KitchenAid KSM2APC Bedienungsanleitung

KSM1APC

KSM2APC

W10767027B_ENv12.indd 1 11/19/15 5:01 PM

Fine spiralizing blade

Thin slicing blade

(small core)*

Medium spiralizing blade Extra ﬁne spiralizing blade*

Slicing blade

(small core)

SIicing blade

(large core)

Peeling blade

Fruit and vegetable

skewer

PARTS AND FEATURES

PARTS AND ACCESSORIES

NOTE: Store your Spiralizer attachment and all accessories in the provided storage box.

Be sure to keep out of the reach of small children.

Attachment

main body Release lever

Blade carrier

*These blades are not included with KSM1APC and are available through an accessory pack (KSMAPC1AP).

W10767027B_ENv12.indd 2 11/19/15 5:01 PM

ENGLISH

SPIRALIZER ATTACHMENT SAFETY | 3

SPIRALIZER ATTACHMENT SAFETY

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always

be followed, including the following:

1. Read all instructions.

2. To protect against risk of electrical shock, do not put Stand Mixer in water or

other liquid.

3. Be sure to turn the Stand Mixer OFF (and detach the Spiralizer attachment

with peel, core and slice from Stand Mixer) after each use of the Spiralizer

attachment and before cleaning. Make sure the motor stops completely

before disassembling.

4. Keep hands, utensils or other objects away from the Spiralizer attachment

with peel, core & slice blades, skewer or moving parts while it is in operation

to reduce the risk of severe injury to persons or damage to the Spiralizer

attachment.

5. Never feed by hand. Always use the provided skewer.

6. If food becomes lodged in any blade or the skewer, turn the motor off and

disassemble Spiralizer attachment to remove the remaining food.

7. Avoid contacting moving parts.

8. The use of attachments not recommended or sold by KitchenAid may cause re,

electric shock, or injury.

9. Do not use outdoors.

10. Close supervision is necessary when any appliance is used by or near children.

11. Do not use the appliance if the driver mechanism or rotating parts are damaged.

Return appliance to the nearest Authorized Service Facility for examination,

repair, or electrical or mechanical adjustment.

12. Do not let the Stand Mixer cord hang over the edge of table or counter.

13. Blades are sharp. Handle carefully when inserting or removing blades.

14. Do not remove food until Stand Mixer is OFF and skewer stops.

15. To avoid damaging the gear assembly, do not immerse the Spiralizer attachment

main assembly in water or other liquids.

SAVE THESE INSTRUCTIONS

W10767027B_ENv12.indd 3 11/19/15 5:01 PM

4 | USING THE SPIRALIZER ATTACHMENT

SPIRALIZER ATTACHMENT BLADE CHART

USING THE SPIRALIZER ATTACHMENT

ICON USE THESE PARTS WITH THESE PARTS SUGGESTED

FOODS SPEED

EXTRA FINE

SPIRALIZING

BLADE* FRUIT AND

VEGETABLE SKEWER

and

OPTIONAL PEELING

BLADE

ZUCCHINI

SWEET POTATO

BEET 2

FINE

SPIRALIZING

BLADE ZUCCHINI

SWEET POTATO

BEET 4

MEDIUM

SPIRALIZING

BLADE ZUCCHINI

SWEET POTATO

POTATO 6

*These blades are not included with KSM1APC and are available through an accessory pack (KSMAPC1AP).

FOR DETAILED INFORMATION ON USING THE SPIRALIZER ATTACHMENT

Visit kitchenaid.com/quickstart for additional instructions with videos, inspiring recipes,

and tips on how to use your Spiralizer attachment.

NOTE: Cut the ends off food items to ensure that the food will properly t on the

Spiralizer, and to create at surfaces for best spiralizing, slicing, and coring results.

Food should be 1.5-3.75 inches (3.81-9.5 cm) in diameter, and no longer than

5.5 inches (14 cm). This step also ensures proper placement onto the fruit and

vegetable skewer.

When beginning to cut, start at the “Stir” speed, then adjust to the recommended

speed for your blade listed in the chart.

W10767027B_ENv12.indd 4 11/19/15 5:01 PM

ENGLISH

USING THE SPIRALIZER ATTACHMENT | 5

USING THE SPIRALIZER ATTACHMENT

*These blades are not included with KSM1APC and are available through an accessory pack (KSMAPC1AP).

ICON USE THESE PARTS WITH THESE PARTS SUGGESTED

FOODS SPEED

THIN SLICING

BLADE

(SMALL CORE)*

FRUIT AND

VEGETABLE SKEWER

and

OPTIONAL PEELING

BLADE

ZUCCHINI

POTATO

CUCUMBER 2

SLICING

BLADE

(SMALL CORE) ZUCCHINI

BEET 4

SLICING

BLADE

(LARGE CORE) APPLE

PEAR 6

PEELING BLADE FRUIT AND

VEGETABLE SKEWER

POTATO

APPLE 4

W10767027B_ENv12.indd 5 11/19/15 5:01 PM

6 | USING THE SPIRALIZER ATTACHMENT

USING THE SPIRALIZER ATTACHMENT

ATTACHING THE SPIRALIZER TO THE STAND MIXER

1For Stand Mixers with a hinged attachment hub cover: Flip up to open.

For Stand Mixers with a removable attachment hub cover: Turn the attachment

knob counterclockwise to remove attachment hub cover.

Insert the Spiralizer attachment

shaft housing into the attachment

hub, making certain that the power

shaft fits into the square hub socket.

Rotate the Spiralizer attachment

back and forth, if necessary. The pin

on the shaft housing will slip fully

into the notch on the hub rim when

it’s in the proper position.

Tighten the attachment knob

until the Spiralizer attachment is

completely secured to the Stand

Mixer. Visit kitchenaid.com/quickstart

for detailed information on how to

use your Spiralizer’s different blades

and features.

W10767027B_ENv12.indd 6 11/19/15 5:01 PM

ENGLISH

USING THE SPIRALIZER ATTACHMENT | 7

USING THE SPIRALIZER ATTACHMENT

PREPARING TO PROCESS

IMPORTANT: To prepare food before spiralizing, wash food, then remove stems,

cut the ends off squarely, and remove any eyes, if applicable.

Install fruit and vegetable skewer

by slipping onto the skewer mount,

and twisting counterclockwise until

it clicks into place.

2Place bowl or plate under the

Spiralizer attachment, then affix food

to the fruit and vegetable skewer.

OPTIONAL: If using the peeler, install

by sliding into the bottom of the blade

carrier until it clicks into place. 3Install the desired blade.

Pull the release lever, then push

the blade carrier towards the

Stand Mixer to align the blade

core with the center of the food.

Press blade core into food for

added stability before operating

the Stand Mixer.

IMPORTANT: When finished,

remove the blade before removing

your food item.

FOR DETAILED INFORMATION ON USING THE SPIRALIZER ATTACHMENT

Visit kitchenaid.com/quickstart for additional Instructions with videos, inspiring recipes,

and tips on how to use your Spiralizer attachment.

W10767027B_ENv12.indd 7 11/19/15 5:01 PM

8 | TROUBLESHOOTING

CARE AND CLEANING

IMPORTANT: To avoid damage, never wash or immerse the main body of the Spiralizer

attachment in water or place in the dishwasher. The removable blades and accessories

are dishwasher safe, top rack only.

CLEANING THE SPIRALIZER ATTACHMENT AND ACCESSORIES

TROUBLESHOOTING

If your Stand Mixer should malfunction

or fail to operate while using the

Spiralizer attachment, please check

the following:

- Did you follow the preparation

suggestions in the “Spiralizer

attachment blade” chart?

- Did you choose a blade recommended

for the type of food you are spiralizing?

- Is the Stand Mixer plugged in? Refer

to the “Instructions” manual that came

with your Stand Mixer to nd possible

solutions.

- Is the fuse in the circuit to the Stand

Mixer in working order? Refer to the

“Instructions” manual that came with

your Stand Mixer to nd possible

solutions.

If the problem is not due to one of the

above items, see the “Arranging for

Service” section in the “Warranty”.

Do not return the Spiralizer attachment

or the Stand Mixer to the retailer, as

they do not provide service.

NOTE: After washing, store your Spiralizer attachment and all accessories in the provided

storage box. Be sure to keep out of the reach of small children.

NOTE: For best cleaning, rinse blades

immediately after use. If necessary, use

a dish washing brush.

After using the Spiralizer, remove

all blades and accessories. Wash

the blades and accessory pieces

by hand with a soft cloth, in warm

sudsy water; or, wash in the top

rack of the dishwasher.

Clean the main body of the

Spiralizer attachment by hand only.

Wash with a soft, damp cloth. Dry

thoroughly with a soft dry cloth. Do

not wash in the dishwasher. Do not

immerse in water.

W10767027B_ENv12.indd 8 11/19/15 5:01 PM
