Kramer 575 Bedienungsanleitung

575, 576 Quick Start (P/N: 2900-301037QS REV 3)

P/N:

2900- 301037QS

Rev:

Scan for full manual

575/576 Quick Start Guide

This guide helps you install and use your 575/576 for the first time.

Go to www.kramerav.com/downloads/575-576 to download the latest user manual and check if

firmware upgrades are available.

Step 1: Check what’s in the box

575 2-Wire Extra Range HD Transmitter /

576 2-Wire Extra Range HD Receiver

Power adapter

Bracket set

Quick start guide

Rubber feet

Step 2: Get to know your 575/576

575 2-Wire Extra Range HD Transmitter

Feature

Function

RESET Recessed Button

Press to reset the device.

BAUD RATE DIP-switches

Set the RS-232 baud rate (baud rate on 575 and 576 should be identical).

ON LED

Lights green when the device is powered.

LOOP OUT HDMI Connector

Connect to a local monitor.

HDMI IN Connector

Connect to an HDMI source.

TO 576 (RX)

CAT 5/6 RJ-45 Port

Connect to the RJ-45 port on 576.

(Connect via

one of these

options)

HD15 15-pin HD Connector

Connect to the 15-pin HD connector on 576.

A, B 2-pin TERMINAL BLOCK

Connector

Connect to the 2-pin terminal block connectors on 576.

RS-232 9-pin D-sub Connector

Bi-directional RS-232 between the devices, allowing control of the display

from the source end/control of a source from the display end.

5V DC

+5V DC connector for powering the unit.

576 2-Wire Extra Range HD Receiver

Feature

Function

RESET Recessed Button

Press to reset the device.

BAUD RATE DIP-switches

Set the baud rate (baud rate on 575 and 576 should be identical).

ON LED

Lights green when the device is powered.

FROM 575 (TX)

(Connect via

one of these

options)

CAT 5/6 RJ-45 Port

Connect to the RJ-45 port on 575.

HD15 15-pin HD Connector

Connect to the 15-pin HD connector on 575.

A, B 2-pinTERMINAL

BLOCK Connector

Connect to the 2-pin terminal block connectors on 575.

OUTPUTS

HDMI Connector

Connect to an HDMI acceptor.

S/PDIF RCA Connector

Connect to a digital audio acceptor.

BAL. AUDIO 5-pin Terminal

Block Connector

Connect to a stereo balanced audio acceptor.

RS-232 9-pin D-sub Connector

Bi-directional RS-232 between the devices, allowing control of the display

from the source end/control of a source from the display end.

5V DC

+5V DC connector for powering the unit.

Step 3: Install 575/576

Install 575/576 using one of the following methods:

Attach the rubber feet and place the unit on a flat surface.

Fasten a bracket (included) on each side of the unit and attach it to a flat surface.

For more information go to www.kramerav.com/downloads/575-576.

Mount the unit in a rack using an optional RK-T2B rack adapter.

Step 4: Connect the inputs and outputs

Always switch OFF the power on each device before connecting it to your 575/576 devices. For best results, we recommend that

you always use Kramer high-performance cables to connect AV equipment to 575/576.

Step 5: Connect the power

Connect the 5V DC power adapters to 575/576 and plug it into the mains electricity.

Safety Instructions

Caution:

There are no operator serviceable parts inside the unit.

Warning:

Use only the Kramer Electronics power adapter that is provided with the unit.

Warning:

Disconnect the power and unplug the unit from the wall before installing.

See www.KramerAV.com for updated safety information.

Step 6: Operate 575/576

DIP-switch Setup:

A switch that is down is on; a switch that is up is off. By default, all the switches are up (off).

Video Switching Selection:

DIP-switch 1

DIP-switch 2

DIP-switch 3

Baud Rate

OFF (up)

2400

ON (down)

OFF (up)

4800

OFF (up)

ON (down)

OFF (up)

9600

ON (down)

OFF (up)

19200

OFF (up)

ON (down)

28800

ON (down)

OFF (up)

ON (down)

38400

OFF (up)

ON (down)

57600

ON (down)

115200

Technical Specifications

575

Inputs

1 HDMI

On a female HDMI connector

Outputs

1 LOOP HDMI

On a female HDMI connector

CAT 5/6

On an RJ-45 connector

VGA

On a 15-pin HD connector

2-wire

On a 2-pin terminal block connector

Ports

RS-232

On 9-pin D-sub connector for serial link extension

576

Inputs

CAT 5/6

On an RJ-45 connector

VGA

On a 15-pin HD connector

2-wire

On a 2-pin terminal block connector

Outputs

1 HDMI

On a female HDMI connector

1 S/PDIF

On an RCA connector

1 Balanced Stereo Audio

On a 5-pin terminal block connector

Ports

RS-232

On 9-pin D-sub connector for serial link extension

General

Video

Max Resolution

1080p60

Compliance

HDCP 1.4

Audio

Support

2.0 channel PCM, 48kHz/44.1kHz sampling rate

Bandwidth

12kHz

Analog THD + NOISE

0.08% @1kHz at nominal level

Extension Range

Full HD (1080p @60Hz)

Up to 600m (2000ft)

Extended RS-232

Baud Rate

2400 to 115200, selectable

Controls

Front Panel

ON LED indicator

Baud rate DIP-switches

Reset recessed button

Power

Consumption

5V DC, 1.5A

Source

5.2V DC, 4A

Cooling

Convection Ventilation

Environmental

Conditions

Operating Temperature

0° to +40°C (32° to 104°F)

Storage Temperature

-40° to +70°C (-40° to 158°F)

Humidity

10% to 90%, RHL non-condensing

Regulatory

Compliance

Safety

CE, UL

Environmental

RoHs, WEEE

Enclosure

Size

Mega Tool

General Information

(per device)

Net Dimensions (W, D, H)

18.75cm x 11.5cm x 2.54cm (7.4" x 4.5" x 1")

Shipping Dimensions (W, D, H)

34.5cm x 16.5cm x 5.2cm (13.6" x 6.5" x 2.1")

Net Weight

0.46kg (1lbs) approx.

Shipping Weight

0.96kg (2.1lbs) approx.

Type

Aluminum

Accessories

Included

2 Power adapters, 2 power cords

Specifications are subject to change without notice at www.kramerav.com
