Kenmore DS6001 Bedienungsanleitung

Use & Care Guide

Manual de Uso y Cuidado

Kenmore

14.4 Volt Cordless

2-in-1 Stick Vacuum

Model/Modelo: DS6001

Aspiradora de varilla 2 en 1

inalámbrica, de 14,4 Volts

www.kenmore.com

Vacuum Cleaner Help Line:

1-877-531-7321

8:00am-5:00pm EST, M-F

Kenmore and the Kenmore logo are registered

trademarks of KCD IP, LLC and/or Sears Brands, LLC

and are used under license by Cleva North America, Inc.

- 2 -

Before Using Your New Vacuum Cleaner ........................................................................ 2

Packing List ..................................................................................................................... 2

Kenmore Vacuum Cleaner Warranty ............................................................................... 3

Important Safety Instructions........................................................................................4-5

Parts and Features...........................................................................................................6

Assembly Instructions...................................................................................................7-8

Operating Instructions ..................................................................................................8-9

Vacuum Cleaner Maintenance and Care.....................................................................10-11

Troubleshooting ..............................................................................................................12

TABLE OF CONTENTS

Please read this guide. It will help you assemble and operate your new Kenmore vacuum cleaner in the

safest and most effective way.

Use the space below to record the model number of your new Kenmore vacuum cleaner.

Model No.____________________________________________

Date of Purchase ______________________________________

Keep this book and your sales check (receipt) in a safe place for future reference.

BEFORE USING YOUR NEW VACUUM CLEANER

PACKING LIST

Your KENMORE 14.4V Cordless 2-in-1 Stick Vacuum is packaged with the following parts

and components included separately in the carton:

1 Handle

1 Main Body

1 Hand Vacuum

1 Motorized Brush

1 Charger Base

1 Vacuum Support

1 Charging Adapter

1 Combination Tool

1 Manual

- 3 -

KENMORE LIMITED WARRANTY

FOR ONE YEAR from the date of sale this product is warranted against defects in

material or workmanship.

WITH PROOF OF SALE a defective product will be replaced free of charge.

The Kenmore brand is used under license. Direct all claims for warranty service to: Cleva

North America, Inc., 1-877-531-7321

This warranty does not cover filters or belts, which are expendable parts that can wear

out from normal use within the warranty period.

This warranty applies for only 90 days from the date of sale if this product is ever used for

other than private household purposes.

This warranty gives you specific legal rights, and you may also have other rights which

vary from state to state.

Cleva North America, Inc., Greenville SC 29607

KENMORE VACUUM CLEANER WARRANTY

- 4 -

IMPORTANT SAFETY INSTRUCTIONS

When using your Kenmore vacuum, basic precautions should always be followed,

including the following:

READ ALL INSTRUCTIONS BEFORE USING THIS VACUUM CLEANER.

To reduce the risk of fire, electric shock, or injury:

• Do not use or charge outdoors or on

wet surfaces.

• Do not allow to be used as a toy. Close

attention is necessary when used by or

near children, pets or plants.

• Use only as described in this manual.

Use only manufacturer’s recommended

attachments.

• Do not use with damaged cord or plug.

If appliance is not working as it should,

has been dropped, damaged, left

outdoors, or dropped into water, return

it to a service center.

• Do not pull or carry by cord, use cord

as a handle, close a door on cord,

or pull cord around sharp edges or

corners. Do not run the vacuum over

the charging adapter cord. Keep cord

away from heated surfaces.

• Do not unplug by pulling on cord. To

unplug, grasp the plug, not the cord.

• Do not handle charger, including

charger plug, and charger terminals

with wet hands.

• Do not put any object into openings. Do

not use with any opening blocked; keep

free of dust, lint, hair, and anything that

may reduce air flow.

•

This vacuum cleaner creates suction and

has a revolving brush roll. Keep hair, loose

clothing, fingers, and all parts of body

away from openings and moving parts.

• Use extra care when cleaning on stairs.

• Do not use to pick up flammable or

combustible liquids, such as gasoline, or

use in areas where they may be present.

• Switch off the appliance before

connecting the accessories.

• Do not pick up anything that is burning

or smoking, such as cigarettes, matches,

or hot ashes.

• Do not pick up toxic liquids such as

chorine bleach, ammonia or drain

cleaner.

• Do not use without dust cup and filter in

place.

• Do not charge the unit outdoors.

• Do not attempt to use the charging

adapter with any other product nor

attempt to charge this product with

another charging adapter.

• To recharge vacuum, use only the

charging adapter model 30007 listed

in the Replacement Parts table.

• Do not incinerate the appliance even

if it is severely damaged. The batteries

inside this product may explode or leak

in a fire.

• Do not immerse vacuum or charging

adapter in water or other liquids.

• Always turn the vacuum off before

connecting or disconnecting the

motorized brush.

• Store the cordless vacuum indoors. Put

the cordless vacuum away after use to

prevent accidents.

• Keep your work area well lit.

• Keep the vacuum moving over the

carpet surface at all times to avoid

damaging the carpet fibers.

• Do not vacuum any liquids.

• Do not use in an enclosed space where

vapors are present from paint, paint

WARNING:

- 5 -

SAVE THESE INSTRUCTIONS

Household use only.

thinner, moth-proofing substances,

flammable dust or other explosive or

toxic materials.

• Do not vacuum up hard or sharp objects

such as glass, nails, screws or coins that

could damage the vacuum.

• To avoid excessive heat and damage

to unit or batteries, do not operate the

vacuum while charging.

• Do not use extension cords or outlets

with inadequate current carrying

capacity.

• DO NOT MUTILATE OR INCINERATE

BATTERIES AS THEY WILL EXPLODE AT

HIGH TEMPERATURES.

• Leaks from battery cells can occur

under extreme usage or temperature

conditions. If the liquid gets on skin,

wash quickly with water. If liquid gets

into the eyes, flush them immediately

with clean water for a minimum of 10

minutes. Seek medical attention.

• While there is no shock hazard from

electrical terminals located on the

vacuum, a burn could result from metal

objects being inserted into the terminal

areas. Vacuum cleaner terminals should

always be kept free of objects.

• Store charger indoors in a cool, dry

area, not exposed to weather to avoid

electrical shock and/or damage to the

vacuum cleaner.

• Changes or modifications to this unit

not expressly approved by the party

responsible for compliance could void

the user’s authority to operate the

equipment.

NOTE: This equipment has been tested

and found to comply with the limits for

a Class B digital device, pursuant to

Part 15 of the FCC Rules. These limits

are designed to provide reasonable

protection against harmful interference in

a residential installation. This equipment

generates, uses and can radiate radio

frequency energy and, if not installed and

used in accordance with the instructions,

may cause harmful interference to radio

communications.

However, there is no guarantee that

interference will not occur in a particular

installation. If this equipment does cause

harmful interference to radio or television

reception, which can be determined

by turning the equipment off and on,

the user is encouraged to try to correct

the interference by one or more of the

following measures:

• Reorient or relocate the receiving

antenna.

• Increase the separation between the

equipment and receiver.

• Connect the equipment into an outlet

on a circuit different from that to which

the receiver is connected.

• Consult the dealer or an experienced

radio/TV technician for help.

Product Disposal

This product contains an internal Lithium-

ion battery pack formulated from

environmentally sensitive materials. This

product must be disposed of properly

with due care for the environment. Do

not dispose of product with household

garbage. Consult your local waste

authority for information regarding

available recycling or disposal options.

This device complies with part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) this device may not cause harmful interference,

and (2) this device must accept any interference received, including

interference that may cause undesired operation.

- 6 -

PARTS AND FEATURES

Combination Tool

Motorized Brush

Powerhead

Dust Cup

(Filter inside)

Charging AdapterCharger Base

Vacuum Support

Hand Vacuum

Power Switch

Lock Button

Release Button

Dust Cup Release

Button

Hand Vacuum

Release Button

It is important to know your 14.4V Cordless 2-in-1 Stick Vacuum's parts and features to

assure its proper and safe use. Review these before using your vacuum.

REPLACEMENT PARTS

Item Part No.

Filter 30002

Alternate Filter 57004

Filter Basket 30003

Charging Adaptor 30007

Charger Base 30005

Vacuum Support 30006

Brush roll 561031104

Main Body

Power/Speed Switch

Battery Charge Indicator

Handle

To order a replacement part

call 1-877-531-7321.

Click!

- 7 -

Before assembling the vacuum, check the PACKING LIST (Page 2). Use this list to verify

that you have received all the components of your new Kenmore Cordless 2-in-1 Stick

Vacuum.

ASSEMBLY INSTRUCTIONS

1. Fit the motorized brush powerhead into

the vacuum body and lock into place.

2. Insert the handle onto the top of the main

body, as illustrated, and lock into

place.

3. Insert the hand

vacuum into the

main body as shown

and lock into place.

Ensure that the dust

cup is secure in

place.

4. Insert vacuum support

into charger base and

lock into place.

5. The charging adapter plug will fit into

the charger base only one way. Insert the

charging adapter plug into the charging

port on the bottom of the charger base

and thread the cord out as illustrated.

6. Plug the adapter into a wall outlet.

Battery Charge Indicator

- 8 -

3. While the vacuum is

being charged, the battery

charge indicator will be

flashing continuously until

fully charged.

WARNING

Before charging, make sure unit is OFF.

CHARGING

2. Make sure the vacuum cleaner is fully

charged before using for the first time. The

vacuum may take up to 5 hours to charge

completely if fully discharged.

1. Plug the charging

adapter into an

outlet. Insert the

vacuum cleaner onto

the charger base as

shown.

4. When the vacuum has reached full

charge (100%), the battery charge

indicator will remain lit for 3 seconds then

go to dormant mode with no illuminated

lights showing.

NOTE: If the battery charge indicator does

not illuminate when charging, ensure the

following:

• The vacuum cleaner is seated properly

onto the charger base.

• The charging adaptor is plugged into the

outlet properly.

• The adaptor power plug is connected

properly on the charger base.

NOTE: For improved battery performance,

always keep the vacuum cleaner on the

charger base while not in use.

OPERATING INSTRUCTIONS

CAUTION

Moving parts! To reduce the risk of personal injury,

DO NOT touch the brush roll when vacuum is on.

Contacting the brush roll while it is rotating can cut,

bruise or cause other injuries. Always turn off before

servicing. Use caution when operating near children.

Power Button

- 9 -

1. To start the vacuum, slide the power

switch to the desired speed position

(Low Speed, High Speed).

2. To stop the vacuum, place the power

switch in (OFF) position.

USING YOUR VACUUM CLEANER

(OFF) (High Speed)(Low Speed)

WARNING

Do not operate vacuum cleaner without

filter in place.

Before vacuuming, check that the brush

powerhead wheels and brush roll are clear

from any sharp objects to avoid scratching

floors.

Use low speed for surface cleaning of bare

floors or low pile rugs and carpets or when

increased runtime is needed.

Use high speed for cleaning of plush rugs

and carpets or when additional cleaning

power is required.

CLEANING WITH THE HAND VACUUM

2. To turn on the hand vacuum, press the

power switch located on top of the handle.

NOTE: When battery power is low, the

battery charge indicator around the switch

will flash.

To charge, place the hand vacuum into the

main body and place the whole unit onto

the charger base.

1. To remove the

hand vacuum, press

the release button

and detach the hand

vacuum from the

main body.

3. To clean difficult to reach areas, use

the combination tool by inserting end of

combination tool into the hand vacuum as

shown.

- 10 -

VACUUM MAINTENANCE & CARE

CAUTION

To reduce the risk of shock, remove vacuum cleaner from the charger base. Turn off

before performing any service or maintenance.

EMPTYING THE DUST CUP AND CLEANING THE FILTER

For best performance, empty the dust cup

after every use. Never operate the vacuum

cleaner without the dust cup and filter in

place.

1. Make sure the vacuum is turned off.

Remove the hand vacuum from the main

body.

2. Press the dust cup release button and

separate the dust cup from the hand

vacuum body.

3. Remove the filter basket from the dust

cup. Empty the dust cup contents into a

waste receptacle.

The key to maximum performance is

having a clean filter. Cleaning the filter

after each use will help your vacuum

operate at peak efficiency.

Use only genuine Kenmore model number

30002 replacement filters in your Kenmore

vacuum. To purchase, call 1-877-531-7321.

4. Remove the filter

from the filter basket.

With a soft brush, brush

accumulated debris from

the side screens of the

filter basket and from the

filter cloth.

5. After much repeated use, it may be

necessary to wash the filter basket and

filter clean of accumulated dust. First brush

loose debris from both basket and filter

cloth, then hand wash basket and filter in

warm water. After washing, set both aside

and allow to air dry. IMPORTANT: The

basket and filter must be completely dry

before reuse.

6. Insert the clean, dry filter into the

basket, fit the basket into the dust cup,

and reconnect the dust cup to the hand

vacuum.

To remove the hand

vacuum, press the release

button and detach the

hand vacuum from the

main body.

Inhaltsverzeichnis

Sprachen:

Andere Kenmore Staubsauger Handbücher

Kenmore

Kenmore 116.38099 Bedienungsanleitung

Kenmore

Kenmore 592.30413 Bedienungsanleitung

Kenmore

Kenmore 1!6O31040 Bedienungsanleitung

Kenmore

Kenmore Progressive DU2001 Bedienungsanleitung

Kenmore

Kenmore SPOTLITE KW2005 Bedienungsanleitung

Kenmore

Kenmore 1163511290 Bedienungsanleitung

Kenmore

Kenmore 3828FI2852V Bedienungsanleitung

Kenmore

Kenmore SEARS 116.25512 Bedienungsanleitung

Kenmore

Kenmore 37115 - Bagged Upright, Tan Bedienungsanleitung

Kenmore

Kenmore 116.30412 Bedienungsanleitung

Kenmore

Kenmore ELITE CROSSOVER ULTRA 125.10335610 Bedienungsanleitung

Kenmore

Kenmore 116.28014 Bedienungsanleitung

Kenmore

Kenmore 116.31912 Bedienungsanleitung

Kenmore

Kenmore 116.30412 Bedienungsanleitung

Kenmore

Kenmore BU1005 Bedienungsanleitung

Kenmore

Kenmore 116.35725 Bedienungsanleitung

Kenmore

Kenmore 24195 - Magic Canister Vacuum Bedienungsanleitung

Kenmore

Kenmore 116.27212 Bedienungsanleitung

Kenmore

Kenmore 2029319 - Canister Vacuum Bedienungsanleitung

Kenmore

Kenmore Elite 116.21814 Bedienungsanleitung

Kenmore

Kenmore KW3050 Bedienungsanleitung

Kenmore

Kenmore 116.38412 Bedienungsanleitung

Kenmore

Kenmore Galaxy 721.36078 Bedienungsanleitung

Kenmore

Kenmore CSV Go XL DS4030 Bedienungsanleitung

Beliebte Staubsauger Handbücher anderer Marken

Bissell

Bissell LittleGreen Proheat 1425 Series Bedienungsanleitung

Panasonic

Panasonic MC-YL637S147-AE Bedienungsanleitung

NEFF

NEFF N17XH10 0 Series Bedienungsanleitung

LG A9 Series Bedienungsanleitung

Oreck

Oreck Cordless Captura BK51700 Series Bedienungsanleitung

Kogan

Kogan KAVACROBVWA Bedienungsanleitung

Kränzle

Kränzle VENTOS 50 ID Benutzerhandbuch

EVVO

EVVO Ai35 Bedienungsanleitung

DeWalt

DeWalt DWH200D Bedienungsanleitung

Pontec

Pontec Pondomatic Vacuum Cleaner Bedienungsanleitung

Cleanmaxx

Cleanmaxx PC-P007E Bedienungsanleitung

Exido

Exido 240-114 Bedienungsanleitung

RIDGID

RIDGID WD1685AU0 Bedienungsanleitung

Ezviz

Ezviz RE4P Bedienungsanleitung

STG global

STG global TANVAC HDV3000 Bedienungsanleitung

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Bedienungsanleitung

Factory

Factory M3340 Bedienungsanleitung

Shop-Vac

Shop-Vac VN92 SERIES Bedienungsanleitung
