Kramer VS-44H Bedienungsanleitung

Kramer Electronics, Ltd.

USER MANUAL

Model:

VS-44H

4 x 4 HDMI Matrix Switcher

Contents

1Introduction 1

2Getting Started 1

2.1 Quick Start 2

3Overview 3

3.1 Defining the EDID 3

3.2 About HDMI 4

3.3 About HDCP 5

3.4 Recommendations for Best Performance 5

4Your VS-44H 4 x 4 HDMI Matrix Switcher 5

5Installing the VS-44H in a Rack 8

6Connecting the VS-44H 4 x 4 HDMI Matrix Switcher 9

7Operating the VS-44H 4 x 4 HDMI Matrix Switcher 10

7.1 Routing Inputs to Outputs 11

7.2 Disconnecting the Outputs 11

7.3 Storing and Recalling a Setting 11

7.4 Acquiring the EDID 12

7.4.1 Acquiring an EDID from a Single Connected Output 12

7.4.2 Acquiring an EDID from Several Sets of Inputs and Outputs 12

7.4.3 Acquiring an EDID from Several Connected Outputs Automatically 13

7.4.4 Acquiring the Default EDID 14

7.5 Connecting to VS-44H via RS-232 14

7.6 Controlling via ETHERNET 14

7.6.1 Connecting the ETHERNET Port directly to a PC (Crossover Cable) 14

7.6.2 Connecting the ETHERNET Port via a Network Hub (Straight-Through Cable) 16

7.6.3 Control Configuration via the Ethernet Port 16

8Technical Specifications 16

9Communication Parameters 17

10 Hex Table 17

11 Kramer Protocol 2000 18

Figures

Figure 1: VS-44H 4 x 4 HDMI Matrix Switcher Front and Rear Views 6

Figure 2: Connecting the VS-44H 4 x 4 HDMI Matrix Switcher 10

Figure 3: Local Area Connection Properties Window 15

Figure 4: Internet Protocol (TCP/IP) Properties Window 15

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Contents

Tables

Table 1: VS-44H 4 x 4 HDMI Matrix Switcher Features 7

Table 2: VS-44H Technical Specifications 16

Table 3: Communication Parameters 17

Table 4: VS-44H Hex Codes for Switching via RS-232/RS-485 17

Table 5: Protocol Definitions 18

Table 6: Instruction Codes for Protocol 2000 19

Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast

range of problems that confront the video, audio, presentation, and

broadcasting professional on a daily basis. In recent years, we have

redesigned and upgraded most of our line, making the best even better! Our

1,000-plus different models now appear in 11 groups1

Note, that the Kramer VS-44H is identical to the VS-44HDMI; just the

name has changed replacing the suffix “HDMI” by “H” (according to

the HDMI Guideline).

that are clearly

defined by function. Thank you for purchasing the Kramer VS-44H 4 x 4

HDMI Matrix Switcher, which is ideal for conference room presentations

and advertising applications, as well as for rental and staging.

Each package includes the following items:

•The VS-44H 4 x 4 HDMI Matrix Switcher

•Power cord2, rack “ears”, Windows®-based Kramer control software3

•Kramer RC-IR3Infrared Remote Control Transmitter (including the

required batteries and a separate user manual4) and this user manual

and Windows®-based Ethernet Configuration Manager and Virtual

Serial Port Manager

2 Getting Started

We recommend that you:

•Unpack the equipment carefully and save the original box and

packaging materials for possible future shipment

•Review the contents of this user manual

•Use Kramer high performance high resolution cables5

1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems;

GROUP 4: Format/Standards Converters; GROUP 5: Range Extenders and Repeaters; GROUP 6: Specialty AV Products;

GROUP 7: Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity;

GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Products

2 We recommend that you use only the power cord supplied with this device

3 Downloadable from our Web site at http://www.kramerelectronics.com

4 Download up-to-date Kramer user manuals from our Web site at http://www.kramerelectronics.com

5 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Getting Started

2.1 Quick Start

This quick start chart summarizes the basic setup and operation steps.

Overview

3 Overview

The VS-44H is a high-performance matrix switcher for HDMI signals. It

reclocks and equalizes the signal and can route any input to any or all

outputs simultaneously.

More specifically the VS-44H features:

•Up to 1.65Gbps bandwidth per graphic channel1

•Four input selector buttons to switch to the four selectable outputs

•Support for HDCP (High Bandwidth Digital Content Protection)

•I-EDIDPro™ Kramer Intelligent EDID Processing™, an intelligent

EDID handling and processing algorithm that ensures Plug and Play

operation for HDMI systems

•An OFF button to disconnect an output

•A PANEL LOCK button to prevent unwanted tampering with the

buttons on the front panel

•1U-high, 19” size for mounting in a professional rack enclosure

The VS-44H can be controlled using the front panel buttons, or remotely via:

•RS-232 serial commands transmitted by a touch-screen system, PC, or

other serial controller

•The Kramer infrared remote control transmitter

•The ETHERNET

3.1 Defining the EDID

The EDID (Extended Display Identification Data2

) is a data-structure,

provided by a display, to describe its capabilities to an HDMI source. The

EDID enables the VS-44H to “know” what kind of monitor is connected to

the output. The EDID includes the name of the manufacturer, the product

type, the timing data supported by the display, the display size, luminance

data and (for digital displays only) the pixel mapping data.

1 Suitable for resolutions up to UXGA at 60Hz, and for all HD resolutions

2 Defined by a standard published by the Video Electronics Standards Association (VESA)

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Overview

3.2 About HDMI

High-Definition Multimedia Interface (HDMI) is an uncompressed all-digital1

In particular, HDMI:

audio/video interface, widely supported in the entertainment and home cinema

industry. It delivers the highest high-definition image and sound quality. Note

that Kramer Electronics Limited is an HDMI Adopter and an HDCP Licensee.

•Provides a simple2interface between any audio/video source, such as

a set-top box, DVD player, or A/V receiver and video monitor, such

as a digital flat LCD / plasma television (DTV), over a single

lengthy3

•Supports standard, enhanced, high-definition video, and multi-

channel digital audio

cable

•Transmits all ATSC HDTV standards and supports 8-channel digital

audio, with bandwidth to spare to accommodate future enhancements

and requirements

on a single cable

•Benefits consumers by providing superior, uncompressed digital

video quality via a single cable5

•Is backward-compatible with DVI (Digital Visual Interface)

, and user-friendly connector

•Supports two-way communication between the video source (such as

a DVD player) and the digital television, enabling new functionality

such as automatic configuration and one-button play

HDMI has the capacity to support existing high-definition video formats

(720p, 1080i, and 1080p/60), as well as standard definition formats such as

NTSC or PAL.

1 Ensuring an all-digital rendering of video without the losses associated with analog interfaces and their unnecessary digital-

to-analog conversions

2 With video and multi-channel audio combined into a single cable, the cost, complexity, and confusion of multiple cables

currently used in A/V systems is reduced

3 HDMI technology has been designed to use standard copper cable construction at up to 15m

4 HDMI supports multiple audio formats, from standard stereo to multi-channel surround-sound. HDMI has the capacity to

support Dolby 5.1 audio and high-resolution audio formats

5 HDMI provides the quality and functionality of a digital interface while also supporting uncompressed video formats in a

simple, cost-effective manner

Your VS-44H 4 x 4 HDMI Matrix Switcher

3.3 About HDCP

The High-Bandwidth Digital Content Protection (HDCP) standard

(developed by Intel), protects digital video and audio signals transmitted

over DVI or DVI connections between two HDCP-enabled devices to

eliminate the reproduction of copyrighted material. To protect copyright

holders (such as movie studios) from having their programs copied and shared,

the HDCP standard provides for the secure and encrypted transmission of

digital signals.

3.4 Recommendations for Best Performance

To achieve the best performance:

•Use only good quality connection cables1

•Avoid interference from neighboring electrical appliances that may

adversely influence signal quality and position your Kramer VS-44H

away from moisture, excessive sunlight and dust

to avoid interference,

deterioration in signal quality due to poor matching, and elevated noise

levels (often associated with low quality cables).

4 Your VS-44H 4 x 4 HDMI Matrix Switcher

Figure 1 and Table 1 define the VS-44H.

1 Available from Kramer Electronics on our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Your VS-44H 4 x 4 HDMI Matrix Switcher

Figure 1: VS-44H 4 x 4 HDMI Matrix Switcher Front and Rear Views

Your VS-44H 4 x 4 HDMI Matrix Switcher

Table 1: VS-44H 4 x 4 HDMI Matrix Switcher Features

Feature

Function

1 IR Receiver LED The red LED is illuminated when receiving signals from the Infra-red

remote control transmitter

2 POWER Switch Illuminated switch for turning the unit ON or OFF

3 ALL Button Use ALL to select all inputs or all outputs (see section 7.1)

4 OFF Button Use OFF to disconnect one or all outputs (see section 7.2)

5 IN ButtonsPress an INPUT selector button to select an input (from 1 to 4)

6 OUT ButtonsPress an OUTPUT selector button to select an output (from 1 to 4)

7 STO Button Press to store an input setting

8 RCL Button Press to recall an input setting

9 LOCK Button Press to toggle disengaging the front panel buttons and to acquire

the EDID (see section 7.4)

10 EDID Button

Press to acquire the EDID

11 7-segment Display Displays the selected input switched to the output (marked above

each input)

12 IN HDMI Connectors Connect to the HDMI sources (from 1 to 4)

13 OUT HDMI ConnectorsConnect to the HDMI acceptors (from 1 to 4)

14 RS-232 9-pin D-sub Port Connects to the PC or the RS-232 Remote Controller

15 ETHERNET Connector Connects to the PC or other Ethernet Controller

16 RESET Button Press the reset button to reset to the ETHERNET factory default

definitions 2

IP number −192.168.1.39

Mask – 255.255.255.0

Gateway – 192.168.1.1

17 REMOTE IR Connector Connect to an external IR receiver unit for controlling the machine

via an IR remote controller (instead of using the front panel IR

receiver)

18 Power Connector with Fuse AC connector enabling power supply to the unit

1 Illuminates when configuring the EDID

2 First disconnect the power cord and then connect it again while pressing the RESET button. The unit will power up and load

its memory with the factory default definitions

Inhaltsverzeichnis

Andere Kramer Matrix-Umschalter Handbücher

Kramer

Kramer 3216HDEE Bedienungsanleitung

Kramer

Kramer LASSEN XL 3216S Bedienungsanleitung

Kramer

Kramer VS-88HDCPxl Bedienungsanleitung

Kramer

Kramer VS-88HDCPxl Bedienungsanleitung

Kramer

Kramer Sierra Video 1616V3 Bedienungsanleitung

Kramer

Kramer VP-727XL Bedienungsanleitung

Kramer

Kramer VS-88UHD Bedienungsanleitung

Kramer

Kramer VS-3232DN-EM Bedienungsanleitung

Kramer

Kramer VP-729 Bedienungsanleitung

Kramer

Kramer VS-88HDxl Bedienungsanleitung

Kramer

Kramer XL 1204V4 Bedienungsanleitung

Kramer

Kramer VP-88ETH Bedienungsanleitung

Kramer

Kramer Sierra Pro XL 1608V5S Bedienungsanleitung

Kramer

Kramer 88D Bedienungsanleitung

Kramer

Kramer VS-8 Series Bedienungsanleitung

Kramer

Kramer XL 3216V2 Bedienungsanleitung

Kramer

Kramer VS-1604 Bedienungsanleitung

Kramer

Kramer VS-3232A Bedienungsanleitung

Kramer

Kramer VS-5x4 Bedienungsanleitung

Kramer

Kramer VS-88HDCPxl Bedienungsanleitung

Kramer

Kramer VS-42HDCP Bedienungsanleitung

Kramer

Kramer Sierra Video 3248V5Sxl Bedienungsanleitung

Kramer

Kramer LASSEN XL 3232S Bedienungsanleitung

Kramer

Kramer VS-84HDCPxl Bedienungsanleitung

Beliebte Matrix-Umschalter Handbücher anderer Marken

Broadcast Tools

Broadcast Tools SS 8.2 Bedienungsanleitung

Altimium

Altimium MATF32 Bedienungsanleitung

ALFAtron

ALFAtron ALF-MUK44N Bedienungsanleitung

Monoprice

Monoprice Blackbird 15377 Bedienungsanleitung

PTN

PTN FMX12 Bedienungsanleitung

CYP

CYP nT15GX01 Bedienungsanleitung

TESmart

TESmart HMA0402A40 Bedienungsanleitung

Octava

Octava HD4XSTPMX Bedienungsanleitung

Intelix

Intelix FLX-88 Betriebsanleitung

Roland

Roland XS-1HD Bedienungsanleitung

Atlona

Atlona AT-HDMI-22M Bedienungsanleitung

Link

Link HD8X8 Bedienungsanleitung

AMX

AMX AVS-OP-2020-117 Anleitungen und Rezepte

Lindy

Lindy 38042 Bedienungsanleitung

Extron electronics

Extron electronics MTPX Plus Series Bedienungsanleitung

Key Digital

Key Digital Champion KD-16x16CS Bedienungsanleitung

Shinybow USA

Shinybow USA SB-8811 Bedienungsanleitung

Optimus

Optimus Compact Bedienungsanleitung
