Lantech IES-2208CA-DNV Bedienungsanleitung

Lantech

IES-2208CA-DNV

8 10/100TX + 2 10/100/1000T/Dual Speed SFP Combo

Managed Industrial Switch

User Manual

V2.01

Jan. 2013

Table of Content

Chapter 1 Introduction.............................................1

1.1 Hardware Features ........................................ 1

1.2 Software Features.......................................... 4

1.3 Package Contents.......................................... 7

Chapter 2 Hardware Description ............................8

2.1 Physical Dimension........................................ 8

2.2 Front Panel..................................................... 8

2.3 Bottom View................................................... 9

2.4 LED Indicators.............................................. 10

Chapter 3 Hardware Installation...........................12

3.1 Installation Steps.......................................... 12

3.2 Wiring the Power Inputs............................... 13

3.3 Wiring the Fault Alarm Contact.................... 14

3.4 Cabling......................................................... 15

Chapter 4 Network Application.............................19

4.1 Pro-Ring2s Application ................................ 20

Chapter 5 Console Management ..........................21

5.1 Connecting to the Console Port................... 21

5.2 Pin Assignment............................................ 21

5.3 Login in the Console Interface..................... 22

5.4 CLI Management ......................................... 23

Chapter 6 Web-Based Management.....................24

6.1 About Web-based Management .................. 24

6.2 Preparing for Web Management.................. 24

6.3 System Login ............................................... 25

6.4 System......................................................... 26

6.5 Time - SNTP ................................................ 29

6.6 Account - Admin........................................... 32

6.7 IP Addressing –IPV4................................... 33

6.8 Syslog .......................................................... 35

Syslog Configuration..................................................... 35

6.9 SNMP Configuration .................................... 36

SNMP - Agent............................................................... 36

6.20.1 SNMP Trap Configuration ............................ 38

6.10 System Alert - Relay Alarm.......................... 39

6.8.1 System Alert - SMTP...................................... 39

6.8.2 System Alert - Event....................................... 41

6.11 DHCP Server ............................................... 43

6.6.1 DHCP Server - Server configuration .............. 43

6.6.2 Client Table .................................................... 44

6.6.3 IP Bindings ..................................................... 44

6.12 Port - Configuration...................................... 46

6.13 Port Status ................................................... 47

6.14 Port Statistics............................................... 48

6.15 Port –Port Alert............................................ 50

6.16 Rate Control –Rate Limit.............................. 51

6.17 Aggregation - Configuration......................... 53

6.17.1 Configuration................................................ 54

6.17.2 Aggregator –Status...................................... 56

6.18 Spanning Tree ............................................. 57

6.18.1 RSTP Setting................................................ 57

6.18.2 RSTP Information.............................................. 59

6.19 Pro-Ring II S................................................. 60

6.20 Multicast Support ......................................... 62

6.21 LLDP............................................................ 65

6.22.1 LLDP Neighbors.......................................... 66

6.23 Filtering Database........................................ 67

6.24 VLAN............................................................ 69

6.24.1. VLAN Configuration..................................... 69

6.24.2 Switch Status................................................ 72

6.25 QoS.............................................................. 73

6.25.1 Global Settings............................................. 73

6.25.2 Port Priority................................................ 74

6.25.3 COS Mapping to Queue ............................... 75

6.25.4 DSCP mapping to queue.............................. 76

6.25. Port Mirroring............................................. 78

6.26. Security ..................................................... 79

6.26.1 IP Source Guard - Configuration.................. 79

6.26.2 IP Source Guard –Static Table.................... 80

6.26.3 802.1X/Radius.............................................. 81

6.26.4 MAC Filtering..................................................... 84

6.26.5 Port Security................................................. 85

You can block the un-authorized MAC by oer port in

this function. .............................................................. 85

6.27. Maintenance.............................................. 86

6.27.1 Save Configuration ..................................... 86

Troubles shooting....................................................91

Appendix A—RJ-45 Pin Assignment .....................92

RJ-45 Pin Assignments.......................................... 92

RJ-45 Pin Assignment of PoE................................ 95

Appendix B—Command Sets.................................97

Switch Setting Commands Set ..................................... 97

Admin Password Commands Set................................. 98

IP Setting Commands Set ............................................ 98

SNTP Commands Set .................................................. 99

LLDP Commands Set................................................. 100

Backup & Restore Commands Set............................. 101

Upgrade Firmware Commands Set ............................ 101

DHCP Server Commands Set .................................... 101

Port Control Commands Set....................................... 103

Port Status Commands Set........................................ 105

Rate Limit Commands Set.......................................... 105

Trunk Commands Set................................................. 106

PRO-RING IIS Commands Set................................... 108

RSTP Commands Set ................................................ 108

VLAN Commands Set................................................. 110

SNMP Commands Set................................................ 113

Traffic Prioritization Commands Set ........................... 114

IGMP Commands Set................................................. 115

Multicast Static Filtering Table Commands Set.......... 116

IP Security Commands Set......................................... 117

Port Security Commands Set ..................................... 118

MAC Blacklist Commands Set.................................... 118

802.1x Commands Set............................................... 119

Fault Alarm Commands Set........................................ 121

System Warning Commands Set................................ 121

Mac Address Table Commands Set........................... 124

Port Statistics Commands Set.................................... 125

Port Monitoring Commands Set.................................. 125

System Event Log Commands Set............................. 126

Ping Commands Set................................................... 126

SFP Monitor Commands Set...................................... 126

Loading Average Commands Set............................... 126

Save Configuration Commands Set ........................... 129

Factory Default Commands Set.................................. 129

System Reboot Commands Set ................................. 129

Logout Commands Set............................................... 129

FCC Warning

This Equipment has been tested and found to comply with the limits for a

Class-A digital device, pursuant to Part 15 of the FCC rules. These limits

are designed to provide reasonable protection against harmful interference

in a residential installation. This equipment generates, uses, and can

radiate radio frequency energy. It may cause harmful interference to radio

communications if the equipment is not installed and used in accordance

with the instructions. However, there is no guarantee that interference will

not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

CE Mark Warning

This is a Class-A product. In a domestic environment this product may

cause radio interference in which case the user may be required to take

adequate measures.

Chapter 1 Introduction

The 8 10/100TX + 2 10/100/1000T/Dual Speed SFP Combo Managed Industrial Switch

is a cost-effective solution and meets the high reliability requirements demanded by

industrial applications. Using fiber port can extend the connection distance that

increases the network elasticity and performance.

1.1 Hardware Features

Standard

IEEE 802.3 10Base-T Ethernet

IEEE 802.3u 100Base-TX/ FX

IEEE802.3ab 1000Base-T

IEEE802.3z Gigabit fiber

IEEE802.3x Flow Control and Back Pressure

IEEE802.3ad Port trunk with LACP

IEEE802.1d Spanning Tree/ IEEE802.1w Rapid Spanning

Tree

IEEE802.1p Class of Service

IEEE802.1Q VLAN Tag

IEEE 802.1x User Authentication (Radius)

IEEE802.1ab LLDP

Switch

Architecture

Back-plane (Switching Fabric): 7.4Gbps

Packet throughput ability(Full-Duplex): 8.3Mpps @64bytes

Transfer Rate

14,880pps for Ethernet port

148,800pps for Fast Ethernet port

1,488,000pps for Gigabit Fiber Ethernet port

Packet Buffer

1Mbits

MAC Address

8K MAC address table

Flash ROM

4Mbytes

DRAM

32Mbytes

Connector

10/100TX: 8 x ports RJ-45 with Auto MDI/MDI-X function

10/100/1000T/SFP Combo port: 2 x RJ-45 + 2 x 100/1000

SFP socket with DDM

RS-232 connector: RJ-45 type

Network Cable

10Base-T: 2-pair UTP/STP Cat. 3, 4, 5/ 5E cable

EIA/TIA-568 100-ohm (100m)

100Base-TX: 2-pair UTP/STP Cat. 5/ 5E cable

EIA/TIA-568 100-ohm (100m)

1000Base-TX: 2-pair UTP/STP Cat. 5/ 5E cable

EIA/TIA-568 100-ohm (100m)

Optical Fiber

Distance:

Multi mode:

0 to 5 km, 1300 nm (50/125 μm, 800 MHz*km)

0 to 4 km, 1300 nm (62.5/125 μm, 500 MHz*km)

Single mode:

0 to 40 km, 1310 nm (9/125 μm, 3.5 PS/(nm*km))

0 to 80 km, 1550 nm (9/125 μm, 19 PS/(nm*km))

Min. TX Output:

Multi mode: -20 dBm

Single mode: 0 to 40 km, -5 dBm; 0 to 80 km, -5 dBm

Max. TX Output:

Multi mode: -14 dBm

Single mode: 0 to 40 km, 0 dBm; 0 to 80 km, 0 dBm

Sensitivity:

-36 to -32 dBm (Single mode); -34 to -30 dBm (Multi mode)

Protocol

CSMA/CD

LED

Per unit: Power (Green), Power 1 (Green), Power 2

(Green), Fault (Red), Master (Green), FWD (Green)

8 port 10/100: Link/Activity (Green), Full duplex/Collision

(Amber)

SFP port: LNK/ACT(Green), 1000T: LNK/ACT(Green),

1000M(Green)

Power Supply

External Power Supply: DC 12~48V, Redundant power DC

12~48V and connective removable terminal block for

master and slave power

Power

Consumption

9.86 W at full load

Operating

Humidity

5% to 95% (Non-condensing)

Operating

Temperature

-40oC ~ 75oC

Storage

Temperature

-40oC ~ 85oC

Case Dimension

IP-30, 74.5mm (W) x 105mm (D) x 182mm (H)

Installation

wall mount plate

EMI

FCC Class A, CE EN61000-4-2, CE EN61000-4-3, CE EN-

61000-4-4, CE EN61000-4-5,

CE EN61000-4-6, CE EN61000-4-8, CE EN61000-4-11, CE

EN61000-4-12, CE EN61000-6-2, CE EN61000-6-4

Safety

UL, cUL, CE/EN60950-1, DNV

Stability Testing

IEC60068-2-32 (Free fall), IEC60068-2-27 (Shock),

IEC60068-2-6 (Vibration)

Inhaltsverzeichnis

Andere Lantech Schalten Handbücher

Lantech

Lantech IES-2008B-DNV Bedienungsanleitung

Lantech

Lantech IPES-3408 Series Bedienungsanleitung

Lantech

Lantech IPGS-0204DSFP-12V Bedienungsanleitung

Lantech

Lantech IPGS-5424 Bedienungsanleitung

Lantech

Lantech LES-2400-RPS Bedienungsanleitung

Lantech

Lantech IPES-3424DSFP-2P-PT Bedienungsanleitung

Lantech

Lantech IGC-0101DSFP Bedienungsanleitung

Lantech

Lantech IES-0008-M12 Bedienungsanleitung

Lantech

Lantech LES-2400-RPS Bedienungsanleitung

Lantech

Lantech LGS-1104 Bedienungsanleitung

Lantech

Lantech 5 10/100TX w/ 4 PoE Injector Industrial... Bedienungsanleitung

Lantech

Lantech IGS-0016 Bedienungsanleitung

Lantech

Lantech IES-5416DF Series Bedienungsanleitung

Lantech

Lantech IPES-5408T-43 Bedienungsanleitung

Lantech

Lantech IPES/IES-0008B Series Bedienungsanleitung

Lantech

Lantech IPGS-0016 Bedienungsanleitung

Lantech

Lantech mini Switch 800 Bedienungsanleitung

Lantech

Lantech IPES-0104FA Bedienungsanleitung

Lantech

Lantech IPGS-5400-2P Bedienungsanleitung

Lantech

Lantech TGS-R6616XFT Bedienungsanleitung

Lantech

Lantech IPES-0008B Series Bedienungsanleitung

Lantech

Lantech IPES-3408GSFP Bedienungsanleitung

Lantech

Lantech IGS-L5408MGSFPR-AC Bedienungsanleitung

Lantech

Lantech 2204F Series Bedienungsanleitung

Beliebte Schalten Handbücher anderer Marken

URC

URC Total Control MFS-8 Bedienungsanleitung

Azbil

Azbil HPQ-D11 Bedienungsanleitung

Sony

Sony DFS-900M Bedienungsanleitung

SICK

SICK i17S Bedienungsanleitung

F&F

F&F SZR-277 Bedienungsanleitung

Shure

Shure UAMS/BK Bedienungsanleitung

Dräger

Dräger X-zone Switch Off Bedienungsanleitung

Asco

Asco Joucomatic 349 Series Bedienungsanleitung

BT Mini Hub Bedienungsanleitung

D-Link

D-Link DES-1226G Bedienungsanleitung

Johnson Controls

Johnson Controls FS80-C Bedienungsanleitung

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Bedienungsanleitung

MicroNet

MicroNet SP1200A Bedienungsanleitung

Ruijie

Ruijie RG-PF2920 Series Installations- und Betriebsanleitung

Altinex

Altinex DA1914SX Bedienungsanleitung

MiLAN

MiLAN MIL-SM2401M Bedienungsanleitung

RJM

RJM MASTERMIND PBC/6X Bedienungsanleitung

Atlas

Atlas MMK-KVM8 Bedienungsanleitung
