Kargo Master 40240 Bedienungsanleitung

Installation Guide

Kargo Master

Rancho Cordova, CA 95742

800-343-7486

CustomerService@KargoMaster.com

For Technical Support Call: 800-343-7486 Monday-Friday 7AM - 4 PM (PST) Page 2

Install Instructions

*PLEASE READ ALL INSTRUCTIONS AND WARNINGS PRIOR TO ASSEMBLING,

INSTALLING AND USING THIS PRODUCT*

Warning

Always check for wires, fuel tanks and lines, brake lines and other important vehicle functionality

items prior to drilling and installing all products.

Tools Needed

1/2" Socket and Wrench

#2 Phillips Drive

7/16" Socket and Wrench



3/8" Socket and Wrench



11/32" Socket and Wrench



3/32" Allen Wrench



Table of Contents

Parts List ...................................................................................................................................... 3

Hardware List ............................................................................................................................4-5

Main File Holder Assembly ........................................................................................................... 6

Ford Transit Installation ............................................................................................................... 7

Promaster Installation .................................................................................................................. 9

Before You Begin

Be sure to check the back side prior to drilling or screwing anything into the vehicle. If not

positioned correctly, some drills and screws can hit wires and important vehicle parts.

For Technical Support Call: 800-343-7486 Monday-Friday 7AM - 4 PM (PST) Page 3

Install Instructions

Parts

KM9050-802

KM9050-106-R1

KM9050-805

KM9050-104

KM9050-804

For Technical Support Call: 800-343-7486 Monday-Friday 7AM - 4 PM (PST) Page 4

Install Instructions

18-00568

For Technical Support Call: 800-343-7486 Monday-Friday 7AM - 4 PM (PST) Page 5

Install Instructions

18-00567

For Technical Support Call: 800-343-7486 Monday-Friday 7AM - 4 PM (PST) Page 6

Install Instructions

Step 1

Bolt File Support (KM9050-104) into Main File Holder (KM9050-804) using four 10-32 x 1/2" Pan Head

Screws, four #10 Flat washer and four 10-32 Nyloc Nuts.

We recommend to have the washer on the outside

*TIGHTEN

Step 2

Bolt Lid (KM9050-802) to Main File Holder using three 10-32 x 3/8" Pan Head Screws.

*TIGHTEN

For Technical Support Call: 800-343-7486 Monday-Friday 7AM - 4 PM (PST) Page 7

Install Instructions

Installation Instructions for Ford Transit

Step 1

Bolt bottom bracket to main assembly through the rear holes as

shown. Use two 1/4" x 7/8" hex bolt, two 1/4" lock washers and two

1/4" flat washers.

*SNUG TIGHTEN

Step 2

Bolt the front bracket to

the front of the main assembly

using two 1/4" x 7/8" hex bolt,

four 1/4" flat washers and two

1/4" nyloc nuts.

*SNUG TIGHTEN

** We recommend having bracket all the way towards the bottom of

the slots.

Step 3

Place main assembly with mounting brackets into van. Put in between seats snug against the passenger

side. Be sure to have the rear support bracket past the rear of the rib in the floor.

Step 4

Mark the slots in the rear bracket onto the

mat or floor.

On the side of the seat pedestal, mark the

slot in the front bracket.

Remove assembly with brackets

For Technical Support Call: 800-343-7486 Monday-Friday 7AM - 4 PM (PST) Page 8

Install Instructions

Step 5

Remove rear support bracket from main assembly.

Return to van, Place rear support bracket where you

previously marked.

Secure to floor using four 5/16" x 1.25" self tapping

screws.

Step 6

If desired, you can drill a clearance hole for a 1/4" bolt

into seat pedestal where previously marked. Or you can

wait and drill once the main assembly is placed back

into van.

Step 7

Place main assembly with front bracket back into van and bolt to previously installed rear support using

two 1/4" x 7/8" hex bolt, two 1/4" lock washers and two 1/4" flat washers.

*SNUG TIGHTEN

Step 8

If hole is not drilled in seat pedestal mount,

align bracket and do so now.

Bolt front bracket to seat pedestal mount

using a 1/4" x 7/8" hex bolt, two 1/4" flat

washers and one 1/4" nyloc nut.

Step 9

Align and square the driver data file. Go back and TIGHTEN all bolts.

Your installation is now complete.

For Technical Support Call: 800-343-7486 Monday-Friday 7AM - 4 PM (PST) Page 9

Install Instructions

Installation in RAM Promaster

Step 1

Bolt rear bracket to main assembly through the rear holes as shown.

Use two 1/4" x 7/8" hex bolt, two 1/4" lock washers and two 1/4"

flat washers.

*SNUG TIGHTEN

Step 2

Bolt the front bracket to the front of the

main assembly using two 1/4" x 7/8" hex

bolt, four 1/4" flat washers and two 1/4"

nyloc nuts.

*SNUG TIGHTEN

** We recommend having bracket all the way

towards the bottom of the slots.

Step 3

Place main assembly with mounting brackets into van.

Put in between seats. In the bottom bracket, mark the

four slots onto the floor of the van. In the front bracket,

Mark slot onto floor.

Remove main assembly from van.

Step 4

Check under the mat where previous slots were marked.

Be sure to have slots located in a way that it does not

interfere with anything important.

Step 5

Remove rear support bracket from main assembly.

Return to van, Place rear support bracket where you

previously marked.

Secure to floor using four 5/16" x 1.25" self tapping screws.

For Technical Support Call: 800-343-7486 Monday-Friday 7AM - 4 PM (PST) Page 10

Install Instructions

Step 6

Place rest of driver data file back into van.

Bolt to previously installed bottom bracket using 1/4" bolts.

Step 7

Align and tighten all bolts from previous steps.

Bolt front bracket to floor using a 5/16" x 1.25" self tapping screw.

Tighten

Your installation is now complete.
