INSTRUCTION MANUAL

ENGLISH

CL310

FRANÇAIS pg. 37

ESPAÑOL pg. 19

400A AC Auto-Ranging

Digital Clamp Meter

400A AC Auto-Ranging

Digital Clamp Meter

400A AC Auto-Ranging

Digital Clamp Meter

True RMS

Measurement

Technology

600V

400A

40M

• AUTO-RANGING

• DATA HOLD

• RANGE HOLD

• TEMPERATURE

• AUDIBLE CONTINUITY

GENERAL SPECIFICATIONS

Klein Tools CL310 is an automatically ranging true root mean square

(TRMS) digital clamp meter that measures AC current via the clamp,

AC/DC voltage, resistance, continuity, frequency, capacitance, and

tests diodes via test-leads, and temperature via a thermocouple probe.

• Operating Altitude: 6562 ft. (2000m)

• Relative Humidity: <95% non-condensing

• Operating Temp: 32°to 122°F (0°to 50°C)

• Storage Temp: 14°to 122°F (-10°to 50°C)

• Accuracy: Values stated at 65° to 83°F (18° to 28°C)

• Temp Coefcient: 0.1 x (Quoted Accuracy) per °C above

28°C or below 18°C, corrections are required when ambient

working temp is outside of Accuracy Temp range

• Dimensions: 8.66" x 3.03" x 1.61" (220 x 77 x 41 mm)

• Weight: 9.88 oz. (280 g) including batteries

• Calibration: Accurate for one year

• Standards: Conforms to: UL 61010-1, UL 61010-2-032,

UL 61010-2-033.

Certified to: CAN/CSA C22.2 NO. 61010-1,

61010-2-032, 61010-2-033, IEC EN 61010-1,

61010-2-032, 61010-2-033, IEC EN 61326-1.

• Pollution degree: 2

• Accuracy: ± (% of reading + # of least significant digits)

• Drop Protection: 3.3 ft. (1m)

• Safety Rating: CATIII 600V, Class 2, Double insulation

• Electromagnetic Environment: IEC EN 61326-1. This

equipment meets requirements for use in basic and controlled

electromagnetic environments like residential properties,

business premises, and light-industrial locations.

Specifications subject to change.

ENGLISH

ELECTRICAL SPECIFICATIONS

Function Range Resolution Accuracy

AC Voltage

(V AC)

4.000V 1mV ±(1.5% + 5 digits)

40.00V 10mV ±(1.2% + 5 digits)

400.0V 100mV

600V 1V ±(1.5% + 5 digits)

DC Voltage

(V DC)

400.0mV 0.1mV ±(1.0% + 8 digits)

4.000V 1mV

±(0.8% + 3 digits)40.00V 10mV

400.0V 100mV

600V 1V ±(1.0% + 3 digits)

Input Impedance: 10MΩ

Frequency Range: 45 to 400Hz

Maximum Input: 600V AC RMS or 600V DC

AC Current

(A AC)

4.000A 1mA ±(2.5% + 30 digits)

40.00A 10mA ±(2.5% + 10 digits)

400.0A 100mA ±(2.0% + 10 digits)

Frequency Range: 50 to 60Hz

Resistance

400.0Ω 0.1Ω ±(1.2% + 5 digits)

4.000KΩ 1Ω

±(1.2% + 3 digits)

40.00kΩ 10Ω

400.0kΩ 100Ω

4.000MΩ 1kΩ

40.00MΩ 10kΩ ±(2.0% + 5 digits)

Maximum Input: 600V AC RMS or 600V DC

OTHER MEASUREMENT APPLICATIONS

Maximum Input: 600V DC or 600V AC RMS

• Diode Test: Approx. 1mA, open circuit voltage ~3.0V DC

• Continuity Check: Audible signal <10Ω, max current 1.5mA

• Sampling Frequency: 3 samples per second

• Auto Power off: After ~15 minutes of inactivity.

• Overload: "OL" indicated on display

• Polarity: "-" on display indicates negative polarity

• Display: 3-3/4 digit, 4000 Count LCD

ELECTRICAL SPECIFICATIONS

Function Range Resolution Accuracy

Capacitance

40.00nF 0.010nF ±(4% + 25 digits)

400.0nF 0.100nF

±(4% + 8 digits)

4.000μF 0.001μF

40.00μF 0.010μF

400.0μF 0.100μF

4.000mF 0.001mF ±(10% + 9 digits)

Maximum Input: 600V AC RMS or 600V DC

Temperature

-40° to 1832°F

°F

≤0°F ±(2.8% + 12 digits)

>0°F ±(2.8% + 6 digits)

-40° to 1000°C

°C ±(2.8% + 6 digits)

Frequency 10Hz to

1MHz

0.001Hz

to 1kHz ±(0.1% + 5 digits)

Duty Cycle

0.1% to 99.9%

(≤100kHz)

0.01% ±1.5%

(Range: 10% – 90%)

Sensitivity: 250mV and < 20V RMS

Maximum Input: 600V AC or 600V DC RMS

ENGLISH

WARNINGS

To ensure safe operation and service of the meter, follow these

instructions. Failure to observe these warnings can result in

severe injury or death.

• Before each use verify meter operation by measuring a known

voltage or current.

• Never use the meter on a circuit with voltages that exceed the

category based rating of this meter.

• Do not use the meter during electrical storms or in wet weather.

• Do not use the meter or test leads if they appear to be damaged.

• Use only with CAT III or CAT IV rated test leads.

• Ensure meter leads are fully seated, and keep fingers away

from the metal probe contacts when making measurements.

• Do not open the meter to replace batteries while the probes

are connected.

• Use caution when working with voltages above 25V AC RMS

or 60V DC. Such voltages pose a shock hazard.

• To avoid false readings that can lead to electrical shock,

replace batteries when a low battery indicator appears.

• Do not attempt to measure resistance or continuity on a live

circuit.

• Always adhere to local and national safety codes. Use personal

protective equipment to prevent shock and arc blast injury

where hazardous live conductors are exposed.

SYMBOLS ON METER

AC (Alternating Current)

AC/DC Voltage

Resistance (in Ohms) Audible Continuity

Double Insulated Class II Ground

Warning or Caution Risk of Electrical Shock

Diode Capacitance

Frequency

Duty-cycle

V Voltage (Volts) A Amperage (Amps)

Temperature (Fahrenheit / Celsius)

SYMBOLS ON LCD

AC AC (Alternating Current) DC DC (Direct Current)

Negative Reading Data Hold

Auto Ranging MAX Maximum Value Hold

MIN Minimum Value Hold Auto Power Off

Low Battery Audible Continuity

Degrees (Fahrenheit)

Degrees (Celsius)

Mega (value x 10

)

kilo (value x 10

)

milli (value x 10

-3

)

micro (value x 10

-6

)

nano (value x 10

-9

)

Volts

Amps Ohms

Hz%

Frequency/Duty Cycle

FEATURE DETAILS

ENGLISH

1. 4000 count LCD display 7. "RANGE" button

2. Function selector switch 8. "MAX/MIN" button

3. Clamp 9. Data Hold button

4. "COM" jack 10.

Clamp trigger (press to open clamp)

5. "VΩ" jack 11. Arrow markings

6. Backlight button 12. "SELECT" button

NOTE: There are no user-serviceable parts inside meter.

FUNCTION BUTTONS

ON/OFF

To power ON the meter, rotate the Function Selector switch

from

the OFF setting to any measurement setting. To power OFF the meter,

rotate the Function Selector switch

to the OFF setting. By default,

the meter will automatically power OFF after 15 minutes of inactivity.

If the meter automatically powers-OFF while in a measurement

setting, rotate Function Selector

switch to any other setting

(excluding the OFF setting) to power ON the meter. To deactivate

the power OFF functionality press and hold the "SELECT" button

before powering ON from the OFF setting. When auto power OFF

is deactivated, the Auto Power Off icon will not be visible in the

display.

"SELECT" BUTTON (FOR SECONDARY FUNCTIONS)

The "SELECT" button

activates the secondary function for each

application accessible by the function selector switch

. For voltage,

it toggles between AC and DC. For the other functions, it switches

between °F and °C, between Hz and % Duty-cycle, and between

Continuity, Resistance, Capacitance and Diode-Test. The default

function for each application is printed on the meter in white; the

secondary function or functions for each setting is printed on the

meter in orange.

BACKLIGHT

Press Backlight button symbol

to turn ON or OFF the backlight.

The backlight does not automatically power OFF.

RANGE

The meter defaults to auto-ranging mode . This mode

automatically determines the most appropriate measurement range

for the testing that is being conducted. To manually force the meter

to measure in a different range, use the "RANGE" button

1. Press the "RANGE" button

to manually select measurement

range ( is deactivated on the LCD). Repeatedly press the

"RANGE" button

to cycle through the available ranges, stopping

once the desired range is reached.

2. To return to auto-ranging mode, press and hold the "RANGE"

button

for more than one second ( is reactivated).

MAX/MIN

When the "MAX/MIN" button

is pressed, the meter keeps track

of the Maximum and Minimum values and the difference between

the Maximum and Minimum values as the meter continues to take

samples.

1. When measuring, press "MAX/MIN" button

to toggle between

the Maximum value (MAX), the Minimum value (MIN), and the

difference between Maximum and Minimum (MAX-MIN) values.

If a new maximum or minimum occurs the display updates with

that new value.

2. Press "MAX/MIN" button

for more than one second to return to

normal measuring mode.

DATA HOLD

Press HOLD

to hold the measurement on the display. Press

HOLD

again to release the display to return to live measuring.

FUNCTION BUTTONS

ENGLISH

OPERATING INSTRUCTIONS

CONNECTING TEST LEADS

Do not test if leads are improperly seated. Results could cause

intermittent display readings. To ensure proper connection, firmly

press leads into the input jack completely.

TESTING IN CAT III / CAT IV MEASUREMENT LOCATIONS

Ensure the test lead shield is pressed firmly in place. Failure to use

the CATIII / CATIV shield increases arc-flash risk.

TESTING IN CAT II MEASUREMENT LOCATIONS

CAT III / CAT IV shields may be removed for CAT II locations. This

will allow testing on recessed conductors such as standard wall

outlets. Take care not to lose the shields.

5/32"

(4 mm)

.7" (18 mm)

INCORRECT

CORRECT

ENGLISH

OPERATING INSTRUCTIONS

AC CURRENT (LESS THAN 400A)

AC Current is measured by pressing the clamp trigger

to open

the clamp and placing it around a current-carrying wire. When

measuring, care should be taken to ensure that the clamp is

completely closed with trigger

fully released, and that the wire

passes perpendicularly through the center of the clamp in line with

the arrow markings

To measure current:

1. Rotate the Function Selector switch

to the 400 A setting.

2. Place clamp around wire. The current measurement will be shown

in the display.

NOTE: If the measurement is less than 40A, rotate the Function

Selector switch

to the 40 A setting for improved resolution. If the

measurement is less than 4A, rotate the Function Selector switch

to the 4 A setting for improved resolution.

Disconnect test leads when measuring with the clamp.

passes perpendicularly through the center of the clamp in line with

WIRE

Andere Handbücher für CL310

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere Klein Tools Messgerät Handbücher

Klein Tools

Klein Tools VDV500-705 Bedienungsanleitung

Klein Tools

Klein Tools CL800E Bedienungsanleitung

Klein Tools

Klein Tools Toner-Pro VDV500-123 Bedienungsanleitung

Klein Tools

Klein Tools CL120VP Bedienungsanleitung

Klein Tools

Klein Tools LAN Scout Jr. 2 Bedienungsanleitung

Klein Tools

Klein Tools CL800A Bedienungsanleitung

Klein Tools

Klein Tools CL2000 Bedienungsanleitung

Klein Tools

Klein Tools ET160 Bedienungsanleitung

Klein Tools

Klein Tools MM1300 Bedienungsanleitung

Klein Tools

Klein Tools CL450 Bedienungsanleitung

Klein Tools

Klein Tools CL150 Bedienungsanleitung

Klein Tools

Klein Tools ET50 Bedienungsanleitung

Klein Tools

Klein Tools CL440 Bedienungsanleitung

Klein Tools

Klein Tools ET180 Bedienungsanleitung

Klein Tools

Klein Tools ET920 Bedienungsanleitung

Klein Tools

Klein Tools Ranger TDR VDV501-090 Bedienungsanleitung

Klein Tools

Klein Tools CL900E Bedienungsanleitung

Klein Tools

Klein Tools Probe-Pro Bedienungsanleitung

Klein Tools

Klein Tools CL445 Bedienungsanleitung

Klein Tools

Klein Tools CL110 Bedienungsanleitung

Klein Tools

Klein Tools CL600 Bedienungsanleitung

Klein Tools

Klein Tools CL120 Bedienungsanleitung

Klein Tools

Klein Tools CL700 Bedienungsanleitung

Klein Tools

Klein Tools ET200 Bedienungsanleitung

Beliebte Messgerät Handbücher anderer Marken

Suaoki

Suaoki D40 Bedienungsanleitung

Elster

Elster BK-G1.6 Bedienungsanleitung

Endress+Hauser

Endress+Hauser Deltabar FMD71 Handbuch

Duratool

Duratool D03128 Bedienungsanleitung

Vega

Vega VEGAPULS 65 Bedienungsanleitung

Tonghui

Tonghui TH2618B Bedienungsanleitung

Tenmars

Tenmars TM-801 Bedienungsanleitung

MSR

MSR 145 Bedienungsanleitung

TPS

TPS WP-82 Bedienungsanleitung

ELMETRON

ELMETRON CP-511 Bedienungsanleitung

PCB Piezotronics

PCB Piezotronics 003C30 Bedienungsanleitung

Tenma

Tenma 72-10465 Bedienungsanleitung

Endress+Hauser

Endress+Hauser Proline Promag 50 Technische Daten

Siemens

Siemens SITRANS F Coriolis FCT030 Stücklistenhandbuch

KLINGER

KLINGER CMF V Series Bedienungsanleitung

EXFO

EXFO FTB-2 Bedienungs- und Wartungshandbuch

Keysight

Keysight M8290A Bedienungsanleitung

ADTEK

ADTEK MW-5 Bedienungsanleitung
