Kramer VS-88H Bedienungsanleitung

KRAMER ELECTRONICS LTD.

USER MANUAL

MODEL:

VS-88H

8x8 HDMI Matrix Switcher

P/N: 2900-000654 Rev 5

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. 07131 911201

Fax 07131 911203

[email protected]

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. 07131 911201

Fax 07131 911203

[email protected]

VS-88H - Contents

Contents

1Introduction 1

2Getting Started 2

2.1 Achieving the Best Performance 2

2.2 Safety Instructions 2

2.3 Recycling Kramer Products 3

3Overview 4

3.1 Defining the VS-88H 8x8 HDMI Matrix Switcher 4

3.2 Using the IR Transmitter 7

4Installing in a Rack 8

5Connecting the VS-88H 9

5.1 Connecting to the VS-88H via RS-232 10

5.2 Using the Ethernet Connection 11

6Operating the VS-88H 8x8 HDMI Matrix Switcher 14

6.1 Routing Inputs to Outputs 14

6.2 Disconnecting the Outputs 14

6.3 Storing and Recalling a Setting 14

6.4 Acquiring the EDID 15

6.5 Locking and Unlocking the Front Panel 18

6.6 Resetting the Ethernet Configuration to Default Values 18

6.7 Controlling Configuration via the Ethernet Port 18

7Technical Specifications 19

8Default Communication Parameters 20

9Kramer Protocol 2000 21

Figures

Figure 1: VS-88H 8x8 HDMI Matrix Switcher Front Panel 5

Figure 2: VS-88H 8x8 HDMI Matrix Switcher Rear Panel 6

Figure 3: Connecting the VS-88H 8x8 HDMI Matrix Switcher 10

Figure 4: Local Area Connection Properties Window 12

Figure 5: Internet Protocol (TCP/IP) Properties Window 12

Figure 6: Store-Recall Button Configuration 15

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. 07131 911201

Fax 07131 911203

[email protected]

VS-88H - Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range of

problems that confront video, audio, presentation, and broadcasting professionals

on a daily basis. In recent years, we have redesigned and upgraded most of our

line, making the best even better!

Our 1,000-plus different models now appear in 11 groups that are clearly defined

by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;

GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:

Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:

Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:

Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11:

Sierra Video Products.

Congratulations on purchasing your Kramer VS-88H 8x8 HDMI Matrix Switcher,

which is ideal for the following typical applications:

Conference room presentations

Advertising applications

Rental and staging

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. 07131 911201

Fax 07131 911203

[email protected]

VS-88H - Getting Started

2 Getting Started

We recommend that you:

Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

Review the contents of this user manual

Go to http://www.kramerelectronics.com/support/product_downloads.asp

to check for up-to-date user manuals, application programs, and to check if

firmware upgrades are available (where appropriate).

2.1 Achieving the Best Performance

To achieve the best performance:

Use only good quality connection cables (we recommend Kramer high-

performance, high-resolution cables) to avoid interference, deterioration in

signal quality due to poor matching, and elevated noise levels (often

associated with low quality cables)

Do not secure the cables in tight bundles or roll the slack into tight coils

Avoid interference from neighboring electrical appliances that may adversely

influence signal quality

Position your Kramer VS-88H away from moisture, excessive sunlight and

dust

This equipment is to be used only inside a building. It may only be

connected to other equipment that is installed inside a building.

2.2 Safety Instructions

Caution:

There are no operator serviceable parts inside the unit

Warning:

Use only the power cord that is supplied with the unit

Warning:

Do not open the unit. High voltages can cause

electrical shock! Servicing by qualified personnel only

Warning:

Disconnect the power and unplug the unit from the wall

before installing

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. 07131 911201

Fax 07131 911203

[email protected]

VS-88H - Getting Started

2.3 Recycling Kramer Products

The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC

aims to reduce the amount of WEEE sent for disposal to landfill or incineration by

requiring it to be collected and recycled. To comply with the WEEE Directive,

Kramer Electronics has made arrangements with the European Advanced

Recycling Network (EARN) and will cover any costs of treatment, recycling and

recovery of waste Kramer Electronics branded equipment on arrival at the EARN

facility. For details of Kramer’s recycling arrangements in your particular country

go to our recycling pages at http://www.kramerelectronics.com/support/recycling/.

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. 07131 911201

Fax 07131 911203

[email protected]

VS-88H - Overview

3 Overview

The VS-88H is a high quality 8x8 matrix switcher for HDMI signals. It reclocks and

equalizes the signal and can route any input to any or all outputs simultaneously.

In particular, the VS-88H features:

Up to 6.75Gbps data rate (2.25Gbps per graphics channel)

Suitable for resolutions up to UXGA at 60Hz and for all HD resolutions.

HDTV compatibility

HDCP compliance

HDMI support for Deep Color, x.v.Color™

3D pass-through

I-EDIDPro™ Kramer Intelligent EDID Processing™ – Intelligent EDID

handling & processing algorithm ensures Plug and Play operation for HDMI

systems

Kramer reKlocking™ & Equalization Technology that rebuilds the digital

signal to travel longer distances

An OFF button to disconnect an output

A lock button to prevent unwanted tampering with the buttons on the front

panel

16 preset memory locations for quick access to common configurations

You can control the VS-88H using the front panel buttons, or remotely via:

RS-232 serial commands transmitted by a PC, touch screen system or other

serial controller

The Kramer infrared remote control transmitter

A PC connected to the Ethernet port on the device via a LAN

3.1 Defining the VS-88H 8x8 HDMI Matrix Switcher

This section defines the VS-88H.

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. 07131 911201

Fax 07131 911203

[email protected]

VS-88H - Overview

VS-88H –Overview

Figure 1: VS-88H 8x8 HDMI Matrix Switcher Front Panel

Feature

Function

IR Indication LED and Receiver

Lights yellow when receiving signals from the infrared remote control transmitter, signal

receiver for the infrared remote control transmitter

POWER LED

Lights when the device is turned on

ALL Button

Press followed by an input button to connect the selected input to all outputs

For example, press ALL and then Input button # 2 to connect input # 2 to all the outputs

OFF Button

Press after pressing an output button to disconnect the selected output from the inputs.

To disconnect all the outputs, press ALL followed by OFF

SELECT Buttons

IN (1 to 8)

Press to select the input to switch after selecting an output (also used for storing machine

setups (see Section 6.3)

OUT (1 to 8)

Press to select an output to switch followed by an input (also used for storing machine setups

(see Section 6.3)

STO Button

Press to store the current switching setting to a preset (see Section 6.3)

RCL Button

Press to recall the current switching setting from a preset (see Section 6.3)

LOCK Button

Press and hold to toggle the locking/release of the front panel buttons.

EDID Button

Press to capture the EDID (see Section 6.4)

OUTPUT/INPUT 7-segment LED Display

Displays the input currently switched to the output which is marked above each input

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. 07131 911201

Fax 07131 911203

[email protected]

VS-88H - Overview

Figure 2: VS-88H 8x8 HDMI Matrix Switcher Rear Panel

Feature

Function

IN HDMI Connectors(1 to 8)

Connect to up to 8 HDMI sources

OUT HDMI Connectors (1 to 8)

Connect to up to 8 HDMI acceptors

RS-232 9-pin D-sub Port Connector

Connect to a PC/serial controller

ETHERNET RJ-45 Connector

Connect to a PC via a LAN

ETH RESET Button

Press to reset to the factory default IP parameters:

IP number 192.168.1.39

Mask –255.255.255.0

Gateway –192.168.1.1

Depress the button while powering on the device. The device powers up with the factory default IP parameters

Mains Power Connector and Fuse

Connect to the mains power

Mains Power Switch

Switch for turning the device on or off

VS-88H –Overview

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. 07131 911201

Fax 07131 911203

[email protected]

VS-88H - Overview

3.2 Using the IR Transmitter

You can use the RC-IR3 IR transmitter to control the machine via the built-in IR

receiver on the front panel or, instead, via an optional external IR receiver (Model:

C-A35M/IRR-50). The external IR receiver can be located up to 15 meters away

from the machine. This distance can be extended to up to 60 meters when used

with three extension cables (Model: C-A35M/A35F-50).

Before using the external IR receiver, be sure to arrange for your Kramer dealer to

insert the internal IR connection cable (P/N: 505-70434010-S) with the 3.5mm

connector that fits into the REMOTE IR opening on the rear panel. Connect the

external IR receiver to the REMOTE IR 3.5mm connector.

im Vertrieb von

CAMBOARD Electronics

www.camboard.de

Tel. 07131 911201

Fax 07131 911203

[email protected]
