Kargo Master 40552 Handbuch

Instruction Guide

40552

Kargo Master

Rancho Cordova, CA 95742

800-343-7486

CustomerService@KargoMaster.com

20200114R1

DATE: ______________

For Technical Support Call: 800-343-7486 Monday-Friday 7AM - 4 PM (PST) Page 1

Instructions –40552

*PLEASE READ ALL INSTRUCTIONS AND WARNINGS PRIOR TO ASSEMBLING,

INSTALLING, AND USING THIS PRODUCT*

Warning

Always check for wires, fuel tanks and lines, brake lines and other important vehicle

functionality items prior to drilling and installing all products.

Tools Needed

Phillips Driver

Table of Contents

Parts List ...............................................................................................................................2

Hardware .............................................................................................................................2

Step 1 –Assemble Shelf .....................................................................................................3

Step 2 –Prepare Shelf Unit ................................................................................................3

Step 3 –Install Back Splash .................................................................................................4

Step 4 –Install Bench Top ..................................................................................................5

Before You Begin

Read all instructions.

Be sure to have a shelf unit to attach bench kit to.

The images in the instructions are shown using a 32” wide shelf. The instructions are the

same in this application.

For Technical Support Call: 800-343-7486 Monday-Friday 7AM - 4 PM (PST) Page 2

Instructions –40552

Parts

Hardware

For Technical Support Call: 800-343-7486 Monday-Friday 7AM - 4 PM (PST) Page 3

Instructions –40552

Step 1 –Assemble Shelf

Have desired shelf unit

built. Be sure the top shelf

is on the highest notch and

oriented with shelf lip down

as shown.

Step 2 –Prepare Shelf Unit

Access rear of shelf unit.

Rear of shelf unit has

gussets installed on the

bottom shelf.

Remove upper screws

attaching top shelf to side

panels as shown.

For Technical Support Call: 800-343-7486 Monday-Friday 7AM - 4 PM (PST) Page 4

Instructions –40552

Step 3 –Install Back Splash

Place back splash over

previously removed screws.

Re-install screws leaving

the middle hole in back

splash vacant.

Snug Tighten.

For Technical Support Call: 800-343-7486 Monday-Friday 7AM - 4 PM (PST) Page 5

Instructions –40552

Step 4 –Install Bench Top

Place bench top on top of shelf as shown. Align

bench top to desired location.

Screw bench top to back splash using a No.10

screw.

On bottom side of shelf, find four appropriate

mounting holes. Screw through these holes

into bottom side of bench top using No.10

screws.

Tighten all screws.

**Only top shelf is shown above for simplicity**

For Technical Support Call: 800-343-7486 Monday-Friday 7AM - 4 PM (PST) Page 6

Instructions –40552

GO BACK AND ENSURE ALL HARDWARE IS TIGHT

Installation is now complete
