Johnson Controls GS-20 Series Bedienungsanleitung

Installation Sheets Manual 121

Gas Combustion Combination Controls and Systems Section G

Technical Bulletin GS-20/25

GS-40/45

Issue Date 1298

Part No. 24-8711-21, Rev. A www.johnsoncontrols.com

Code No. LIT-121900

Introduction Page 3

Application 3

Electrical Ratings 3

Specifications 4

Installation 5

Mounting 5

Standard Wiring (From Burner Sequence Control) 6

4-Pin Connector Plug Wiring (From Burner Sequence Control) 7

GS-406_ Connection of the Impulse Lines 8

Checkout Procedure 9

Adjustments 11

GS-_ _1_ (On/Off with Flow Adjustment) 11

GS-_ _2_ (On/Off Step-slow Opening with Flow Adjustment) 12

GS-_03_ (On/Off with Pressure Regulator) 12

GS-405_ (On/Off with Servo Precision Regulator) 12

GS-406_ (On/Off with Gas/Air Ratio Control) 14

Repairs and Replacement 17

GS-20/25 and GS-40/45 Series

Single-block Multi-function Gas Control Valves

2G—GS-20/25 and GS-40/45 Series Single-block Multi-function Gas Control Valves Technical Bulletin

G—GS-20/25 and GS-40/45 Series Single-block Multi-function Gas Control Valves Technical Bulletin 3

Introduction

Figure 1: GS Series Single-block

Multi-function Control Valves

The GS Series single-block multi-function gas control valves are intended

for use on atmospheric and forced-draft gas burners in heating

installations. This multi-functional control on a single-block valve body

provides a compact answer to gas train applications. The GS valve

replaces multiple gas train components, such as on/off gas valves, gas

pressure regulators, and modulating gas valves. Optional sizing of body

flanges offers greater adaptation to diversified burner designs and

applications. Valves are approved to North American and European

standards.

Typical applications include boilers, burners and ovens, rooftop units,

makeup air heaters, hot water heaters, kilns, and paint booths.

Table 1: Electrical Ratings

Valve Model Operating Voltages Power Consumption

GS-2_ _ _ 230 VAC +10/-15%, 50/60 Hz

120 VAC +10/-15%, 50/60 Hz

24 VAC +10/-15%, 50/60 Hz 23 VA

GS-4_ _ _ 230 VAC +10/-15%, 50/60 Hz

120 VAC +10/-15%, 50/60 Hz

24 VAC +10/-15%, 50/60 Hz 23 VA

Application

Electrical

Ratings

4G—GS-20/25 and GS-40/45 Series Single-block Multi-function Gas Control Valves Technical Bulletin

Table 2: Specifications

Media 1st (Manufactured Gas), 2nd (Natural Gas), and 3rd (Liquefied

Petroleum [LP] Gas) Family Gases

Maximum Inlet

Pressure

Europe:

GS-_01 _ and GS-_02_: 360 mbar

GS-251_ and GS-252_: 200 mbar

All Other Models: 100 mbar

North America:

GS-_01 _ and GS-_02_: 5 psi

GS-251_ and GS-252_: 2 psi

All Other Models: 0.5 psi

Maximum

Regulating

Setting

20 mbar (8 in. W.C.) (GS-_ 03_)

50 mbar (20 in. W.C.) (GS-405_ and GS-406_)

Reverse

Pressure Rating 150 mbar (60 in. W.C.) minimum; Class A (EN 161)

Regulator

Classification Spring Regulator (GS-_03_): Class B (EN 88)

Servo Regulator (GS-405_): Class A (EN 88)

Permissible

Ambient

Temperature

-15 to 60°C (5 to 140°F)

Body

Connections Detachable flanges with pipe thread 3/8 to 1-1/2 in. NPT or Rp

Valve Torsion

Group Group 2 (EN 88 and EN 161)

Pressure Taps Flanges: 9.0 mm (0.35 in.) spigot for flexible tubing

Body: Rp 1/8 thread standard (multi-position)

Rp 1/4 thread special (multi-position) GS-4 only

Materials Body and Flanges: Die cast aluminum

Diaphragms and Seals: Perbunan rubber

Solenoid Enclosure: IEC 529 (NEMA 1 and IP 54)

Filter Segment Standard Dirt Strainer: 0.5 mm (0.02 in. ) metal mesh

Optional Filter Set: 0.05 mm(0.002 in.) nylon mesh and fleece filter

Operating Time

Rating 100% Continuous

Valve Timings Closing Time: < 1 second

Opening Time: < 1 to 15 seconds

Dead Time: < 1 second

Electrical

Connections Standard Wiring: PG 13.5 compression fitting with cage-type

terminal blocks inside the electrical box

Optional Wiring: 1/2 in. NPT conduit adapter or

4-pin connector plug (ISO 4400 [DIN 43650])

Coil Insulation

Class Class F

Agency

Listings IAS (AGA/CGA) Certificate Numbers: C0197002

C0197004

European Certificate Number: CE 0063AN3731

Specification

Standards EN 88, EN 126, and EN 161

Standards Complying with the EMC Directive

Standards Complying with the Low Voltage Directive

ANSI Standards, Z21.18, Z21.21, and Z21.78

Canadian Standards CAN1-6.3 and CAN1-6.5

The performance specifications are nominal and conform to acceptable industry standards. For

application at conditions beyond these specifications, consult the local Johnson Controls office.

Johnson Controls, Inc. shall not be liable for damage resulting from misapplication or misuse of its

products.

Refer to the GS-20/25 and GS-40/45 Series Product Bulletin (LIT-4350240) for necessary information on

operating and performance specifications of this product.

Specifications

G—GS-20/25 and GS-40/45 Series Single-block Multi-function Gas Control Valves Technical Bulletin 5

Installation

IMPORTANT: This technical bulletin is intended as a guide for

authorized service personnel installing or servicing

Johnson Controls products. Carefully follow all

instructions in this sheet and all instructions on the

appliance. Limit repairs, adjustments, and servicing to

the operations listed in this sheet or on the appliance.

WARNING: The system must meet all applicable codes. Improper

installation may cause fire, explosions, property

damage, and injuries or death.

Carefully follow all instructions in this sheet and all instructions on the

appliance. Limit repairs, adjustments, and servicing to the operations listed

in this sheet or on the appliance.

WARNING: Fire or explosion hazard. Shut off the gas supply at

the main manual shutoff valve before installing or

servicing the GS Series valve.

1. Ensure that the maximum ambient temperature is not exceeded

(see Table 2).

2. Check the power supply voltage for compatibility with the required

valve voltage. All wiring must conform to national and local electrical

codes and regulations.

3. When installing the valve on the manifold, the gas must flow through

the valve body in the direction indicated by the arrow on the body. If

the valve is installed with the gas flow opposite the arrow, leakage can

occur.

4. Shut off the gas at the main manual shutoff valve.

5. Mount the valve. It is recommended that the flanges be mounted to

the pipe separately with the valve then mounted between the

two flanges. For valves supplied with a filter set and filter plate as

standard, the assembly should be installed (using the longer bolts)

between the inlet flange and the valve.

Mounting

6G—GS-20/25 and GS-40/45 Series Single-block Multi-function Gas Control Valves Technical Bulletin

The GS Series valve may be mounted on a horizontal manifold with

the magnetic operator pointed up (vertical) or in any position not

exceeding 90ofrom the vertical. The valve may also be mounted on a

vertical manifold in any position around its axis (see Figure 2). Do not

install the solenoid actuator upside down. Install vertically wherever

possible.

90° Maximum

from Vertical

90° Maximum

from Vertical

Limited Horizontal and Vertical

Figure 2: GS Series Valve Mounting Position

Use an approved pipe joint sealing compound on male threads before

assembly.

6. Remove excess compound after mounting the flanges to the pipe.

Threads of pipe and nipples must be smooth and free of tears and

burrs. Steam clean all piping to remove foreign substances such as

cutting oil or thread chips.

WARNING: Shock hazard. Avoid electrical shock and equipment

damage by disconnecting electrical power to the valve

before proceeding.

CAUTION: Equipment damage hazard. To prevent possible

grounding of the 24 VAC transformer secondary,

do not connect the ground wire on 24 VAC models.

Follow the procedure below to wire the valve when using the standard

PG 13.5 cable compression electrical connection.

1. Observe that the operating voltage is identical to the information on

the product identification label.

2. Route the electrical cable for the valve solenoid from the burner

sequence control to the valve.

3. Remove the cover of the electrical box and make wiring connections

in accordance with Figure 3.

4. Reattach the electrical box cover.

Standard Wiring

(From Burner

Sequence

Control)

G—GS-20/25 and GS-40/45 Series Single-block Multi-function Gas Control Valves Technical Bulletin 7

5. Use a wrench to tighten the PG 13.5 cable compression plug to secure

wires and prevent moisture from entering the terminal box.

Note: If an optional 1/2 in. NPT thread electrical connector or 4-pin

DIN 43650 (ISO 4400) electrical connector (each ordered

separately) is used for wiring, refer to the documentation supplied

with the electrical connector for specific wiring instructions.

NV2V1

Electrical Box

Connection

GND

PG 13.5 Cable

Compression Plu

(

Factor

Installed

)

Wirin

Connections

N = Common

V1 = Line Valve 1

V2 = Not Connected

GND = Earth Ground*

(

* Do not connect earth

round

for 24 VAC models.

)

Figure 3: Standard Wiring Electrical Connections

WARNING: Shock hazard. Avoid electrical shock and equipment

damage by disconnecting electrical power to the valve

before proceeding.

CAUTION: Equipment damage hazard. To prevent possible

grounding of the 24 VAC transformer secondary,

do not connect the ground wire on 24 VAC models.

Follow the procedure below to wire the valve when using a factory-

installed 4-pin DIN 43650 (ISO 4400) electrical plug connection.

1. Observe that the operating voltage is identical to the information on

the product identification label.

2. Route the electrical cable for the valve solenoid from the burner

sequence control to the valve.

3. Make wiring connections in accordance with Figure 4.

4-Pin Connector

Plug Wiring

(From Burner

Sequence

Control)

8G—GS-20/25 and GS-40/45 Series Single-block Multi-function Gas Control Valves Technical Bulletin

(

Common

)

Line

Not Connected

Terminal Desi

nations

Figure 4: 4-Pin Wiring Electrical Connections

The internal diameter of the impulse tubes for the combustion air (PA)

and the combustion chamber pressure (PF) should be 4.0 mm (5/32 in.)

(see Figure 5). Make the connections as short as possible and route to

prevent the entry of condensate into the controller. The installation of a

condensation trap in the connection line from the combustion chamber is

highly recommended. Do not close the connection for PFif not used.

IMPORTANT: Avoid sharp bends or kinks in the tubing to avoid

damage to the tubing and allow for an accurate pressure

reading.

Figure 5: Impulse Line Connections

GS-406_

Connection of

the Impulse

Lines

G—GS-20/25 and GS-40/45 Series Single-block Multi-function Gas Control Valves Technical Bulletin 9

WARNING: Fire or explosion hazard. Verify that the valve

functions properly and there are no gas leaks. Follow

this checkout procedure before leaving the installation.

Failure to verify proper valve installation, equipment

operation, and gas tight connections may result in fire,

explosion, property damage, and injuries or death.

1. Shut off the gas at the main manual shutoff valve and open the

pressure connection between the manual shutoff valve and the GS

valve.

2. Connect air tubing with a maximum pressure of 1-1/2 times the

valve’s maximum operating pressure (as indicated on the valve) to the

opened pressure connection.

3. Paint the pipe connections and flanges of the valve with a rich soap

and water solution to check for leakage.

If bubbles occur, this is an indication of a leak. To stop a leak, tighten

joints and pipe connections. Replace the part if the leak cannot be

stopped.

If bubbles do not occur, remove the air tubing and close the upstream

pressure connection.

4. Open the main manual shutoff valve.

5. Refer to the Adjustments section to make any necessary valve setting

adjustments.

WARNING: Fire or explosion hazard. Valve settings must be in

accordance with the appliance or equipment

manufacturer’s specifications.

6. Before leaving the installation, observe at least three complete

operating cycles to ensure that all components are functioning

correctly.

Checkout

Procedure

10 G—GS-20/25 and GS-40/45 Series Single-block Multi-function Gas Control Valves Technical Bulletin

Andere Handbücher für GS-20 Series

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Johnson Controls Steuereinheit Handbücher

Johnson Controls

Johnson Controls GH-5000 Bedienungsanleitung

Johnson Controls

Johnson Controls IOM3711 Bedienungsanleitung

Johnson Controls

Johnson Controls S300 Series Montageanleitung

Johnson Controls

Johnson Controls GM 20 Series Bedienungsanleitung

Johnson Controls

Johnson Controls Tyco RSV-1 Bedienungsanleitung

Johnson Controls

Johnson Controls A19 Series Bedienungsanleitung

Johnson Controls

Johnson Controls Tyco DV-5a Series Bedienungsanleitung

Johnson Controls

Johnson Controls UL Listed GS-20 Series Bedienungsanleitung

Johnson Controls

Johnson Controls VF Series Bedienungsanleitung

Johnson Controls

Johnson Controls VMA 1410 Installationsanleitung

Johnson Controls

Johnson Controls System 450 Series Bedienungs- und Wartungshandbuch

Johnson Controls

Johnson Controls Mercury P2000 CKM-MR16IN Handbuch

Johnson Controls

Johnson Controls Tyco DV-5a Series Bedienungsanleitung

Johnson Controls

Johnson Controls System 350 Y350R Service-Handbuch

Johnson Controls

Johnson Controls M300CJ-R Bedienungsanleitung

Johnson Controls

Johnson Controls FX-PCX2721 Bedienungsanleitung

Johnson Controls

Johnson Controls V46SA Series Bedienungsanleitung

Johnson Controls

Johnson Controls METASYS TC-9102 Series Service-Handbuch

Johnson Controls

Johnson Controls METASYS NU-XBN101-0 Bedienungsanleitung

Johnson Controls

Johnson Controls Penn P28 Series Bedienungsanleitung

Johnson Controls

Johnson Controls Facility Explorer FX20 Bedienungsanleitung

Johnson Controls

Johnson Controls Tyco DV-5a Series Bedienungsanleitung

Johnson Controls

Johnson Controls VG1000 Series Bedienungsanleitung

Johnson Controls

Johnson Controls VP101DBB Bedienungsanleitung

Beliebte Steuereinheit Handbücher anderer Marken

Festo

Festo Compact Performance CP-FB6-E Stücklistenhandbuch

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Bedienungsanleitung

JS Automation

JS Automation MPC3034A Bedienungsanleitung

JAUDT

JAUDT SW GII 6406 Series Kurzanleitung

Spektrum

Spektrum Air Module System Bedienungsanleitung

BOC Edwards

BOC Edwards Q Series Bedienungsanleitung

KHADAS

KHADAS BT Magic Bedienungsanleitung

Etherma

Etherma eNEXHO-IL Bedienungsanleitung

PMFoundations

PMFoundations Attenuverter Bedienungsanleitung

GEA

GEA VARIVENT Bedienungsanleitung

Walther Systemtechnik

Walther Systemtechnik VMS-05 Bedienungsanleitung

Altronix

Altronix LINQ8PD Montageanleitung

Eaton

Eaton Powerware Series Bedienungsanleitung

WAGO

WAGO 750-407/040-000 Bedienungsanleitung

Sony

Sony CCU-590 Bedienungsanleitung

Graco

Graco 25D614 Bedienungsanleitung

Task Force Tips

Task Force Tips YE-RF-900 Programmierhandbuch

Shini

Shini SPV-U Series Bedienungsanleitung
