This equipment has been tested and found to comply with the limits for a Class A digital

device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful

interference when the equipment generates, uses, and can radiate radio frequency

energy and, if not installed and used in accordance with the instruction manual, may

cause harmful interference to radio communications. Operation of this equipment in a

residential area is likely to cause harmful interference in which case the user will be

required to correct the interference at his own expense.

The design and production of this unit conform to FCC regulations, and any changes

or modifications must be registered with the FCC and are subject to FCC control. Any

changes made by the purchaser or user without first contacting the manufacture will

be subject to penalty under FCC regulations.

WARNING

DR1600.book 1 ページ２００８年６月１８日　水曜日　午後６時２７分

Installation and Operation Precautions

Safety Information

This section contains detailed instructions on the operation and maintenance of this machine. To achieve

optimum utility of this device, all operators should carefully read and follow the instructions in this manual.

Please read the following section before connecting the machine to the supply. It contains important in-

formation related to user safety and preventing equipment problems.

Please keep this manual in a handy place near the machine.

Make sure you observe all of the precautions appear in each section of this manual.

KM_Ver.01E_C

Note

Some parts of the contents of this section may not correspond with the purchased product.

Warning and Precaution Symbols

The following indicators are used on the warning labels or in this manual to categorize the level of safety

warnings.

Meaning of Symbols

WARNING

Ignoring this warning could cause serious injury or even death.

CAUTION

Ignoring this caution could cause injury or damage to property.

A triangle indicates a danger against which you should take precaution.

This symbol warns against cause burns.

A diagonal line indicates a prohibited course of action.

This symbol warns against dismantling the device.

A solid circle indicates an imperative course of action.

This symbol indicates you must unplug the device.

DR1600.book 1 ページ２００８年６月１８日　水曜日　午後６時２７分

Disassemble and modification

WARNING

• Do not attempt to remove the covers and panels which have

been fixed to the product. Some products have a high-volt-

age part or a laser beam source inside that could cause an

electrical shock or blindness.

• Do not modify this product, as a fire, electrical shock, or

breakdown could result. If the product employs a laser, the

laser beam source could cause blindness.

Power cord

WARNING

• Use only the power cord supplied in the package. If a power

cord is not supplied, only use the power cord and plug that

is specified in POWER CORD INSTRUCTION. Failure to use

this cord could result in a fire or electrical shock.

• Use the power cord supplied in the package only for this ma-

chine and NEVER use it for any other product. Failure to ob-

serve this precaution could result in a fire or electrical shock.

• Do not scratch, abrade, place a heavy object on, heat, twist,

bend, pull on, or damage the power cord. Use of a damaged

power cord (exposed core wire, broken wire, etc.) could re-

sult in a fire or breakdown.

Should any of these conditions be found, immediately turn

OFF the power switch, unplug the power cord from the pow-

er outlet, and then call your authorized service representa-

tive.

DR1600.book 2 ページ２００８年６月１８日　水曜日　午後６時２７分

Power source

WARNING

• Use only the specified power source voltage. Failure to do

that could result in a fire or electrical shock.

• Connect power plug directly into wall outlet having the same

configuration as the plug. Use of an adapter leads to the

product connecting to inadequate power supply (voltage,

current capacity, grounding), and may result in fire or shock.

If proper wall outlet is not available, the customer shall ask

qualified electrician for the installation.

• Do not use a multiple outlet adapter nor an extension cord in

principle. Use of an adapter or an extension cord could

cause a fire or electrical shock.

Contact your authorized service representative if an exten-

sion cord is required.

• Consult your authorized service representative before con-

necting other equipment on the same wall outlet. Overload

could result in a fire.

CAUTION

• The outlet must be near the equipment and easily accessi-

ble. Otherwise you can not pull out the power plug when an

emergency occurs.

Power plug

WARNING

• Do not unplug and plug in the power cord with a wet hand,

as an electrical shock could result.

• Plug the power cord all the way into the power outlet. Failure

to do this could result in a fire or electrical shock.

CAUTION

• Do not tug the power cord when unplugging. Pulling on the

power cord could damage the cord, resulting in a fire or

electrical shock.

• Remove the power plug from the outlet more than one time

a year and clean the area between the plug terminals. Dust

that accumulates between the plug terminals may cause a

fire.

Grounding

WARNING

• Connect the power cord to an electrical outlet that is

equipped with a grounding terminal.

DR1600.book 3 ページ２００８年６月１８日　水曜日　午後６時２７分

Installation

WARNING

• Do not place a flower vase or other container that contains

water, or metal clips or other small metallic objects on this

product. Spilled water or metallic objects dropped inside the

product could result in a fire, electrical shock, or breakdown.

Should a piece of metal, water, or any other similar foreign

matter get inside the product, immediately turn OFF the

power switch, unplug the power cord from the power outlet,

and then call your authorized service representative.

CAUTION

• After installing this product, mount it on a secure base. If the

unit moves or falls, it may cause personal injury.

• Do not place the product in a dusty place, or a site exposed

to soot or steam, near a kitchen table, bath, or a humidifier.

A fire, electrical shock, or breakdown could result.

• Do not place this product on an unstable or tilted bench, or

in a location subject to a lot of vibration and shock. It could

drop or fall, causing personal injury or mechanical break-

down.

• Do not let any object plug the ventilation holes of this prod-

uct. Heat could accumulate inside the product, resulting in a

fire or malfunction.

• Do not use flammable sprays, liquids, or gases near this

product, as a fire could result.

Ventilation

CAUTION

• Always use this product in a well ventilated location. Oper-

ating the product in a poorly ventilated room for an extended

period of time could injure your health. Ventilate the room at

regular intervals.

DR1600.book 4 ページ２００８年６月１８日　水曜日　午後６時２７分

Actions in response to troubles

WARNING

• Do not keep using this product, if this product becomes in-

ordinately hot or emits smoke, or unusual odor or noise. Im-

mediately turn OFF the power switch, unplug the power cord

from the power outlet, and then call your authorized service

representative. If you keep on using it as is, a fire or electrical

shock could result.

• Do not keep using this product, if this product has been

dropped or its cover damaged. Immediately turn OFF the

power switch, unplug the power cord from the power outlet,

and then call your authorized service representative. If you

keep on using it as is, a fire or electrical shock could result.

When moving the machine

CAUTION

• Whenever moving this product, be sure to disconnect the

power cord and other cables. Failure to do this could dam-

age the cord or cable, resulting in a fire, electrical shock, or

breakdown.

• When moving this product, always hold it by the locations

specified in the User’s Guide or other documents. If the unit

falls it may cause severe personal injury. The product may

also be damaged or malfunction.

Before successive holidays

CAUTION

• Unplug the product when you will not use the product for

long periods of time.

DR1600.book 5 ページ２００８年６月１８日　水曜日　午後６時２７分

CONTENTS

SPECIFICATIONS................................................................................................ 1

INSTALLATION .................................................................................................... 2

PARTS IDENTIFICATION .................................................................................... 4

CONTROL PANEL KEYS AND INDICATORS ..................................................... 6

REMOVING AND INSTALLING THE FILM UNIT................................................. 8

FILMING PROCEDURE ....................................................................................... 9

LOADING AND UNLOADING FILM ................................................................... 10

SPACING............................................................................................................ 14

RELATIONSHIP BETWEEN DOCUMENT SIZE AND MAGNIFICATION.......... 15

TAKING A STEP TEST ...................................................................................... 16

MICROFILMING ................................................................................................. 17

RECORDING DOCUMENT MARK..................................................................... 18

RECORDING FRAME NUMBER........................................................................ 20

MANUAL EXPOSURE MODE ............................................................................ 22

CHOICE MODES................................................................................................ 23

MAINTENANCE AND SERVICES...................................................................... 27

POTENTIAL PROBLEMS................................................................................... 29

TROUBLESHOOTING........................................................................................ 30

SUPPLEMENT ................................................................................................... 31

DR1600.book 1 ページ２００８年６月１８日　水曜日　午後６時２７分

SPECIFICATIONS

■ Type: : Planetary Microfilmer

■ Lens: : Micro-Rokkor f = 28 mm

■ Film: : 16-mm Roll Film (Non-Perforated)

5 mil - 100 ft., 2.5 mil - 215 ft.

■ Document Size: : Max. 17” x 11” or A3

■ Frame (Aperture) Size: : Single - 9.7 x 12.6 mm

Double - 18.2 x 12.6 mm

Automatically selected according to the original size detected, or manually selected.

■ Pulldown: : Single - 10.0 mm (9.5 to 11.75 mm)

Double - 18.5 mm (18.0 to 23.5 mm)

■ Spacing: : Single Frame, Prefixed Frames (5 to 250 frames) and Any Desired Frames

(1 to 9999 frames)

■ Resolution: : 150 lines or more/mm

■ Depth of Field: : +20 mm from Copy Board

■ Reduction Ratios: : 1/25 (Single and Double Frames)

1/32 (Single Frame)

■ Numbering: : 12 digits (4 digits x 3 fields)

• Used for the block, batch, and item numbers.

• Can also be used as an 8- or 4-digit counter.

■ Document Marks: : Three document mark levels

Tri level (L, M, S)

Dual level (L, S)

Single level (L or M or S)

■ Document Mark : Document Mark Positioning of the medium width Single Level Mark can be adjusted

Positioning: by using choice Mode (between 1.21 to 4.21 mm).

■ Film Supply Warning: : Beeping warns that the film will soon be running out and a warning Light indicates

the length of film remaining for use reaches approx. 1.5 meters. (5 ft.)

■ Exposure Control: : Automatic and Manual exposure control

■ Light Source: : Two 15-W fluorescent lamps

■ Power Requirement: : 120 V 60 Hz, 220/230 - 240 V 50 Hz

■ Power Consumption: : 100W

■ Dimensions: : 900 (W) x 700 (D) x 1250 (H) mm or 35-7/16” (W) x 27-9/16” (D) x 49-7/32” (H)

■ Weight: : 41 kg or 90 lbs

■ Options: : Foot Pedal, Black Board, Resettable Counter (6-digit), RS232C Interface Kit

■ Accessory: : Blower Brush, Reel

CAUTION

Use a shielded cable for the RS-232C interface cable.

Specification of this equipment are subject to change without notice.

DR1600.book 1 ページ２００８年６月１８日　水曜日　午後６時２７分

INSTALLATION

■INSTALLATION

■ Space Requirements

To ensure easy operation and service the machine requires the following installation space.

DR1600.book 2 ページ２００８年６月１８日　水曜日　午後６時２７分

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Konica Minolta Scanner Handbücher

Konica Minolta

Konica Minolta Dimage Scan Elite 5400II Bedienungsanleitung

Konica Minolta

Konica Minolta Color Centro IC-601 Bedienungsanleitung

Konica Minolta

Konica Minolta DiMAGE Scan Elite 5400 II Handbuch

Konica Minolta

Konica Minolta BIZHUB PRO 1050 Bedienungsanleitung

Konica Minolta

Konica Minolta PS5000C MKII Bedienungsanleitung

Konica Minolta

Konica Minolta DiMAGE Scan Dual IV Bedienungsanleitung

Konica Minolta

Konica Minolta PS5000C MKII Bedienungsanleitung

Konica Minolta

Konica Minolta SL1000 Microfiche Bedienungsanleitung

Konica Minolta

Konica Minolta MS7000 MK II Bedienungsanleitung

Konica Minolta

Konica Minolta PS5000C MKII Bedienungsanleitung

Konica Minolta

Konica Minolta II Bedienungsanleitung

Konica Minolta

Konica Minolta MS6000 MK II Bedienungsanleitung

Konica Minolta

Konica Minolta SCANNER RX-1 - V2.1.0 Bedienungsanleitung

Konica Minolta

Konica Minolta MS 7000 Bedienungsanleitung

Konica Minolta

Konica Minolta bizhub PRESS C8000 Bedienungsanleitung

Konica Minolta

Konica Minolta PS7000C MKII Bedienungsanleitung

Konica Minolta

Konica Minolta SL1000 Digital Film Scanner Bedienungsanleitung

Konica Minolta

Konica Minolta bizhub 160 Bedienungsanleitung

Konica Minolta

Konica Minolta Fujitsu fi-6800 Bedienungsanleitung

Konica Minolta

Konica Minolta SL1000 Digital Film Scanner Bedienungsanleitung

Konica Minolta

Konica Minolta RX-II Bedienungsanleitung

Konica Minolta

Konica Minolta bizhub PRESS 1052 Bedienungsanleitung

Konica Minolta

Konica Minolta Vivid 910 Bedienungsanleitung

Konica Minolta

Konica Minolta IV Bedienungsanleitung

Beliebte Scanner Handbücher anderer Marken

Plustek

Plustek Scanner Bedienungsanleitung

Z/I Imaging

Z/I Imaging PhotoScan 2001 Bedienungsanleitung

Renkforce

Renkforce DS100-5M Bedienungsanleitung

Image Access

Image Access WideTEK A2 Bedienungsanleitung

Canon

Canon imageFORMULA CR-120N Bedienungsanleitung

Fujitsu

Fujitsu FI-4860C2 Bedienungsanleitung

GeoSlam

GeoSlam ZEB Horizon Montageanleitung

Kodak

Kodak i5800 Scanner Bedienungsanleitung

Kodak

Kodak i7300 Bedienungsanleitung

Revopoint

Revopoint POP Bedienungsanleitung

Fujitsu

Fujitsu fi-4860C Bedienungsanleitung

Eddyfi Technologies

Eddyfi Technologies Floormap X Bedienungsanleitung

Faselase

Faselase F6 Bedienungsanleitung

Fujitsu

Fujitsu CardMinder Bedienungsanleitung

Uniden

Uniden BC340CRS Bedienungsanleitung

Infinite Peripherals

Infinite Peripherals INFINEA TAB M Bedienungsanleitung

Mustek

Mustek PageExpress 4800 Pro Bedienungsanleitung

Optex

Optex 750830 Bedienungsanleitung
