KitchenAid KUDC10FXSS Bedienungsanleitung

Stainless Steel Wash Arms

Four stainless steel wash arms are an industry exclusive

and part of the quality KitchenAid performance features

that demonstrate the highest level of craftsmanship in

each of our products.

AquaSense™Fill System

A sensor assesses water pressure before the selected cycle

begins, ensuring the optimal amount of water for superior

results, regardless of the cycle selected.

Adjustable Upper Rack with Manual Adjusters

Manual adjusters allow the rack to easily roll out and

adjust to one of two pre-set positions, making more room

for loading dishes.

Stainless Steel

KUDC10FXSS

Classic Series Dishwasher

Architect®Series II

KUDC10FX – 52 dBA**

Performance

• Built-In Hard Food Disposer

• 4 Cycles (Heavy Duty, Normal, One Hour Wash,

Rinse Only)

• 3 Options (Hi-Temp Scrub, Heat Dry, Control Lock)

• Dedicated Drying System with Heat Dry Option

• Optimum Wash Sensor

• AquaSense™ Fill System

• Whisper Quiet® 52 Sound Insulation System

Craftsmanship & Design

• Fully Integrated Console

• Architect® Series II Handle

• Tall Tub with Stainless Steel Interior

• 4 Stainless Steel Wash Arms

• 14 Place Setting Capacity

• Light-Touch Controls with Audio Feedback

• Status Lights

• Flood Protection Technology

• ENERGY STAR® Qualied

• CEE Tier 2 Qualied

Upper and Lower Racks

• DuraKote™ Nylon-Coated Racks

• Cushion-Tip™ Tines

Upper Rack

• Adjustable with Manual Adjusters

• Robust Handle

• 2 Sure-Hold® Light Items Clips

Lower Rack

• Fold-Down Row with Three-Position Tines

• Silverware Basket

Colors

• White (WH), Black (BL), Stainless Steel (SS)

25% Better Results

vs. the Competition*

*Combined wash and dry results of leading premium brands’

highest MSRP models; dry testing conducted without rinse aid.

** Per IEC standards, normal cycle.

®ENERGY STAR is a U.S. registered mark.

®Registered trademark/™Trademark/the shape of the stand mixer is a registered trademark of KitchenAid, U.S.A.

KitchenAid • Benton Harbor, Michigan 49022 U.S.A.

®ENERGY STAR is a U.S. registered mark.

Dimensions are for planning purposes only. For complete details, see Installation

Instructions packed with product. Specifications subject to change without notice.

07/10 (29768RC0710)

KUDC10FX

For additional information about KitchenAid®appliances, visit KitchenAid.com

or call the Customer Experience Center at 800-422-1230. We’ll help you select the

ideal model and answer questions about appliance operation and performance.

Classic Series Dishwasher

PRODUCT DIMENSIONS

115/16"

337/8" Min. –

341/2" Max.

237/8"

Recessed

width

241/2"

491/2"

313/16"

Towel Bar Handle

Stainless Steel – W10320831

HaNDlE

The following handle is available

as an optional accessory.

Cut openings in shaded area of cabinet

walls or floor as specified in chart:

Measured from the lowest point on the

underside of countertop. May be reduced to

337/8" by removing wheels from dishwasher.

Minimum, measured from narrowest point

of opening.

***

May be increased to 67/8" if height of opening

is 341/2" at its lowest point.

24"**

24" Min.

All surfaces must be free

from intrusions.

OPENING FOR: DIAMETER:

water line

drain line

direct wire

power supply cord

1/2"

11/2"

3/4"

11/2"

34" Min.*

31/4"

51/2"

6"***

23/4" 31/4"

9" 2"

10"

31/4" 23/4"

6"***

31/4"

CUTOUT DIMENSIONS
