Kramer FC-31 Bedienungsanleitung

Kramer Electronics, Ltd.

USER MANUAL







Model:

FC-31

UXGA to DVI Converter

Contents

Introduction 1

Getting Started 1

2.1

Quick Start 2

Overview 3

Your FC-31 UXGA to DVI Converter 3

4.1

Dipswitch Settings 4

Connecting the FC-31 UXGA to DVI Converter 7

Technical Specifications 8

Figures

Figure 1: FC-31 UXGA to DVI Converter 3

Figure 2: Dipswitch Definitions 4

Figure 3: Connecting the FC-31 UXGA to DVI Converter 7

Tables

Table 1: FC-31 UXGA to DVI Converter Features 4

Table 2: Dipswitch Definitions 4

Table 3: (Vs) Vertical Positioning Dipswitch Settings 4

Table 4: (Hs) Horizontal Positioning Dipswitch Settings 5

Table 5: Sharpness Dipswitch Settings 6

Table 6: Technical Specifications of the FC-31 UXGA to DVI Converter 8

Introduction

1 Introduction

Welcome to Kramer Electronics (since 1981): a world of unique, creative and

affordable solutions to the infinite range of problems that confront the video,

audio and presentation professional on a daily basis. In recent years, we have

redesigned and upgraded most of our line, making the best even better! Our

500-plus different models now appear in 8 Groups

, which are clearly defined

by function.

Congratulations on purchasing your Kramer MultiTOOLS®: FC-31 UXGA to

DVI Converter, which is ideal for:

Home theater, presentation and multimedia applications

Rental and staging

The package includes the following items:

FC-31 UXGA to DVI Converter

Power adapter (12V DC Input)

This user manual

2 Getting Started

We recommend that you:

Unpack the equipment carefully and save the original box and

packaging materials for possible future shipment

Review the contents of this user manual

Use Kramer high performance high resolution cables

Caution – No operator-serviceable parts inside unit.

Warning – Use only the Kramer Electronics input power

wall adapter that is provided with this unit

Warning – Disconnect power and unplug unit from wall

before installing or removing device or servicing unit.

1 GROUP 1: Distribution Amplifiers; GROUP 2: Video and Audio Switchers, Matrix Switchers and Controllers; GROUP 3:

Video, Audio, VGA/XGA Processors; GROUP 4: Interfaces and Sync Processors; GROUP 5: Twisted Pair Interfaces;

GROUP 6: Accessories and Rack Adapters; GROUP 7: Scan Converters and Scalers; and GROUP 8: Cables and Connectors

2 Download up-to-date Kramer user manuals from the Internet at this URL: http://www.kramerelectronics.com

3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

4 For example: model number AD2512C, part number 2535-000251

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Getting Started

2.1 Quick Start

This quick start chart summarizes the basic setup and operation steps.

Overview

3 Overview

The Kramer MultiTOOLS® FC-31 UXGA to DVI Converter is a high quality

converter for converting an analog computer graphics signal on an HD15

connector to a digital DVI-D signal. In particular, the FC-31:

Includes dipswitches that let you adjust the horizontal position, the

vertical position, and/or the sharpness of the image

Supports an input resolution of up to UXGA

Is 12VDC fed

Achieving the best performance means:

Connecting only good quality connection cables, thus avoiding

interference, deterioration in signal quality due to poor matching, and

elevated noise levels (often associated with low quality cables)

Avoiding interference from neighboring electrical appliances and

positioning your FC-31 away from moisture, excessive sunlight and dust

4 Your FC-31 UXGA to DVI Converter

Figure 1 and Table 1 define the FC-31:

Figure 1: FC-31 UXGA to DVI Converter

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Your FC-31 UXGA to DVI Converter

Table 1: FC-31 UXGA to DVI Converter Features

# Feature Function

1 12V DC +12V DC connector for powering the unit

2 UXGA IN HD15 Connector Connects to the computer graphics source

3 DVI OUT Connector Connects to the DVI acceptor

4 ON LED Illuminates when receiving power

5 ADJUST Dipswitches Used to adjust the vertical and/or horizontal position on the screen,

and/or the sharpness of the picture (see section 4.1)

4.1 Dipswitch Settings

Figure 2 and Table 2 define the dipswitches:

Table 2: Dipswitch Definitions

DIPs Set to adjust the:

1 to 3 (Vs) Vertical position on the screen

4 to 8 (Hs) Horizontal position on the screen

9 to 12 (SHARP) Sharpness of the picture

Figure 2: Dipswitch Definitions

To adjust the vertical position of the image, set the dipswitches as required,

according to Table 3:

Table 3: (Vs) Vertical Positioning Dipswitch Settings

In this state: DIP 1 DIP 2 DIP 3

Shift Down (4 steps) OFF OFF OFF

Shift Down (3 steps) ON OFF OFF

Shift Down (2 steps) OFF ON OFF

Shift Down (1 step) ON ON OFF

No shift OFF OFF ON

Shift Up (1 step) ON OFF ON

Shift Up (2 steps) OFF ON ON

Shift Up (3 steps) ON ON ON

Your FC-31 UXGA to DVI Converter

To adjust the horizontal position of the image, set the dipswitches as required,

according to Table 4:

Table 4: (Hs) Horizontal Positioning Dipswitch Settings

In this

state:

DIP

In this

state:

DIP

Shift Left

(16 steps)

OFF OFF OFF OFF OFF

No Shift OFF OFF OFF OFF ON

Shift Left

(15 steps)

ON OFF OFF OFF OFF

Shift Right

(1 step)

ON OFF OFF OFF ON

Shift Left

(14 steps)

OFF ON OFF OFF OFF

Shift Right

(2 steps)

OFF ON OFF OFF ON

Shift Left

(13 steps)

ON ON OFF OFF OFF

Shift Right

(3 steps)

ON ON OFF OFF ON

Shift Left

(12 steps)

OFF OFF ON OFF OFF

Shift Right

(4 steps)

OFF OFF ON OFF ON

Shift Left

(11 steps)

ON OFF ON OFF OFF

Shift Right

(5 steps)

ON OFF ON OFF ON

Shift Left

(10 steps)

OFF ON ON OFF OFF

Shift Right

(6 steps)

OFF ON ON OFF ON

Shift Left

(9 steps)

ON ON ON OFF OFF

Shift Right

(7 steps)

ON ON ON OFF ON

Shift Left

(8 steps)

OFF OFF OFF ON OFF

Shift Right

(8 steps)

OFF OFF OFF ON ON

Shift Left

(7 steps)

ON OFF OFF ON OFF

Shift Right

(9 steps)

ON OFF OFF ON ON

Shift Left

(6 steps)

OFF ON OFF ON OFF

Shift Right

(10 steps)

OFF ON OFF ON ON

Shift Left

(5 steps)

ON ON OFF ON OFF

Shift Right

(11 steps)

ON ON OFF ON ON

Shift Left

(4 steps)

OFF OFF ON ON OFF

Shift Right

(12 steps)

OFF OFF ON ON ON

Shift Left

(3 steps)

ON OFF ON ON OFF

Shift Right

(13 steps)

ON OFF ON ON ON

Shift Left

(2 steps)

OFF ON ON ON OFF

Shift Right

(14 steps)

OFF ON ON ON ON

Shift Left

(1step)

ON ON ON ON OFF

Shift Right

(15 steps)

ON ON ON ON ON

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Your FC-31 UXGA to DVI Converter

To sharpen the image, adjust the dipswitches, as defined in Table 5:

Table 5: Sharpness Dipswitch Settings

DIP 9 DIP 11 DIP 10 DIP 12

OFF OFF OFF OFF

ON OFF OFF OFF

OFF ON OFF OFF

ON ON OFF OFF

OFF OFF ON OFF

ON OFF ON OFF

OFF ON ON OFF

ON ON ON OFF

OFF OFF OFF ON

ON OFF OFF ON

OFF ON OFF ON

ON ON OFF ON

OFF OFF ON ON

ON OFF ON ON

OFF ON ON ON

ON ON ON ON

Connecting the FC-31 UXGA to DVI Converter

5 Connecting the FC-31 UXGA to DVI Converter

To connect your FC-31 UXGA to DVI Converter, as the example in Figure 3

illustrates, do the following

1. Connect a computer graphics source (for example, a computer) to the

UXGA IN connector.

2. Connect the DVI OUT connector to a DVI projector.

3. Connect the 12V DC power adapter (wall transformer) to the 12V DC

socket and connect the transformer to the mains electricity.

Figure 3: Connecting the FC-31 UXGA to DVI Converter

1 Switch OFF the power on each device before connecting it to your FC-31. After powering up your FC-31, switch on the

power on each device

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Technical Specifications

6 Technical Specifications

Table 6 includes the technical specifications:

Table 6: Technical Specifications

of the FC-31 UXGA to DVI Converter

INPUT: 1 UXGA on an HD15F connector

OUTPUT: 1 DVI

, 1.2Vpp on a DVI Molex 24pin female connector; DDC signal 5Vpp (TTL)

ANALOG

RESOLUTION:

VGA70 (720x400) @ 70Hz; VGA (640x480) @ 60Hz / 75Hz; SVGA (800x600) @

60Hz / 75Hz / 85Hz; XGA (1024x768) @ 60Hz / 75Hz / 85Hz; SXGA (1280x1024)

@ 60Hz / 75Hz / 85Hz; UXGA (1600x1200) @ 60Hz

DVI BANDWIDTH: 1.65GHz

CONTROLS: Dipswitches

COUPLING: DC

POWER SOURCE: 12V, 230mA

DIMENSIONS: 10.7cm x 4.0cm x 15.9cm (4.20" x 1.59" x 6.26") W, D, H

WEIGHT: 0.15kg. (0.55lbs.) approx.

ACCESSORIES: Power supply

1 Specifications are subject to change without notice

2 On a DVI-I connector. Note that only the digital signal (DVI-D) is available on the DVI connector
