 32
●
Dummy-Loading Unused CPU-2000 Circuits 33
●
Connecting the RS-485 Interface 34
●
Typical NFPA Style B Initiating Device Circuit 35
Installing the FC-2000
2 Installation—Installing the FC-2000
●
Typical NFPA Style D Initiating Device Circuit
Page
37
●
Typical NFPA Style Y and Z Indicating Appliance Circuit 39
●
Field Wiring of the Control Relay Module (CRM-4) and Control Relay
Expander (CRE-4) 40
Power Supplies 41
●
MPS-24A Main Power Supply 41
●
Installing an Optional Main Power Meter 45
●
MPS-24B Main Power Supply 47
Applications 53
●
Waterflow Alarm 53
●
Supervisory Service 53
●
Central Station 54
●
Proprietary Protective Signaling 54
●
Transmitters 54
●
Digital Communicators 55
●
Tee-Tapping 58
●
4-Wire Smoke Detectors 59
●
Indicating Appliance Circuit Current Limitations 60
●
Remote Command Inputs 63
●
Remote Presignal Inhibit, All Call (General Alarm), Emergency Alert, Acknowledge,
Signal Silence, and System Reset Switches 65
●
Telephone Paging 68
Testing the System 71
●
Acceptance Test 71
●
Periodic Testing and Service 71
●
Operational Checks 71
●
Battery Checks and Maintenance 73
Calculating Power Supply Requirements 75
●
AC Branch Circuit 75
●
Main Power Supply 75
Installation—Installing the FC-2000 3
Introduction
The FC-2000 is an expandable multi-zone Fire Alarm Control Panel
designed with maximum flexibility and modularity as a basic requirement.
The heart of the system is the Central Processor Unit (CPU-2000) module,
which monitors and directs the actions of all other modules in the system.
Fifteen other modules may be installed in various configurations. Internal
communications are accomplished over a high-speed serial bus.
The CPU-2000 is provided with the Basic Equipment package. This
module provides two Style Z and/or Style Y indicating appliance circuits,
Form-C alarm and trouble contacts, remote station alarm and trouble
outputs, and a municipal central box output.
A Main Power Supply (MPS-24A or MPS-24B) and an Indicating Zone
Module (IZM-8) must be added to make the basic system functional.
The basic system can be expanded using one or more of the following
optional modules or boards:
●IZM-8 Initiating Zone Module
●IZE-A Initiating Zone Expander
●ICM-4 Indicating Circuit Module
●ICE-4 Indicating Circuit Expander
●AVPS-24 Audio Visual Power Supply
●CRM-4 Control Relay Module
●CRE-4 Control Relay Expander
●ARM-4 Auxiliary Relay Module
●VCM-4 Voice Control Module
●VCE-4 Voice Control Expander
●DCM-2 Dual Channel Module
●TCM-2 Time Control Module
●TCM-4 Time Control Module
●AIM-200 Addressable Intelligent Module
●FFT-7 Fire Fighter’s Telephone
●AMG-1 Audio Message Generator
Description
4 Installation—Installing the FC-2000
System expansion must comply with the:
●physical limitations of the cabinet configuration
●electrical limitations of the system power supply
●capacity of the secondary power source (standby batteries)
See this section for a description of the various optional modules, and the
Installation section of this document for installation information.
The FC-2000 has the following important features:
●Distributed microprocessor electronics using latest technology
●Field programmable in minutes using front panel touch switches
●Large system capacity, conventional or addressable/intelligent devices
●Voice alarm options with solid state messages
●Extensive line of serial annunciators
●Manual On/Off/Disable control for all indicating appliance circuits
and control relays
●Plug-in terminal blocks for ease of field wiring
●Walk test any portion of system while remainder provides fire
protection
●Liquid crystal display and printer options
The following FC-2000 components are required for compliance with
NFPA standards 71 and 72:
1. BE-2000 Basic Equipment Package, which includes:
CPU-2000 Central Processor Module, VP-1 Vented Dress Panel,
BP-3 Battery Dress Panel, CHS-4 Chassis, interconnecting cables,
and instruction manuals
2. An IZM-8 Initiating Zone Module for up to eight Style B initiating
device circuits or an AIM-200 Addressable Intelligent Module for up
198 addressable devices
3. Main Power Supply (MPS-24A or MPS-24B)
4. Standby Batteries--Refer to the Calculating Power Supply
Requirements section of this document.
5. Cabinet (CAB-A3, B3, C3 or D3)
Key Features
Minimum
System
Configurations
Installation—Installing the FC-2000 5
In addition, the following equipment is required for the specific NFPA
standards listed below:
An NFPA-72 Remote Station Protected Premises Control Unit requires:
6. Sprinkler Supervisory service requires a CRM-4 Control Relay
Module and a cable assembly (Part No. 71270). Refer to the
Applications section of this document.
An NFPA-72 Proprietary Protected Premises Control Unit requires:
6. NIB-96 Network Interface Board. Refer to the Applications section of
this document. Not for sprinkler supervisory service.
An NFPA-71 Central Station Protected Premises Control Unit requires:
6. 911A Digital Alarm Communicator. Refer to the Applications section
of this document.
7. Sprinkler Supervisory and/or Waterflow Alarm service requires a
CRM-4 Control Relay Module. Refer to the Applications section of
this document.
An NFPA-72 Emergency Voice/Alarm Communication System requires:
6. VTCC-1, VCC-2 or VTCC-2 Voice/Telephone Command Center for
a voice evacuation system
7. AA-120 Audio Amplifier
8VCM-4 Voice Control Module for up to four speaker or telephone
circuits or DCM-4 Dual Channel Module
Before proceeding, the installer should be familiar with the following
standards (as appropriate):
●NFPA 71 Installation, Maintenance, and Use of Central Station
Signaling Systems
●NFPA 72 Installation, Maintenance, and Use of Local, Auxiliary,
Remote Station, and Proprietary Protective Signaling Systems
●NFPA 72 Emergency Voice Alarm Service
●NFPA 72 Automatic Fire Detectors
●NFPA 72 Installation, Maintenance, and Use of Indicating Appliances
for Protective Signaling Systems
●NFPA 72 Testing Procedures for Signaling Systems
NFPA
Standards
6 Installation—Installing the FC-2000
Before proceeding, the installer should be familiar with the following
documents (as appropriate):
●UL 38 Manually Actuated Signaling Boxes
●UL 217 Smoke Detectors, Single and Multiple Station
●UL 228 Door Closers--Holders for Fire Protective Signaling Systems
●UL 268 Smoke Detectors for Fire Protective Signaling Systems
●UL 268A Smoke Detectors for Duct Applications
●UL 346 Waterflow Indicators for Fire Protective Signaling Systems
●UL 464 Audible Signaling Appliances
●UL 521 Heat Detectors for Fire Protective Signaling Systems
●UL 864 Standard for Control Units for Fire Protective Signaling
Systems
●UL 1481 Power Supplies for Fire Protective Signaling Systems
●UL 1638 Visual Signaling Appliances
●RS-232D Serial Interface Standards
●RS-485 Serial Interface Standards
●NEC Article 300 Wiring Methods
●NEC Article 760 Fire Protective Signaling Systems
In addition, you must adhere to the standards of the applicable local and
state building codes and requirements of the local Authority Having
Jurisdiction (AHJ).
UL Documents
Other
Standards and
Documents
Installation—Installing the FC-2000 7
Figure 1: Physical Configuration Options
Note: The ARM-4 must be mounted under or in a position adjacent to its
associated CRM-4 or CRE-4.
ARM-4 ARM-4
DCM-4
ARM-4
IZE-A
IZM-8
Permissible Position Sharing Combinations
ARM-4
ICM-4
OR
TCM-2
OR
TCM-4
OR
VCM-4
ARM-4
CRE-4
CRM-4
or
AVPS-24
or
AVPS-24 or
AVPS-24
configop
CPU-2000
VCE-4, CRE-4 or ICE-A
8 Installation—Installing the FC-2000
Installation—Installing the FC-2000 9
Installation
Modules in the system communicate with the CPU through a common
ribbon cable connection.
aim200up
Figure 2: Module Connection Example
10 Installation—Installing the FC-2000
The following procedure outlines the installation and field wiring of the
FC-2000’s modules and refers to illustrations in the Installation, Field
Wiring the Modules, and Power Supplies sections of this document. This
procedure, and its diagrams and instructions, must be followed closely to
avoid damage to the control panel and its associated equipment. To a
great extent, reliability depends upon proper installation and maintenance.
1. Cabinet--Mount the cabinet and draw all field wiring through the
knockouts provided (Figure 3). Ensure that the cabinet is properly
grounded to earth.
Note: If the door is to be hung on the left side, mount door hardware
now. The MPS-24A/MPS-24B rests on the lower door mount.
Do not draw wiring into the bottom nine inches of the cabinet,
or conflict with the power supply and batteries may result.
2. Chassis--Mount all chassis. Refer to Figures 12 and 13 for
installation of the CHS-4 and CHS-4L chassis.
3. Main Power Supply--Mount the main power supply to the cabinet as
illustrated in Figure 15. Do not wire anything at this time!
4. Audio Visual Supplies--If any optional Audio Visual Power Supplies
(AVPS-24) are to be employed, mount them to the chassis. Refer to
Figure 14 for mounting of the AVPS-24 to the CHS-4.
5. Audio Visual Cables--Connect the AVPS trouble cable(s). Connect
the auxiliary bell power harness to the AVPS-24. Refer to Figure 36
to connect these cables.
6. Auxiliary Relay Modules--If any optional Auxiliary Relay Modules
(ARM-4) are to be employed, mount them to the chassis as illustrated
in Figure 16.
7. Preliminary System Wiring--The main power supply and any
AVPS-24s or ARM-4s should be wired at this time while the
terminals are readily accessible. Refer to the Power Supplies section
of this document to wire the MPS-24A/B, the AVPS-24s (see
Figure 36) and any ARM-4s (see Figure 22).
8. Module Ribbon Cables--Connect the first row ribbon cable to the
CPU as illustrated in Figure 17. For each additional row of modules
installed in the cabinet, connect an expander row ribbon cable to the
CPU.
9. CPU-2000--Install the CPU module in the top left cabinet position as
illustrated in Figure 20. Connect the power ribbon and power harness
between the CPU and the main power supply as illustrated in
Figures 32 and 35.
10. Module Expander Boards--If optional expanders are to be used with
a module, install as illustrated in Figure 18.
Installation
Outline
Andere Handbücher für FC-2000
2
Dieses Handbuch passt für folgende Modelle
4
Inhaltsverzeichnis
Andere Johnson Controls Bedienfeld Handbücher
Johnson Controls
Johnson Controls IFC-200 Referenzhandbuch
Johnson Controls
Johnson Controls CIW01 Bedienungsanleitung
Johnson Controls
Johnson Controls Bentel Security tyco ABSOLUTA Plus Benutzerhandbuch
Johnson Controls
Johnson Controls Frick QUANTUM Series Leitfaden
Johnson Controls
Johnson Controls Frick QUANTUM HD VILTER Bedienungsanleitung
Johnson Controls
Johnson Controls IFC-3030 Bedienungsanleitung
Johnson Controls
Johnson Controls IFC-3030 Betriebsanleitung
Johnson Controls
Johnson Controls FRICK QUANTUM HD Handbuch
Johnson Controls
Johnson Controls IQ4 NS Bedienungsanleitung
Johnson Controls
Johnson Controls Bentel Security Absoluta 630 4.10 Benutzerhandbuch
Johnson Controls
Johnson Controls YORK OPTIVIEW CONTROL CENTER Bedienungsanleitung
Johnson Controls
Johnson Controls IQ Panel Bedienungsanleitung
Johnson Controls
Johnson Controls Frick QUANTUM LX Bedienungsanleitung
Johnson Controls
Johnson Controls IFC-200 Bedienungsanleitung
Johnson Controls
Johnson Controls S1-TTSCC01 Kurzanleitung
Johnson Controls
Johnson Controls FC-2000 Bedienungsanleitung
Johnson Controls
Johnson Controls FRICK QUANTUM HD Leitfaden
Johnson Controls
Johnson Controls T20 Bedienungsanleitung
Johnson Controls
Johnson Controls Frick QUANTUM LX Leitfaden
Johnson Controls
Johnson Controls Frick QUANTUM LX Bedienungsanleitung
