JVC XS-N1132BA Bedienungsanleitung

Portable Bluetooth Speaker

XS-N1132BA

Important Safety Instructions

Warning: To avoid electrical shock, do not dismantle. Refer all servicing to

qualified service personnel.

1. Please read all of the instructions carefully and retain for future reference.

2. When using electrical appliances, basic safety precautions should always

be followed.

3. This product is not a toy! Children should be supervised to ensure that

they do not play with the appliance.

4. There are no user-serviceable parts inside. Do not attempt to repair by yourself.

5. Do not immerse the unit in water or other liquids.

6. Do not insert foreign objects into any opening on the unit.

7. Do not play music at excessive volume levels as this can cause hearing loss

or damage the unit.

8. Keep the speaker and charging cable away from direct sunlight, excessive

heat or flammable materials. Do not cover the speaker during use.

9. Do not expose batteries to heat or fire as they may explode. Do not store the

speaker in a car during hot weather.

10. Do not dispose of batteries in your household waste. Contact your local

council for information on disposal or recycling.

Product Overview:

1.Power Button: Press and hold to turn on or turn off the speaker.

2.Lights Button:

Short press repeatedly to switch between available lighting modes

and to turn off the lights.

3.– Button (Previous/Volume Down):

Press and hold to play the previous song (or previous channel in FM mode).

Short press to reduce volume.

4.+ Button (Next/Volume Up):

Press and hold to play the next song (or next channel in FM mode).Short press

to increase volume.

5.Mode Button: Short press to switch between available modes: BT/FM/TF

/USB/AUX.

6.Play/Pause Button:

Short press to play or pause.

When a phone call comes, short press to receive the call; short press

again to end the call; press and hold for 2 seconds to reject the call.

In FM mode, short press to scan available FM stations and store into

memory; short press again to stop scanning.

7.USB port: Insert USB memory device to play compatible audio.

Included:

1.Speaker

2.Micro USB Charging Cable

3.AUX Cable

4.User Manual

5.Warranty Card

Specifications:

Supported Profiles: A2DP v1.2, HFP v1.5, HSP v1.2

Bluetooth Range: 33ft (10m)

Dimensions: 220 X 100 X 96 mm

Battery: Li-Ion 3.7V, 1200 mAh

Charging Input: DC 5V, 1A(Max)

Charging the Speaker:

Turn off the unit before charging. Charge the unit fully before using it for the

first time and whenever the sound becomes weak (there is a low battery

alert ‘beep’).

1.Connect the USB charging cable to the microUSB Charging Port on the unit.

Connect the other end of the charging cable to a DC 5V, 1A power adaptor to

charge the unit. You can also connect it to the USB port of a computer or similar.

8.MicroSD (TF) card port: Insert microSD card to play compatible audio.

9.DC 5V microUSB Charging Port to charge the speaker.

10.AUX Input: Connect auxiliary device using 3.5mm AUX cable to

play audio.

FM Radio Playback:

USB/microSD/AUX Input:

Short press Mode Button to switch to FM Radio mode.

Short press Play/Pause Button to scan available FM stations and store into

memory; short press again to stop scanning.

Press and hold the Previous or Next Buttons to switch between the saved

channels.

Connect a USB/microSD memory device, or an AUX cable connected to your

device, to the appropriate port. If needed, press and hold the ‘Mode’ Button to

switch to the correct mode.

2.The red Charging Indicator near the Charging Port turns on when the unit is

charging and turns off when it is fully charged. Remove the charging cable

promptly. Do not overcharge.

Charging time: Around 2-3 hours.

Battery run time: Around 2-3 hours.

Bluetooth Connection:

Place the speaker close to (within 10 metres of) your Bluetooth enabled device.

If not in Bluetooth mode, short press Mode Button to switch to Bluetooth mode.

Enable Bluetooth function on your Bluetooth-enabled smartphone, tablet or

media player; navigate to the Bluetooth setting menu, and search for new

devices. The Bluetooth name for this speaker is ‘XS-N1132’.

Once connected, you can press and hold Previous or Next Button to play the

previous or next song.

Troubleshooting:

Note:

Making/Receiving Phone Calls:

Only MP3 format files are compatible.

Maximum size of the USB/ microSD device that can be connected is 32GB.

When a phone call comes, short press Play/Pause Button to receive the call;

short press again to end the call; press and hold for 2 seconds to reject the call.

A tone is heard every

few seconds

Cannot connect

Bluetooth device

Cannot play file from

USB/microSD

No sound

Speaker does not

control track volume

Battery is low. Charge it fully before using it again.

Problem Possible cause/ Solution

Move device closer to the speaker when

connecting.

Disconnect all other Bluetooth devices that are

connected to the speaker and try again.

File might be in an incompatible format.

Only mp3 files are compatible.

File path might not be recognized; try storing the

file directly in the root directory.

Try increasing the volume. Choose the correct

audio source.

If connected to a computer, make sure correct

audio output is selected.

Full volume control is only for Bluetooth mode.

For Aux mode, control the volume on the source

device.
