Kärcher Sensor 2 Bedienungsanleitung

86400000-G 12/10/21

Sensor 2 (120V)

Description

CHECK

BRUSH

ON/OFF

CHECK

BRUSH

ON/OFF

Operating instructions (ENG)

MODELS:

1.012-070.0

12” Sensor 2

1.012-071.0

14” Sensor 2

286400000 - Sensor 2

Machine Data Label

Warranty Registration

Thank you for purchasing a Kärcher North America product. Warranty registration is quick

and easy. Your registration will allow us to serve you better over the lifetime of the product.

To register your product go to :

http://warranty.karcherna.com

For customer assistance:

1-800-444-7654

Table of Contents

Machine Data Label . . . . . . . . . . . . . . . . . . . . . . . . 2

Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . 3

How To Use This Manual . . . . . . . . . . . . . . . . . . . 4

Safety

IMPORTANT SAFETY INSTRUCTIONS . . . . . . . 5

HAZARD INTENSITY LEVEL . . . . . . . . . . . . . . . . 6

GROUNDING INSTRUCTIONS . . . . . . . . . . . . . . 7

Caution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Operations

Technical Specifications . . . . . . . . . . . . . . . . . . . 10

Assembling the Vacuum Cleaner . . . . . . . . . . . . 12

Operating Instructions. . . . . . . . . . . . . . . . . . . . . 14

Maintenance

Bag Full Indicator . . . . . . . . . . . . . . . . . . . . . . . . 16

Changing The Paper Filter Bag . . . . . . . . . . . . . 16

Changing the Filters . . . . . . . . . . . . . . . . . . . . . . 16

Changing the Brush Strip . . . . . . . . . . . . . . . . . . 17

Clearing Blockages . . . . . . . . . . . . . . . . . . . . . . . 18

Parts

Upper Housing . . . . . . . . . . . . . . . . . . . . . . . . . . 22

12” Power Head . . . . . . . . . . . . . . . . . . . . . . . . . 26

14” Power Head . . . . . . . . . . . . . . . . . . . . . . . . . 26

Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . .28

86400000 - Sensor 2

How To Use This Manual

This manual contains the following sections:

• How to Use This Manual

•Safety

• Operations

• Maintenance

• Parts List

The HOW TO USE THIS MANUAL section will tell

you how to find important information for ordering

correct repair parts.

Parts may be ordered from authorized dealers. When

placing an order for parts, the machine model and

machine serial number are important. Refer to the

MACHINE DATA box which is filled out during the

installation of your machine. The MACHINE DATA

box is located on the inside of the front cover of this

manual.

The model and serial number of your machine is

located on the bottom of the machine.

The SAFETY section contains important information

regarding hazardous or unsafe practices of the

machine. Levels of hazards are identified that could

result in product damage, personal injury, or severe

injury resulting in death.

The OPERATIONS section is to familiarize the

operator with the operation and function of the

machine.

The MAINTENANCE section contains preventive

maintenance to keep the machine and its compo-

nents in good working condition. They are listed in

this general order:

• Bag Indicator

• Changing the Bag

• Changing the Filter

• Changing the Brush Strip

• Clearing Blockages

The PARTS LIST section contains assembled parts

illustrations and corresponding parts list. The parts

lists include a number of columns of information:

•REF – column refers to the reference number

on the parts illustration.

•PART NO. – column lists the part number for

the part.

•PRV NO. – reference number.

•QTY – column lists the quantity of the part

used in that area of the machine.

•DESCRIPTION – column is a brief descrip-

tion of the part.

•NOTES – column for information not noted by

the other columns.

NOTE: If a service or option kit is installed on your

machine, be sure to keep the KIT INSTRUCTIONS

which came with the kit. It contains replacement

parts numbers needed for ordering future parts.

NOTE: The manual part number is located on the

lower right corner of the front cover.

Model:

Date of Purchase:

Serial Number:

Dealer:

Address:

Phone Number:

Sales Representative:

86400000 - Sensor 2

Safety

IMPORTANT SAFETY INSTRUCTIONS

When using this machine, basic precaution

must always be followed, including the following:

READ ALL INSTRUCTIONS BEFORE USING THIS MACHINE.

To reduce the risk of fire, electric shock, or injury:

1. Do not leave appliance when plugged in. Unplug from outlet when not in use and before servicing.

2. Do not use outdoors or on wet surfaces.

3. Do not use near small children. Do not allow to be used as a toy. Close attention is necessary when used by

or near children.

4. Use only as described in this manual. Use only manufacturer's recommended attachments.

5. Do not use with damaged cord or plug. If appliance is not working as it should, has been dropped,

damaged, left outdoors, or dropped into water, return it to a service center.

6. Do not pull or carry by the cord, use cord as a handle, close a door on cord, or pull cord around sharp edges

or corners. Do not run appliance over cord. Keep cord away from heated surfaces. Do not wind cord tighter

than necessary to keep it on the cord hooks.

7. Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.

8. Do not handle plug or appliance with wet hands.

9. Do not put any object into openings. Do not use with any opening blocked; keep free of dust, lint, hair, and

anything that may reduce air flow.

10. Keep hair, loose clothing, fingers and all parts of body away from openings and moving parts. Do not place

fingers or other body parts under vacuum unless unplugged.

11. Do not pick up anything that is burning or smoking, such as cigarettes, matches, or hot ashes.

12. Do not use without dust bag and/or filters in place. Do not wash filters.

13. Turn off all controls before unplugging.

14. Use extra care when cleaning on stairs. Do not use to pick up flammable or combustible liquids such as

gasoline or use in areas where they may have been present.

15. Do not operate this machine near flammable fluids, dust or vapors.

16. Maintenance and repairs must be done by qualified personnel.

17. Connect to a properly grounded outlet only. See Grounding Instructions.

18. Do not use machine as a step.

19. If used on plush carpet or carpet with thick padding, do not leave machine in one place with machine turned

on.

20. Use of extension cord or light socket with inadequate current-carrying capacity could result in electric shock

or fire hazard.

READ AND SAVE THESE INSTRUCTIONS

86400000 - Sensor 2

Safety

The following symbols are used throughout this guide as indicated in their descriptions:

HAZARD INTENSITY LEVEL

There are three levels of hazard intensity identified by signal words -WARNING and CAUTION and FOR

SAFETY. The level of hazard intensity is determined by the following definitions:

WARNING - Hazards or unsafe practices which COULD result in severe personal injury or death.

CAUTION - Hazards or unsafe practices which could result in minor personal injury or product or property

damage.

FOR SAFETY: To Identify actions which must be followed for safe operation of equipment.

Report machine damage or faulty operation immediately. Do not use the machine if it is not in proper operating

condition. Following is information that signals some potentially dangerous conditions to the operator or the

equipment. Read this information carefully. Know when these conditions can exist. Locate all safety devices

on the machine. Please take the necessary steps to train the machine operating personnel.

FOR SAFETY:

DO NOT OPERATE MACHINE:

Unless Trained and Authorized.

Unless Operation Guide is Read and understood.

In Flammable or Explosive areas.

In areas with possible falling objects

WHEN SERVICING MACHINE:

Avoid moving parts. Do not wear loose clothing; jackets, shirts, or sleeves when working on the machine. Use

manufacturer approved replacement parts.

86400000 - Sensor 2

Safety

GROUNDING INSTRUCTIONS

This appliance must be grounded. If it should malfunction or breakdown, grounding provides a path of least

resistance for electric current to reduce the risk of electric shock. This appliance is equipped with a cord having

an equipment-grounding conductor and grounding plug. The plug must be inserted into an appropriate outlet

that is properly installed and grounded in accordance with all local codes and ordinances.

Improper connection of the equipment-grounding conductor can result in a risk of electric shock.

Check with a qualified electrician or service person if you are in doubt as to whether the outlet is

properly grounded. Do not modify the plug provided with the appliance - if it will not fit the outlet, have

a proper outlet installed by a qualified electrician.

This appliance is for use on a nominal 120-volt circuit, and has a grounded plug that looks like the plug illus-

trated in sketch A. A temporary adapter looks like adapter illustrated in sketches B and C, may be used to

connect this plug to a 2-pole receptacle as shown in sketch B if a properly grounded outlet is not available. The

temporary adapter should be used only until a properly grounded outlet (sketch A) can be installed by a qualified

electrician. The green colored rigid ear, lug or the like extending from the adapter must be connected to a

permanent ground such as a properly grounded outlet box cover. Whenever the adapter is used, it must be held

in place by a metal screw.

NOTE: In Canada, the use of a temporary adapter is not permitted by the Canadian Electrical Code.

GROUNDING

GROUNDED

OUTLET ADAPTER

METAL SCREW TAB FOR

GROUNDING SCREW

GROUNDED

OUTLET BOX

(A) (B) (C)

86400000 - Sensor 2

Safety

Please save these instructions. If you pass the machine to a third party, please pass these on as well. The use

of the machine is at your own risk. The manufacturer / supplier is not liable for any injury or damage caused by

incorrect usage of the machine. This appliance is suitable for commercial use, e.g. in hotels, schools, hospitals,

factories, shops, offices, and rental companies. This appliance can be used by children aged from 8 years and

above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if

they are given supervision or instruction concerning use of the appliance in a safe way and understand the

hazards involved. Children should not play with the appliance. Cleaning and user maintenance should not be

done by children without strict supervision.

Caution

Before using the vacuum cleaner, always check for any signs of damage, especially to the mains cable and

hose. If a component is damaged, it must be replaced with a authorized manufacturer part. For safety reasons

internal components must be fitted by a Manufacturer Service Representative or an Authorized Service Techni-

cian. The use of non-genuine parts will waive the warranty for this product and could pose a serious safety risk.

All repairs within the guarantee period should be performed by an authorized Service Representative. Electrical

appliance, do not expose to liquid, moisture or heat.

86400000 - Sensor 2

Notes

86400000 - Sensor 2

Operations

Technical Specifications

Item Description

Vacuum Motor 1000 Watt

Suction 225 mbar [2300mm WS]

Air Flow 106 cfm/50 l/s

Filter Bag 1.4 gallon/5.3 liter, 3 layer

Working Width:

12” Sensor2 11.8 inches/300mm

14” Sensor2 14.2 inches/360mm

Brush Strip Replaceable

Brush Drive Non-slip drive belt

Cable

12” Sensor2 25ft/7.6m

14” Sensor2 39 feet/12m

Weight:

12” Sensor2 20.4 pounds/9.3kg

14” Sensor2 20.7 pounds/9.4kg

Protection Grounded

Sound Pressure Level LpA 76 dB[A]

Uncertainty KpA 2 dB[A]

Hand-arm Vibration Value < 2.5 m/s2

Uncertainty K 0.2 m/s2

86400000 - Sensor 2

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere Kärcher Staubsauger Handbücher

Kärcher

Kärcher KNT 2 Premium Bedienungsanleitung

Kärcher

Kärcher VC 7 Cordless yourMax Bedienungsanleitung

Kärcher

Kärcher NT 45/1 Tact Te H Bedienungsanleitung

Kärcher

Kärcher WD 2.2 Series Bedienungsanleitung

Kärcher

Kärcher WD 4 Bedienungsanleitung

Kärcher

Kärcher SC 4.100 CB Bedienungsanleitung

Kärcher

Kärcher VC 6 Bedienungsanleitung

Kärcher

Kärcher WD 5.220 M Steel Edition Bedienungsanleitung

Kärcher

Kärcher 1.055-401.0 Bedienungsanleitung

Kärcher

Kärcher IVR-L 40/12-1 Bedienungsanleitung

Kärcher

Kärcher SV 1905 Bedienungsanleitung

Kärcher

Kärcher SE 5.100 Bedienungsanleitung

Kärcher

Kärcher IV 100/40 M B1 Bedienungsanleitung

Kärcher

Kärcher WD 5 Bedienungsanleitung

Kärcher

Kärcher Sensor XP18 Bedienungsanleitung

Kärcher

Kärcher 1159129 Bedienungsanleitung

Kärcher

Kärcher AD 3.200 Bedienungsanleitung

Kärcher

Kärcher VC 3 Plus Bedienungsanleitung

Kärcher

Kärcher IVC 60/30 Ap M Z22 Bedienungsanleitung

Kärcher

Kärcher VC 7 Cordless yourMax Bedienungsanleitung

Kärcher

Kärcher IV 60/27-1 M B1 Bedienungsanleitung

Kärcher

Kärcher DS 5.800 Bedienungsanleitung

Kärcher

Kärcher IVM 40/24-2 M Lp Bedienungsanleitung

Kärcher

Kärcher T 10/1 Bedienungsanleitung

Beliebte Staubsauger Handbücher anderer Marken

Bissell

Bissell LittleGreen Proheat 1425 Series Bedienungsanleitung

Panasonic

Panasonic MC-YL637S147-AE Bedienungsanleitung

NEFF

NEFF N17XH10 0 Series Bedienungsanleitung

LG A9 Series Bedienungsanleitung

Oreck

Oreck Cordless Captura BK51700 Series Bedienungsanleitung

Kogan

Kogan KAVACROBVWA Bedienungsanleitung

Kränzle

Kränzle VENTOS 50 ID Benutzerhandbuch

EVVO

EVVO Ai35 Bedienungsanleitung

DeWalt

DeWalt DWH200D Bedienungsanleitung

Pontec

Pontec Pondomatic Vacuum Cleaner Bedienungsanleitung

Cleanmaxx

Cleanmaxx PC-P007E Bedienungsanleitung

Exido

Exido 240-114 Bedienungsanleitung

RIDGID

RIDGID WD1685AU0 Bedienungsanleitung

Ezviz

Ezviz RE4P Bedienungsanleitung

STG global

STG global TANVAC HDV3000 Bedienungsanleitung

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Bedienungsanleitung

Factory

Factory M3340 Bedienungsanleitung

Shop-Vac

Shop-Vac VN92 SERIES Bedienungsanleitung
