Lanaform Moya Bedienungsanleitung

DIFFUSEUR D’HUILES

ESSENTIELLES

VERDAMPER VAN

ETHERISCHE OLIËN

DIFUZÉR ESENCIÁLNÍCH

OLEJŮ

DIFÚZOR ÉTERICKÝCH

OLEJOV

RAZPRŠILNIK

ETERIČNIH OLJ

Moya

ESSENTIAL OIL DIFFUSER

AIR QUALITY

BAMBOO BASE &

CERAMIC COVER

RELAXING

BREATHING LIGHT

TIMER FUNCTION

(1, 3, 8 HOURS)

CONTINUOUS OR

CYCLICAL DIFFUSION

2/ 84

12 11

3/ 84

1 2

543 6

4/ 84

2 2

2 3 4 5 6 7

5/ 84

ENGLISH EN

The photographs and other

images of the product in this

manual and on the packaging

are as accurate as possible, but

do not claim to be a perfect re-

production of the product.

Please read all the instruc-

tions before using your product,

particularly these basic safety

instructions.

Always place the device on a

hard, at, horizontal surface in-

side. Keep it away from walls and

heat sources such as stoves, ra-

diators, etc. Please note: If it is

not placed on a horizontal sur-

face, it may not work properly.

Check that your mains voltage is

the same as that of your device.

Do not connect or disconnect

the plug with wet hands. If the

power cable is damaged, it must

be replaced by a similar cable

available from the supplier or

the supplier’s after-sales depart-

ment. Do not leave the device in

the sun for a long period of time.

Do not take the device apart en-

tirely. Do not lift the glass cover

when the device is on. If you no-

tice a suspicious smell or sound,

switch the device o immedi-

ately and consult the “Trouble-

shooting” section of these in-

structions for use. If the problem

persists, ask the supplier or its

after-sales department to check

the device. Do not use essential

oils that are not recommended

for diusion. To nd out which

essential oils are recommended,

6/ 84

consult the advice provided in

these instructions for use. Do

not use perfume or synthetic es-

sences as these could damage

the device. Unplug the device

before cleaning it. Use only the

mains adaptor supplied with this

device. The adaptor supplied

must be used only with the de-

vice and not for other purposes.

Do not wash the entire unit with

water and do not immerse it in

water. Consult the cleaning in-

structions in this manual. Do not

use any chemical products (such

as acids, alkalis, etc.) or corro-

sive detergents to clean the de-

vice. Never scrape the transduc-

er with a hard tool and consult

the cleaning instructions in this

manual. Be sure never to emp-

ty the water from the reservoir

through the exhaust vents as this

would damage the diuser. Tip

the water out of the side oppo-

site the exhaust vent. For opti-

mum maintenance, use mineral

water. Do not ll above the line

indicating the maximum water

level. Always pour the water in

before adding essential oils. Do

not use essential oils without di-

luting them in water. This appli-

ance can be used by children

aged from 8 years and above

and persons with reduced phys-

ical, sensory or mental capabil-

ities or lack of experience and

knowledge if they have been

given supervision or instruction

concerning use of the appliance

in a safe way and understand

the hazards involved. Children

shall not play with the appliance.

7/ 84

Cleaning and user maintenance

shall not be made by children

without supervision. Children

should be supervised to make

sure they do not play with the de-

vice. Use this device only for its

intended purpose, as described

in these instructions for use.

Introduction

Thank you for choosing the Moya by LANA

FORM. With its ceramic shell ltering the light

and its natural bamboo base, the Moya essen-

tial oil diuser combines well-being and qual-

ity. What is more, it assists soothing breathing

through light cycles. The light intensity increas-

es for 5 seconds, then decreases for 5 seconds.

The aim is to synchronise breathing with these

cycles so as to reproduce the “cardiac coherence”

respiration exercise. The aim of this breathing

technique is to regulate the heart rate and the

autonomous nervous system with the aim of re-

laxing and improving the body’s functions. Prac-

tised regularly, it brings numerous benets to

mental, emotional and physical health.

Components of

the device 1

01 Mist outlet

02 Ceramic cover

03 Internal reservoir cover

04 Exhaust vent cover

05 Water reservoir

06 Exhaust vent

07 Transducer

08 DC jack socket

09 Bamboo base

10 Button for adjusting diusion and timer

11 Button for adjusting the light

12 Light indicators

Instructions for use

Features

• Ultrasound diuser

• Natural bamboo base

• Ceramic cover

• 280ml capacity

• Emission intensity (15-20ml/hr)

• Continuous or cyclical diu-

sion (30”ON/30”OFF)

• Timer fu nction (1, 3, 8 hours)

• Warm white light

• 2 levels of light intensity

8/ 84

• Provides help with soothing respi-

ration through its light cycles

• Light separate from diusion

• Switches o automatically

Preparation 2

01 Put the Moya diuser in the room

half an hour before turning it on to al-

low it to adjust to room temperature.

02 Make sure it is always placed on a

hard, at and horizontal surface.

03 Make sure the device is clean

before starting to use it.

04 Remove the ceramic cover .

05 Then remove the reservoir cover .

06 Pour fresh, preferably demineralised

water into the reservoir and do not

exceed the maximum level .

07 Pour 3 or 4 drops of essential

oil into the water .

08 Replace the reservoir cover

then the ceramic cover .

09 Make sure your hands are completely

dry when connecting (and even

disconnecting) the device .

10 The diuser is now operational.

Instructions for use 3

Adjusting diusion and timer

• Press once on the button for adjusting

diusion and timer 1 to start diu-

sion. It runs in continuous diusion mode

by default; three indicators light up

• Press a second time on the button for

programming diusion for 1 hour; the

indicator on the left lights up .

• Press a third time on the button for

programming diusion for 3 hours;

the middle indicator lights up .

• Press the button for programming dif-

fusion for 8 hours a fourth time; the in-

dicator on the right lights up .

• Press the button for stopping dif-

fusion a fth time; there are no

longer any light indicators .

• To go to intermittent diusion

mode (30 seconds ON; 30 sec-

onds OFF), press the button for 2 sec-

onds; a light indicator will ash.

• Repeat this operation to go back

to continuous diusion mode

The timer is not interrupted when the dif-

fusion mode has changed.

9/ 84

Adjusting the light mode

• Press the button for adjusting the

light once 1 to activate the

light with a greater intensity.

• Press the button for reducing

the intensity a second time.

• Press the button for starting the “breath-

ing” mode a third time; the light inten-

sity increases for 5 seconds, then de-

creases for 5 seconds, in cycles.

• Press the button a fourth time

to switch o the light.

The light switches o by default when dif-

fusion stops (either with the timer, or with

the system that automatically switches o

when the reservoir is empty). But it is pos-

sible to programme the light separately

from diusion.

• To do that, press the two buttons at the

same time 1 , . The left-hand and

middle indicators light up You will

then be able to enjoy the atmospher-

ic lighting, even after diusion stops.

• To de-activate independent program-

ming of the light, press both buttons

again at the same time. The middle and

right-hand indicators will light up .

Even though there is a safety device that

stops the transducer from working, do not

leave the device connected when you are

not using it.

Additional information about

the use of essential oils:

Before using essential oils, please check the

harmful eects that use of these products may

have on your health.

Always choose quality essential oils that are

pure, 100% natural and intended for diusion.

Use them in moderation and with care. Follow

the instructions and warnings stated on the

packaging of the essential oils, making sure in

particular that:

• Pregnant women, people with epilepsy,

asthmatics and people who suer from al-

lergies, those with heart problems or seri-

ous illnesses should not use essential oils.

• Essential oils should be used only

for periods not exceeding 10 min-

utes in the room of a baby (un-

der 3 years old) and only when the

baby is not actually in the room.

Make sure that children and minors do not play

with or use the device.

Just a few drops (3 to 4 drops at most) of essen-

tial oils are sucient to ensure that the device

10 / 84

works properly and the scent is diused. Exces-

sive use of essential oils could damage the device.

Make sure you pour water into the reservoir

rst before adding the drops of essential oils.

Lanaform cannot be held liable in the event of

accidental damage resulting from any use con-

trary to the instructions given in these instruc-

tions for use.

Maintenance

and storage

When you are not using the diuser, emp-

ty the water out of the reservoir. Do not tip

the water out of the reservoir from the ex-

haust vent side. If the water gets into the

exhaust vent, this might damage the de-

vice! 4

To prevent this from happening:

• Use a container to pour wa-

ter into the reservoir.

• Do not shake the diuser.

• Do not move the diuser when

there is water in the reservoir.

If water accidentally enters the exhaust vent

5 , there is a safety device for removing wa-

ter from the base of the diuser:

• Disconnect the power ca-

ble from the diuser.

• Empty the reservoir completely through

the opposite side to the exhaust vent.

• Bend the diuser towards one of the

drainage holes 5 to empty the water.

• Leave the diuser in a dry

place for 24 hours.

Always unplug the device with

dry hands before cleaning it!

Maintenance

If the water contains too much calcium and

magnesium, it may deposit a white powder

in the device. If this foam is deposited on the

transducer 1 , it will prevent the device from

working properly.

We recommend:

01 Using distilled or demineral-

ised water each time it is used.

02 Cleaning the reservoir every 2 days and

cleaning the transducer every week.

03 Emptying and cleaning the device

(see explanations below) and

making sure that all its parts are

completely dry when it is not in use.

Andere Handbücher für Moya

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere Lanaform Zubehör Handbücher

Lanaform

Lanaform Aroma Design Bedienungsanleitung

Lanaform

Lanaform Heating Overblanket Bedienungsanleitung

Lanaform

Lanaform Aroma Globe Bedienungsanleitung

Lanaform

Lanaform Aroma Design Bedienungsanleitung

Lanaform

Lanaform Borneo Bedienungsanleitung

Lanaform

Lanaform Wake Up Light LA190201 Bedienungsanleitung

Lanaform

Lanaform Eclipse LA120324 Bedienungsanleitung

Lanaform

Lanaform Heating Blanket S1 Bedienungsanleitung

Lanaform

Lanaform Java Bedienungsanleitung

Lanaform

Lanaform Moa Bedienungsanleitung

Lanaform

Lanaform Mili Bedienungsanleitung

Lanaform

Lanaform Heating Blanket S1 Bedienungsanleitung

Lanaform

Lanaform Moya Bedienungsanleitung

Lanaform

Lanaform S2 Heating Blanket Bedienungsanleitung

Lanaform

Lanaform Aroma Decor Bedienungsanleitung

Lanaform

Lanaform Heating Overblanket Bedienungsanleitung

Lanaform

Lanaform Aroma Decor Bedienungsanleitung

Lanaform

Lanaform Fidji Bedienungsanleitung

Lanaform

Lanaform Noumea Bedienungsanleitung

Lanaform

Lanaform Bali Bedienungsanleitung

Lanaform

Lanaform AROMA ZEN Bedienungsanleitung

Lanaform

Lanaform Aroma Globe Bedienungsanleitung

Lanaform

Lanaform Bora Bora Bedienungsanleitung

Lanaform

Lanaform Mahe LA120320 Bedienungsanleitung

Beliebte Zubehör Handbücher anderer Marken

Hillco

Hillco 2810 Bedienungsanleitung

Siemens

Siemens QSA2700D Bedienerhandbuch

Contours

Contours ZY024 Bedienungsanleitung

Saivod

Saivod VS621 Bedienungsanleitung

Virtuox

Virtuox VirtuCLEAN 2.0 Bedienungsanleitung

SCE

SCE ENVIRO-THERM SCE-TE170B24VSS Bedienungsanleitung

Z-Wave

Z-Wave HSD-200Z Bedienungsanleitung

turck

turck FMX-IM-2UPLI63FX Bedienungsanleitung

Decagon Devices

Decagon Devices 10HS Bedienungsanleitung

UPPAbaby

UPPAbaby Cup Holder Bedienungsanleitung

Elko

Elko SmartSensor Leakage Wireless Bedienungsanleitung

Grizzly

Grizzly H8371 Bedienungsanleitung

Panasonic

Panasonic HG-T Series Bedienungsanleitung

IFM Electronic

IFM Electronic Efector 250 Series Referenzhandbuch

DigiDesign

DigiDesign 888/24 I/O Bedienungsanleitung

PROZIS

PROZIS QUAY Bedienungsanleitung

patagonia

patagonia PSI Vest Bedienungsanleitung

SFC Energy

SFC Energy EFOY GO! Bedienungsanleitung
